30" MINIMAL HANDLELESS OVENS AND
COMPANIONS
PLANNING GUIDE
SERIES 9 & 11
SELF-CLEANING OVEN | OB30SMPUNB3, OB30SMPUNG3
SELF-CLEANING STEAM ASSIST OVEN | OB30SMPSUNB3, OB30SMPSUNG3
COMBI-STEAM | OS30SMUNB3, OS30SMUNG3
COMPACT COMBI-STEAM | OS30NMUNB3, OS30NMUNG3
COMPACT CONVECTION-SPEED | OM30NMUNB3, OM30NMUNG3
BUILT-IN COFFEE MAKER | EB30MSB3
WARMING DRAWER | WB30SMB3, WB30SMG3, WB30SDEI3
VACUUM DRAWER | VB30SMB3, VB30SMG3, VB30SDEI3
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 290004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
CONCEPT DESIGN PAGE
DEVELOPED AND DETAILED DESIGN PAGE DEVELOPED AND DETAILED DESIGN PAGE
DESIGN CHoICE
Styles 4
Minimal Family 5
Installation Options 6
Overview 7
SPECIFICATIoN GUIDE
Self-Cleaning Oven 9
Self-Cleaning Steam Assist Oven 10
Combi-Steam Oven 11
Compact Combi-Steam Oven 12
Built-In Coee Maker 13
Warming Drawer 14
Integrated Warming Drawer 15
Vacuum Seal Drawer 16
Integrated Vacuum Seal Drawer 17
Dimensions - Ovens 18
Dimensions - Compact Ovens & Built-In Coee Maker 19
Dimensions - Drawers 20
Services 21
SUPPORT
For additional design planning and installation support please
contact the Fisher & Paykel design support team.
designsupport@fisherpaykel.com
CONTENTS | 30" OVENS AND COMPANIONS
INTRODUCTION
This comprehensive planning guide provides you with the
framework and tools to achieve your desired design outcome
with Fisher & Paykel appliances. In this guide, you will find a
range of conceptual, detailed, and dimensional product
information to bring your ideas to life and create spaces that
truly reflect your vision.
NOTES
The models shown in this Planning Guide may not be available
in all markets and are subject to change at any time. Refer to to
our website fisherpaykel.com for the latest document version.
Product specifications may vary from those shown.
This Planning Guide should not be used as installation guidance
for any product. Specific installation guidance will be available
with the product on delivery and on our website.
<< CONTENTS
CONTENTS
PAGE 3© FISHER & PAYKEL APPLIANCES LIMITED 2025PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 202590004604A
DESIGN CHOICE
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 490004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
DESIGN CHOICE | 30" OVENS AND COMPANIONS STYLES
MINIMAL STYLEMINIMAL STYLE - HANDLELESS CONTEMPORARY STYLE PROFESSIONAL STYLE
Distinctive and bold, Professional style ovens
are the perfect interpretation of the
commercial kitchen for the home chef.
Experience refined performance with
stainless steel construction that is built to
last.
This Planning Guide is for the Minimal
Handleless Style 30" Ovens and Companions.
For information on other styles, please visit
the Fisher and Paykel website. To see what
models are available, head to the 'Overview'
section in this Planning Guide.
Celebrating a singular aesthetic to blend seamlessly into the kitchen, Minimal style ovens feature subtle
textural and tonal contrasts for a sense of refinement and purity.
Defined by clean lines and timeless design
cues, Contemporary style ovens bring a
sense of balance and refinement. A versatile
aesthetic that complements a range of
kitchen styles.
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 590004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
MINIMAL FAMILYDESIGN CHOICE | 30" OVENS AND COMPANIONS
GreyBlack
Minimal Handleless Family
Series 9 and 11
Minimal Handle Family
Series 9 and 11
Installation in wall
Installation under-bench
FINISH OVENS COMPANIONS INSTALLATION OPTIONS
SELF-
CLEANING
SELF-
CLEANING
STEAM
ASSIST STEAM SPEED
COFFEE
MAKER
WARMING DRAWERS
VACUUM SEAL DRAWERS
*Integrated model, panel ready for a custom front panel.
