EasyCut 40/18V P4A Art. 14733
EN Operator’s manual
Battery Hedge Trimmer
EN
2
3
O1
C
Y
>
O2
å
X
Y
O3
å
O4
€
∑
ç
«
O5 O6
O7 O8
1
N
4
3
C Y
>
2
5
EN Battery Hedge Trimmer
1. SAFETY .............................................. 8
2. OPERATION ...........................................10
3. MAINTENANCE ........................................11
4. STORAGE ............................................11
5. TROUBLESHOOTING ...................................12
6. TECHNICAL DATA ......................................12
7. ACCESSORIES ........................................12
8. SERVICE / WARRANTY ................................... 12
Translation of the original instructions.
This product is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities,
orlack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the product by a person
responsible for their safety. Children should be supervised to ensure that
they do not play with the product. The use of this product by young people
under the age of 16 is not recommended.
Intended use:
The GARDENA Hedge Trimmer is intended to cut hedges, shrubs and
grass coverings in private domestic gardens and allotments.
The product is not intended for long term use.
DANGER! Risk of physical injury!
v Do not use the product to cut lawns / lawn edges, to chop up
material or to make compost.
1. SAFETY
IMPORTANT!
Read the operator’s manual carefully before use and keep for future
reference.
DE
8
EN
Symbols on the product:
Read operator’s manual.
Danger – Keep hands away from blade.
Do not expose to rain.
For the charger:
Remove plug from the mains immediately if the cable
is damaged or cut.
Wear eye and ear protection.
Remove the Battery before cleaning or maintenance.
General safety warnings
General machine safety warnings
WARNING!
Read all safety warnings, instructions, illustrations and specifications
provided with this machine. Failure to follow the warnings and instructions may
result in electric shock, fire and / or serious injury.
Save all warnings and instructions for future reference.
The term “machine” in the warnings refers to your mains operated (corded)
machine or battery operated (cordless) machine.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate machines in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust.
Machines create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a machine.
Distractions can cause you to lose control.
2) Electrical safety
a) Machine plugs must match the outlet. Never modify the plug in any
way. Do not use any adaptor plugs with earthed (grounded) machines.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose machines to rain or wet conditions.
Water entering a machine will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the machine. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a machine outdoors, use an extension cord suitable
for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a machine in a damp location is unavoidable, use
aresidual current device (RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a machine. Do not use a machine while you are tired
or under the influence of drugs, alcohol or medication. A moment of inat-
tention while operating machines may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the OFF-posi-
tion before connecting to power source and / or battery pack, picking up
or carrying the machine.
Carrying machines with your finger on the switch or energising machines that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the machine on.
A wrench or a key left attached to a rotating part of the machines may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times.
This enables better control of the machine in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of machines allow
you to become complacent and ignore machine safety principles.
A careless action can cause severe injury within a fraction of a second.
4) Machine use and care
a) Do not force the machine. Use the correct machine for your appli-
cation. The correct machine will do the job better and safer at the rate for which
it was designed.
b) Do not use the machine if the switch does not turn it on and off.
Any machine that cannot be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and / or the battery pack
from the machine before making any adjustments, changing acces-
sories, or storing machines. Such preventive safety measures reduce
the risk of starting the machine accidentally.
d) Store idle machines out of the reach of children and do not allow
persons unfamiliar with the machine or these instructions to operate the
machine. Machines are dangerous in the hands of untrained users.
e) Maintain machines. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect
the machine’s operation. If damaged, have the machine repaired before
use. Many accidents are caused by poorly maintained machines.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the machine, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the machine for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe handling
and control of the machine in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer.
A charger that is suitable for one type of battery pack may create a risk of fire
when used with another battery pack.
b) Use machines only with specifically designated battery packs.
Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behavior resulting in
fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack
or tool outside the temperature range specified in the instructions.
Charging improperly or at temperatures outside the specified range may damage
the battery and increase the risk of fire.
6) Service
a) Have your machine serviced by a qualified repair person using only
identical replacement parts.
This will ensure that the safety of the machine is maintained.
b) Never service damaged battery packs. Service of battery packs should
only be performed by the manufacturer or authorised service providers.
Hedge trimmer safety warnings
a) Keep all parts of the body away from the blade. Do not remove cut
material or hold material to be cut when blades are moving. Blades con-
tinue to move after the switch is turned off. A moment of inattention while
operating the hedge trimmer may result in serious personal injury.
b) Carry the hedge trimmer by the handle with the blade stopped and
taking care not to operate any power switch.
Proper carrying of the hedge trimmer will decrease the risk of inadvertent starting
and resultant personal injury from the blades.
c) When transporting or storing the hedge trimmer, always fit the blade
cover. Proper handling of the hedge trimmer will decrease the risk of personal
injury from the blades.
d) When clearing jammed material or servicing the unit, make sure all
power switches are off and the battery pack is removed or disconnected.
Unexpected actuation of the hedge trimmer while clearing jammed material or
servicing may result in serious personal injury.
e) Hold the hedge trimmer by insulated gripping surfaces only, because
the blade may contact hidden wiring.
Blades contacting a “live" wire may make exposed metal parts of the hedge
trimmer "live" and could give the operator an electric shock.
f) Keep all power cords and cables away from cutting area.
Power cords or cables may be hidden in hedges or bushes and can be acciden-
tally cut by the blade.
g) Do not use the hedge trimmer in bad weather conditions, especially
when there is a risk of lightning.
This decreases the risk of being struck by lightning.
EN
9
Search hedges and bushes for hidden objects (e.g. wire fences and hidden
wires).
The use of a residual current device (RCD) with a trip current of 30 mA or less is
recommended.
Hold the hedge trimmer with both hands on both handles.
The hedge trimmer is intended for use when the user is standing on the ground
and not on a ladder or other unstable surface.
Additional safety warnings
Battery safety
Read all the safety and general instructions.
Failure to observe the safety and general instructions may result in electric shock,
fire and / or serious injury.
Store these instructions in a safe place.
Only use the charger if you can fully evaluate all functions and carry them out
without restrictions, or if you have received corresponding instructions.
v Supervise children during use, cleaning and maintenance.
This will ensure that children do not play with the charger.
v Charge only lithium-ion batteries of the POWER FOR ALL system type
PBA 18V with a capacity of 1.5 Ah or more (5 battery cells or more). The
battery voltage must match the battery charging voltage of the charger.
Do not charge any non rechargeable batteries.
Otherwise there is a risk of fire and explosion.
v
Do not expose the charger to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
v Keep the charger clean. Dirt poses a risk of electric shock.
v Always check the charger, cable and plug before use. Stop using the
charger if you discover any damage. Do not open the charger yourself,
and have it repaired only by a qualified specialist using only original
replacement parts.
Damaged chargers, cables and plugs increase the risk of electric shock.
v Do not operate the charger on an easily ignited surface (e. g. paper,
textiles, etc.) or in a flammable environment.
There is a risk of fire due to the charger heating up during operation.
v In order to avoid safety hazards, if the power supply cord needs to be
replaced, this must be done by GARDENA or by a customer service centre that is
authorised to repair GARDENA power tools.
v Do not operate the product while it is charging.
