MRC5/ MRC5B
Installation Instructions
Marine Radio Cover
- 1 -
Thank you for purchasing a BOSS Audio Systems product. Please read through
these instructions carefully so you will know how to install this product properly.
Package Contents
• 1x Marine radio cover
• 6x Pan head screws (M4 x 25mm)
and clip nuts
• Sticky EVA gasket ring
• Warranty
Introduction and Features
• Head unit installation opening (W x H): 7.18” x 2.11” (182.4 x 53.5 mm)
• Fits single DIN head units (W x H): 7” x 2.0” (178 x 51 mm)
• Marine radio cover dimensions (W x H x D): 9.09” x 4.02” x 1.92” (231 x 102 x 48.8 mm)
• UV-stabilized ABS plastic housing
• Impact-resistant ABS
• Door sealed with an EVA gasket for water resistance
Product Overview
Flip-up door
Screw hole for xing
the radio cover
Removable plastic tab
Head unit installation opening
- 2 -
Installation
Step 1
If your single DIN head unit does not t in the center opening of the radio cover, use a
proper tool to cut out the two tabs (ABS plastic) in the center opening.
Plastic tab
Plastic tab
2.11”
Step 2
The head unit installation opening is 7.18” x 2.11”. Attach your single DIN head (7” x 2.0”)
unit to the radio cover through the opening, then place in the supplied EVA ring around the
head unit face for shock absorption and added protection against the elements.
7.18”
2.11”
Sticky EVA ring
Step 3
Secure the radio cover in the dash via the six screw holes using the supplied screws and
clip nuts. Make sure the head unit is securely attached.
Screw hole
0424
V:1D
Customer service: 805-751-4853
Tech support: www.bossaudio.com/support
