FIG. PART NO. DESCRIPTION OF PART
l 1 2344-0190
2 23-52-0160
* 3 22-l 6-0275
* 4 06-95-0075
5 23-66-l 125
6 06-95-5150
7 31-44-0630
8 06-55-0835
9 06-81-0473
10 06-95-0700
11 48-76-3008
12 44-40-0440
13 31-44-0640
*14 22-22-1330
l 15 06-81-1058
16 22-56-0391
17 06850200
18 12-99-0030
+I9 28-50-6201
+20 02-04-0845
21 31-55-0030
22 23-l 60456
23 18-30-0200
24 06-57-2975
25 31-05-0050
+ 26 16-30-0325
Brush Retaining Screw
Brush Spring
Carbon Brush
632 x 3/8 Trus Hd. Taptite Screw
Switch
Ground Screw
R.H. Half D Handle
8-32 Hex Nut
832 x 1” Pan Hd. Pozidriv Screw
8-32 x l/2” Pan Hd. Taptite Screw
Cord Set (1 ncludes Fig. No. 12)
Cord Nut
L.H. Half D Handle
Brush Holder Assembly
Insulated Field Bolt
Pin Housing Aay.
6x114 Rd. Hd. Type 2. Screw
Nameplate
Motor Housing
Ball Bearing
Coil Shield
Field Insulator
120 V. Field
8-32 Flexlock Hex Nut
Baffle
120 V. Armature (Incl. Fig. No. 27)
NO. REQ.
(21
(2)
(2)
(2)
(1)
(1)
(1)
(5)
(5)
(4)
(1)
(2)
(1)
(1)
(2)
(1)
(2)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
FIG. PART NO.
* 27 28840530
* 28 02-04-0911
* 29 28-28-0585
30 02-50-2110
31 32-75-l 601
32 45-36-0210
33 02-50-l 640
34 32-40-l 241
35 06-42-0800
36 36-66-2001
37 02-04-0640
38 28-14-0686
* 39 43-62-0875
40 02-04-l 560
41 34-80-2500
t 42 06-95-5270
It 43 06-95-5250
44 06-42-l 600
45 38-50-3651
46 06-75-3150
47 48-66-l 360
48 48-66-3280
49 48-66-4040
50 IO-985987
DESCRIPTION OF PART
Fan Assembly
Ball Bearing
Diaphragm
Needle Bearing
Spindle Gear
Spindle Gear Spacer
Needle Bearing
Intermediate Gear
Woodruff Key
Intermediate Shaft
Ball Bearing
Gear Case
Side Handle
Ball Bearing
Retaining Ring
&32x1-7/8 Fil. Hd. Sem
8-32x1-118 Fil. Hd. Sem
Woodruff Key
Spindle
1/4-20x1 L.H. Skt. Cap Screw
1/2”Chuck (Includes Fig. 48)
Chuck Key
Key Holder
Warning Label (Not Shown)
Omit For Canadian Tools
NO. REQ.
1:;
(I)
(1)
(1)
(I)
(I)
(I)
(1)
(1)
(I)
(I)
(1)
(1)
(1)
(2)
(1)
(I)
(1)
(1)
(1)
(1)
(1)
(1)
