2-year limited warranty
INSTRUCTION MANUAL AND
WARRANTY INFORMATION
complete compression system
SR-CM10 Series | L-04182, Rev. 1
wrist
wrap
knee
wrap
calf
wrap
foot
wrap
please take a
moment now
register your product at
www.Homedics.com/register
Your valuable input regarding this
product will help us create
the products you will want
in the future.
universal
battery
2
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY
WHEN CHILDREN ARE PRESENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED,
INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING.
DANGER – TO REDUCE THE RISK OF ELECTRIC SHOCK:
• Always unplug this appliance from the electrical outlet
immediately after using and before cleaning.
• DO NOT reach for a unit that has fallen into water.
Unplug it immediately.
• NEVER use pins or other metallic fasteners with this
appliance.
WARNING – TO REDUCE THE RISK OF BURNS, FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS:
• An appliance should never be left unattended when plugged
in. Unplug from outlet when not in use, and before putting
on or taking off parts or attachments.
• Close supervision is necessary when this appliance is used
by, on, or near children, invalids, or disabled persons.
• DO NOT use outdoors.
• Use this appliance only for its intended use as
described in this manual. DO NOT use attachments
not recommended by Homedics; specifically, any
attachments not provided with the unit.
• DO NOT carry this appliance by the supply cord or use
cord as a handle.
• NEVER operate this appliance if it has a damaged cord or
plug, if it is not working properly, if it has been dropped
or damaged, or if it has been dropped into water. Return
the appliance to the Homedics Service Center for
examination and repair.
• Keep the cord away from heated surfaces.
• NEVER operate the appliance with the air openings blocked.
Keep the air openings free of lint, hair, and the like.
• NEVER drop or insert any object into any opening.
• DO NOT operate where aerosol (spray) products are
being used or where oxygen is being administered.
• DO NOT operate under a blanket or pillow. Excessive heating
can occur and cause fire, electric shock, or injury to persons.
• To disconnect, turn all controls to the off position, then
remove plug from outlet.
• DO NOT stand on or in appliance. Use only while seated.
• Keep long hair away from massager while in use.
• DO NOT use massager in close proximity to loose
3
clothing or jewelry.
• Never operate on a soft surface such as a bed or couch
where the air openings may be blocked.
• Prevent unintentional starting. Ensure the switch is in the
off position before connecting to battery pack, picking
up or carrying the appliance. Carrying the appliance with
your finger on the switch or energizing appliance that
have the switch on invites accidents.
• Disconnect the battery pack from the appliance before
making any adjustments, changing accessories, or
storing appliance. Such preventive safety measures
reduce the risk of starting the appliance accidentally.
• Use heated surfaces carefully. May cause serious
burns. DO NOT use over insensitive skin areas or in the
presence of poor circulation. The unattended use of heat
by children or incapacitated persons may be dangerous.
• Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
• Use appliances only with specifically designated battery
packs. Use of any other battery packs may create a risk
of injury and fire.
• When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, seek medical help.
Liquid ejected from the battery may cause irritation or burns.
• DO NOT use a battery pack or appliance that is damaged
or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk
of injury.
• DO NOT expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may cause explosion.
• Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specified in the instructions. Charging improperly
or at temperatures outside of the specified range may
damage the battery and increase the risk of fire. Product
operating and charging range: 0°C – 40°C
4
SAVE THESE INSTRUCTIONS
CAUTION – PLEASE READ ALL INSTRUCTIONS
CAREFULLY BEFORE OPERATING.
• Consult your doctor prior to using this product, if:
– You are pregnant
– You have a pacemaker
– You have any concerns regarding your health
• NOT recommended for use by diabetics.
• NEVER leave the unit unattended, especially if children
are present.
• NEVER cover the unit when it is in operation.
• DO NOT use this product for more than 15 minutes at a
time.
• Extensive use could lead to the product’s excessive
heating and shorter life. Should this occur, discontinue
use and allow the unit to cool before operating.
• NEVER use this product directly on swollen or inflamed
areas or skin eruptions.
• DO NOT use this product as a substitute for medical
attention.
• DO NOT use this product before bed. The massager has a
stimulating effect and can delay sleep.
• This product should never be used by any individual
suffering from any physical ailment that would limit the
user’s capacity to operate the controls.
• NOT for use by children.
• This unit should not be used by people with disabilities
without supervision.
• This appliance is intended for household use only.
• This product should NEVER be used by any individual
suffering from any physical ailment that would limit
the user’s capacity to operate the controls or who has
sensory deficiencies.
NOTE: This unit will shut off automatically after 15 minutes
of use. If your unit overheats, turn off the unit and let cool
for 30 minutes before turning on again and continuing use.
