KODAK LUMA 150
PORTABLE WIRELESS PROJECTOR
User Manual
3.9"H | 3.9"W | 0.87"D (9.9 cm | 9.9cm | 2.2 cm)
Please read all directions before using the product and retain this guide for reference.
2
INTRODUCTION
SPECIFICATIONS
BOX CONTENTS
SAFETY PRECAUTIONS
PRODUCT OVERVIEW
CHARGING THE PROJECTOR
USING THE PROJECTOR TO CHARGE DEVICES
USING THE AUDIO OUT JACK
POWERING THE PROJECTOR ON/OFF
CONTROLLING PHOTO PLAYBACK
CONTROLLING VIDEO PLAYBACK
SCREEN MIRRORING
WIRELESS SETTINGS AND SOFTWARE UPDATES
ADJUSTING FOCUS
ADJUSTING VOLUME
CONNECT YOUR DEVICE
VIEWING DISTANCE AND SCREEN SIZE
USING THE PROJECTOR
CUSTOMER SERVICE
WARRANTY
CONTENTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
3
3
3
4
5
5
5
6
6
6
7
9
9
10
11
11
11
3
Thank you for purchasing the KODAK LUMA 150 Portable Wireless Projector. This User Guide is intended
to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to
the user. Any use that does not conform to the guidelines described in this User Guide may void the
limited warranty.
Please read all directions before using the product and retain this guide for reference. This product is
intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
1. INTRODUCTION
Rated Input: 5V, 2.4A
Rated Output: 5V, 1.0A
KODAK LUMA 150 Portable Wireless Projector
HDMI®-to-HDMI® Cable
USB Charging Cable
User Guide
2. SPECIFICATIONS
• Do not attempt to disassemble this device for any reason.
• Do not store the projector in areas where it will be exposed to high temperatures, humidity, or direct
sunlight. Exposure to any or all of these could permanently damage the projector.
• Never handle the projector with damp or wet hands. This could damage the projector or create the
risk of electric shock.
• Keep the projector out of the reach of children.
• Never point the projector at someone else’s face or look directly into the projector light. The light is
bright and could cause damage.
• Do not use products such as alcohol, gasoline, diluent, or any other organic solvent when cleaning or
attempting to clean this product.
• Do not use this device in an environment where it will be exposed to heavy dust or humidity/moisture.
• Never drop or shake the projector, as this could cause it to malfunction or permanently damage the
inside parts.
• Do not use the projector while bathing or in a shower.
• Do not place or store the projector where it can fall or be pulled into a tub or sink.
3. BOX CONTENTS
4. SAFETY PRECAUTIONS
4
• Do not place, drop, or submerge the projector in water or any other liquid.
• If the projector somehow falls into water despite you taking all of the above precautions, please do
not reach into the water to retrieve it. Unplug it immediately and then retrieve it.
• Take care that objects do not fall and liquids are not spilled onto the projector.
5. PRODUCT OVERVIEW
1. Lens
2. Speaker
3. Return
4.
5. Right / FF / Volume +
6. Left / REW / Volume -
7. Volume Switch
8. Power Indicator
9. Audio Output (3.5mm)
10. USB Input / Power Out
11. HDMI Input
12. DC Input (5V/2.4A)
13. Reset
1. Power
2. Focus Wheel
3. Air Inlet
4. Tripod Dock
5. Rating Label
6. Non-slip Mat
7. MicroSD Slot
8. Speaker
5
Before using the projector, connect it to a charger, plug the USB end of the charging cable into a wall
charger or similar power source and allow it to fully charge. This process should take about three hours.
Always use the original charging cable that was provided to ensure proper charging, and make sure the
power rating of the adapter for the charging cable is ≤ 2.4A.
The four indicator lights will show the approximate battery capacity, with each light representing
approximately 25% battery life. One indicator light lit means the battery is at less than 25% and should
be charged soon. Two lights means the battery percentage is between 25% and 49%, and so on. Four
lights lit means that battery is fully charged.
When the projector is powered on, you can connect the charging cable of your device to the USB
port of the projector, and it will operate as a mobile power bank to charge your electronic devices. The
power output is 5V/1A.
