ICE MAKER ICM1250
USER MANUAL
Before operating the appliance, please read this manual and all the
safety instructions thoroughly and retain it for future reference.
A
D
D
W
A
T
E
R
I
C
E
F
U
L
L
CUSTOMER SERVICE DEPARTMENT
Thank you for supporting our brand. If you have any questions, please
choose the way you prefer to contact the service team, the service team
will get back to you within 24 hours on the business day.
1. Ocial E-mail Address: [email protected]
2. Log in Amazon Account - Click “Orders” - Go to the specific product
page - Click the name of the seller(behind “sold by”)- Click “Ask a
question”- Follow the steps to contact.
Steps figure below:
①
②
③
Store
TABLE OF CONTENTS
Important Safeguards
Product Components
Display
Before First Use
Using Your Ice Maker
Operation Guide
Clean And Maintenance
Troubleshooting
Warning
Correct Disposal Of This Product
01
03
04
04
05
05
06
07
09
09
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety
precautions should always be followed to reduce the risk of
fire, electric shock, and/or injury, including the following:
• Read all instructions before using.
• Remove all packing material and carefully check your ice maker to
ensure it is in good condition and that there is no damage to the ice
maker or power cord and plug.
• Before using the Ice maker for the first time, please wait 2 hours after
positioning it, and keep the transparent lid open for at least 2 hours
• Pure water is not allowed to be used on this unit, spring water is recom-
mended.
• Ensure the voltage is compliant with the voltage range stated on the
rating label, and ensure the earthing of the socket is in good condition.
• If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
• Do not upend this product or incline it over a 45° angle.
• To protect against risk of electric shock, do not pour water on cord, plug
and ventilation, immerse the appliance in water or any other liquid.
• Unplug the appliance after using or before cleaning.
• Keep the appliance 8cm from other objects to ensure the good heat
releasing.
• Do not use the accessories which are not recommended by Manufactur-
er.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
• Do not use the appliance close by flames, hot plates or stoves.
• Do not switch on the power button frequently (ensure 5min. interval at
least) to avoid the damage of compressor.
• Metal sheet or other electric objects are not allowed to be inserted into
the appliance to avoid fire and short circuit.
01
• Do not use outdoors.
• Never clean with scouring powders or hard implements.
• Please keep the instruction manual.
• Warning: Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• This appliance is intended to be used in household and similar applica-
tions such as
– sta kitchen areas in shops, oces and other working environments;
– farm houses and by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail applications
• When positioning the appliance, ensure the supply cord is not trapped or
damaged.
• Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance
• The refrigerant and insulation blowing gas is flammable, when disposing
of the appliance, do so only at an authorized waste disposal centre. Do
not expose to flame.
This symbol indicates the refrigerant R600a and the
non-metallic materials of the appliance are flammable. It’s a
warning symbol.
Warning: Risk of fire / flammable materials.
Warning; Risk of fire / flammable materials.
• WARNING: When positioning the appliance, ensure the supply cord is
not trapped or damaged.
• WARNING: Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
• Children aged from 3 to 8 years are allowed to load and unload refrig-
erating appliances. To avoid contamination of food, please respect the
following instructions:
– Opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance.
02
A
D
D
W
A
T
E
R
I
C
E
F
U
L
L
– Clean regularly surfaces that can come in contact with food and acces-
sible drainage systems.
– Clean water tanks if they have not been used for 48 h; flush the water
system connected to a water supply if water has not been drawn for 5
days.
– If the refrigerating appliance is left empty for long periods, switch o,
defrost, clean, dry, and leave the door open to prevent mould develop-
ing within the appliance.)
• Regarding the information pertaining to the use of the appliance, thanks
to refer to the below paragraph of the manual.
PRODUCT COMPONENTS
1. Transparent lid
2. Liner
3. Control panel
4. Front housing
5. Ice shovel board
6. Rear housing
7. Air Vent
8. Bullet evaporator
9. Water box
10. Ice scoop
11. Ice basket
5
8
9
10 11
6
7
1
2
3
4
03
Small Size
Menu
Power Button
DISPLAY
Large Size
Self-cleaning
Mode
Ice Full
Ice-making Mode
Add Water
BEFORE FIRST USE
1. Remove all packaging from the ice maker, including any temporary
stickers. Read all instructions.
2. During transportation, do not tilt the machine more than 45 degrees,
do not reverse the machine. This may damage the compressor and the
sealing system.
3. Remove all packing materials, check the machine carefully and make
sure that the machine, power cord and plug are complete.
4. The machine should be on a level surface. To ensure sucient
ventilation, the distance of the ice maker’s back to the wall should be at
least 150 mm, it should be away from the oven, radiator or other heat
source.
5. Before using the machine for the first time, let the machine sit and leave
the transparent cover open for at least 24 hours.
6. Make sure that the household voltage is consistent with the voltage
indicated on the product label.
7. It’s recommended to use edible water, or add a filter to your water tap
to prolong the life of machine. Mineral water is not recommended.
8. TIPS: When the ambient temperature is below 15°C/59°F, it's
recommended to choose "Small" ice size.