5
Congratulations on your purchase of a Homedics modulair™
product. Modulair
™ is the first pneumatic compression system
that allows you to customize your experience by offering
compression wraps and products for all parts of the body all
using the same battery module for complete flexibility. To
start using your modulair
™ system, you’ll need at least one
modulair
™ battery module (Model SR-CMX10J) and at least
one modulair ™ compression wrap.
CAUTION: To avoid injury, always remain seated when
using massager.
1. Your modulair
™ compression system uses a
modulair battery module (SR-CMX10J). To
start, when opened, your battery module
may require charging. To charge the
battery, plug one end of the USB cord into the
unit and plug the other end into an adapter.
Charge time varies based on current
battery level, but expect a maximum 5
hour charge time for a full charge. On a full
charge, your battery module has a runtime
of approximately 5 hours, but this varies
based on mode, intensity and heat setting
during use.
NOTE: This device only comes with a USB
cord, not an adapter. A USB charger will also
charge the units. Do not attempt to use a cord
that is not a USB-type cord. Use only with Listed/Cer tified ITE
Power Supply. The units will not operate when charging. Use
a 5V/2A (or 5V/1A, slower) charger, but not higher than 5V.
2. Your compression wrap can be used on either the left or
right side.
3. Use the fastening tape to adjust the wrap so it’s snug but
comfortable. Do not overtighten.
4. Connect your battery module to the compression wrap, sliding
it into the dock until it “clicks” into place. See image to the right.
5. Press the power button to turn on the unit. The display will
illuminate to confirm the unit is on.
6. Press the “MODE” button to select between the 4 massage
modes. Press the “HEAT” button to toggle between 3 levels of
heat. Press the “INTENSITY” button to adjust the intensity of
the air compression.
7. The unit will turn off automatically after 15 minutes. Be sure
to check out homedics.com for a growing list of wraps and
products that work with this system to offer a customizable, all-
body compression solution.
6
BATTERY INDICATOR
The color indicates the battery
level remaining.
• Solid White: 40% - 100% Charge
• Solid Red: 20 - 40% Charge
• Flashing Red: ≤20% Charge
HEAT
INDICATOR
The color indicates
the intensity of the
heat selected .
• Green: Low
• Blue: Medium
• Purple: High
POWER
To turn the massager on/o,
press the power button. The
screen will illuminate white to
indicate that the unit is on.
NOTE: The massager will begin
on mode A and 60% intensity
with no heat.
INTENSITY
Press the intensity
button to select
your preferred
level of pressure.
The intensity level
is indicated on the
LED screen to the
left of the button.
• 20%
• 40%
• 60%
• 80%
• 100%
MODE BUTTON
Press the mode button to select
between the four massage
modes. The mode is indicated
on the LED screen directly above
the button.
• (A) Alternating
• (B) Full
• (C) Sequential
• (D) Pulsing
HEAT BUTTON
To select between
three levels of
heat therapy (Low,
Medium, and High),
press the heat
button to reach
the desired level.
The modulair™ Battery Module is equipped with our
intelligent SMRTflex chip. This technology gives our battery
module the ability to detect which modulair
™ compression
wrap it’s docked into and perform the programs specific
to that wrap. This allows you to add on to your system and
build a compression regimen that fits your needs, all while
doing it with the same battery module.
7
MODE A: ALTERNATING
The rst airbag is inated to the desired pressure
and maintains the pressure for 5 seconds. The air is
then released for 2 seconds. The second airbag
begins to inate to the desired pressure and
maintains the desired pressure for 5 seconds.
The air is then released for 2 seconds. Both airbags
inate simultaneously and maintain pressure for 5
seconds. The pattern continues to repeat until
auto shuto at 15 minutes.
MODE B: FULL
The two airbags are inated to the desired
pressure at the same time. The airbags hold
the pressure for 5 seconds and then release
the air for 3 seconds. This pattern continues to
repeat until auto shuto at 15 minutes.
4 MASSAGE MODES
MODE C: SEQUENTIAL
The lower airbag is inated to the desired
pressure, and the pressure is held for 3
seconds. The upper airbag then inates to the
desired pressure. Air pressure is held in both
airbags for 5 seconds and then released for 5
seconds. This pattern continues to repeat until
auto shuto at 15 minutes.
MODE D: PULSING
The two airbags are inated to the desired
pressure at the same time, then the airbags
immediately release the air for 1 second. The
airbags then continue to inate to the desired
pressure. This pattern continues to repeat until
auto shuto at 15 minutes.
8
MAINTENANCE
TO CLEAN THE MASSAGER
Allow it to cool before cleaning. Clean only with a soft,
slightly damp sponge. Never allow water or any other liquids
to come into contact with the unit. DO NOT clean the unit
while charging.
• DO NOT immerse in any liquid to clean.
• NEVER use abrasive cleaners, brushes, or strong
chemicals that may or may not be flammable and/or
damaging to the product to clean.
