User Manual | GTF1130
Digital Air Fryer Oven
For customer service visit www.gourmia.com or call 888.552.00332
Contents
Congratulations 3
Important Safeguards 4
Before First Use 6
Know Your Air Fryer Oven 8
Accessories 8
Display and Control Panel 9
Using Your Air Fryer Oven 10
Stop / Cancel Cooking 10
Troubleshooting 10
Preset Chart 11
Using the Popcorn Preset 14
Cooking Tips 14
Cleaning & Maintenance 15
Warranty & Service 16
All rights reserved. No portion of this manual may be reproduced by any means whatsoever without written permission
from The Steelstone Group, except for the inclusion of quotations in a media review. Although every precaution has been
taken in the preparation of this manual, The Steelstone Group assumes no responsibility for errors or omissions. Nor is
any liability assumed for damages resulting from the use of the information contained herein. Although every effort has
been made to ensure that the information contained in this manual is complete and accurate, The Steelstone Group
is not engaged in rendering professional advice or services to the individual consumer; further, The Steelstone Group
shall not be held responsible for any loss or damage allegedly arising from any information or suggestions in this manual.
Model: GTF1130 | © 2024 Gourmia | 1.0
The Steelstone Group Brooklyn, NY | Gourmia.com
3User Manual | Digital Air Fryer Oven | GTF1130
Here at Gourmia, our one and only goal is to make sure nutritious and delicious
meals are always a practical possibility no matter how fast-paced your life is.
Whether you’re in need of a hearty breakfast, a mid-day snack, or a satisfying
supper, our dependable, easy-to-use appliances are designed to work for you
while you work your way through your busy day.
This manual provides an overview and instructions on all the oven’s functions
and features, along with directions for assembling, operating, cleaning, and
maintaining your appliance. Please read all safety instructions before getting
started. Keep this manual handy for future use and review.
Our team is available to help with any and every question you might have about
your new oven. We’re excited for you and want you to get the most out of your
purchase—so whether you need assistance with setup or guidance on which
features to enable for which foods, we’re happy to walk you through it, step by
step.
Happy and easy cooking!
Congratulations on the purchase of your
Digital Air Fryer Oven from Gourmia!
@gourmia
We’d love to hear about the delicious dishes you’re creating! Share your
thoughts, recipes, and photos with us.
Important Safeguards
For customer service visit www.gourmia.com or call 888.552.00334
1. This appliance is not intended
for use by children or persons
with reduced physical, sensory,
or mental capabilities, or lack of
experience and knowledge, unless
they have supervision.
2. Close supervision is necessary
when any appliance is used by or
near children. Children should be
supervised to ensure that they
do not play with the appliance.
Cleaning and user maintenance
should not be done by children
unless they are older than 8 and
supervised.
3. Check if the voltage indicated
on the appliance corresponds to
the local main voltage before you
connect the appliance.
4. Always ensure the appliance is
fully assembled before plugging it
into a wall outlet and turning it on.
5. Do not use the appliance if the
plug, main cord, or appliance itself
is damaged or has malfunctioned.
Return the appliance to the
nearest authorized service
facility for examination, repair, or
adjustment.
6. Never connect this appliance
to an external remote-control
system or timer to avoid a
hazardous situation.
7. Do not use an outlet below the
countertop’s surface. The cord
should always be behind and away
from the appliance.
8. Do not let the cord hang over the
edge of the counter or table, nor
let it touch hot surfaces.
9. Do not plug in the appliance or
operate the controls with wet
hands.
10. Always ensure the plug is inserted
into the outlet properly.
11. Do not leave the appliance
unattended when plugged in.
12. Place the appliance on a stable,
level, and heat-resistant surface.
Ensure that the area is clean and
dry. NEVER place the appliance
on or near gas or electric burners
and ovens even if the burner or
oven is turned off.
13. Do not place the appliance
against a wall or against other
appliances. Leave at least 4
inches of free space on the back
and sides, and 4 inches of free
space above the appliance.
14. Do not place anything on top of
the appliance when in use.
15. A fire may occur if the oven is
covered or touching flammable
material, including curtains,
draperies, tablecloths, walls, and
the like, when in operation. Do
not place the oven on or near
combustible materials.
16. To avoid overheating or the
risk of fire: NEVER cover the
crumb tray or the oven walls with
aluminum foil or parchment paper.
Important Safeguards
Read all instructions before using the electric appliance.
For household use only.