6. CHARGING THE PROJECTOR
7. USING THE PROJECTOR TO CHARGE DEVICES
While the projector does include built-in speakers for regular use, you can also connect either
headphones or a portable speaker to the 3.5mm AUDIO OUT jack as shown in the below image.
8. USING THE AUDIO OUT JACK
6
powered on, the projector’s main menu will display the remaining battery percentage.
your device. In slideshow mode, each photo will automatically display in the order they are stored.
projector to bring up the control menu. Then you may perform the following actions:
1. Pause the slideshow: tap the center circle button. Tap it again to resume.
2. Play next image: tap the > button.
3. Return to previous image: tap the < button.
on top of the projector to bring up the control menu. Then you may perform the following actions:
1. Pause video: tap the center circle button. Tap it again to resume.
2. Fast forward: tap the > button. To increase the fast forward speed, tap the button again. Each press
will increase the speed in this order: 2x, 4x, 8x, 16x.
3. Rewind: tap the < button. To increase the rewind speed, tap the button again. Each press will
increase the speed in this order: 2x, 4x, 8x, 16x.
4.
the button a second time to exit out to the main menu completely.
10. CONTROLLING PHOTO PLAYBACK
11. CONTROLLING VIDEO PLAYBACK
7
This projector allows you to share the screen from your compatible iOS, Android™, or Windows® 10
device. Follow these steps to activate the screen sharing function:
1. Open the third menu option, “Wireless.” The name of the device and the password to connect to it
2. Activate your device’s screen mirroring software and let it scan for devices.
a. To activate screen mirroring on your Android™ device:
expanded view, and then swipe left (if necessary) and touch the
“SmartView” icon to activate screen sharing.
NOTE: Check your device settings for the screen casting/screen mirroring
options. The name of the function may vary by device model and service
carrier. Other names used may include, “Cast,” or “Screen Mirroring,” as well
as “Smart View”. All devices must be running at least Android version 4.1.2.
b. To activate screen mirroring on your iOS device:
i. Swipe up to reveal the Control Center and tap the “AirPlay Mirroring”
button.
c. To activate screen mirroring on your Windows® 10 device:
i. From the start menu, select “Settings.”
ii. In the Settings menu, select “Devices.”
iii. On the left side of the Devices menu, select “Connected Devices,” and
then click “Add a Device.”
3. Select the projector from the list of compatible devices.
4. If the system prompts you to enter a password, enter “12345678.”
5. When connected, the screen from your device will be mirrored to the projector, so you can then
use your device to play videos, share images, etc.
12. SCREEN MIRRORING
8
13. WIRELESS SETTINGS AND SOFTWARE UPGRADES
To adjust the wireless settings and/or upgrade the software on this projector, you’ll need to connect to
the projector’s hotspot while it is in wireless mode and proceed from there. Follow these instructions to
connect to the hotspot:
1. Turn on the projector and select the third menu option, “Wireless”. The name of the device and the
NOTE: You can change the wireless hotspot password from the wireless settings menu that can be
accessed by following these steps.
2. Open your device’s wireless settings, and you should see a secure wireless network with the
3. Open your device’s internet browser and enter the following URL to adjust the settings: 192.168.49.1
9
14. ADJUSTING FOCUS
4. The browser should display two options, to adjust the wireless access points, or to adjust the
settings. Software upgrades can be found and installed from the Settings menu. You can also adjust
the projector’s hotspot password and other advanced options from this menu.
If the image on the screen appears fuzzy or unfocused when you turn the projector on, use the focus
wheel on the side to correct the image. Turn the wheel up or down until the image appears sharp and
clear.
NOTE:
button to return to the main menu. If the main menu graphics appear clear and the image is still fuzzy,
the problem may be the image or video quality.
During playback, if you need to adjust the volume, touch the button, and the screen will display the
volume bar.
Once the volume bar appears on screen, use the < and > buttons to adjust the volume accordingly.
15. ADJUSTING VOLUME
10
A. USB Drives or Micro SD Cards
To access photos or videos stored on any USB drive or micro SD card, simply insert the drive or card
B. HDMI® Compatible Devices
If you’re using an HDMI compatible device, such as a laptop, personal computer, smartphone, tablet, or
video game console, connect an HDMI cable from the device to your projector. To make things a little
easier, we’ve compiled this table of devices and adapters for your convenience.
