ALT58LI401
ALT58B
ADT18
A18FPHD142
2
2
I
mportant!
It is essential that you read the instructions in this manual before
assembling, operating, and maintaining the product.
Subject to technical modifications.
ADT18
x 1 x 1 x 1
x 1
x 16 x 8
x 8 x 1 x 1
x 1
WARNING: To prevent personal injury or damage to underground utility equipment, consult local organisations for advice,
such as DIAL BEFORE YOU DIG (call 1100 or visit www.1100.com.au).
3
3
ADT18
x 1 x 1 x 1
x 1
x 16 x 8
x 8 x 1 x 1
x 1
4
4
LED INDCATOR DESCRIPTIONS
LED State Description
Status LED Solid red The kickback protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed.
Status LED Flashing red The overload protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed or
clear the auger from the hole more often.
Speed mode LED Solid green Indicates what speed the auger is spinning at.
● Speed 1 = 100 rpm
● Speed 2 = 150 rpm
● Speed 3 = 200 rpm
FWD/REV LED Solid green Indicates which direction the auger is spinning in.
A18FPHD142
x 2 x 2
x 1 x 1
x 1 x 1 x 1
x 1
x 1
x 16 x 8
x 8
5
5
LED INDCATOR DESCRIPTIONS
LED State Description
Status LED Solid red The kickback protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed.
Status LED Flashing red The overload protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed or
clear the auger from the hole more often.
Speed mode LED Solid green Indicates what speed the auger is spinning at.
● Speed 1 = 100 rpm
● Speed 2 = 150 rpm
● Speed 3 = 200 rpm
FWD/REV LED Solid green Indicates which direction the auger is spinning in.
A18FPHD142
x 2 x 2
x 1 x 1
x 1 x 1 x 1
x 1
x 1
x 16 x 8
x 8
TRIGGER RELEASE
LED INDICATOR
SPEED SELECTOR
KICKBACK BAR
HANDLE
TRIGGER SWITCH
FORWARD/REVERSE
BUTTON
GEAR BOX
QUICK LOCK PIN
AUGER
6
6
START
STOP
13
14
STARTING THE PRODUCT
OPERATING THE PRODUCT
12
INSTALLING THE HANDLE ASSEMBLIES
INSTALLING THE BATTERIES
8
7
7
START
STOP
19
17
11
16 10
STORING THE PRODUCT
CLEANING THE PRODUCT
INSTALLING THE AUGER
INSTALLING THE KICKBACK BARUSING THE KICKBACK BAR
8
8
1
1
2
2
1
2
3
4
x 1x 16
x 8x 8
5
6
7
INSTALLING THE HANDLE ASSEMBLIES
1. Locate the frame bolts, nuts and washers, as
well as the spanner and Torx wrench.
2. Facing the LED side of the powerhead, slide
in the left-hand handle assembly and align
the bolts holes (handle without the trigger
switch).
3. Facing the LED side of the powerhead, slide
in the right-hand handle assembly and align
the bolt holes.
4. Insert the bolts through the frame holes, with
a washer on either side of the frame. Install
and hand-tighten nuts on each bolt to keep
the handles in place.
5. Securely tighten the bolts using the Torx
wrench and spanner.
6. Connect the signal cable in the right handle
assembly to the signal cable from the
powerhead. Ensure that the pins are aligned
before connecting and securing.
7. Connect the signal cable in the right
handle assembly to the signal cable from
the powerhead. Ensure that the pins are
aligned before connecting and securing.
9
9
1
1
2
2
1
2
3
4
x 1x 16
x 8x 8
5
6
7
5. Securely tighten the bolts using the Torx
wrench and spanner.
6. Connect the signal cable in the right handle
assembly to the signal cable from the
powerhead. Ensure that the pins are aligned
before connecting and securing.
7. Connect the signal cable in the right
handle assembly to the signal cable from
the powerhead. Ensure that the pins are
aligned before connecting and securing.
10
10
1
2
3
4
click
INSTALLING THE AUGER
1
2
3
INSTALLING THE KICKBACK BAR
NOTE: When attaching the auger, align the holes
on the drive shaft and auger. This is most easily
completed by laying the product on the ground.
