SERVICE MANUAL
E
CHARCOAL STOVE
MODEL NO.: L250
NOTE: This is one of the basic models. The shape and
specifications of the item are subject to change.
1
Troubleshooting
1. The heater doesn't turn on with the power switch.
①The POWER button on, the remote is off.
Press the POWER button on the remote.
②The circuit breaker has tripped.
Too many appliances are on this circuit. Be sure that the electrical supply for this
unit is an individual circuit.
③The heater is unplugged from the wall outlet.
Make sure the power cord is plugged into a functioning and properly grounded 15
Amp 120V AC electrical outlet.
④
The power cord or power plug is damaged.
Contact a qualified electrician to replace the power cord.
⑤The power outlet for the power plug prong is loose.
Check the power outlet and replace it with a new one.
⑥Loose wiring.
Check all wiring for loose connections. Contact a qualified electrician.
⑦
Mainboard Breaks
There is a problem with the mainboard, replace the mainboard
There are two
sets of
heating here,
and if one
falls off, one
set will not be
heated.
Common Heated End
Dropping this end will cause both
the fan and the heating to stop
2
2. The heater is on, but there is no flame or low flame intensity.
①The heater switches are on, but the flame power switch is not on.
Turn on the flame power switch.
②The flame adjusting knob is at low setting.
Turn the knob to the maximum setting.
③
Loose wiring.
Check all wiring for loose connections. Contact a qualified electrician.
3. There is no flame.
①
The flame element is not attached to the motor.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
②The rotation motor is defective.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
4. Excessive noise in the lower portion of the heater.
①The flame element isn't seated properly.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
②The motor is defective.
Contact us via Amazon Message or call customer service number:213-4467172 or
661-4358826.
5. Heater system doesn't function.
①
The power switch is off.
Turn the power switch to the "ON" position.
②The heater system is overheated.
Maybe the heater is covered, or the air inlet or outlet is blocked; remove the clothes
or the blockage, turn off the heater by pressing the remote’s power switch and
unplug it. Wait for 10 minutes, and then turn the heater on again.
3
③Loose wiring.
Check all wiring for loose connections. Contact a qualified electrician.
④The air inlet or air outlet is blocked completely.
Leave adequate space around the unit. Remove the blockage that is left on or in
front of the air outlet.
6. "HEAT" button has been turned on, but there is no airflow.
①The heater system is overheated. Temperature limit thermostat is switched off.
Check the air inlet and outlet. Turn off the heater by pressing the remote’s power
switch and unplug it. Wait for 10 minutes, and then turn on the heater again.
②
The fan motor is defective.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
③The fan blower is broken.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
④The "POWER" and the "HEAT” switches are not turned on.
Turn on these two switches.
7. There is no difference between the two heats
Check both ends of heating 1 and 2, one of them is loose or fell off
8. The fan runs, but no heat is coming out.
①
Loose wiring.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
②Bad heating element.
Contact us via Amazon Message or call customer service number: 213-4467172 or
661-4358826.
③Built-up dirt on the fans.
Clean all fans.
④
The heater fan is defective.
4
Contact us via Amazon Message or call customer service number:213-4467172 or
661-4358826.
9. The remote control does not work.
①The battery is not properly installed.
Make sure the battery is properly installed. Remove the transparent insulating piece
of the battery before using.
②The remote control doesn’t point to the right position.
Aim the remote control at the receiver (at the middle of the fireplace).
③
There is an obstacle in front of the machine.
Remove the objects that may be in the way. Items between the remote control and
its receiver can block the signal.
④Press the buttons on the remote control too quickly.
Don't press the buttons too quickly. Give the unit enough time to respond to your
commands.
10. There is an odor coming from the heater.
The heater may emit a slight, harmless odor when first used. This is a normal
condition caused by the initial heating of the internal parts and will not occur again.
NOTE: For most functional problems, you can unplug the unit, wait for 10
minutes, and plug it again; the machine will reset to the initial status (default
settings).
If the problem is still not solved, please contact us via Amazon Message or call
customer service number: 213-4467172 or 661-4358826.