Please note, if you connect an HDMI device as well as a micro SD card or USB drive, the HDMI device
will take precedence and you will need to disconnect it to access the other connected sources.
16. CONNECT YOUR DEVICES
1 Devices with HDMI port
2 Devices with mini HDMI port
3 Devices with micro HDMI port
4 iOS devices with lightning port
5
(USB type C) port
6
(USB type C) port
HDMI to HDMI cable (included)
Mini HDMI to HDMI adapter HDMI to HDMI cable (included)
Mini HDMI to HDMI adapter HDMI to HDMI cable
Lightning digital AV adapter
HDMI to HDMI cable
HDMI to HDMI cable
USB type C to HDMI cable
11
See the chart below to see how far away to place your projector from the display area to create the
intended screen size.
1. Turn the projector on and connect your device.
2. Optionally, connect a speaker or headphones to the AUDIO OUT jack.
3. Use the touch menu on the top of the projector to navigate to either “Images” or “Videos” from the
both sections.
4. If you want to use the screen mirroring option, navigate to “Wireless” from the main menu and follow
the instructions on page 7 to connect your device.
5. Turn the focus wheel to make sure the image is crisp and clear as you view your videos, images, or
mirrored screen.
6. Enjoy!
Should you experience any problems with your product, please contact us before returning the item to
the place of purchase. We’re here to help!
U.S. Support: kodak@camarketing.com
International Support: kodakintl@camarketing.com
17. VIEWING DISTANCE AND SCREEN SIZE
18. USING THE PROJECTOR
19. CUSTOMER SERVICE
12
20. WARRANTY
LIMITED WARRANTY TO ORIGINAL CONSUMER
This KODAK LUMA 150 Portable Wireless Projector (“Product”), including any accessories included in
the original packaging, as supplied and distributed new by an authorized retailer is warranted by
C&A Marketing, Inc. (the “Company”) to the original consumer purchaser only, against certain
defects in material and workmanship (“Warranty”) as follows:
To receive Warranty service, the original consumer purchaser must contact the Company or its
authorized service provider for problem determination and service procedures. Proof of purchase
in the form of a bill of sale or receipted invoice, evidencing that the Product is within the applicable
Warranty period(s), MUST be presented to the Company or its authorized service provider in order to
obtain the requested service.
Service options, parts availability, and response times may vary and may change at any time. In
accordance with applicable law, the Company may require that you furnish additional documents
and/or comply with registration requirements before receiving warranty service. Please contact our
customer service for details on obtaining warranty service:
Shipping expenses to the Company’s Return Facility are not covered by this warranty, and must be paid
by the consumer. The consumer likewise bears all risk of loss or further damage to the Product until
delivery to said facility.
EXCLUSIONS AND LIMITATIONS The Company warrants the Product against defects in materials
and workmanship under normal use for a period of ONE (1) YEAR from the date of retail purchase by
the original end-user purchaser (“Warranty Period”). If a hardware defect arises and a valid claim is
received within the Warranty Period, the Company, at its sole option and to the extent permitted by
law, will either (1) repair the Product defect at no charge, using new or refurbished replacement parts,
(2) exchange the Product with a Product that is new or which has been manufactured from new or
serviceable used parts and is at least functionally equivalent to the original device, or (3) refund the
purchase price of the Product.
A replacement Product or part thereof shall enjoy the warranty of the original Product for the remainder
of the Warranty Period, or ninety (90) days from the date of replacement or repair, whichever provides
you longer protection. When a Product or part is exchanged, any replacement item becomes your
property, while the replaced item becomes the Company’s property. Refunds can only be given if the
original Product is returned.
This Warranty does not apply to:
(a) Any non-KODAK LUMA 150 Portable Wireless Projector product, hardware or software, even if
packaged or sold with the Product;
(b) Damage caused by use with non-KODAK LUMA 150 Portable Wireless Projector products;
(d) Damage caused by operating the Product outside the permitted or intended uses described by the
Company;
13
(e) Damage caused by third party services;
permission of the Company;
(g) Consumable parts, such as batteries, fuses and bulbs;
(h) Cosmetic damage; or
(i) If any KODAK LUMA 150 Portable Wireless Projector serial number has been removed or defaced.