11
11
1
2
3
4
click
INSTALLING THE AUGER
1
2
3
NOTE: When attaching the auger, align the holes
on the drive shaft and auger. This is most easily
completed by laying the product on the ground.
12
12
1
2
click
1
2
INSTALLING THE BATTERIES
NOTE: The product requires two battery packs
to operate. For best performance use two FORCE
battery packs of the same capacity.
13
13
1
2
click
1
2
START
STOP
STARTING THE PRODUCT
14
14
click
1
2
OPERATING THE PRODUCT
NOTE: Always use the product with 2 hands.
Keep the product as close to the body as
possible to prevent injury and ensure kickback
protection can be activated if required.
15
15
click
1
2
3
4
5
1
2
NOTE: The product has 3 dierent auger
speeds — 100/150/200 RPM. The multiple
speeds can be beneficial in dierent scenarios.
In rocky soil a slower speed may help in
preventing kickback issues.
NOTE: Frequently remove dirt and debris
from the hole and auger during use to improve
digging eiciency.
16
16
3
4
2
1
STOP
USING THE KICKBACK BAR
NOTE: If the kickback protection is activated,
release trigger, allow the kickback bar to go
back to its natural position, and then restart the
product to continue digging.
17
17
3
4
2
1
CLEANING THE PRODUCT
STOP
18
18
6
5
NOTE: The auger can be cleaned with water
once it has been removed from the powerhead
and moved away to a safe distance from the
powerhead.
NOTE: Do not clean the powerhead with water.
Only clean it with a dry cloth or soft brush.
3
4
2
1
STORING THE PRODUCT
19
19
6
5
3
4
2
1
STORING THE PRODUCT
20
20
6
5
NOTE: Always store the product in a cool,
dry, well ventilated area.
BATTERY AND CHARGER
Model ADT18 A18FPHD142
Battery pack — A18FB4 x 2
Charger — BL1218 x 2
Compatible battery
packs
L1815R, L1820R, L1825R, L1830R, L1840R,
L1850R, L1860R, L1850R-X5, L1860B,
L1890R, L1860R-X5
Compatible
chargers
BL1218, BLK1218, AL1218, BL18DP,
BL18DP2-X5
INTENDED USE
The cordless digging tool is intended to be used only by adults who
have read and understood the instructions and warnings in this
manual and can be considered responsible for their actions.
The product is intended only for outdoor use in a well-ventilated
area. For safety reasons, the product must be adequately controlled
by a two-handed operation.
TECHNICAL DATA CORDLESS DIGGING TOOL ADT18/A18FPHD142
Voltage 36V d.c. (2 x 18 V)
RPM
Speed 3 200+-10% / min
Speed 2 150+-10% / min
Speed 1 100+-10% / min
Weight with battery pack (no auger) 10.5 kg
Weight with auger and two battery packs 15.05 kg
Auger size 250 mm
Maximum reach 600 mm
Vibration level (in accordance with AS/NZS 62841.1:2015+A1:2015)
Vibration
Left handle 0.858 m/s
2
/ K= 1.5 m/s
2
Right handle 1.022 m/s
2
/ K= 1.5 m/s
2
Noise emission level (in accordance with AS/NZS 62841.1:2015+A1:2015)
A-weighted sound power level at the operator’s position 74.8 dB (A)
Uncertainty of measurement 3 dB
A-weighted sound power level 85.8 dB (A)
Uncertainty of measurement 3 dB
WARNING!
The declared vibration total values and the declared noise emission values given in this instruction manual have been measured in
accordance with a standardised test and may be used to compare one tool with another. They may be used for a preliminary assessment
of exposure
The declared vibration and noise emission values represent the main applications of the tool. However, if the tool is used for dierent
applications, used with dierent accessories, or poorly maintained, the vibration and noise emission may dier. These conditions may
significantly increase the exposure levels over the total working period.
An estimation of the level of exposure to vibration and noise should take into account the times when the tool is turned o or when it is
running idle. These conditions may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration and noise, such as maintaining the tool and the
accessories, keeping the hands warm (in case of vibration), and organising work patterns.
