BEFORE USING YOUR PRODUCT: Please read this manual carefully & follow all safety rules
& operating instructions. Keep this manual for future reference.
Chest Freezer
R
5 cu. ft. 453-5418 7.0 cu. ft. 453-5419 453-542010.4 cu. ft.
GENERAL SAFETY RULES
WARNING: Read all of the instructions before using this appliance.
When using this appliance, always exercise basic
safety precautions, including the following:
NOTE: If the freezer has been placed in a horizontal or tilted position
for any period of time wait 24 hours before plugging the unit in.
1. Use this appliance only for its intended purpose as described in this use
and care guide.
2. This freezer must be properly installed in accordance with the installation
instructions before it is used. See grounding instructions in the installation
section.
3. Use 3 prong grounded plug provided on power cord.
4. Never unplug your freezer by pulling on the power cord. Always grasp the
plug firmly and pull straight out from the outlet.
5. Repair or replace immediately, all electric service cords that have become
frayed or otherwise damaged. Do not use a cord that shows cracks or
abrasion damage along its length, the plug or the connector end.
6. Unplug your freezer before cleaning or before making any repairs.
7. Do not use any electrical device or any sharp instrument in
defrosting your freezer.
8. If your old freezer is not being used, we recommend that you remove the
doors. This will reduce the possibility of danger to children.
WARNING: After your freezer is in operation, do not touch the
9. Do not refreeze foods, which have been thawed completely. The United
States Department of Agriculture recommends: “…You may safely refreeze
frozen foods that have thawed if they still contain ice crystals or if they are
still cold-below 40˚F”.
“…Thawed ground meats, poultry, or fish that have any off-odor or off-
color should not be refrozen and should not be eaten. Thawed ice cream
should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat.”
“…Even partial thawing and re-freezing reduce the consumption quality of
foods, particularly fruits, vegetables, and prepared foods. The consumption
quality of red meats is affected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of its eating quality as
you can.
2
cold surfaces in the freezer compartment, particularly
when hands are damp or wet. Skin may adhere to
these extremely cold surfaces.
10. Do not clean with flammable fluids. Do not store flammable liquids in
freezer.
11. This freezer should not be recessed or built-in an enclosed cabinet. It is
designed for freestanding installation only.
12. Do not operate your freezer in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors.
Staple your receipt to your manual.
You will need it to obtain warranty service.
3
5
2
1
4
3
8
4
2
6
7
3
8. Basket (
Rotating the adjustable feet clockwise will thread into the box lowering the freezer's
height. Rotating the adjustable feet counterclockwise will thread out of the box increasing
the freezer's height. Adjust the feet and be sure the freezer is same level per your floor.
10.4cf two baskets)
Adjustment instructions for support feet
1. Place the freezer on a floor strong enough to support it fully loaded.
2. Remove all packaging material. This includes the foam base and all
adhesive tape holding the freezer accessories inside and outside.
3. Inspect and remove any remains of packing, tape or printed materials
before powering on the freezer.
1. Your freezer is designed for freestanding installation only.
It should not be recessed or built-in.
2. When moving the freezer, never tilt it more than a 45-degree angle. This
could damage the compressor and the sealed system.
3. If the freezer is tilted let it stand in an upright position for at least 24
hours prior to plugging. This is to allow the refrigerant to settle.
To assure your freezer works at the maximum efficiency it was designed
for, install in a location where there is proper air circulation, plumbing
and electrical connections.
The following are recommended clearances around the freezer:
Sides 4” (102mm)
Back 4” (102mm)
Top Do not block
Unpacking Your Freezer
Adjusting Your Freezer
Proper Air Circulation
Installing Your Freezer
5
1. Install on a level surface.
2. Allow 4 hours after installation before connecting to power source.
3. Allow unit to operate for 6–8 hours before placing food inside.
4. Clean interior with lukewarm water and mild detergent using sponge or
soft cloth. Be sure interior is dry before using.
Installing Your Freezer
DO NOT USE EXTENSION CORD LONGER THAN 12 FT.
6
15 amps outlet
Garage ready in ambient temperatures of 0° to 110° F (-17.8° to 43.3° C).
·
·
Features
For
to
FAST FREEZE and at
to
(Note: If the freezer has been
placed in a horizontal or tilted
position for any period of time
wait 24 hours before plugging the
unit in.)
·
in it in an
·
· In
or an
it
Freezer Features and Use
Operating Your Freezer
FAST FREEZE
Set the temperature, on the temoerature control knob. “MIN” is cold and
“
FAST FREEZE” is coldest.lnitially set the temperature on “4” . Place food
inside the freezer. After using the freezer for 24 hours set the freezer to
your desired setting.
OFF
4
3
5
6
7
MED
MIN
1
2
Power Indicator
Light（red）
Power
FAST
FREEZE
8
·
·
·
·
·
·
·
Frozen Food:
• Wipe containers before storing to avoid needless spills.
• Hot food should be allowed to cool before storing in the freezer. This will
prevent unnecessary energy use.