This Warranty is valid only in the country where the consumer purchased the Product, and only applies
to Products purchased and serviced in that country.
The Company does not warrant that the operation of the Product will be uninterrupted or error-free.
The Company is not responsible for damage arising from your failure to follow instructions relating to
its use.
NOTWITHSTANDING ANYTHING TO THE CONTRARY AND TO THE MAXIMUM EXTENT PERMITTED BY
CONVENIENCE AND THE COMPANY AND ITS LICENSORS AND SUPPLIERS EXPRESSLY DISCLAIM
ALL WARRANTIES AND CONDITIONS, WHETHER EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING
THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, QUIET
NOT GUARANTEE ANY SPECIFIC RESULTS FROM THE USE OF THE PRODUCT, OR THAT THE COMPANY
WILL CONTINUE TO OFFER OR MAKE AVAILABLE THE PRODUCT FOR ANY PARTICULAR LENGTH
OF TIME. THE COMPANY FURTHER DISCLAIMS ALL WARRANTIES AFTER THE EXPRESS WARRANTY
PERIOD STATED ABOVE.
YOU USE THE PRODUCT AT YOUR OWN DISCRETION AND RISK. YOU WILL BE SOLELY RESPONSIBLE
FOR (AND THE COMPANY DISCLAIMS) ANY AND ALL LOSS, LIABILITY, OR DAMAGES RESULTING FROM
YOUR USE OF THE PRODUCT.
NO ADVICE OR INFORMATION, WHETHER ORAL OR WRITTEN, OBTAINED BY YOU FROM THE
COMPANY OR THROUGH ITS AUTHORIZED SERVICE PROVIDERS SHALL CREATE ANY WARRANTY.
IN NO EVENT WILL THE COMPANY’S TOTAL CUMULATIVE LIABILITY ARISING FROM OR RELATED TO
THE PRODUCT, WHETHER IN CONTRACT OR TORT OR OTHERWISE EXCEED THE FEES ACTUALLY PAID
BY YOU TO THE COMPANY OR ANY OF ITS AUTHORIZED RESELLERS FOR THE PRODUCT AT ISSUE
IN THE LAST YEAR FROM YOUR PURCHASE. THIS LIMITATION IS CUMULATIVE AND WILL NOT BE
INCREASED BY THE EXISTENCE OF MORE THAN ONE INCIDENT OR CLAIM. THE COMPANY DISCLAIMS
ALL LIABILITY OF ANY KIND OF ITS LICENSORS AND SUPPLIERS. IN NO EVENT WILL THE COMPANY
OR ITS LICENSORS, MANUFACTURERS AND SUPPLIERS BE LIABLE FOR ANY INCIDENTAL, DIRECT,
INDIRECT, SPECIAL, PUNITIVE OR CONSEQUENTIAL 29 DAMAGES (SUCH AS, BUT NOT LIMITED TO,
DAMAGES FOR LOSS OF PROFIT
S, BUSINESS, SAVINGS, DATA OR RECORDS) CAUSED BY THE USE,
MISUSE OR INABILITY TO USE THE PRODUCT.
Nothing in these terms shall attempt to exclude liability that cannot be excluded under applicable
law. Some countries, states or provinces do not allow the exclusion or limitation of incidental or
consequential damages or allow limitations on warranties, so certain limitations or exclusions may not
state to state or province to province. Contact your authorized retailer to determine if another warranty
applies.
Kodak does NOT manufacture this Product or provide any Warranty or support.
14
www.kodakphotoplus.com
The Kodak trademark, logo, and trade dress are used under license from Kodak.
Android is a trademark of Google Inc.
Lightning is a trademark of Apple Inc. in the U.S. and other countries.
iOS is a trademark of Cisco in the U.S. and other countries and is used under license.
Windows is a trademark of Microsoft Corporation and other countries.
All other products, brand names, company names, and logos are trademarks of their respective owners, used merely to identify their
respective products, and are not meant to connote any sponsorship, endorsement or approval.
Distributed by: C&A Marketing, Inc., 114 Tived Lane East, Edison, NJ 08837, USA
C&A Marketing UK LTD, 167 Hermitage Road, Crusader Industrial Estate, London N4 1LZ, UK
© 2018. All Rights Reserved. Made in China.