21
21
6
5
BATTERY AND CHARGER
Model ADT18 A18FPHD142
Battery pack — A18FB4 x 2
Charger — BL1218 x 2
Compatible battery
packs
L1815R, L1820R, L1825R, L1830R, L1840R,
L1850R, L1860R, L1850R-X5, L1860B,
L1890R, L1860R-X5
Compatible
chargers
BL1218, BLK1218, AL1218, BL18DP,
BL18DP2-X5
INTENDED USE
The cordless digging tool is intended to be used only by adults who
have read and understood the instructions and warnings in this
manual and can be considered responsible for their actions.
The product is intended only for outdoor use in a well-ventilated
area. For safety reasons, the product must be adequately controlled
by a two-handed operation.
The product is intended for planting and digging holes for
applications such as:
■ planting of trees, shrubs, and flowers
■ cultivating and preparing soil
■ light duty fencing and posting
Do not use the product to dig holes of more than 250 mm in
diameter, as this can damage the product, can cause possible injury,
and may void your warranty.
Do not use the product for any other purpose.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings, instructions,
illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool’’ in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
TECHNICAL DATA CORDLESS DIGGING TOOL ADT18/A18FPHD142
Voltage 36V d.c. (2 x 18 V)
RPM
Speed 3 200+-10% / min
Speed 2 150+-10% / min
Speed 1 100+-10% / min
Weight with battery pack (no auger) 10.5 kg
Weight with auger and two battery packs 15.05 kg
Auger size 250 mm
Maximum reach 600 mm
Vibration level (in accordance with AS/NZS 62841.1:2015+A1:2015)
Vibration
Left handle 0.858 m/s
2
/ K= 1.5 m/s
2
Right handle 1.022 m/s
2
/ K= 1.5 m/s
2
Noise emission level (in accordance with AS/NZS 62841.1:2015+A1:2015)
A-weighted sound power level at the operator’s position 74.8 dB (A)
Uncertainty of measurement 3 dB
A-weighted sound power level 85.8 dB (A)
Uncertainty of measurement 3 dB
WARNING!
The declared vibration total values and the declared noise emission values given in this instruction manual have been measured in
accordance with a standardised test and may be used to compare one tool with another. They may be used for a preliminary assessment
of exposure
The declared vibration and noise emission values represent the main applications of the tool. However, if the tool is used for dierent
applications, used with dierent accessories, or poorly maintained, the vibration and noise emission may dier. These conditions may
significantly increase the exposure levels over the total working period.
An estimation of the level of exposure to vibration and noise should take into account the times when the tool is turned o or when it is
running idle. These conditions may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration and noise, such as maintaining the tool and the
accessories, keeping the hands warm (in case of vibration), and organising work patterns.
22
22
WORK AREA SAFETY
■ Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
■ Do not operate power tools in explosive atmospheres, such
as in the presence of flammable liquids, gases or dust. Power
tools create sparks, which may ignite the dust or fumes.
■ Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
■ Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
■ Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric shock if your body is earthed or
grounded.
■ Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
■ Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges, or moving parts. Damaged or
entangled cords increase the risk of electric shock.
■ When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
■ If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of
an RCD reduces the risk of electric shock.
PERSONAL SAFETY
■ Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while
you are tired or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating power
tools may result in serious personal injury.
■ Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
■ Prevent unintentional starting. Ensure the switch is in the
o-position before connecting to power source and/or
battery pack, picking up, or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools
that have the switch on invites accidents.
■ Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
■ Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
■ Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
■ Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, flush
with water. If liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause irritation or
burns.
■ Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable
behaviour resulting in fire, explosion or risk of injury.
■ Do not expose a battery pack or tool to fire or excessive
temperature. Exposure to fire or temperature above 130 °C
may cause explosion.
■ Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range specified
in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and
increase the risk of fire.,
SERVICE
■ Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
■ Never service damaged battery packs. Service of battery
packs should only be performed by the manufacturer or
authorised service providers.
ADDITIONAL GENERAL SAFETY WARNINGS
■ Some regions have regulations that restrict the use of the
product. Check with your local authority for advice.
■ Never allow children or people unfamiliar with the instructions
to use the product. Local regulations may restrict the age of
the operator.
■ Ensure before each use that all controls and safety devices
function correctly. Do not use the product if the “off” switch
does not stop the motor.
■ Wear full eye and hearing protection, strong sturdy gloves, as
well as head protection while operating the product; use a face
mask if operation is dusty.
