Specifications:
Input power: DC 9~14.4V 2A
Output Power: 30 W
Speaker impedance: 2-8Ω
Frequency response: 20Hz-20kHz
Total harmonic distortion: <0.4%
SNR: >80dB
PFA100
Class T Amplifier
The PFA100 uses a Class-T audio amplifier
IC for low distortion and acoustically
accurate reproduction of music.
Tone/direct switching allows for
customized listening via separate bass and
treble adjustments — or the original signal
can be passed through without
enhancement.
The built-in loudspeaker protection circuit triggers when the amplifier is
turned on to protect speakers from high volume bursts of audio.
Over-voltage protection circuit shuts down the amplifier if input voltage
exceeds 14.4 V DC.
State of the art design using surface mount components and advanced
engineering for proven performance, reduced signal interference, and long
operational life.
Front Inputs: 3.5mm (1/8”)
Rear Outputs: Speaker, RCA L/R, ¼” Mic
