Please read the user manual thoroughly before using
USER MANUAL
E1000
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
ONLY CONNECT
ED TO BATTERY
EXTRA BATTERY PORT
20
3 5
4
2 1
AC INPUT 100~120V 15A MAX
①
②
③
④
⑤
LCD Display
Main Switch
DC 11V~60V Charging Port
Adjustment Button of DC Charging Port
AC 100V~120V Output
⑥
⑦
⑧
⑨
⑩
DC 12V / USB Switch
AC 100V~120V Switch
DC12V Auxiliary Output
DC12V(5525) Output
DC12V XT60 Output
⑪
⑫
⑬
⑭
USB-A / USB-C Ports
External Grounding Port
AC 100V~120V Charging Port
Battery Expansion Port
FUNCTION INTRODUCTION
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
①
⑧
⑨
⑩
⑪
⑭
⑥
⑦
③
②
④
⑤
⑫
⑬
Battery Type
Capacity
1024Wh(51.2V20Ah)
LiFePO4 (3500+Cycles to 80%)
GENERAL INFO
Temperature
Dimension
0℃~45℃/32°F~113°F (Charging)
-20℃~45℃/-4°F~113°F (Discharging)
L14.9*W9.4*H10 in
L378*W239*H255 mm
E1000
AC
DC
18W*2
12V 20A 最大
100W*2
5A
20A
10A
DC 输出
AC 输出-1800W 最大
11~60V-600W 最大
8A20A
DC 充电
Around 29lb
Around 13.5Kg
Net Weight
BS-U20 *5
USB-A *2 (5V,9V,12V, Max 18W)*2
USB-C *2
DC 12V-10ACigar Port *1
DC 12V-20A
280W Max
XT60 Output *1
DC 12V-5ADC 5525 Output *1
SPECIFICATIONS
AC OUTPUT
DC OUTPUT
Pure sine wave 100V~120V
Rated 1800W Max
(5V,9V,12V,20V, Max 100W)*2
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
8A 20A
HOW TO USE THE E1000 LFP
Short press to turn on, long press to turn off,
short press to turn off the screen while working;
Press and hold to turn on / off DC / USB;
Press and hold to turn on / off AC;
Charging current adjustable during 12-30Vdc;
(Please turn off the AC function if there is no AC load on the unit)
MJ32 *1 48V, 20A MAX
3 5
4
2 1
DC INPUT
EXTRA BATTERY PORT
AC INLET *1
XT60 *1
AC INPUT
100Vac~120Vac 50/60HZ
15A Max
11V~60V
600W Max 20A Max
DC
AC
DC
AC
Note: Long press the AC+DC to reset WIFI and enter pairing mode;
Long press the main switch+DC to activate ECO mode;
DETAILS AND OPERATING INSTRUCTIONS OF THE DISPLAY
①
②
③
④
⑤
⑥
⑦
⑧
⑨
WIFI Connection
Bluetooth Connection
Current Switching Button of DC Charging
ECO Mode
Connection Of Expansion Battery Pack
Battery Level
UPS Function
DC Output/Input
AC Output/Input
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
Fan Working
AC/DC Input Wattage
Equipment Alarm
Temperature Alarm
Timer Swith On
Battery heating has been turned on
Battery Volume(voltage)
AC/DC Output Wattage
Remaining Hours Of Charge/Discharge
①
⑫
⑪
② ③ ④ ⑤ ⑥ ⑧⑦ ⑨ ⑩
⑱
⑰
⑬ ⑭ ⑮ ⑯
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
UPS FUNCTION
The E1000 LFP supports UPS function. It can provide the loads(such as computers, data centers, telecommunication
equipment) near-instantaneous(within 8~20ms) protection from unexpected power interruptions of the main power
supply.
Note: Not applicable to specific applications that need transfer time under 8ms, such as servers and workstations.
This UPS function only support protection for loads under 1800W(120V), we recommend that you only
connect one device at a time to avoid overload and thus result in protection failure.
PECRON is not responsible for any devices damage or loss of data resulting from failing to follow the instructions.
PACKING LIST
PECRON E1000 LFP *1 AC Cable *1 Single port XT60 to
MC4 solar charging cable *1
Cigarette lighter male head
to car charging cable XT60 * 1
Accessory bag * 1 User Instruction *1
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
ONLY CONNECT
ED TO BATTERY
EXTRA BATTERY PORT
20
3 5
4
2 1
AC INPUT 100~120V 15A MAX
Please use the official cascading cable with MJ32 socket when you want to connect
with 1 pcs of expansion battery pack (EP3000-48V) to avoid damage of the power
station.