■ Do not wear loose fitting clothing, short trousers, or jewellery
of any kind.
■ Secure long hair so it is above shoulder level to prevent
entanglement in moving parts.
■ Beware of thrown, flying, or falling objects; keep all bystanders,
children, and animals at least 15 m away from work area.
■ Do not operate in poor lighting. The operator requires a clear
view of the work area to identify potential hazards.
■ Use of hearing protection reduces the ability to hear warnings
(shouts or alarms). The operator must pay extra attention to
what is going on in the working area.
■ Operating similar tools nearby increases both the risk of hearing
injury and the potential for other persons to enter your working
area.
■ Keep firm footing and balance. Do not overreach. Overreaching
can result in loss of balance and can increase the risk of kickback.
■ Keep all parts of your body away from any moving part.
■ Inspect the product before each use. Check for correct operation
of all controls. Check for loose fasteners, make sure all guards,
and handles are properly and securely attached. Replace any
damaged parts before use.
■ If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
■ Do not let familiarity gained from frequent use of tools allow
you to become complacent and ignore tool safety principles.
A careless action can cause severe injury within a fraction of a
second.
POWER TOOL USE AND CARE
■ Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
■ Do not use the power tool if the switch does not turn it on
and o. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
■ Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories or storing power tools.
Such preventive safety measures reduce the risk of starting the
power tool accidentally.
■ Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
■ Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of parts
and any other condition that may aect the power tool’s
operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power
tools.
■ Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
■ Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of the
power tool for operations dierent from those intended could
result in a hazardous situation.
■ Keep handles and grasping surfaces dry, clean and free from
oil and grease. Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in unexpected
situations.
BATTERY TOOL USE AND CARE
■ Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery
pack.
■ Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of injury
and fire.
■ When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
23
23
■ Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, flush
with water. If liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause irritation or
burns.
■ Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable
behaviour resulting in fire, explosion or risk of injury.
■ Do not expose a battery pack or tool to fire or excessive
temperature. Exposure to fire or temperature above 130 °C
may cause explosion.
■ Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range specified
in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and
increase the risk of fire.,
SERVICE
■ Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
■ Never service damaged battery packs. Service of battery
packs should only be performed by the manufacturer or
authorised service providers.
ADDITIONAL GENERAL SAFETY WARNINGS
■ Some regions have regulations that restrict the use of the
product. Check with your local authority for advice.
■ Never allow children or people unfamiliar with the instructions
to use the product. Local regulations may restrict the age of
the operator.
■ Ensure before each use that all controls and safety devices
function correctly. Do not use the product if the “off” switch
does not stop the motor.
■ Wear full eye and hearing protection, strong sturdy gloves, as
well as head protection while operating the product; use a face
mask if operation is dusty.
■ Do not wear loose fitting clothing, short trousers, or jewellery
of any kind.
■ Secure long hair so it is above shoulder level to prevent
entanglement in moving parts.
■ Beware of thrown, flying, or falling objects; keep all bystanders,
children, and animals at least 15 m away from work area.
■ Do not operate in poor lighting. The operator requires a clear
view of the work area to identify potential hazards.
■ Use of hearing protection reduces the ability to hear warnings
(shouts or alarms). The operator must pay extra attention to
what is going on in the working area.
■ Operating similar tools nearby increases both the risk of hearing
injury and the potential for other persons to enter your working
area.
■ Keep firm footing and balance. Do not overreach. Overreaching
can result in loss of balance and can increase the risk of kickback.
■ Keep all parts of your body away from any moving part.
■ Inspect the product before each use. Check for correct operation
of all controls. Check for loose fasteners, make sure all guards,
and handles are properly and securely attached. Replace any
damaged parts before use.
■ Do not modify the product in any way or use parts and
accessories, which are not recommended by the manufacturer.
■ Do not allow familiarity with the product to make you careless. A
careless fraction of a second is sufficient to inflict serious injury.
■ Keep handles and grasping surfaces dry, clean, and free from
oil and grease. Slippery handles and grasping surfaces do not
allow for safe handling and control of the product in unexpected
situations.
WARNING! If the product is dropped, suers heavy impact,
or begins to vibrate abnormally, immediately stop the product
and inspect for damage or identify the cause of the vibration. Any
damage should be properly repaired or replaced by an authorised
service centre.