*
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 690004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
INSTALLATION OPTIONSDESIGN CHOICE | 30" OVENS AND COMPANIONS
CONSIDERATIONS
Dierent configurations possible, consider
heights for grid and row installations.
STACK HEIGHT
Stack Height is overall product height with
minimum clearance above appliance front
panel to upper cabinetry front panel or
appliance.
STACKED INSTALLATION GRID INSTALLATION ROW INSTALLATION
Stack Height
28 3/4" (731mm)
Stack Height
46 7/8" (1191mm)
Stack Height
28 3/4" (731mm)
Stack Height
28 3/4" (731mm)
Stack Height
57 9/16" (1462mm)
Stack Height
52 3/8" (1331mm)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 790004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SELF-CLEANING
OVEN
SELF-CLEANING
STEAM ASSIST
OVEN
COMBI-STEAM
OVEN
COMPACT COMBI-
STEAM OVEN
COMPACT
CONVECTION-
SPEED OVEN
BUILT-IN COFFEE
MAKER
WARMING DRAWER VACUUM SEAL
DRAWER
Series Series 9 Series 11 Series 11 Series 9 Series 9 Series 9 Series 9 Series 9
Black Models OB30SMPUNB3 OB30SMPSUNB3 OS30SMUNB3 OS30NMUNB3 OM30NMUNB3 EB30MSB3 WB30SMB3 VB30SMB3
Grey Models OB30SMPUNG3 OB30SMPSUNG3 OS30SMUNG3 OS30NMUNG3 OM30NMUNG3 - WB30SMG3 VB30SMG3
Integrated Models - - - - - - WB30SDEI3 VB30SDEI3
Interface 6.8" Touchscreen 6.8" Touchscreen 6.8" Touchscreen 6.8" Touchscreen 6.8" Touchscreen 4.3" Touchscreen - -
Overall Height 28 11/16" (729mm) 28 11/16" (729mm) 23 9/16" (598mm) 18 " (45 8mm) 18" (458mm) 1 8 " (458mm) 10 11/16" (271mm) 10 11/16" (271mm)
Front Panel Thickness 13/16" (20mm) 13/16" (20mm) 13/16" (20mm) 13/16" (20mm) 13/16" (20mm) 13/16" (20mm) 13/16" (20mm) 13/16" (20mm)
*Integrated models available.
OVERVIEWDESIGN CHOICE | 30" OVENS AND COMPANIONS
SIDE
ELEVATION
FRONT
ELEVATION
* *
<< CONTENTS
PAGE 8© FISHER & PAYKEL APPLIANCES LIMITED 2025PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 202590004604A
SPECIFICATION GUIDE
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 990004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB30SMPUNB3, OB30SMPUNG3SPECIFICATION GUIDE | SELF-CLEANING OVEN, 30"
OVERVIEW
Designed to complement Minimal style appliances, this
handleless oven delivers a clean, uninterrupted finish – ideal for
true handleless kitchen designs. Pyrolytic self-cleaning simplifies
maintenance, while intuitive temperature and heat type
recommendations accessed via the large touch screen and
SmartHQ™ support optimal cooking results across a wide range
of functions and food types.
