Page 1 of 2
INCLUDED
x1
x1
x1
x1
x1
x20
6x16
Pan Head
Screw
x46
5x12
Pan Head
Screw
x20
Spring
Washer
M6
Washer
x1
x2
x2
TOOLS NEEDED
Open the package from the top and take
inventory of all the parts.
CoyoteOutdoor.com
CoyoteOutdoor.com
3
6x16
Pan Head Screw
Spring Washer
M6 Washer
x16
Page 2 of 2
Place the top on the cart and attach it using the
screws provided. (6 – 5x12 Pan Head Screw)
Finally, Attach the handle to the cart using the screws
and washers provided.
(4 – 6x16 Pan Head Screw, Spring Washer, M6 Washer)
Flip the base and lock the front wheels. Then, attach the
left and right-side panels using the screws provided.
(28 – 5x12 Pan Head Screw)
Flip the cart base and attach the casters with the locking
casters at the front using the provided screws and washers.
(16 – 6x16 Pan Head Screws, Spring Washer, M6 Washer)
Install screws under the cart as shown. If needed, lay the cart
on the side to complete this step. (12 – 5x12 Pan Head Screw)
CoyoteOutdoor.com
5x12
Pan Head Screw
x28
5x12
Pan Head Screw
x12
5x12
Pan Head Screw
x6
6x16
Pan Head Screw
Spring Washer
M6 Washer
x4