CORDLESS DIGGING TOOL SAFETY WARNINGS
WARNING! Maintain a firm grip on the handles with both hands
while using the auger. Keep the auger bit away from your body and
below waist level.
■ Replace the auger if it is cracked, bent, or damaged in any way.
Make sure that the auger is properly installed and securely
fastened. Failure to do so can cause serious injury.
■ Make sure that the handles are properly and securely attached.
■ Consider the environment in which you are working. Keep the
working area free from electric cables or underground utilities.
■ Use only the manufacturer’s replacement augers. Do not use
any other attachment.
■ Replace the auger bit immediately if there are any cracks or any
damage.
■ Do not touch the auger bit when the product is turned on.
■ If the auger bit jams, stop the product immediately.
■ Maintain a firm grip on both handles during operation.
■ Do not use the product with the handle above waist level to
avoid serious chest injuries when the product hits a hard object.
■ Always keep the handles dry and clean.
■ Ensure that all handles are properly fitted and are in good
condition.
■ Do not start using the product until you have a clear work area
and secure footing.
■ Do not modify the product in any way or use it to power any
attachments or devices not recommended by the manufacturer.
■ Before starting the product, make sure the bit is not contacting
any object.
■ Do not use the product when there is a possibility of
thunderstorm or lightning. Store the product safely indoors.
■ Turn off the product and remove the battery pack. Make sure all
moving parts have come to a complete stop:
● before servicing
● before leaving the product unattended
● before clearing a blockage
● before checking, cleaning, and working on the product
● before changing accessories
● after striking a foreign object
● whenever performing maintenance
● whenever the product starts to vibrate
■ Immediately turn off the product and remove the battery pack
in the event of an accident or breakdown. Do not operate the
product again until it has been fully checked by an authorised
service centre.
■ If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
■ Do not let familiarity gained from frequent use of tools allow
you to become complacent and ignore tool safety principles.
A careless action can cause severe injury within a fraction of a
second.
POWER TOOL USE AND CARE
■ Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
■ Do not use the power tool if the switch does not turn it on
and o. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
■ Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories or storing power tools.
Such preventive safety measures reduce the risk of starting the
power tool accidentally.
■ Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
■ Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of parts
and any other condition that may aect the power tool’s
operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power
tools.
■ Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
■ Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of the
power tool for operations dierent from those intended could
result in a hazardous situation.
■ Keep handles and grasping surfaces dry, clean and free from
oil and grease. Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in unexpected
situations.
BATTERY TOOL USE AND CARE
■ Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery
pack.
■ Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of injury
and fire.
■ When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
24
24
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of fire, personal injury, and
product damage due to a short circuit, never immerse the tool,
battery pack, or charger in fluid or allow fluid to flow inside them.
Corrosive or conductive fluids, such as seawater, certain industrial
chemicals, and bleach or bleach-containing products, etc., can cause
a short circuit.
ACTIVE KICKBACK AND OVERLOAD DISPLAY
The kickback feature is active when the dotted blue lights are
on. When the product detects tough soil or debris, the feature is
activated to protect the user. When the product stops, release the
trigger and then remove the product from the hole.
The overload function is activated when the red bar light is
highlighted. When the product stops, release the trigger and then
remove the product from the hole.
SWITCH POSITION
Display Description Location
REV Reverse Bottom
1 Speed 1 Middle
2 Speed 2 Top
NOTE: Turning o the kickback prrotection at any time is not
recommended. However, in the event that it is deactivated, the
product still has overload protection.
Ensure that the operator has a rm grip and solid stance when using
the product.
TRANSPORTATION AND STORAGE
■ Turn off the product, remove the battery pack, and allow the
product to cool down before storing or transporting.
■ Clean all foreign material from the product.
■ Do not store or transport the product with the battery pack
fitted. Remove the battery pack, and secure it separately. Store
the product in a cool, dry, and well-ventilated place that is
inaccessible to children. Keep the product away from corrosive
agents, such as garden chemicals and de-icing salts. Do not
store the product outdoors.