• DO NOT attempt to repair the massager. There are no
user-serviceable parts. For service, contact Consumer
Relations at the telephone number listed in the Warranty
section.
TO STORE
Place massager in its box or in a cool, dry place. Avoid
contact with sharp edges or pointed objects which might
cut or puncture the fabric surface. To avoid breakage, do
not wrap the charging cable around the unit. DO NOT hang
the unit by the charging cable.
CAUTION: All servicing of this massager must be
performed by authorized Homedics service personnel only.
9
SUPPLIER’S DECLARATION OF CONFORMITY
Product Description: MODULAIR PNEUMATIC
COMPRESSION SYSTEM
Model Number: SR-CMX10J, SR-CMXC10HJ, SR-CMXF10HJ,
SR-CMXH10HJ, SR-CMXK10HJ
Trade Name: Homedics
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
U.S. Contact Information
Company: Homedics, LLC.
Address: 3000 N Pontiac Trail, Commerce Township, MI 48390
8:30am-7:00pm EST Monday-Friday 1-800-466-3342
Homedics is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment.
Such modifications could void the user authority to operate
the equipment.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
CAN ICES-003(B)/NMB-003(B)
10
Homedics sells its products with the intent that they are free of
defects in manufacture and workmanship for a period of 2 years
from the date of original purchase, except as noted below. Homedics
warrants that its products will be free of defects in material and
workmanship under normal use and service. This warranty extends
only to consumers and does not extend to Retailers.
To obtain warranty service on your Homedics product, contact a
Consumer Relations representative for assistance. Please make sure
to have the model number of the product available.
Homedics does not authorize anyone, including, but not limited to,
Retailers, the subsequent consumer purchaser of the product from
a Retailer or remote purchasers, to obligate Homedics in any way
beyond the terms set forth herein. This warranty does not cover
damage caused by misuse or abuse; accident; the attachment of
any unauthorized accessory; alteration to the product; improper
installation; unauthorized repairs or modifications; improper use of
electrical/power supply; loss of power; dropped product; malfunction
or damage of an operating part from failure to provide manufacturer’s
recommended maintenance; transportation damage; theft; neglect;
vandalism; or environmental conditions; loss of use during the period
the product is at a repair facility or otherwise awaiting parts or repair;
or any other conditions whatsoever that are beyond the control of
Homedics.
This warranty is effective only if the product is purchased and
operated in the country in which the product is purchased. A product
that requires modifications or adoption to enable it to operate
in any other country than the country for which it was designed,
manufactured, approved and/or authorized, or repair of products
damaged by these modifications is not covered under this warranty.
THE WARRANTY PROVIDED HEREIN SHALL BE THE SOLE
AND EXCLUSIVE WARRANTY. THERE SHALL BE NO OTHER
WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS OR ANY OTHER
OBLIGATION ON THE PART OF THE COMPANY WITH RESPECT TO
PRODUCTS COVERED BY THIS WARRANTY. HOMEDICS SHALL
HAVE NO LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL,
OR SPECIAL DAMAGES. IN NO EVENT SHALL THIS WARRANTY
REQUIRE MORE THAN THE REPAIR OR REPLACEMENT OF ANY
PART OR PARTS WHICH ARE FOUND TO BE DEFECTIVE WITHIN
THE EFFECTIVE PERIOD OF THE WARRANTY. NO REFUNDS WILL
BE GIVEN. IF REPLACEMENT PARTS FOR DEFECTIVE MATERIALS
ARE NOT AVAILABLE, HOMEDICS RESERVES THE RIGHT TO MAKE
PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR OR REPLACEMENT.
This warranty does not extend to the purchase of opened, used,
repaired, repackaged and/or resealed products, including but not
limited to sale of such products on internet auction sites and/or sales
of such products by surplus or bulk resellers. Any and all warranties or
guarantees shall immediately cease and terminate as to any products
or parts thereof which are repaired, replaced, altered, or modified,
without the prior express and written consent of Homedics.
2-YEAR LIMITED WARRANTY
11
©2023 Homedics, LLC. All rights reserved.
Homedics is a registered trademark of Homedics, LLC.
Distributed by Homedics, LLC, 3000 N Pontiac Trail, Commerce Township, MI 48390
IB-SRCM10
FOR SERVICE IN THE USA
CSERVICE@HOMEDICS.COM
8:30AM-7:00PM EST
MONDAY-FRIDAY
1-800-466-3342
FOR SERVICE IN CANADA
CSERVICE@HOMEDICSGROUP.CA
8:30AM-5:00PM EST
MONDAY-FRIDAY
1-888-225-7378
This warranty provides you with specific legal rights. You may have
additional rights which may vary from state to state and country to
country. Because of individual state and country regulations, some of
the above limitations and exclusions may not apply to you.
For more information regarding our product line in the USA, please visit
www.Homedics.com. For Canada, please visit www.Homedics.ca.