Products sold in GB only: Your product is fitted with an BS 1363/A approved
electric plug with internal fuse (ASTA approved to BS 1362). If the plug is not suit-
able for your socket outlets, it should be cut off and an appropriate plug fitted in
its place by an authorised customer service agent. The replacement plug should
have the same fuse rating as the original plug. The severed plug must be dis-
posed of to avoid a possible shock hazard and should never be inserted into a
mains socket elsewhere.
v These safety warnings apply only for lithium-ion batteries of the
POWER FOR ALL system PBA 18V.
v Only use the battery with products of the POWER FOR ALL system
manufacturers. This is the only way in which you can protect the battery against
dangerous overload.
v Recharge only with the charger specified by the manufacturer.
A charger that is suitable for one type of battery pack may create a risk of fire
when used with another battery pack.
v The battery is supplied partially charged.
To ensure full battery capacity, fully charge the battery in the charger before using
your power tool for the first time.
v Keep battery packs out of the reach of children.
v Do not open the battery. There is a risk of short-circuiting.
v In case of damage and improper use of the battery, vapours may be
emitted. The battery can set alight or explode.
Ensure the area is well ventilated and seek medical attention should you experi-
ence any adverse effects. The vapours may irritate the respiratory system.
v If used incorrectly or if the battery is damaged, flammable liquid may
be ejected from the battery. Contact with this liquid should be avoided. If
contact accidentally occurs, rinse off with water. If the liquid comes into
contact with your eyes, seek additional medical attention.
Liquid ejected from the battery may cause irritation or burns.
v If the battery is damaged liquid can be ejected and cover nearby sur-
faces. Check affected parts. Clean these parts or change them if necessary.
v Do not short-circuit the battery pack. When the battery pack is not in
use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a connection
from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
v The battery contacts can be hot after use. Be careful of the hot con-
tacts when remove the battery.
v The battery can be damaged by pointed objects such as nails or
screwdrivers or by force applied externally. An internal short circuit may
occur, causing the battery to burn, smoke, explode or overheat.
v Never service damaged battery packs.
Service of battery packs should only be performed by the manufacturer or
authorized service providers.
v
Protect the battery against heat, e. g. against continuous intense
sunlight, fire, dirt, water and moisture.
There is a risk of explosion and short-circuiting.
v Only operate and store the battery at an ambient temperature between
– 20 °C and + 50 °C. Do not leave the battery in your car in the summer, for exam-
ple. At temperatures of < 0 °C some devices may experience a loss of power.
v Only charge the battery at an ambient temperature which is between
0°C and + 45 °C. Charging outside of this temperature range can increase the
risk of damage to the battery and pose a fire hazard.
v After use, allow the battery to cool down for at least 30 minutes before
charging or storing.
Electrical safety
DANGER! Cardiac arrest!
This product makes an electromagnetic field while it operates. This field
may under some conditions interfere with active or passive medical
implants. To decrease the risk of conditions that can possibly injure or
kill, we recommend persons with medical implants to speak with their
physician and the medical implant manufacturer before you operate the
product.
Remove battery in case of emergency.
Only use the battery product between – 10 °C and 40 °C.
Thoroughly inspect the area where the product is to be used and remove all wires
and other foreign objects.
In case of an unintended start (e.g. due to a welded switch) disconnect the
battery immediately from device and let the product repaired by the GARDENA
service.
Disconnect the product from the mains and disconnect the battery if the product
starts to vibrate abnormally. Check immediately. Excessive vibration can cause
injury.
Do not use the product near water.
Do not operate next to swimming pools or garden ponds.
Protect the electrical contacts of the battery from moisture.
Personal safety
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There is also a risk that the polybag
can suffocate toddlers. Keep toddlers away when you assemble the
product.
Know how to stop the product quickly in an emergency.
Avoid contact with the oil of the blade, allergic reaction is possible.
Only work in the daylight or when visibility is good.
Check your product before each use. Always visually inspect your Hedge Trimmer
before each use. Check that the ventilation slots are not obstructed in any way.
If the product gets hot whilst in operation, let it cool down before storage.
Warning! When wearing hearing protection, and due to the noise produced by the
product, the operator may not notice persons approaching.
Always wear suitable clothing, protective gloves, and stout shoes.
Always ensure that you have a secure foothold whilst working.
2. OPERATION
DANGER! Risk of physical injury!
Cut injury when the product starts accidentally.
v Wait for the blade to stop, remove the battery and slide
the protective cover over the blade before you transport
the product.
To charge the battery [ Fig. O1 / O2 / O3 ]:
CAUTION!
Note the mains voltage! The voltage of the power source must
match the voltage specified on the rating plate of the charger.
For the GARDENA Battery Hedge Trimmer Art. 14733-55 there is
no battery and no charger in the scope of delivery.
Thanks to the intelligent charging process, the charge condition of the
battery is automatically detected and then charged up with the optimal
charge current depending on battery temperature and voltage.
In this way, the battery is treated with care and remains permanently fully
charged when it is stored in the charger.
1. Push the locking button
>
and remove the battery
Y
from the battery
holder
C
.
2. Connect the battery charger
X
into a mains socket.
3. Slide the battery charger
X
onto the battery
Y
.
When the battery charge indicator
å
at the charger flashes green
the battery is being charged.
EN
10
When the battery charge indicator
å
at the charger illuminates
permanently green the battery is completely charged
(Charging time, see 6. TECHNICAL DATA).
4. Examine the charge status regularly while you charge.
5. When the battery
Y
is completely charged, you can disconnect the
battery
Y
from the charger
X
.
Meaning of the indication elements:
Indication on the charger [ Fig. O3 ]:
Flashing of the Battery
Charge Indicator
å
The charging procedure is indicated by flashing of the battery charge
indicator
å
.
Note: The charging procedure is only possible when the battery
temperature is within the allowable charging temperature range,
see 6. TECHNICAL DATA.
Continuous Lighting
of the Battery
Charge Indicator
å
Continuous lighting of the battery charge indicator
å
indicates that
the battery is fully charged or that the temperature of the battery is
not within the allowable charging temperature range and can therefore
not be charged.
When the battery is not inserted, continuous lighting of the battery
charge indicator
å
indicates that the mains plug is inserted in the
socket outlet and that the battery charger is ready for operation.
Battery charge status indication
N
on the product
[ Fig. O4 / O8 ]:
After starting the product, the battery charge status indication
N
is displayed for 5 seconds.
Battery charge status Battery charge status indication
67 – 100 % charged
«
,
∑
and
€
illuminate green
34 – 66 % charged
«
and
∑
illuminate green
11 – 33 % charged
«
illuminates green
0 – 10 % charged
«
flashes green
If the LED
«
flashes green, the battery must be charged.
If the error LED
ç
is illuminated or flashing, see 5. TROUBLESHOOTING.
Work positions:
The hedge trimmer can be operated in 3 positions.
– Side trimming [ Fig. O5 ]
– High trimming [ Fig. O6 ]
– Low trimming [ Fig. O7 ]
To start the hedge trimmer [ Fig. O1 /O8 ]:
DANGER! Risk of physical injury!
Risk of injury if the product does not stop when you
release the start levers.
v Do not bypass the safety devices or switches. For example do
not attach the start levers to the handle.
To start:
The product is provided with a two-handed safety device (2 start
levers) to prevent the product from being turned on by accident.
1. Put the battery
Y
into the battery holder
C
until it audibly engages.
2. Remove the protective cover from the blade.
3. Hold the front handle
1
with one hand and pull the front start lever
2
.
4. Hold the main handle
3
with the other hand and pull the rear start
lever
4
.
The hedge trimmer starts and the battery charge status indication
N
is displayed for 5 seconds.
To stop:
1. Release the two start levers
2
/
4
.
The hedge trimmer stops.
2. Slide the protective cover over the blade.
3. Push the locking button
>
and remove the battery
Y
from the battery
holder
C
.
