Trace Elliot®
TE Pro 4x10 Cabinet
Owner’s Manual
- Four proprietary custom 10” Neodymium drivers
- 8 Ohms; 1000W(rms) power handling capability (conservative)
- Trace Elliot HF compression tweeter
- Substantially reinforced 15mm Poplar plywood construction
- Extremely durable weatherproof two stage epoxy coating with added metal corners
- Dual parallel Neutrik Speakon® ¼” combination input jacks
- Top and side recessed handles for easier maneuverability
- Logo and foot/recesses on three sides allow for solid and attractive horizontal or vertical stacking
- Optional 3” heavy duty locking casters and screws included
- Top recess to accommodate the new TE-1200 bass amp head
- Removable protective front panel with magnetic retainers
- Newly designed crossover with improved overload protection
76.14 lbs (34.5 kg) w/o casters
80.33 lbs (36.4 kg) with casters
H = 30.3” (76.9 cm)
W = 23.0” (58.4 cm)
D (w/o casters) = 18.5” (46.9 cm)
D (with casters)= 22.5” (57.1 cm)
Tweeter Level
Red = Full Up
Blue = Half-way
Green = O
Trace Elliot 4X10
dB (Pascals)
Frequency (Hz)
Warranty registration and information for U.S. customers available online at
www.traceelliot.com/warranty
or use the QR tag below