Notes about cascade:
Cascading will be faster if there is only 10% difference between the main power
station and the expansion battery pack.
EXPANDABLE BATTERY
HOW TO CHARGE THE E1000 LFP BY AC ?
ONLY CONNECT
ED TO BATTERY
EXTRA BATTERY PORT
20
3 5
4
2 1
AC INPUT 100~120V 15A MAX
AC INPUT 100~120V 15A MAX
ONLY CONNECT
ED TO BATTERY
EXTRA BATTERY PORT
20
3 5
4
2 1
AC INPUT 100~120V 15A MAX
3 5
4
2 1
3 5
4
2 1
25%
EXTRA BATTERY PORT 1 EXTRA BATTERY PORT 2
50% 75% 100%
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
HOW TO CHARGE E1000 LFP BY USING STORAGE BATTERY
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
HOW TO CHARGE THE E1000 LFP BY VEHICLE ?
8A 20A
Attention: Do not adjust to 20A for use when using car charging because
the car cigarette lighter plug cannot hold 20A current!
Note: This spare part requires additional purchase.
11~60V-600W Max
8A 20A
DC INPUT
XT90
Adjusting the current to
20A via the DC charging
port adjustment button.
11~60V-600W Max
8A 20A
DC INPUT
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
11~60V-600W Max
8A 20A
DC INPUT
USING SOLAR PANELS TO CHARGE THE E1000 LFP
XT60 Charging Port: PV(operating voltage) range 11V~60V, 600W maximum; VOC(open circuit voltage) of solar
panel/array must be less than 60V, otherwise, it will damage the unit! Do not wire more than two 36V solar panels in
series, or more than four 18V solar panels in series. (18V/36V stands for Vmp of the solar panel)
XT60 Charging Port:
PV11V~60V-600W Maximum Input
USING SOLAR PANELS TO CHARGE THE E1000 LFP
Charging the E1000 LFP with one solar panel
MC4 Solar Charging Cable *1
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 60V, and the VMP should be greater than 11V.
DO NOT WIRE TWO SOLAR PANELS IN SERIES！
Use two solar panels in parallel to charge the E1000 LFP
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 60V, and the VMP should be greater than 11V.
11~60V-600W Max
8A 20A
DC INPUT
※ PV(XT60) Port Only work within 12V~60V Open Circuit voltage, exceeding 60V will damage the machine.
11~60V-600W Max
8A 20A
DC INPUT
MC4 Solar Charging Cable*1
Y Branch MC4 Charging Cable(+)*1
Y Branch MC4 Charging Cable(-)*1
(NOTE：This parallel charging cable sold separately)
1：What kind of battery is used in E1000 LFP? How long it can last?
E1000 LFP utilizes high quality UL certified automotive LiFePO4 battery, it can retain 80% of its original capacity at
3500 complete charge cycles.
2：What devices can E1000 LFP power?
Please note that the AC output port can only charge or power devices that operate at less than 1800W.
DC output port can only charge or power that operate at less than 12V-20A.
3：Can the E1000 LFP be used as UPS?
E1000 LFP supports UPS function with an automatic switchover time of 8~20ms.
4：How to calculate the E1000 LFP running time?
To estimate the operation time of the E1000 LFP, consider the load you're applying:
Operation time = Battery Capacity (Wh) x DoD x n ÷ (Load Power + E1000 LFP Self-con-sumption)
Note: DoD refers to the depth of discharge. E1000 LFP works at 95% DoD for longer battery life.n is the conversion
efficiency of the inverter, typically over 93% for E1000 LFP. The self-consumption of E1000 LFP is approximately 12W.
E.g. lf you have a 40W refrigerator, you can run it for about 34.7 hours.
Operation time =1024Wh x 95% x 93% ÷ (40W + 12W) ≈ 17 hours.
Please keep in mind that the estimated operation time provided is for referencepurposes and may vary based on
actual usage conditions. Factors such as lowtemperature and excessive loads can sianificantly affect the battery
capacity, leading toa reduction in the average operation time.
5：Does E1000 LFP have built-in MPPT charge controller?
Yes, there is one independent built-in MPPT controller; “XT60”port supports 11~60V(Max 600W) PV input.
