RECHARGEABLE UNDER-BONNET LIGHT, 9W
SMD LED, 600 LUMENS
MODEL NO: LED141
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 It is important to ensure that the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT leave battery in a discharged state. Recharge battery immediately.
9 Recharge the battery at least once every six months of non-use.
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using this light.
Account for all tools being used and DO NOT leave them in or near the engine.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°).
2. INTRODUCTION
Rechargeable Under-Bonnet 600 Lumen SMD LED worklight with three brightness settings. 180° Swivel handle for accurately directing the light
at any angle required. Each end has a 360° swivel/hanging hook and a magnet for hands-free operation. LED Charge indicator displays the
current battery level during use and while charging. 3.7V 1.8Ah Lithium-ion battery. Charges via a USB Type-C cable (supplied).
3. SPECIFICATION
Model No .................................................................. LED141
Battery ............................................... 3.7V 1.8Ah Lithium-ion
Charging Time ........................................... 3-4hr at 5V DC 2A
LED Qty: ............................................................................ 42
LED Type ....................................................................... SMD
Lumen Output ...................................................... 600 Lumen
Operating Time .................................. High/Med/Low: 1/2/4hr
Power ................................................................................9W
Nett Weight: ............................................................... 0..62kg
4. OPERATION
4.1. OPERATIONAL MODES (Refer to g.1)
4.1.1. Press On/O button once to turn the unit on. This will also light up the four LEDs (g.1) to indicate the battery state. 4 bars lit
indicates 100%, 1 bar lit indicates 25% (or less).
4.1.2. LED Charge indicator displays the current battery level during use and while charging.
4.1.3. Press On/O button again and the unit operates in full power mode.
4.1.4. Press On/O button again and the unit operates in mid-power mode.
4.1.5. Press On/O button again and the unit operates in low power mode.
4.1.6. Press On/O button again and the unit switches o.
4.2. UNIT MOUNTING AND ADJUSTMENT (Refer to g.2)
4.2.1. The unit is tted with a hook at each end to enable suspension from a suitable source.
4.2.2. The unit also has a magnet at each end to allow it to be supported from a ferrous surface / object.
4.2.3. To enable lighting position adjustment, the unit is tted with hinging/rotating elbows at both ends.
4.2.4. Pull the end caps out to expose the joint (g.2). Each elbow can be rotated through 180
0
and in one of 9 set positions.
LED141 Issue 1 13/03/25
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL / REPLACEMENT
Remove the screws in the black section of the lamp control section to remove the batteries.
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
LED141 Issue 1 13/03/25
5. MAINTENANCE
5.1. Keep lamp clean and check for damage before every use. If damage is observed, remove from use until unit is repaired.
6. END OF LIFE
6.1. Dispose of item in accordance with national and regional regulations. Review footers below.
fig.1
fig.1
USB Connection
Power / Mode
Selector
Indicator LEDs
Rotate 90
0
positions
Rotate 180
0
fig.2
Hanging Hooks
