BLAZE GRILL CART ASSEMBLY
CALIFORNIA PROPOSITION 65 WARNING
WARNING: This prod
uct can expose you to chemicals including Chromium (hexavalent compounds), which are known to the
State of California to cause cancer and birth defects or other reproductive harm. For more information go to:
www.P65Warnings.ca.gov
WARNING:
Do not use power tools to assemble. Only use hand tools, as power tools can damage or loosen the nutsert.
Before getting started:
- Unpack and lay out all of the included parts. Most of the stainless steel pieces come with a protective film. Remove all of the
plastic film and pay no attention to the print on the film as it has nothing to do with the assembly instructions.
- Take caution with the stainless steel components as to not scratch them during the assembly process. Use a non-aggressive
surface and protect the stainless steel as best as possible.
- (16) M5 x 12 mm screw will be paired with a M5 lock washer. Use M5
flat washer and lock washer for installing the casters to the base. All other connections will be made with a screw only.
- NOTE - screws for the door handles are smaller and those are packaged with the handles them self.
- (2) M5 x 24 mm - are to used last and are for securing BBQ to cart.
- The parts diagram has the parts labeled in the order in which they are used. Use the diagram as a reference, while following
the steps below.
Tools Needed: #2 Phillips Head Screw
Driver – “Not Included”
M5 x 12 mm
M5 x 24 mm
M5 washer
M5 lock
washer