3. MAINTENANCE
DANGER! Risk of physical injury!
Cut injury when the product starts accidentally.
v Wait for the blade to stop, remove the battery and slide
the protective cover over the blade before you maintain
the product.
To clean the Hedge Trimmer [ Fig. O8 ]:
DANGER! Risk of physical injury!
Risk of injury and risk of damage to the product.
v Do not clean the product with water or with a water jet
(in particular high-pressure water jet).
v Do not clean with chemicals including petrol or solvents.
Some can destroy critical plastic parts.
The airflow slots must always be clean.
1. Clean the hedge trimmer with a damp cloth.
2. Clean the airflow slots
5
with a soft brush (do not use a screwdriver).
3. Lubricate the blade with a low viscosity oil (e. g. GARDENA
Maintenance Oil Art. 2366).
Avoid contact with the plastic parts.
To clean the battery and the battery charger:
Make sure that the surface and the contacts of the battery and the battery
charger always are clean and dry before you connect the battery charger.
Do not use running water.
v Battery charger: Clean the contacts and the plastic parts with a soft
and dry cloth.
v Battery: Occasionally clean the ventilation slots and the terminals on
the battery using a soft brush that is clean and dry.
4. STORAGE
To put into storage:
The product must be stored away from children.
1. Slide the protective cover over the blade.
2. Remove the battery.
3. Charge the battery.
4. Clean the hedge trimmer, the battery and the battery charger
(see 3. MAINTENANCE).
5. Store the hedge trimmer, the battery and the battery charger in a dry,
enclosed and frost-free place.
Disposal:
(in accordance with RL2012/19/EC / S.I. 2013 No. 3113)
The product must not be disposed of to normal household
waste. It must be disposed of in line with local environmental
regulations.
IMPORTANT!
v Dispose of the product through or via your municipal recycling collection
centre.
Disposal of the battery:
Li-ion
The battery contains lithium-ion cells that should not be disposed
of with normal household waste at the end of its life.
IMPORTANT!
v Dispose of the batteries through or via your municipal recycling
collection centre.
1. Discharge the lithium-ion cells completely (contact the GARDENA
Service).
2. Protect the contacts on the lithium-ion cells against short circuits.
3. Dispose of the lithium-ion cells properly.
EN
11
5. TROUBLESHOOTING
DANGER! Risk of physical injury!
Cut injury when the product starts accidentally.
v Wait for the blade to stop, remove the battery and slide the
protective cover over the blade before you troubleshoot the
product.
Problem Possible Cause Remedy
Hedge trimmer can no
longer be stopped
Start lever is stuck. v
Remove the battery and
loosen the start lever.
Hedge is not cleanly cut Blade is blunt or damaged. v
Let the blade be replaced by
the GARDENA Service.
Hedge trimmer vibrates
severely
Blade is damaged. v
Switch off the product and
let the blade be replaced.
Hedge trimmer does not
start or stops.
LED
«
is flashing green
[ Fig. O4 ]
Battery is empty. v
Charge the battery.
Hedge trimmer does not
start or stops.
Error-LED
ç
is illuminated
red [ Fig. O4 ]
Battery temperature is outside
the permissible temperature
range.
v
Wait until the battery tem-
perature is between
0 °C – + 45 °C again.
There are drops of water or
moisture between the battery
contacts on the hedge trimmer.
v
Remove the water drops /
moisture with a dry cloth.
Engine is blocked. v
Remove the obstacle.
Start again.
Hedge trimmer does not
start or stops.
Error-LED
ç
is flashing
red [ Fig. O4 ]
Product is defective. v
Contact the GARDENA
Service.
Hedge trimmer does not
start or stops.
Error-LED
ç
is not
illuminated [ Fig. O4 ]
Battery is not put completely
into the battery holder.
v
Put the battery completely
into the battery holder until
it audibly engages.
Battery is defective. v
Replace the battery.
Product is defective. v
Contact the GARDENA
Service.
Charging is not possible.
Battery charge indicator
å
is continuously illuminated
[ Fig. O3 ]
The battery is not connected
(correctly).
v
Connect the battery to
charger correctly.
Battery contacts are dirty. v
Clean the battery contacts
(e. g. by connecting and
disconnecting the battery
several times. Replace the
battery if necessary.
Battery temperature is outside
the permissible charging
temperature range.
v
Wait until the battery
tem perature is between
0 °C – + 45 °C again.
Battery is defective. v
Replace the battery.
Battery charge indicator
å
is not illuminated [ Fig. O3 ]
Mains plug of the charger is
not (correctly) plugged in.
v
Insert the mains plug into the
mains socket (completely).
Socket outlet, mains cable or
charger is defective.
v
Check the mains voltage.
Let the charger be checked
if necessary by an authorised
specialist dealer or the
GARDENA Service.
NOTE: For any other malfunctions please contact the GARDENA service depart-
ment. Repairs must only be done by GARDENA service departments or specialist
dealers approved by GARDENA.
6. TECHNICAL DATA
Battery Hedge Trimmer
Unit Value (Art. 14733)
Strokes 1/min 2400
Length of blade cm 40
Tooth gap of blade mm 16
Weight (without Battery) g 1890
Sound pressure level L
pA
1)
Uncertainty k
pA
dB (A)
77
3.0
Sound power level L
WA
2)
:
measured / guaranteed
Uncertainty k
WA
dB (A)
86 / 88
2.3
Battery Hedge Trimmer
Unit Value (Art. 14733)
Hand/arm vibration a
vhw
1)
Uncertainty k
vhw
m/s
2
1.3
1.5
Measuring process complying with:
1)
62841-4-2
2)
RL 2000/14/EC / S.I. 2001 No.1701
NOTE: The stated vibration emission value has been measured according to
astandardised test procedure and can be used for comparison of one electric
power tool with another. It can also be used for preliminary evaluation of expo-
sure. The vibration emission value can vary during actual use of the electric power tool.
System Battery
PBA 18V 2.0Ah W-B
Unit Value (Art. 14902)
Battery voltage V (DC) 18
Battery capacity Ah 2.0
Number of cells (Li-Ion) 5
Appropriate POWER FOR ALL system Battery Chargers: AL 1810 CV / AL 1815 CV / AL18-20 /
AL 1830 CV / AL 1880 CV.
Battery Charger
AL 1810 CV P4A
Unit Value (Art. 14900)
Mains voltage V (AC) 220 – 240
Mains frequency Hz 50 – 60
Rated power W 26
Battery charging voltage V (DC) 18
Max. battery charging
current
mA 1000
Battery charging time 80 % /
97 – 100 % (approx.)
PBA 18V 2,0Ah W-B
PBA 18V 2,5Ah W-B
PBA 18V 4,0Ah W-C
min.
min.
min.
96 / 124
120 / 154
192 / 244
Permitted charging
temperature range
°C 0 – 45
Weight according to
EPTA-Procedure 01:2014
kg 0.17
Protection class
/ II
Appropriate POWER FOR ALL system Batteries: PBA 18V.
7. ACCESSORIES
GARDENA Maintenance Oil Extends the life of the blade and the battery idling
time.
Art. 2366
GARDENA System Battery
PBA 18V/45 P4A
PBA 18V/72 P4A
Battery for additional duration or for replacement.
Art. 14903
Art. 14905
GARDENA Battery Quick
Charger AL 1830 CV P4A
Charger for fast charging the POWER FOR ALL
System Batteries PBA 18V..W-..