PRODUCTS
oB30SMPUNB3 - Black
30" Series 9 Minimal Handleless Self-Cleaning Oven
oB30SMPUNG3 - Grey
30" Series 9 Minimal Handleless Self-Cleaning Oven
SERIES & STYLE
Series 9
Minimal
FEATURES
1 Handleless oven design ensures smooth, uninterrupted lines
in kitchen cabinetry for a cohesive look
2 Self-cleaning pyrolytic function breaks down food residue
for an easy clean
3 Effortlessly open and close the oven with a gentle press of a
button, ensuring convenience and smooth operation in the
kitchen
4 Generous 4.6 cu ft useable capacity
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Twin vertical fans, perfect for multi-shelf cooking
8 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
9 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Self-cleaning-proof Side Ladders
2 Full Extension Sliding Shelf (x3)
3 Air Fry Tray
4 Multi-functional Deep Roasting Dish
5 Wired Temperature Sensor
OB30SMPUNG3
OB30SMPUNB3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1090004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | SELF-CLEANING STEAM ASSIST OVEN, 30" OB30SMPSUNB3, OB30SMPSUNG3
OB30SMPSUNG3
OB30SMPSUNB3
OVERVIEW
Designed to complement Minimal style appliances, this
handleless oven oers a sleek, uninterrupted finish – ideal for
true handleless kitchen designs. Steam Assist enhances
convection cooking, while pyrolytic cleaning simplifies
maintenance. Intuitive temperature and heat type
recommendations accessed via the large touch screen and
SmartHQ™ support optimal cooking results across a wide range
of functions and food types.
PRODUCTS
oB30SMPSUNB3 - Black
30" Series 11 Minimal Handleless Self-Cleaning Steam Assist
Oven
oB30SMPSUNG3 - Grey
30" Series 11 Minimal Handleless Self-Cleaning Steam Assist
Oven
SERIES & STYLE
Series 11
Minimal
ACCESSORIES
1 Self-cleaning-proof Side Ladders
2 Full Extension Sliding Shelf (x3)
3 Air Fry Tray
FEATURES
1 Handleless oven design ensures smooth, uninterrupted lines
in kitchen cabinetry for a cohesive look
2 Steam Assist combines convection heat with steam to
enhance the cooking process
3 Self-cleaning pyrolytic function breaks down food residue
for an easy clean
4 Effortlessly open and close the oven with a gentle press of a
button, ensuring convenience and smooth operation in the
kitchen
5 Generous 4.6 cu ft useable capacity
6 Large 6.8" touchscreen is intuitive and easy to use
7 Achieve optimal results with temperature and heat type
recommendations
8 Twin vertical fans, perfect for multi-shelf cooking
9 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
"0
Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
4 Multi-functional Deep Roasting Dish
5 Wired Temperature Sensor
6 Descale Solution - 2 sachets (Part 580925)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1190004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMBI-STEAM OVEN, 30" OS30SMUNB3, OS30SMUNG3
OVERVIEW
Designed to complement Minimal style appliances, this
handleless Combi-Steam oven oers a sleek, uninterrupted
finish – ideal for true handleless kitchen designs. Featuring a
larger cavity ideal for cooking larger dishes and multiple trays
simultaneously. With versatile cooking options including steam
or convection, plus a Steam Clean function for easy
maintenance. Intuitive temperature and heat type
recommendations can be accessed via the large touch screen
and SmartHQ™, to support optimal cooking results across a
wide range of functions and food types.
PRODUCTS
oS30SMUNB3 - Black
30" Series 11 Minimal Handleless Combi-Steam Oven
oS30SMUNG3 - Grey
30" Series 11 Minimal Handleless Combi-Steam Oven
SERIES & STYLE
Series 11
Minimal
FEATURES
1 Handleless design ensures smooth, uninterrupted lines in
kitchen cabinetry for a cohesive look
2 Versatile cooking options with steam or convection heat for
optimal results
3 Effortlessly open and close the oven with a gentle press of a
button, ensuring convenience and smooth operation in the
kitchen
4 Generous 2.5 cu ft useable capacity with four shelf positions
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Moisture control and even heat distribution thanks to
ActiveVent™ and AeroTech™ technology
8 Steam Clean function ensures a spotless oven with minimal
effort
9 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
"0
Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
OS30SMUNG3
OS30SMUNB3
ACCESSORIES
1 Chrome Side Ladders
2 Full Extension Sliding Shelf (x2)
3 Step Down Wire Shelf
4 Roasting Dish
5 Broil Rack
ACCESSORIES
6 Smokeless Broil Tray
7 Large Perforated Steam Dish
8 Small Perforated Steam Dish
9 Large Steam Dish
"0
Wired Temperature Sensor
"1
Descale Solution - 2 sachets (Part 580925)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1290004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMPACT COMBI-STEAM OVEN, 30" OS30NMUNB3, OS30NMUNG3
OVERVIEW
Designed to complement Minimal style appliances, this
handleless Combi-Steam oven oers a sleek, uninterrupted
finish – ideal for true handleless kitchen designs. With versatile
cooking options including steam or convection, plus a Steam
Clean function for easy maintenance. Intuitive temperature and
heat type recommendations can be accessed via the large
touch screen and SmartHQ™, to support optimal cooking results
across a wide range of functions and food types.