• When storing meats, keep in the original
packaging or rewrap as necessary.
• Proper freezer storage requires correct packaging. All foods must be in
packages, which do not allow the flow of air or moisture in, or out.
Improper storage will result in odor and taste transfer and will result in
the drying out of the improperly packaged food.
• Follow package or container instructions for proper storage.
• Packaging Recommendations:
o Plastic containers with air tight lids
o Heavy duty aluminum foil
o Plastic wrap made from saran film
o Self-sealing plastic bags
• Do not refreeze defrosted/thawed foods.
• It is recommended that the freezing date be marked on the packaging.
These are some suggestions for safe storage:
• TV Dinners 3 - 4 Months
• Fresh Shrimp, Scallops, Crawfish
3 - 6 Months
•
Hamburgers, Stew Meats 3 - 4 Months
•
Ground Turkey, veal, pork 4 - 6 Months
•
Chops 4 - 6 Months
•
Steaks 6 - 12 Months
•
Chicken or Turkey, whole 1 - Year
For detailed storage chart visit FDA website: www.FDA.gov
Food Storage Information
9
WARNING:
CAUTION:
To avoid electric shock always unplug your freezer
before cleaning. Ignoring this warning may result in
death or injury.
Before using cleaning products, always read and follow
manufacturer’s instructions and warnings to avoid
personal injury or product damage.
General:
• Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed
with warm water. Use sponge or soft cloth, dampened with the cleaning
solution, to wipe down your freezer.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine
bleach,concentrated detergents, solvents or metal scouring pads. SOME
of these chemicals may dissolve, damage and/or discolor your freezer.
• Clean door gaskets every three months according to general
instructions. Gaskets must be kept clean and pliable to assure a proper
seal.
• Petroleum jelly applied lightly on the hinge side of gaskets will keep the
gasket pliable and assure a good seal.
Proper Freezer Care and Cleaning
Cleaning and Maintenance
Door Gaskets:
10
• Occasionally there may be power interruptions due to thunderstorms or
other causes. Remove the power cord from AC outlet when a power
outage occurs. When power has been restored, replug power cord to AC
outlet. If outage is for a prolonged period, inspect and discard spoiled or
thawed food in freezer. Clean freezer before reusing.
• For long vacations or absences, empty food from freezer, unplug the
unit and clean the door gaskets according to “General cleaning”
section. Prop doors open, so air can circulate inside. When moving
always move the freezer vertically. Do not move with the unit lying down.
Possible damage to the sealed system could occur.
Power Interruptions
Vacation and Moving Care
WARNING:
IF OUTAGE IS FOR A PROLONGED PERIOD,
INSPECT AND DISCARD SPOILED OR THAWED
FOOD IN FREEZER. CLEAN FREEZER BEFORE
REUSING.
11
Freezer Does Not Operate:
• Check if freezer is plugged in.
• Check if there is power at the ac outlet, by checking the circuit breaker.
• Wait for 30-40 minutes to see whether freezer will start. Compressor cycle
must be complete to operate.
• Check Temperature Control.
Food temperature appears too warm:
• Frequent door openings.
• Check door to be sure it is closed properly.
• Allow time for recently added warm food to reach freezer temperature.
• Check gaskets for proper seal.
• Adjust temperature control to colder setting.
Too much frost build-up inside unit:
• Make sure temperature control is not set to “MAX” setting for
extended period of time.
Food temperature is too cold:
• If temperature control setting is too cold, adjust to a warmer setting and
allow several hours for temperature to adjust.
• Ice build-up on interior walls
Troubleshooting
12
Vibration:
• Make sure the unit is level.
• Check to be sure the unit is not touching the wall.
• Double check whether the unit has been properly installed.
· may normal to maintain
temperature and
· may opened or for an extended period of
time.
·
for proper
· to are
· for from food
· Interior
· improperly wrapped are off
Warranty
e
See following page for full 1 Year Limited Warranty
One
one
1
Year Limited Warranty
4
Products with original serial numbers that have been removed, altered
or cannot be readily determined.
2. Products that have been transferred from its original owner to another
Damages due to shipping damage or improper installation.
Damages due to misuse or abuse.
Punctures to the evaporation system due to improper defrosting of the
unit.
ailure or defects of this product if used for other purposes than its
intended purpose or used other than in accordance with the provided
instructions.
Disposal costs for failed unit not returned to Manufacturer.
Any delivery/installation costs incurred as the result of a unit that fails
to perform as specified.
exchanging or returning the unit.
for making the unit accessible, such as removal of trim, cupboards,
shelves, etc. or if not installed in accordance with the provided
installation instructions.
Damages to the finish of the unit or home incurred during installation,
including but not limited to floors, cabinets, walls, etc.
Damages caused by external causes such as abuse, misuse,
inadequate power supply, accidents, fires, or acts of God.
unit
per the sales receipt.
One
Customer Service: (toll free: 1-833-953-1758) between the hours of 8:00 am and
4:00 pm EST
EMAIL: [email protected]
Product Registration: plasticdevelopmentgroup.com/applianceregistration
5