Art. 14901
8. SERVICE / WARRANTY
Service:
Please contact the address on the enclosed warranty card.
Warranty statement:
The warranty is only granted according to the warranty conditions printed
on the enclosed warranty card.
Consumables:
The blade and eccentric drive are consumables and are not included in the
warranty.
EN
12
129
Produktbezeichnung:
Description of the product:
Désignation du produit :
Beschrijving van het product:
Beskrivning av produkten:
Beskrivelse af produktet:
Tuotteen kuvaus:
Descrizione del prodotto:
Descripción del producto:
Descrição do produto:
Opis produktu:
A termék leírása:
Popis výrobku:
Popis produktu:
Περιγραφή του προϊόντος:
Opis izdelka:
Opis proizvoda:
Descrierea produsului:
Описание на продукта:
Toote kirjeldus:
Gaminio aprašas:
Izstrādājuma apraksts:
Akku-Heckenschere
Battery Hedge Trimmer
Taille-haies à batterie
Accu-heggenschaar
Accu-häcksax
Hækkeklipper med genopladelig accu
Akkukäyttöinen pensasleikkuri
Tagliasiepi a batteria
Recortasetos con Accu
Corta sebes a bateria
Akumulatorowe nożyce do żywopłotu
Akkumulátoros sövénynyíró
Akumulátorové nůžky na živý plot
Akumulátorové nožnice na živý plot
Μπορντουροψάλιδο μπαταρίας
Akumulatorske škarje za živo mejo
Baterijske škare za živicu
Trimmer de gard viu cu baterie
Акумулаторна ножица за жив плет
Akuga hekilõikur
Akumuliatorinės gyvatvorių žirklės
Ar akumulatoru darbināmas dzīvžoga šķēres
Produkttyp:
Product type:
Type de produit :
Producttype:
Produkttyp:
Produkttype:
Tuotetyyppi:
Tipo adi prodotto:
Tipo de producto:
Tipo de produto:
Typ produktu:
Terméktípus:
Druh výrobku:
Typ produktu:
Τύπος προϊόντος:
Vrsta izdelka:
Vrsta proizvoda:
Tip produs:
Тип продукт:
Tootetüüp:
Gaminio tipas:
Produkta veids:
EasyCut 40/18V P4A
Artikelnummer:
Article number:
Référence :
Artikelnummer:
Artikelnummer:
Artikelnummer:
Tuotenumero:
Codice articolo:
Referencia:
Número de referência:
Numer katalogowy:
Cikkszámok:
Objednací číslo:
Objednávacie číslo:
Κωδικός είδους:
Številka izdelka:
Kataloški broj:
Cod articol:
Артикул номер:
Artiklinumber:
Dalies numeris:
Artikula numurs:
14733
EU-Richtlinien:
EC-Directives:
Directives CE :
EG-richtlijnen:
EU-direktiv:
EF-direktiver:
EY-direktiivit:
Direttive UE:
Directiva CE:
Diretivas CE:
Dyrektywy WE:
EK-irányelvek:
Předpisy ES:
Smernice EÚ:
Οδηγίες ΕΚ:
Direktive EU:
EC direktive:
Directive CE:
Директиви на ЕО:
EÜ direktiivid:
EB direktyvos:
EK direktīvas:
2006/42/EG
2011/65/EU
2014/30/EU
2014/35/EU
Hinterlegte
Dokumentation:
GARDENA Technische
Dokumentation,
M. Jäger, 89079 Ulm
Deposited Documentation:
GARDENA Technical
Documentation,
M. Jäger, 89079 Ulm
Documentation déposée :
Documentation
technique GARDENA,
M. Jäger, 89079 Ulm
Konformitätsbewer tungs-
verfahren:
Nach 2000/14/EG Art. 14
Anhang V
Conformity Assessment
Procedure:
according to 2000/14/EC
Art.14 Annex V
Procédure d’évaluation
de la conformité :
Selon 2000/14/CE art. 14
Annexe V
Harmonisierte EN-Normen /
Harmonised EN:
EN ISO 12100
EN 62841-1
EN 62841-4-2
Schall-Leistungspegel: gemessen / garantiert
Noise level: measured / guaranteed
Niveau sonore : mesuré / garanti
Geluidsniveau: gemeten / gegarandeerd
Ljudnivå: uppmätt / garanterad
Støjniveau: målt / garanteret
Äänitaso: mitattu / taattu
Livello acustico: misurato / garantito
Nivel de ruido: medido / garantizado
Nível de ruído: medido / garantido
Poziom hałasu: zmierzony / gwarantowany
Zajszint: mért / garantált
Hladina hluku: naměřená / zaručená
Hladiny hluku: namerané/zaručené
Επίπεδο θορύβου: μετρημένο / εγγυημένο
Raven zvočne moči: izmerjena / zagotovljena
Razina buke: mjerena / zajamčena
Nivel de zgomot: măsurat / garantat
Ниво на шум: измерено / гарантирано
Müratase: mõõdetud / garanteeritud
Triukšmo lygis: išmatuotas / garantuojamas
Trokšņa līmenis : mērītais / garantētais
86 dB(A) / 88 dB(A)
Ulm, den 15.03.2022
Ulm, 15.03.2022
Fait à Ulm, le 15.03.2022
Ulm, 15-03-2022
Ulm, 2022.03.15.
Ulm, 15.03.2022
Ulmissa, 15.03.2022
Ulm, 15.03.2022
Ulm, 15.03.2022
Ulm, 15.03.2022
Ulm, dnia 15.03.2022
Ulm, 15.03.2022
Ulm, 15.03.2022
Ulm, dňa 15.03.2022
Ulm, 15.03.2022
Ulm, 15.03.2022
Ulm, dana 15.03.2022
Ulm, 15.03.2022
Улм, 15.03.2022
Ulm, 15.03.2022
Ulm, 15.03.2022
Ulme, 15.03.2022
Der Bevollmächtigte
Authorised representative
Le mandataire
De gevolmachtigde
Auktoriserad representant
Autoriseret repræsentant
Valtuutettu edustaja
Persona delegata
La persona autorizada
O representante
Pełnomocnik
Meghatalmazott
Zplnomocněnec
Splnomocnený
Ο εξουσιοδοτημένος
Pooblaščenec
Ovlaštena osoba
Conducerea tehnică
Упълномощен
Volitatud esindaja
Įgaliotasis atstovas
Pilnvarotā persona
Anbringungsjahr der CE-Kennzeichnung:
Year of CE marking:
Année d’apposition du marquage CE :
Installatiejaar van de CE-aanduiding:
Märkningsår:
CE-Mærkningsår:
CE-merkin kiinnitysvuosi:
Anno di applicazione della certificazione CE:
Colocación del distintivo CE:
Ano de marcação pela CE:
Rok nadania oznakowania CE:
CE-jelzés elhelyezésének éve:
Rok umístění značky CE:
Rok udelenia značky CE:
Έτος σήματος CE:
Leto namestitve CE-oznake:
Godina dobivanja CE oznake:
Anul de marcare CE:
Година на поставяне на CE-маркировка:
CE-märgistuse paigaldamise aasta:
Metai, kada pažymėta CE-ženklu:
CE-marķējuma uzlikšanas gads:
2022
DE EU-Konformitätserklärung
Der Unterzeichnende bestätigt als Bevollmächtigte des Herstellers, der GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Schweden, dass das (die) nachfolgend bezeichnete(n) Gerät(e) in der von uns in Verkehr gebrachten
Ausführung die Anforderungen der harmonisierten EU-Richtlinien, EU-Sicherheitsstandards und produktspezifischen Standards
erfüllt /erfüllen. Bei einer nicht mit uns abgestimmten Änderung des (der) Geräte(s) verliert diese Erklärung ihre Gültigkeit.