Setting Up
ADD WATER
ICE FULL
04
USING YOUR ICE MAKER
- Ice full alarm
When the ice reaches the maximum capacity of the ice basket, the "ICE
FULL" light turns red, and the machine stops. Please use ice scoop to
remove the ice in the basket. The ice maker will automatically restart
after several minutes. For an instant restart please press the button
for 2 times.
- Water shortage alarm
When the “ADD WATER” light turns red, please add water to the water
tank and press the button for 2 times to restart the ice making cycle.
ADD WATER
ICE FULL
OPERATION GUIDE
1. Open the lid and take out the basket and add water to the reservoir.
[Figure 1] Note: The water should not exceed the MAX water level.
2. Plug in the ice maker, the machine enters "standby mode", no indicator
lights brighten.
3. Press the button, the machine enters "working mode", the indica-
tor and the indicator both brighten.(Default: Large)
4. Press button to select the or ice size, the corresponding size
indicator light flashes for 5 seconds, the ice size is programmed.
NOTE:
1. The ice produced during the first 5
cycles may not be in perfect and
complete status. It’s normal.
2. When the ice basket is full, please
take out the ice immediately.
3. The button doesn't work under
"standby mode".
Figure 1
A
D
D
W
A
T
E
R
I
C
E
F
U
L
L
05
CLEAN AND MAINTENANCE
Recommended cleaning frequency: once a week.
1. Before cleaning: unplug the unit and remove all the ice cubes. Prepare
a diluted solution of water and baking soda.
2. Plug in the ice maker, the machine enters "standby mode", no indicator
lights brighten.
· Press the button, the machine enters "working mode", the indica-
tor and the indicator both brighten.
· Press button to select the , the indicator flashes for 5 seconds,
the self-clean mode is activated.
· At that time, the indicators of and both brighten, and the machine
will start a round of self-check to remove the ice cubes sticking to the
evaporator.
· Then comes the cleaning process.
· Then it will enter "standby mode". Finally, unscrew the drain plug and
empty the water tank.
NOTE:
· The button doesn't work under "standby mode".
· Do not cut the power o while self-clean mode.
3. Do not spray chemicals or diluted agents such as acids, gasoline, or oil
on the ice maker.
4. Keep ventilation openings exposed, no obstructions.
5. To ensure the purity of ice, never leave water in the tank for several days
and then use it to make another round of ice. Change water everyday or
the ice’s flavor may be aected.
6. If do not use for a long time, please drain the water out and clean it up.
7. If the compressor stops due to water shortage, full ice basket, or power
cut, it will delay for 3mins to start up after restart.
8. Always use fresh water before starting ice production either at initial
installation or after a long shut-o period.
06
TROUBLESHOOTING
If a power cut occurs due to disconnection of the power cord,
unexpected pushing of POWER button during an ice making cycle or
power blackout, the already formed ice on the evaporator will not fall
immediately, but keep sticking to the evaporator.
Under this circumstance, please disconnect the power cord and
gently push the shovel to the rear of the ice-making cabinet, then
power on again, let the ice fall by itself before pressing POWER
button to restart the ice-making cycle.
Buzzing
noise
The voltage is lower
than recommended
value
PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS
Stop the ice maker, check if the
household voltage is consistent
with the recommended value.
ADD WATER
light on
There is no water
There is water, but
not enough
The conductivity of the
water used is too low
Do not use ultrapure water or
distilled water
Add water until it reaches MAX
position, press button for 2
times to restart
Indicator
lights on
display
are not on
No power/Under
"standby mode"
Internal damage
(Plug in the machine,) Press
button to enter "working mode"
Contact online customer
service
07
The ice collects
together
The ice of previous
cycles didn’t drop
Turn power o and let the
ice drop itself
Incapable of
making ice
The compressor
has no refrigerant
Compressor
damaged
Fan motor damaged
Solenoid broke down
Contact online customer
service
PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS
All indicators
twinkle
simultaneously
The water collecting
box is blocked by ice
Motor error
Micro switch damaged
Unplug the power, remove
the ice, then plug in power,
press the button (After
3 minutes, the machine will
restart automatically)
ICE FULL icon
doesn’t flash
despite full ice
basket
Sunlight interference
Set the machine away from
direct sunlight
ICE FULL icon
flashes despite
empty ice basket
There are foreign
objects on the infrared
sensor
Clean the surface of the
infrared sensor
Infrared sensor damaged
Contact online customer
service
Contact online customer
service
08
WARNING
1. If the power cord is damaged; it must be replaced by the manufacturer,
its service agent or a similarly qualified person in order to avoid a
hazard.
2. Fill with potable water only.
3. It is normal for the compressor and condenser surface to reach
temperatures between 70°C/158°F and 90°C/194°F during operation
and surrounding areas may be very hot.
4. Due to fast freezing, ice cubes may opaque. This is air trapped in the
water and will not aect quality or taste of ice.
5. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
6. Children should be supervised to ensure that they do not play with the
appliance.
7. Do not immerse in water.
CORRECT DISPOSAL OF
THIS PRODUCT
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device,
please use the return and collection systems or contact
the retailer where the product was purchased. They
can take this product for environmental safe recycling.
09
HOUSEHOLD USE ONLY
