Trace Elliot®
TE Pro 2x12 Cabinet
Owner’s Manual
- One ultra high end 12” coaxial driver paired with its 12” woofer-only compliment
- 8 Ohms; 1000W(rms) power handling capability (conservative)
- Dual plane bae with coaxial driver mounted on the slanted portion for superior HF dispersion
- Substantially reinforced 15mm Poplar plywood construction
- Extremely durable weatherproof two stage epoxy coating with added metal corners
- Dual parallel Neutrik Speakon® ¼” combination input jacks
- Top and side recessed handles for easier maneuverability
- Logo and foot/recesses on three sides allow for solid and attractive horizontal or vertical stacking with all
other TE Pro Series cabs
- Optional 3” heavy duty locking casters and screws included
- Top recess to accommodate the new TE-1200 bass amp head
- Removable protective front panel with magnetic retainers
- Newly designed crossover with improved overload protection
80.44 lbs (36.5 kg) w/o casters
84.63 lbs (38.4 kg) with casters
H = 30.3” (76.9 cm)
W = 21.0” (53.3 cm)
D (w/o casters) = 18.5” (46.9 cm)
D (with casters)= 22.5” (57.1 cm)
Trace Elliot 2X12
Tweeter Level
Red = Full Up
Blue = Half-way
Green = O
dB (Pascals)
Frequency (Hz)
Warranty registration and information for U.S. customers available online at
www.traceelliot.com/warranty
or use the QR tag below