PRODUCTS
oS30NMUNB3 - Black
30" Series 9 Minimal Handleless Compact Combi-Steam Oven
oS30NMUNG3 - Grey
30" Series 9 Minimal Handleless Compact Combi-Steam Oven
SERIES & STYLE
Series 9
Minimal
FEATURES
1 Handleless design ensures smooth, uninterrupted lines in
kitchen cabinetry for a cohesive look
2 Versatile cooking options with steam or convection heat for
optimal results
3 Effortlessly open and close the oven with a gentle press of a
button, ensuring convenience and smooth operation in the
kitchen
4 1.6 cu ft useable capacity with four shelf positions
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Moisture control and even heat distribution thanks to
ActiveVent™ and AeroTech™ technology
8 Steam Clean function ensures a spotless oven with minimal
effort
9 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
"0
Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
OS30NMUNG3
OS30NMUNB3
ACCESSORIES
1 Chrome Side Ladders
2 Full Extension Sliding Shelf
3 Flat Wire Shelf
4 Flat Brushed Baking Tray
5 Roasting Dish
6 Broil Rack
ACCESSORIES
7 Large Perforated Steam Dish
8 Small Perforated Steam Dish
9 Large Steam Dish
"0
Wired Temperature Sensor
"1
Descale Solution - 2 sachets (Part 580925)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1390004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | BUILT-IN COFFEE MAKER, 30" EB30MSB3
OVERVIEW
Designed to complement Minimal style appliances, this Coee
Maker delivers a seamless, flush finish – ideal for modern
kitchen designs. It remembers your favorite brews over time,
oering personalized coee at the touch of a button. With
precise grinding, creamy milk frothing, and eortless self-
cleaning, it brings barista-quality coee home.
PRODUCTS
EB30MSB3 - Black
30" Series 9 Minimal Built-in Coee Maker
SERIES & STYLE
Series 9
Minimal
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Intuitive touch display brews a perfect cup of coffee at the
touch of a button
3 Programmable timer turns on the Coffee Maker at the ideal
time each day
4 Personalised coffee and smart self-learning menu
preferences with 13 functions to suit any taste
5 Allows you to prepare hot milk or creamy froth in seconds
6 Stainless steel conical burr grinder with 13 coarseness
positions
7 15 bar pump pressure
8 Self-cleaning function and easy to empty coffee grounds
container and drip tray
9 81 fl oz (2.4L) water tank capacity
ACCESSORIES
1 Milk Container (Auto-Froth)
2 Steam Wand
3 Coffee Spoon
4 Cleaning Brush
5 Descaler Solution - 1 bottle
6 Water Hardness Indicator Paper
7 Water Filter
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1490004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | WARMING DRAWER, 30" WB30SMB3, WB30SMG3
OVERVIEW
Designed to complement Minimal style appliances, this
Warming Drawer delivers a seamless, flush finish – ideal for
modern kitchen designs. Featuring a push-to-open mechanism,
intuitive touch controls, and a smooth glass base for easy
cleaning. With six tailored programmes and space for 16 place
settings, it keeps meals ready to serve.