6：Can the E1000 LFP be charged while discharging?
Yes, It can be charged and discharged at the same time. Under the non-UPS state, if uninterrupted use is required, the
average power of charging must be greater than the average power of electricity, otherwise the battery will eventually
run out and shut down.
7：How to store the E1000 LFP?
Please turn off the unit and then store it in a dry, ventilated place at normal room temperature. Do not place this unit
near water sources or a wet/moist environment. For long-term storage, it is recommended to discharge the battery to
30% every three months and recharge it to 60% to sustain the battery life.
FAQS
1、 Do not place the device near heat source, such as a fire or a heating furnace.
2、 Do not immerse in any liquid, or expose the unit to rain or wet conditions.
3、 Do not use the battery in a strong static electricity or electromagnetic environment.
4、 Do not disassemble or puncture the product with sharp objects in any way.
5、 Short circuits can be caused by: vermin or pests chewing through wires; water or other fluids coming into contact
with electrical wiring.
6、 It's prohibited to be used as car jump starter, only can be used to charge the car battery.
7、 Do not use accessories or parts other than those provided by PECRON. Please visit our website www.pecron.com or
reach our support team for a complete list of accessories and parts.
Please read the user manual thoroughly before using this product, and keep this manual in a safe place for future
reference. Failure to follow the instructions for proper set up, use, and care for the device can increase the risk of serious
personal injury, death, or property damage. Once you use this device, you are deemed to have understood, recognized
and accepted all terms and contents of this document. The user shall be responsible for his own actions and all
consequences arising from failure to use the device in accordance with the “User Manual”, or as authorized in PECRON's
current product literature.
In compliance with laws and regulations, PECRON reserves all rights for final explanation, and to change these terms and
conditions at any time without prior notice. In the event that any revisions are made, the revised terms and conditions
shall be posted on our website immediately, please visit our website to inform yourself of any changes.
DISCLAIMER
WARNING
8：Other issues to be noted.
Pay attention to the ponit that the product is without waterproof function and prevent water getting into it.
Pay attention to ventilation and heat dissipation when using, and keep good ventilation at the air inlet and outlet of
the product.
Do not use the product in special occasions (under the mine, gas station, etc.)
DISPOSAL
1、When conditions permit, please be sure to completely discharge the battery of this product, and then put the product
in the designated battery recycling box. This product contains batteries. Batteries are dangerous chemicals and are
strictly prohibited from being disposed of in ordinary trash. For details, please follow local laws and regulations on
battery recycling and disposal.
2、If the battery cannot be completely discharged due to the failure of the product itself, please do not dispose of the
battery directly in the battery recycling box, and contact a professional battery recycling company for further disposal.
3、The battery will not be able to start after being over-discharged, please dispose of it according to the principle of
disposal.
8、 When using this product, please strictly follow the ambient temperature for use in the user manual. If the temperature
is too high, the battery can potentially result in self-combustion and will burst into flames, which can cause
widespread damage. If the temperature is too low, the performance of the battery will be seriously degraded, and it
may even fail to meet the normal use requirements.
9、 Do not stack heavy objects on this product.
10、Do not block the air vents during use, or leave the device in a non-ventilated or dusty space.
11、Please avoid impacts, fall off, and violent vibration. Please turn off the device immediately and stop using it in the
event of major exterior impact. Please fasten the unit firmly during transportation to avoid vibration and impact.
12、In the event of immersing the device into the water accidently, please place the unit in a safe open area and keep
away from the unit until it is completely dry. The dried unit should not be reused and should be disposed of properly
according to the local regulation. If the device catches fire, use the fire extinguishing equipment in the following
recommended order: water or mist, sand, fire blanket, dry chemical, carbon dioxide fire extinguisher.
13、Please wipe it with a dry cloth to clean the surface of the device.
14、Please place this device with care to prevent the product from being damaged due to fall off. If the product is
damaged due to fall off, please turn off the unit immediately and place it in an open area, keep away from
combustibles and crowds, and dispose of in accordance with local laws and regulations.
15、Please store this device in a place out of reach of children and pets.
EXCLUSIONS
PECRON’s warranty does not apply to：
Misused, abused, modified, damaged by accident, or used for anything other than normal consumer
use as authorized in PECRON’s current product literature.
CUSTOMER SUPPORT：[email protected]
WEBSITE：www.pecron.com