EN EC Declaration of Conformity
The undersigned hereby certifies as the authorized representative of the manufacturer, GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Sweden, that, when leaving our factory, the unit(s) indicated below is / are in accordance with the
harmonised EU guidelines, EU standards of safety and product specific standards. This certificate becomes void if the unit(s)
is/are modified without our approval.
FR Déclaration de conformité CE
Le soussigné déclare, en tant que mandataire du fabricant, la GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm,
Suède, qu’à la sortie de ses usines le matériel neuf désigné ci-dessous était conforme aux prescriptions des directives européen-
nes énoncées ci-après et conforme aux règles de sécurité et autres règles qui lui sont applicables dans le cadre de l’Union
européenne. Toute modification portée sur ce(s) produit(s) sans l’accord express de notre part supprime la validité de ce certificat.
NL EU-conformiteitsverklaring
De ondergetekende bevestigt als gevolmachtigde van de fabrikant, GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm,
Zweden, dat het/de onderstaand vermelde apparaat/apparaten in de door ons in de handel gebrachte uitvoering voldoet/voldoen
aan de eisen van de geharmoniseerde EU-richtlijnen, EU-veiligheidsnormen en productspecifieke normen. Bij een niet met ons
afgestemde verandering van het apparaat/de apparaten verliest deze verklaring haar geldigheid.
SV EU-försäkran om överensstämmelse
Undertecknad intygar som befullmäktigad företrädare för tillverkaren, GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Sverige, att nedan angiven apparat / nedan angivna apparater i det utförande vi har släppt på marknaden,
uppfyller fordringarna i de harmoniserade EU-direktiven, EU-säkerhetsstandarderna och de produktspecifika standarderna.
Denna försäkran upphör att gälla vid en ändring av apparaten/apparaterna som inte har stämts av med oss.
DA EU-overensstemmelseserklæring
Underskriveren bekræfter som fuldmægtig for producenten, GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Sverige,
at det (de) efterfølgende betegnede apparat(er) i den af os markedsførte udførelse opfylder kravene i de harmoniserede EU-direk-
tiver, EU-sikkerhedsstandarder og produktspecifikke standarder. Foretages en ændring af apparatet/apparaterne, der ikke er aftalt
med os, mister denne erklæring sin gyldighed.
FI EU-vaatimustenmukaisuusvakuutus
Allekirjoittanut vahvistaa valmistajan, GARDENA Germany AB, PO Box 7454, S-103 92, Tukholma, Ruotsi, valtuuttamana hen-
kilönä, että seuraava laite täyttää / seuraavat laitteet täyttävät meidän toimittamassa mallissa yhdenmukaistettujen EU-direktiivien,
EU-turvallisuusmääräysten ja tuotekohtaisten standardien vaatimukset. Laitteen/laitteiden muutoksissa, joista ei ole sovittu meidän
kanssamme, menettää tämä selvitys voimassaolonsa.
IT Dichiarazione di conformità UE
Il sottoscritto, in quanto soggetto autorizzato dal produttore, GARDENA Germany AB, PO Box 7454, S-103 92, Stoccolma, Svezia,
dichiara che l’apparecchio/gli apparecchi di seguito denominato/i, nella versione da noi immessa in commercio, soddisfa/no
i requisiti delle direttive UE armonizzate, degli standard di sicurezza europei e degli standard specifici per il prodotto.
La presente dichiarazione perde di validità in caso di modifica dell’apparecchio/degli apparecchi non concordata con noi.
ES Declaración de conformidad de la UE
El firmante confirma, en calidad de apoderado del fabricante GARDENA Germany AB, PO Box 7454, S-103 92 Estocolmo (Suecia),
que el/ los aparato(s) mencionado(s) a continuación cumple(n), en la versión lanzada al mercado por nuestra empresa, los requisi-
tos de las directivas de la UE armonizadas, los estándares de seguridad de la UE y los estándares específicos del producto.
La presente declaración perderá su validez si se modifica(n) el/los aparato(s) sin previa aprobación por nuestra parte.
PT Declaração CE de Conformidade
O abaixo-assinado, na qualidade de representante do fabricante, GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm,
Schweden, confirma que o(s) aparelho(s) a seguir designado(s) no modelo lançado por nós no mercado cumpre / cumprem
os requisitos das diretivas UE harmonizadas, as normas de segurança UE e as normas específicas para estes produtos.
Esta declaração perde a sua validade se forem realizadas alterações no(s) aparelho(s) sem o nosso consentimento.
PL Deklaracja zgodności UE
Niżej podpisany potwierdza jako upoważniony przedstawiciel producenta, spółki GARDENA Germany AB, PO Box 7454,
S-103 92, Sztokholm, Szwecja, że określone poniżej urządzenie/-nia w wersji wprowadzonej przez nas do obrotu spełnia /
-niają wymogi zharmonizowanych dyrektyw UE, norm bezpieczeństwa UE oraz norm dotyczących konkretnych produktów.
Niniejsza deklaracja traci ważność w przypadku wprowadzania nieuzgodnionych z nami zmian urządzenia/ń.
HU EU megfelelőségi nyilatkozat
Az alulírott, a GARDENA Germany AB, Pf. 7454, S-103 92, Stockholm, Svédország megbízotti minőségében megerősíti, hogy
az általunk alábbi kivitelben forgalomba hozott, lent nevezett eszköz(ök) megfelel(nek) az uniós irányelvekkel összhangba hozott
nemzeti előírások követelményeinek, az EU biztonsági szabványainak és a konkrét termékre vonatkozó szabványoknak.
Az eszköz(ök)nek velünk nem egyeztetett módosítása esetén ez a nyilatkozat érvényét veszti.
CS EU prohlášení o shodě
Podepsaná osoba zplnomocněná výrobcem GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Švédsko potvrzuje,
že v následujícím uvedený(-é) přístroj(-e) v provedení námi uvedeném na trh splňuje/splňují požadavky směrnic EU, bezpečnost-
ních norem EU a norem specifických pro výrobek. V případě změny přístroje(-ů), která s námi nebyla dohodnuta, ztrácí toto pro-
hlášení svou platnost.
SK EÚ vyhlásenie o zhode
Dolu podpísaný potvrdzuje, ako splnomocnený zástupca výrobcu, GARDENA Germany AB, PO Box 7454, S-103 92, Štokholm,
Švédsko, že ďalej označené zariadenie/ a vo vyhotovení uvedenom na trh spĺňa/ jú požiadavky harmonizovaných smerníc EÚ,
bezpečnostných štandardov EÚ a predpisov, špecifických pre dané výrobky. Pri zmene zariadenia/ zariadení, ktorá nebola odsúhla-
sená našou spoločnosťou, stráca toto vyhlásenie platnosť.
EL Δήλωση συμμόρφωσης ΕΕ
Ο υπογεγραμμένος βεβαιώνει ως πληρεξούσιος του κατασκευαστή, της εταιρείας GARDENA Germany AB, Τ.Θ. 7454, S-103 92,
Στοκχόλμη, Σουηδία, ότι η (οι) παρακάτω αναφερόμενη(ες) συσκευή(ές) στην έκδοση που τίθεται από εμάς σε κυκλοφορία πληροί/πλη-
ρούν τις απαιτήσεις των εναρμονισμένων οδηγιών της ΕΕ, προτύπων ασφαλείας της ΕΕ και των ειδικών για το προϊόν προτύπων. Σε
περίπτωση τροποποίησης της (των) συσκευής(ών) χωρίς προηγούμενη συνεννόηση με την εταιρεία μας παύει να ισχύει η δήλωση.