PRODUCTS
WB30SMB3 - Black
30" Series 9 Minimal Warming Drawer
WB30SMG3 - Grey
30" Series 9 Minimal Warming Drawer
SERIES & STYLE
Series 9
Minimal
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Automatic switch-off and delayed start functionality to help
keep dishes warm until it is time to serve
6 Room for 16 standard-sized place settings
7 Six tailored programmes for Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
ACCESSORIES
1 Accessory rack for optimising space
WB30SMG3
WB30SMB3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1590004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | INTEGRATED WARMING DRAWER, 30" WB30SDEI3
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Automatic switch-off and delayed start functionality, to help
keep dishes warm until it is time to serve
5 Room for 16 standard-sized place settings
6 Six tailored programmes for Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
7 Six tailored programmes for Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
ACCESSORIES
1 Accessory rack for optimising space
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Warming Drawer with kitchen cabinetry
for a cohesive kitchen look. Featuring a push-to-open
mechanism, intuitive touch controls, and a smooth glass base
for easy cleaning. With six tailored programmes and space for
16 place settings, it keeps meals ready to serve.
PRODUCTS
WB30SDEI3*
30" Series 9 Integrated Warming Drawer
*Panel ready.
SERIES & STYLE
Series 9
Integrated
Integrated Warming Drawer WB30SDEI3
Integrated Warming Drawer WB30SDEI3 with Compact
Combi-Steam Oven OS30NMUNB3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1690004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | VACUUM SEAL DRAWER, 30" VB30SMB3, VB30SMG3
OVERVIEW
Designed to complement Minimal style appliances, this Vacuum
Seal Drawer delivers a seamless, flush finish – ideal for modern
kitchen designs. A push-to-open mechanism and intuitive touch
controls oer eortless use, while three vacuum and heat
sealing levels support sous vide preparation, marinating, and
food storage, using reusable and BPA-free food-grade bags.
PRODUCTS
vB30SMB3 - Black
30" Series 9 Minimal Vacuum Seal Drawer
vB30SMG3 - Grey
30" Series 9 Minimal Vacuum Seal Drawer
SERIES & STYLE
Series 9
Minimal
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Three levels of vacuum and heat sealing - for easy re-
sealing, food portioning, marinating, storage and extending
shelf life
6 Allows effortless preparation for sous vide cooking
7 Our food-grade, BPA-free bags are an excellent storage
option — these can be re-used if sealed and cut
appropriately.
ACCESSORIES
1 Large BPA-free Vacuum Bags - 50 bags (Part 793034)
2 Small BPA-free Vacuum Bags - 50 bags (Part 793033)
3 External Vacuuming Accessory Kit
VB30SMG3
VB30SMB3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1790004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | INTEGRATED VACUUM SEAL DRAWER, 30" VB30SDEI3
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Three levels of vacuum and heat sealing - for easy re-
sealing, food portioning, marinating, storage and extending
shelf life
5 Allows effortless preparation for sous vide cooking
6 Our food-grade, BPA-free bags are an excellent storage
option — these can be re-used if sealed and cut
appropriately.
ACCESSORIES
1 Large BPA-free Vacuum Bags - 50 bags (Part 793034)
2 Small BPA-free Vacuum Bags - 50 bags (Part 793033)
3 External Vacuuming Accessory Kit
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Vacuum Seal Drawer with kitchen
cabinetry for a cohesive kitchen look. A push-to-open
mechanism and intuitive touch controls oer eortless use,
while three vacuum and heat sealing levels support sous vide
preparation, marinating, and food storage, using reusable and
BPA-free food-grade bags.
PRODUCTS
vB30SDEI3*
30" Series 9 Integrated Vacuum Seal Drawer
*Panel ready.
