Model: T01A
Rugged Android Tablet
Quick Start Guide
Please do not hesitate to contact us if you have
any questions.
Official Customer Service
Email: [email protected]
Cell: +1 (626)438-1404
Note:
When contacting Tera support, please have the following
information available
1. Order number
2. Model number
Follow us:
Instagram: tera_digital
Youtube: Tera Digital
Twitter: Tera Digital
Facebook: Tera
You can visit our official website using the link below or
by scanning the QR code provided:
https://www.tera-digital.com
Report missing or damaged items?
+1(626)438-1404
https://www.tera-digital.com
Unpack Your Device
Getting Started
After you open the shipping carton containing the product,
take the following steps:
1.Check for damage during shipment. Report damage
immediately to us.
2.Make sure the items in the carton match your order.
3.Save the shipping container for later storage or shipping
Features
No. Feature Description
1 Scan Engine Capture barcodes
2 Volume +/- Increase/Descrease the volume
3 Power Button Press and release the Power Button to
turn on/off the terminal screen.
Press and hold the button for
approximately
3 seconds, and then release to view the
options menu
. Power Off
. Restart
. Emergency
4 F Button Trigger the scan engine
5 Front Camera 5 Megapixel
1
1234
5
7
8
9
10
12
14
16
15
13
11
6
About the Battery
The tablet uses a rechargeable Li-polymer battery as its power
source. Several factors determine the life of your battery, such
as display brightness, display timeout, input device, extreme
temperature, and usage. We recommend that you keep the
battery charged at all times to prevent data loss.
Charge the Battery Before Use
The device ships with a partially charged battery. Fully charge
the battery with the adapter before using your tablet for the
first time.
To charge the device, connect the AC adapter to the tablet and
an electrical outlet. The battery icon in the status bar indicates
charging status.
When setting up the computer, you should consider how apps,
services, and UI settings affect battery power consumption.
Set the screen tirmeout feature to turn off the screen sooner
and enable the Adaptive brightness featurre to minimize
battery use. Restrict unnecessary apps or services from
runningin the background to prevent battery drain.
6 Touch Panel Corning gorilla glass touch screen
7 Audio Jack 3.5mm
8 USB-C Port N/a
2
9 USB-A Port USB 2.0
10 DC Power Jack 5V/3A
11 Pogo Pin Connect docking charger
12 SIM Card Slot N/a
13 TF Card Slot Up to 512GB
14 Speaker 1W, Waterproof
15 NFC Antenna Exchange data
15 Rear Camera 13 Megapixel with flash
3
Specifications
Mechanical
Dimensions (WxLxH):
225.6x144.6x21.5 mm/8.88x5.69x0.85 in
Weight:
715g/25.22oz without battery
Battery:
Built-in Li-polyment Battery
8500mAh/3.7V, battery life 9 hours
(50% volume, 50% brightness, 1080P HD video playback)
Display:
8-in, 700 nits brightness; aspect ratio: 16:10;
1280 x 800 resolution
Audio:
Integrated Waterproof 1W speaker
Sensors:
Light Sensor *1, Compass Sensor *1,
Gyro Sensor*1, G-sensor*1
Camera:
Rear: 13 MP with Flash, Front 5 MP
Environmental
-20°C to 60°C (-4°F to 140°F)
Operating Temperature:
-30°C to 70°C (-22°F to 158°F)
Storage Temperature:
95% RH, non-condensing
Humidity:
1.2 m (4 ft), MIL-STD-810H
Transit Drop:
MIL-STD-810H
Vibration:
IP67
Environmental Sealing:
+/-8 kV direct; +/-15 kV air
ESD:
System Architecture
MT6789 2*A76 2.2GHz, 6*A55 2.0GHz
Processor:
Android 12 GMS
Operating System:
RAM 8GB LPDDR4; ROM 128GB
Memory:
Up to 512GB
Storage Expansion:
4
Data Collection
Zebra SE4710
Scan Engine:
ISO/IEC 14443A, read range: 3 cm to 5 cm/ 1.18 in to 1.97 in
NFC:
Wireless Connectivity
WIFI 802.11(a/b/g/n/ac) Dual-band 2.4G+5WIFI
WLAN:
2, 3, 5, 8
GSM:
1, 2, 5, 8
WCDMA:
Bands B1, B2, B3, B4, B5, B7, B8, B20, B28A, B28B
LTE (FDD):
Bands 38, 39, 40, 41N
LTE (TDD):
10 m/ 32.81 ft
Bluetooth：5.2 (BLE) class1, transmission range:
GSP, Glonass, Beidou
GPS:
I/O Ports:
USB 2.0 *1 USB Type C *1
TF Card Slot *1
Power Jack (DC 5V 3A) *1
SIM Card Slot*1
Audio Jack *1
12-Pin Pogo Pin*1