SL Izjava EU o skladnosti
Spodaj podpisani kot pooblaščenec proizvajalca GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Švedska,
potrjuje, da v nadaljevanju označene naprave v izvedbi, v kakršni smo jih dali v promet, izpolnjujejo zahteve usklajenih direktiv EU,
varnostnega standarda EU in standardov, ki veljajo za posamezne izdelke. V primeru spremembe naprave, ki ni usklajena
z nami, ta izjava neha veljati.
HR EU izjava o sukladnosti
Dolje potpisani kao opunomoćenik proizvođača, tvrtke GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Švedska,
potvrđujemo da niže navedeni uređaj(i) odgovarajuće izvedbe koji/koje smo iznijeli na tržište ispunjavaju kriterije usklađenih
direktiva EU i sigurnosnih standarda EU kao i standarda koji se tiču proizvoda. Ova izjava gubi valjanost u slučaju izmjena uređaja
koje nisu prethodno ugovorene s nama.
RO Declaraţie de conformitate UE
Semnatarul, în calitatea sa de împuternicit al producătorului GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Suedia,
confirmă că aparatul (aparatele) descrise în cele ce urmează, în execuţia pusă de noi pe piaţă îndeplineşte (îndeplinesc) cerinţele
directivelor armonizate UE, ale standardelor de siguranţă UE şi ale standardelor specifice produsului.
În cazul modificării fără aprobarea noastră prealabilă a aparatului (aparatelor), această declaraţie îşi pierde valabilitatea.
BG ЕС-Декларация за съответствие
Долуподписаният удостоверява като пълномощник на производителя GARDENA Germany AB, PO Box 7454, S-103 92,
Стокхолм, Швеция, че по-долу описаният(ите) уред(и) във варианта на изпълнение пуснат от нас на пазара изпълнява /
изпълняват изискванията на хармонизираните ЕС-директиви, ЕС-норми за безопасност и специфичните норми за
продукцията. В случай на промяна на уреда(ите), която не е съгласувана с нас, тази декларация губи своята валидност.
ET EL-i vastavusdeklaratsioon
Allakirjutanu kinnitab tootja, GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Rootsi, poolt volitatud isikuna,
et järgnevalt nimetatud seade (seadmed) täidab (täidavad) meie poolt turule toodud versiooni kujul harmoneeritud EL-i direktiivide,
EL-i ohutusstandardite ja tootepõhiste standardite nõuded. Seadmel (seadmetel) meiega kooskõlastamata muudatuse tegemise
korral kaotab käesolev deklaratsioon oma kehtivuse.
LT ES atitikties deklaracija
Pasirašantysis, kaip gamintojo, GARDENA Germany AB, PO Box 7454, S-103 92, Stokholmas, Švedija, įgaliotasis atstovas patvir-
tina, kad žemiau nurodyto(-ų) prietaiso(-ų) modeliai, kurie buvo pagaminti mūsų gamyklose, atitinka darniąsias ES direktyvas,
ES saugumo standartus ir specifinius gaminio standartus. Atlikus bet kokį prietaiso(-ų) pakeitimą, kuris nėra suderintas su mumis,
ši deklaracija praranda galiojimą.
LV ES atbilstības deklarācija
Zemā parakstījusies persona kā ražotāja, uzņēmuma GARDENA Germany AB, PO Box 7454, S-103 92, Stokholma, Zviedrija,
pilnvarotais pārstāvis apstiprina, ka tālāk norādītā(-s) ierīce(-s) izpildījumā, kādā mēs to (tās) esam laiduši tirgū, atbilst saskaņota-
jām ES direktīvām, ES drošības standartiem un konkrētajam produktam noteiktajiem standartiem.
Ierīcē(-s) veicot ar mums nesaskaņotas izmaiņas, šī deklarācija zaudē savu spēku.
Reinhard Pompe
Vice President
Wolfgang Engelhardt
Vice President Supply Chain
130
EN UKCA Declaration of Conformity
The manufacturer: GARDENA Germany AB, PO Box 7454, S-103 92 Stockholm, Sweden hereby certifies, when leaving our factory, the unit(s)
indicated below is / are in accordance with the UK Regulations, designated standards of safety and product specific designated standards.
This certificate becomes void if the units are modified without our approval.
Description of the Product:
Battery Hedge Trimmer
Product type:
EasyCut 40/18V P4A
Article Number:
14733
UK regulations:
S.I. 2008/1597
S.I. 2016/1091
S.I. 2012/3032
S.I. 2001/1701
Designated Standards:
EN ISO 12100
EN 62841-1
EN 62841-4-2
Authorised Representative:
Husqvarna UK Limited
Deposited Documentation:
Preston Road,
Aycliffe,
County Durham
UK
DL5 6 UP
Conformity Assessment Procedure:
According to S.I. 2001/1701 Art. 11 Schedule 8
Noise level: measured / guaranteed
86 dB(A) / 88 dB(A)
Aycliffe, 15.03.2022
Authorised Representative:
John Thompson
Director
134
Croatia
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Phone: (+43) 732 77 01 01-485
service.gardena@husqvarnagroup.com
Cyprus
Pantelis Papadopoulos S.A.
92 Athinon Avenue
Athens
10442 Greece
Phone: (+30) 21 0519 3100
Czech Republic
Gardena
Service Center Vrbno
c/o Husqvarna
Manufacturing CZ s.r.o.
Jesenická 146
79326 Vrbno pod Pradedem
Phone: 800 100 425
Denmark
GARDENA DANMARK
Lejrvej 19, st.
3500 Værløse
Tlf.: (+45) 70 26 47 70
gardenadk@husqvarnagroup.com
www.gardena.com / dk
Dominican Republic
BOSQUESA, S.R.L
Carretera Santiago Licey
Km. 5 ½
Esquina Copal II.
Santiago De Los Caballeros
51000 Dominican Republic
Phone: (+1) 809-562-0476
Egypt
Universal Agencies Co
26, Abdel Hamid Lotfy St.
Giza
Phone: (+20) 3 761 57 57
Estonia
Husqvarna Eesti OÜ
Valdeku 132
EE-11216 Tallinn
Finland
Oy Husqvarna Ab
Juurakkotie 5 B 2
01510 Vantaa
www.gardena.
France
Husqvarna France
9/11 Allée des pierres mayettes
92635 Gennevilliers Cedex
France
http://www.gardena.com/fr
N° AZUR: 0 810 00 78 23
(Prix d’un appel local)
Georgia
Transporter LLC
#70, Beliashvili street
0159 Tbilisi, Georgia
Number: (+995) 322 14 71 71
info@transporter.com.ge
www.transporter.com.ge
Service Address and
Importer to Great Britain
Husqvarna UK Ltd
Preston Road
Ayclie Industrial Park
Newton Ayclie
County Durham
DL5 6UP
Phone: (+44) (0) 344 844 4558
info.gar[email protected]
Greece
Π.ΠΑΠΑΔΟΠΟΥΛΟΣ ΑΕΒΕ
Λεωφ. Αθηνών 92
Αθήνα
Τ.Κ.104 42
Ελλάδα
Τηλ. (+30) 210 5193 100
Hong Kong
Tung Tai Company
151-153 Hoi Bun Road
Kwun Tong, Kowloon
Hong Kong
Phone: (+852) 3583 1662
Hungary
Husqvarna Magyarország Kft.