SERIES & STYLE
Series 9
Integrated
Integrated Vacuum Seal Drawer VB30SDEI3
Integrated Vacuum Seal Drawer VB30SDEI3 with Compact
Combi-Steam Oven OS30NMUNB3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1890004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB30SMPUNB3, OB30SMPUNG3, OB30SMPSUNB3,
OB30SMPSUNG3, OS30SMUNB3, OS30SMUNG3 SPECIFICATION GUIDE | 30" OVENS AND COMPANIONS
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
A
B
C
D
E
F
g
h
i
SELF-CLEANING OVEN
OB30SMPUNB3, OB30SMPUNG3
SELF-CLEANING STEAM ASSIST OVEN
OB30SMPSUNB3, OB30SMPSUNG3
COMBI-STEAM OVEN
OS30SMUNB3, OS30SMUNG3
PRODUCT DIMENSIONS inch mm inch mm inch mm
A Overall height 28 11/16 729 28 11/16 729 23 9/16 598
B Overall width 29 7/8 758 29 7/8 758 29 7/8 758
C Chassis height 27 7/8 708 27 7/8 708 22 5/8 575
D Chassis width 28 3/8 720 28 3/8 720 28 3/8 720
E Chassis depth 22 5/8 575 22 5/8 575 22 7/16 545
F Control panel thickness 13/16 20 13/16 20 13/16 20
Depth with door fully open* 23 3/8 594 23 3/8 594 18 1/8 460
*Measured from front of control panel.
CAVITY DIMENSIONS inch mm inch mm inch mm
G Minimum inside height of cavity 28 1/32 712 28 1/32 712 22 13/16 580
H Minimum inside width of cavity 28 1/2 724 28 1/2 724 28 1/2 724
I Minimum inside depth of cavity* 23 1/2** 597** 23 1/2** 597** 21 5/8 550
Recommened cabinet height 28 3/4 731 28 3/4 731 24 600
Recommened cabinet width 30 762 30 762 30 762
*Measured from front of chassis.**Requires ventilation at the rear of the cavity.
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
Ventilation
required
Ventilation
required
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1990004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OS30NMUNB3, OS30NMUNG3,
OM30NMUNB3 OM30NMUNG3, EB30MSB3 SPECIFICATION GUIDE | 30" OVENS AND COMPANIONS
A
B
C
D
E
F
g
h
i
COMPACT COMBI-STEAM OVEN
OS30NMUNB3, OS30NMUNG3
COMPACT CONVECTION-SPEED OVEN
OM30NMUNB3, OM30NMUNG3
BUILT-IN COFFEE MAKER
EB30MSB3
PRODUCT DIMENSIONS inch mm inch mm inch mm
A Overall height 18 458 18 458 18* 458*
B Overall width 29 7/8 758 29 7/8 758 29 7/8* 758*
C Chassis height 17 1/8 435 17 1/8 435 17 1/2 445
D Chassis width 28 3/8 720 28 3/8 720 22 1/16 560
E Chassis depth 2 1 7/16 545 21 7/1 6 545 18 1/8 460
F Control panel thickness 13/16 20 13/16 20 13/16* 20*
Depth with door fully open** 12 5/8 320 12 5/8 320 - -
*Measurements with trim kit. **Measured from front of control panel.
CAVITY DIMENSIONS inch mm inch mm inch mm
G Minimum inside height of cavity 17 5/16 440 17 5/16 440 17 3/4 450
H Minimum inside width of cavity 28 1/2 724 28 1/2 724 22 1/16*** 560***
I Minimum inside depth of cavity* 21 5/8 550 21 5/8** 550** 22 1/16** 560**
Recommened cabinet height 18 1/8 460 18 1/8 460 18 1/8 460
Recommened cabinet width 30 762 30 762 30 762
*Measured from front of chassis. **Requires ventilation at the rear of the cavity. ***Cabinetry requires additional vertical sidewalls to secure the product.