■ For transportation in vehicles, secure the product against
movement or falling to prevent injury to persons or damage to
the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery pack in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling when
transporting batteries by a third party. Ensure that no batteries can
come in contact with other batteries or conductive materials while
in transport by protecting exposed connectors with insulating, non-
conductive caps or tape. Do not transport batteries that are cracked
or leaking. Check with the forwarding company for further advice
MAINTENANCE
■ Use only original manufacturer’s replacement parts, accessories,
and attachments. Failure to do so can cause possible injury, can
contribute to poor performance, and may void your warranty.
■ Servicing requires extreme care and knowledge and should
be performed only by a qualified service technician. Have the
product serviced by an authorised service centre only.
WARNING! The auger bit is very sharp. To prevent personal
injury, exercise extreme caution when cleaning, fitting, or removing
the auger bit. Always wear protective gloves when performing
maintenance on the bit.
■ Turn off the product and remove the battery pack before
conducting any maintenance or cleaning work.
■ You may make adjustments and repairs described in this
manual. For other repairs, contact an authorised service centre.
■ After each use, clean the body and handles of the product with
a soft, dry cloth. Any part that is damaged should be properly
repaired or replaced by an authorised service centre.
■ Check all nuts, bolts, and screws before each use and at frequent
intervals for proper tightness to ensure that the product is in
safe working condition. Any part that is damaged should be
properly repaired or replaced by an authorised service centre.
■ Bring the product to an authorised service centre to replace
damaged or unreadable labels.
SYMBOLS ON THE PRODUCT
Read and understand all instructions before
operating the product. Follow all warnings and
safety instructions.
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Wear ear protection.
Wear eye protection.
Do not expose the product to rain or damp
condition.
Wear non-slip, heavy-duty protective gloves.
Wear non-slip safety footwear when using the
product.
Remove the battery pack before starting any work
on the product.
Beware of thrown or flying objects. Keep all
bystanders, especially children and pets, at least 15
m away from the operating area.
Keep feet and legs away from the auger.
Never operate the auger in areas with underground
electric, gas, water, or telephone lines.
Maintain a firm grip with both hands on the auger
during operation.
89
Guaranteed sound power level
Waste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.
SYMBOLS IN THIS MANUAL
Note
Warning
.
25
25
WARNING! The auger bit is very sharp. To prevent personal
injury, exercise extreme caution when cleaning, fitting, or removing
the auger bit. Always wear protective gloves when performing
maintenance on the bit.
■ Turn off the product and remove the battery pack before
conducting any maintenance or cleaning work.
■ You may make adjustments and repairs described in this
manual. For other repairs, contact an authorised service centre.
■ After each use, clean the body and handles of the product with
a soft, dry cloth. Any part that is damaged should be properly
repaired or replaced by an authorised service centre.
■ Check all nuts, bolts, and screws before each use and at frequent
intervals for proper tightness to ensure that the product is in
safe working condition. Any part that is damaged should be
properly repaired or replaced by an authorised service centre.
■ Bring the product to an authorised service centre to replace
damaged or unreadable labels.
SYMBOLS ON THE PRODUCT
Read and understand all instructions before
operating the product. Follow all warnings and
safety instructions.
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Wear ear protection.
Wear eye protection.
Do not expose the product to rain or damp
condition.
Wear non-slip, heavy-duty protective gloves.
Wear non-slip safety footwear when using the
product.
Remove the battery pack before starting any work
on the product.
Beware of thrown or flying objects. Keep all
bystanders, especially children and pets, at least 15
m away from the operating area.
Keep feet and legs away from the auger.
Never operate the auger in areas with underground
electric, gas, water, or telephone lines.
Maintain a firm grip with both hands on the auger
during operation.
89
Guaranteed sound power level
Waste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.
SYMBOLS IN THIS MANUAL
Note
Warning
.
This manual may feature third party recommendations or displays links to web sites, services, and content owned and
operated by third parties. The third party do not form part of this manual and are not under our control. By referencing or
displaying the third party, we do not in any way represent that we recommend or endorse the relevant third party, its goods,
or its services. We do not accept any responsibility in connection with any third party. If you engage with any such third
party features, we will not be liable under any circumstance for your engagement, and you do so entirely at your own risk.
AEG is a registered trademark used under
license from AB Electrolux (publ).
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
AEG is a registered trade mark used under
license from AB Electrolux (publ).
© 2020–21 Techtronic Cordless GP.
960087599-01