Ezred u. 1 – 3
1044 Budapest
Phone: (+36) 1 251-4161
vevosz[email protected]
Iceland
BYKO ehf.
Skemmuvegi 2a
200 Kópavogur
Phone: (+354) 515 4000
byko@byko.is
MHG Verslun ehf
Víkurhvarf 8
203 Kópavogur
Phone: (+354) 544 4656
India
B K RAMAN AND CO
Plot No. 185, Industrial Area,
Phase-2, Ram Darbar
Chandigarh
160002 India
Phone: (+91) 98140 06530
raman@jaganhardware.com
Iraq
Alshiemal Alakhdar Company
Al-Faysalieah, Near Estate Bank
Mosul
Phone: (+964) 78 18 18 46 75
Ireland
Liey Distributors Ltd.
309 NW Business Park, Ballycoolen
15 Dublin
Phone: (+353) 1 824 2600
info@lieyd.com
Israel
HAGARIN LTD.
2 Nahal Harif St.
8122201 Yavne
Phone: (+972) 8-932-0400
Deutschland / Germany
GARDENA Manufacturing GmbH
Central Service
Hans-Lorenser-Straße 40
D-89079 Ulm
Produktfragen:
(+49) 731 490-123
Reparaturen:
(+49) 731 490-290
www.gardena.com/de/kontakt
Albania
KRAFT SHPK
Autostrada Tirane-Durres
Km 7
1051 Tirane
Phone: (+355) 69 877 7821
Argentina
ROBERTO C. RUMBO S.R.L.
Predio Norlog
Lote 7
Benavidez. ZC: 1621
Buenos Aires
Phone: (+54) 11 5263-7862
Armenia
AES Systems LLC
Marshal Babajanyan Avenue 56/2
0022 Yerevan
Phone: (+374) 60 651 651
masisohanyan@icloud.com
Australia
Husqvarna Australia Pty. Ltd.
Locked Bag 5
Central Coast BC
NSW 2252
Phone: (+ 61) (0) 2 4352 7400
customer.ser[email protected]
Austria / Österreich
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: (+43) 732 77 01 01-485
service.gardena@husqvarnagroup.com
Azerbaijan
Proqres Xüsusi Firması
Aliyar Aliyev 212, Baku, Azerbaijan
Sales: +994 70 326 07 14
Aftersales: +994 77 326 07 14
www.progress-garden.az
info@progress-garden.az
Bahrain
M.H. Al-Mahroos
BUILDING 208, BLOCK 356,
ROAD 328
Salhiya
Phone: +973 1740 8090
Belarus / Беларусь
ООО «Мастер Гарден»
220118, г. Минск,
улица Шаранговича, дом 7а
Тел. (+375) 17 257 00 33
mg@mastergarden.by
Belgium
Husqvarna Belgium nv
Gardena Division
Leuvensesteenweg 542
Planet II E
1930 Zaventem
België
Bosnia / Herzegovina
Silk Trade d.o.o.
Poslovna Zona Vila Br. 20
Phone: (+387) 61 165 593
Brazil
Nordtech Maquinas e Motores Ltd.
Avenida Juscelino Kubitschek
de Oliveira Curitiba
3003 Brazil
Phone: (+55) 41 3595-9600
www.nordtech.com.br
Bulgaria
AGROLAND България АД
бул. 8 Декември, № 13
Офис 5
1700 Студентски град
София
Тел.: (+359) 24 66 6910
info@agroland.eu
Canada / USA
GARDENA Canada Ltd.
125 Edgeware Road
Unit 15 A
Brampton L6Y 0P5
ON, Canada
Phone: (+1) 905 792 93 30
gardena.customerservice@ husqvarnagroup.com
Chile
REPRESENTACIONES JCE S.A.
AV. DEL VALLE NORTE 857 PISO 4
HUECHURABA, SANTIAGO, CHILE
Phone: (+ 56) 2 2414 2600
China
Husqvarna (Shanghai)
Management Co., Ltd.
富世华（上海）管理有限公司
3F, Benq Square B,
No 207, Song Hong Rd.,
Chang Ning District,
Shanghai, PRC. 200335
上海市长宁区淞虹路207号明
基广场B座3楼, 邮编: 200335
Colombia
Equipos de Toyama Colombia SAS
Cra. 68 D No 25 B 86 Of. 618
Edicio Torre Central
Bogota
Phone: +57 (1) 703 95 20 /
+57 (1) 703 95 22
www.toyama.com.co
Costa Rica
Exim CIA Costa Rica
Calle 25A, B°. Montealegre
Zapote
San José
Costa Rica
Phone: (+506) 2221-5654 / (+506) 2221-5659
info@agro.house
www.agro.house
Vietnam
Vision Joint Stock Company
BT1-17, Khu biet thu –
Khu Đoan ngoai giao Nguyen Xuan Khoat
Xuan Đinh, Bac Tu Liem
Hanoi, Vietnam
Phone: (+8424)-38462833/34
Zimbabwe
Cutting Edge
159 Citroen Rd, Msasa
Harare
Phone: (+263) 8677 008685
14733-20.960.02/0422
© GARDENA Manufacturing GmbH
D-89079 Ulm
https://www.gardena.com
Italy
Husqvarna Italia S.p.A.
Centro Direzionale Planum
Via del Lavoro 2, Scala B
22036 ERBA (CO)
Phone: (+39) (0) 31 4147700
[email protected]arna.com
Japan
Husqvarna Zenoah Co. Ltd. Japan
1-9 Minamidai, Kawagoe
350-1165 Saitama
Japan
gardena-jp@husqvarnagroup.com
Kazakhstan
ТОО “Ламэд”
Russian
Адрес: Казахстан, г. Алматы,
ул. Тажибаевой, 155/1
Тел.: (+7) (727) 355 64 00 /
(+7) (700) 355 64 00 [email protected]
Kazakh
Мекен-жайы: Қазақстан,
Алматы қ.,
көш. Тәжібаевой, 155/1
Тел.: (+7) (727) 355 64 00 /
(+7) (700) 355 64 00
Kuwait
Palms Agro Production Co
Al Rai- Fourth Ring Road – Block 56.
P.O Box: 1976 Safat
13020 Al-Rai
Phone: (+965) 24 73 07 45
info@palms-kw.com
Kyrgyzstan
OOsO Alye Maki
Av. Moladaya Guardia 83
720014 Bishkek
Phone: (+996) 312 322115
Latvia
Husqvarna Latvija SIA
Ulbrokas 19A
LV-1021 Rīga
Lebanon
Technomec
Safra Highway (Beirut – Tripoli) Center
622 Mezher Bldg.
P.O.Box 215
Jounieh
Phone: (+961) 9 853527 /
(+961) 3 855481
Lithuania
UAB Husqvarna Lietuva
Ateities pl. 77C
LT-52104 Kaunas
Luxembourg
Magasins Jules Neuberg
39, rue Jacques Stas
Luxembourg-Gasperich 2549
Case Postale No. 12
Luxembourg 2010
Phone: (+352) 40 14 01
Malaysia
Glomedic International Sdn Bhd
Jalan Ruang No. 30
Shah Alam, Selangor
40150 Malaysia
Phone: (+60) 3-7734 7997
Malta
I.V. Portelli & Sons Ltd.