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
Ventilation
required
Ventilation
required
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 2090004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
WB30SMB3, WB30SMG3, WB30SDEI3,
VB30SMB3, VB30SMG3, VB30SDEI3 SPECIFICATION GUIDE | 30" OVENS AND COMPANIONS
A
B
C
D
E
F
g
h
i
WARMING DRAWER
WB30SMB3, WB30SMG3
INTEGRATED WARMING DRAWER
WB30SDEI3
VACUUM SEAL DRAWER
VB30SMB3, VB30SMG3
INTEGRATED VACUUM SEAL DRAWER
VB30SDEI3
PRODUCT DIMENSIONS inch mm inch mm inch mm inch mm
A Overall height 10 11/16 271 10 11/16 271 10 11/16 271 10 11/16 271
B Overall width 29 7/8 758 29 7/8 758 29 7/8 758 29 7/8 758
C Chassis height 10 11/16 271 10 11/16 271 10 11/16 271 10 11/16 271
D Chassis width 27 3/4 704 27 3/4 704 28 1/2** 724** 28 1/2** 724**
E Chassis depth* 21 9/16 547 21 9/16 547 21 11/16 551 21 11/16 551
F Front panel thickness 13/16 20 min 5/8*** min 16*** 13/16 20 min 5/8*** min 16***
Front panel height 10 1/2 267 10 1/2 267 10 1/2 267 10 1/2 267
Front panel width 29 7/8 758 29 7/8 758 29 7/8 758 29 7/8 758
*Including power plug. **Including side brackets. ***A clearance of 1/16" (2mm) between the cabinet and the custom panel is required for the push-to-open mechanism (spacer included). Maximum custom panel weight 11 lb (5kg).
CAVITY DIMENSIONS inch mm inch mm inch mm inch mm
G Minimum inside height of cavity 10 3/4 273 10 3/4 273 10 3/4 273 10 3/4 273
H Minimum inside width of cavity 28 1/2 724 28 1/2 724 28 1/2 724 28 1/2 724
I Minimum inside depth of cavity* 22 13/16 580 22 13/16 580 22 13/16 580 22 13/16 580
Recommened cabinet height 10 3/4 273 10 3/4 273 10 3/4 273 10 3/4 273
Recommened cabinet width 30 762 30 762 30 762 30 762
*Measured from front of chassis.
Note: Drawers can fully support 30inch Fisher & Paykel oven, without adding shelf in between.
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 2190004604A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
ALL MODELSSERVICES | 30" OVENS AND COMPANIONS
ISOMETRIC
VIEW
SELF-CLEANING OVEN
OB30SMPUNB3,
OB30SMPUNG3
SELF-CLEANING STEAM
ASSIST OVEN
OB30SMPSUNB3,
OB30SMPSUNG3
COMBI-STEAM OVEN
OS30SMUNB3,
OS30SMUNG3
COMPACT COMBI-STEAM
OVEN
OS30NMUNB3,
OS30NMUNG3
COMPACT CONVECTION-
SPEED OVEN
OM30NMUNB3,
OM30NMUNG3
BUILT-IN COFFEE
MAKER
EB30MSB3
WARMING DRAWER
WB30SMB3, WB30SMG3,
WB30SDEI3
VACUUM SEAL DRAWER
VB30SMB3, VB30SMG3,
VB30SDEI3
PRODUCT
REQUIREMENTS
Supply 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 120 V, 60 Hz 120 V, 60 Hz 120 V, 60 Hz
Service 20 A 20 A 20 A 20 A 20 A 10 A 10 A 10 A
Connection
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Plug with flex cord
66 15/16" (1700mm)
Plug with flex cord
70 7/8" (1800mm)
Plug with flex cord
70 7/8" (1800mm)
CAPACITY
Total Oven capacity 4.9cu ft (137L) 4.9cu ft (137L) 3cu ft (85L) 1.9cu ft (55L) 1.7cu ft (49L) - - -
Total water tank capacity - 22.65fl oz (0.67L) 47.3fl oz (1.4L) 47.3fl oz (1.4L) - 81 fl oz (2.4L) - -
Note: All Coee Makers and Steam Ovens have internal water tanks which need to be filled manually. No external water supply is required.
<< CONTENTS