85, 86, Triq San Pawl
Rabat - RBT 1240
Phone: (+356) 2145 4289
Mauritius
Espace Maison Ltée
La City Trianon, St Jean
Quatre Bornes
Phone: (+230) 460 85 85
Mexico
AFOSA
Av. Lopez Mateos Sur # 5019
Col. La Calma 45070
Zapopan, Jalisco, Mexico
Phone: (+52) 33 3818-3434
Moldova
Convel SRL
Republica Moldova,
mun. Chisinau,
sos. Muncesti 284
Phone: (+373) 22 857 126
www.convel.md
Mongolia
Soyolj Gardening Shop
Narnii Rd
Ulaanbaatar
14230 Mongolia
Phone: +976 7777 5080
soyolj@magicnet.mn
Morocco
Proekip
64 Rue de la Participation
Casablanca-Roches Noires
20303 Morocco
Phone: (+212) 661342107
Netherlands
Husqvarna Nederland B.V.
GARDENA Division
Postbus 50131
1305 AC ALMERE
Phone: (+31) 36 521 00 10
Neth. Antilles
Jonka Enterprises N.V.
Sta. Rosa Weg 196
P.O. Box 8200
Curaçao
Phone: (+599) 9 767 66 55
New Zealand
Husqvarna New Zealand Ltd.
PO Box 76-437
Manukau City 2241
Phone: (+64) (0) 9 9202410
North Macedonia
Sinpeks d.o.o.
Ul. Kravarski Pat Bb
7000 Bitola
Phone: (+389) 47 20 85 00
Norway
Husqvarna Norge AS
Gardena Division
Trøskenveien 36
1708 Sarpsborg
Northern Cyprus
Mediterranean Home & Garden
No 150 Alsancak, Karaoğlanoğlu
Caddesi Girne
Phone: (+90) 392 821 33 80
info@medgardener.com
Oman
General Development Services
PO 1475, PC - 111
Seeb
111 Oman
Phone: 96824582816
Paraguay
Agroeld SRL
AV. CHOFERES DEL CHACO
1449 C/25 DE MAYO
Asuncion
Phone: (+595) 21 608 656
consultas@agroeld.com.py
Peru
Sierras y Herramientas Forestal SAC
Av. Las Gaviotas 833, Chorrillos
Lima
Phone: (+51) 1 2 52 02 52
www.siersac.com
Philippines
Royal Dragon Traders Inc
10 Linaw Street, Barangay
Saint Peter Quezon City
1114 Philippines
Phone: (+63) 2 7426893
aida.fernande[email protected]
Poland
Gardena Service Center Vrbno
c/o Husqvarna Manufacturing CZ
s.r.o. Jesenická 146
79326 Vrbno pod Pradedem
Czech Republic
Phone: (22) 336 78 90
Portugal
Husqvarna Portugal, SA
Lagoa - Albarraque
2635 - 595 Rio de Mouro
Phone: (+351) 21 922 85 30
Fax: (+351) 21 922 85 36
Romania
Madex International Srl
Soseaua Odaii 117 - 123,
RO 013603 Bucureşti, S1
Phone: (+40) 21 352 7603
Russia / Россия
ООО „Хускварна“
141400, Московская обл.,
г. Химки,
улица Ленинградская,
владение 39, стр.6
Бизнес Центр
„Химки Бизнес Парк“,
помещение ОВ02_04
http://www.gardena.ru
Saudi Arabia
SACO
Takhassusi Main Road P.O. Box:
86387 Riyadh 12863
40011 Saudi Arabia
Phone: (966) 11 482 8877
webmaster@saco-ksa.com
Al Futtaim Pioneer Trading
5147 Al Farooq Dist.
Riyadh 7991
Phone: (+971) 4 206 6700
Serbia
Domel d.o.o.
Slobodana Đurića 21
11000 Belgrade
Phone: (+381) 11 409 57 12
Singapore
Hy-Ray PRIVATE LIMITED
40 Jalan Pemimpin
#02-08 Tat Ann Building
Singapore 577185
Phone: (+65) 6253 2277
info@hyray.com.sg
Slovak Republic
Gardena
Service Center Vrbno
c/o Husqvarna
Manufacturing CZ s.r.o.
Jesenická 146
79326 Vrbno pod Pradedem
Phone: 0800 154044
Slovenia
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Phone: (+43) 732 77 01 01-485
service.gardena@husqvarnagroup.com
South Africa
Husqvarna South Africa (Pty) Ltd
Lifestyle Business Park –
Ground Floor Block A Cnr
Beyers Naude Drive and Ysterhout
Road Randpark Ridge, Randburg
Phone: (+27) 10 015 5750
South Korea
Kyung Jin Trading Co., Ltd
8F Haengbok Building, 210,
Gangnam-Daero 137-891 Seoul
Phone: (+82) 2 574 6300
Spain
Husqvarna España S.A.
Calle de Rivas nº 10
28052 Madrid
Phone: (+34) 91 708 05 00
atencioncliente@gardena.es
Sri Lanka
Hunter & Company Ltd.
130 Front Street
Colombo
Phone: 94-11 232 81 71
Suriname
Deto Handelmaatschappij N.V.
Kernkampweg 72-74
P.O. Box: 12782
Paramaribo
Suriname
Phone: (+597) 43 80 50
info@deto.sr
Sweden
Husqvarna AB /
GARDENA Sverige
Drottninggatan 2
561 82 Huskvarna
Sverige
Phone: (+46) (0) 36-14 60 02
Switzerland / Schweiz
Husqvarna Schweiz AG
Consumer Products
Industriestrasse 10
5506 Mägenwil
Phone: (+ 41) (0) 62 887 37 90
Taiwan
Hong Ying Trading Co., Ltd.
No. 46 Wu-Kun-Wu Road
New Taipei City
Phone: (+886) (02) 2298 1486
Tajikistan
ARIERS JV LLC
39, Ayni Street, 734024
Dushanbe, Tajikistan
Thailand
Spica Co. Ltd
243/2 Onnuch Rd., Prawat
Bangkok
10250 Thailand
Phone: (+66) (0)2721 7373
Tunisia
Société du matériel agricole et maritime
Nouveau port de peche de Sfax Bp 33
Sfax 3065
Phone: (+216) 98 419047/
(+216) 74 497614
Türkiye
Dost Bahçe
Yunus Mah. Adil Sk. No:3
Kartal
Istanbul
34873 Türkiye
Phone: (+90) 216 389 39 39
Turkmenistan
I.E. Orazmuhammedov Nurmuhammet
80 Ataturk, BERKARAR Shopping Center,
Ground oor, A77b,
Ashgabat 744000
TURKMENISTAN
Phone: (+993) 12 468859
Mob: (+993) 62 222887
info@jayhyzmat.com /
bekgiye[email protected]
www.jayhyzmat.com
UAE
Al-Futtaim ACE Company
L.L.C Building, Al Rebat Street
Festival City, Dubai
7880 UAE
Phone: (+971) 4 206 6700
Ukraine / Україна
АТ «Альцест»
вул Петропавлівська 4
08130, Київська обл.
Києво-Святошинський р-н. с.
Петропавлівська Борщагівка Україна
Тел.: (+38) 0 800 503 000
Uruguay
FELI SA
Entre Ríos 1083
11800 Montevideo
Phone: (+598) 22 03 18 44
info@felisa.com.uy
Uzbekistan
AGROHOUSE MChJ
O’zbekiston, 111112
Toshkent viloyati
Toshkent tumani
Hasanboy QFY, THAY yoqasida
Phone: (+998)-93-5414141 /
(+998)-71-2096868