The following basic precautions should always be followed:
Save These Instructions
5User Manual | Digital Air Fryer Oven | GTF1130
17. You may use foil or parchment
paper as a liner on the baking
pan. However, cut the liner so it
is fitted to the exact size of the
baking pan and is not raised above
or hanging below the pan, to
ensure the liner is not close to the
heating elements.
18. NEVER leave the liner on the
baking pan during preheating and
cooking, unless there is food on
the liner to weigh it down and
keep it safely secured in place.
19. Do not use the appliance for any
other purpose than described in
this manual. The use of accessory
attachments not recommended
by the appliance manufacturer
may cause injuries.
20. Do not place any of the following
materials in the oven: paper (other
than parchment paper), cardboard,
plastic, and the like. Extreme
caution should be exercised when
using containers constructed of
anything other than metal or glass.
21. Oversized foods or metal utensils
must not be inserted into the
toaster oven, as they may create a
fire or risk of electric shock.
22. During cooking, hot steam is
released through the air vents.
Keep your hands and face at a
safe distance from the steam and
from the air vents. Be careful of
hot steam when you open the
doors of the appliance.
23. Do not touch hot surfaces.
Use handles and protective
equipment to avoid burns. Use
extreme caution when removing
accessories or disposing of hot
grease.
24. Extreme caution must be used
when moving an appliance
containing hot oil or other hot
liquids.
25. Extreme caution should be
exercised when using containers
constructed of materials other
than metal or glass.
26. Immediately unplug the appliance
if you see dark smoke coming
from the appliance.
27. After using the appliance, avoid
contact with the hot metal inside.
28. Always attach plug to appliance
first, then plug cord into the wall
outlet. To disconnect, turn any
control to ″off″, then remove plug
from wall outlet.
29. Unplug from outlet when not in
use and before cleaning. Allow the
appliance to cool before cleaning.
30. To protect against electric shock,
do not immerse the cord, plug, or
appliance in water or other liquid.
31. Do not clean with metal scouring
pads. Pieces can break off the pad
and touch electrical parts, creating
a risk of electric shock.
32. Do not store any materials
other than manufacturer’s
recommended accessories in this
oven when not in use.
33. Do not use outdoors.
34. Do not use in moving vehicles or
boats.
35. For household use only.
Save These Instructions
Before First Use
For customer service visit www.gourmia.com or call 888.552.00336
Before First Use
1. Remove and discard all packaging material, labels, and tape from the oven.
2. Thoroughly clean air fry basket, oven rack, baking pan, and crumb tray
with hot water, dishwashing liquid, and a non-abrasive sponge. Dry all
parts before use.
3. Wipe the inside and outside of the oven with a moist cloth.
Cord and Plug Safety
1. A short power-supply cord is provided to reduce risk of becoming
entangled in or tripping over a longer cord.
2. Extension cords may be used if care is exercised in their use.
3. If an extension cord is used:
• The marked electrical rating of the extension cord should be at
least equal to the electrical rating of the appliance.
• The longer cord should be arranged so that it will not drape over
the countertop or tabletop where it can be pulled on by children
or tripped over.
Electrical Polarized Plug
This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, the plug is
intended to be used by inserting it into the electrical outlet
only one way. If the plug does not fit securely into the
outlet, reverse the plug and re-insert. If it still does not fit,
contact a qualified electrician for assistance. Do not modify
the plug in any way.
POWER
AC120V~ 60Hz 1,000W
Before First Use
7User Manual | Digital Air Fryer Oven | GTF1130
WARNING:
DO NOT place the oven against a wall or against other appliances. Leave
at least 4 inches of free space on the back and sides, and 4 inches of
free space above the oven.
To avoid the risk of fire:
DO NOT place anything on top of the oven.
NEVER cover the crumb tray or the oven walls with aluminum foil or
parchment paper.
You may use foil or parchment paper as a liner on the baking pan,
however:
• Cut the liner so it is fitted to the exact size of the baking pan and is
not raised above or hanging below the pan, to ensure the liner is not
close to the heating elements.
• NEVER leave the liner on the baking pan during preheating and
cooking, unless there is food on the liner to weigh it down and keep
it safely secured in place.
When cooking greasy or drippy foods, use the baking pan instead of the
air fry basket
ALWAYS use CAUTION when opening the door; hot steam may escape!
The oven, accessories and food will be hot! DO NOT touch hot
surfaces. Use oven mitts when inserting or removing food from the oven.
Using Oil
When spraying food for a
crispier finish, we recommend
using cooking oil instead of
cooking spray, as the latter may
damage the accessories and
reduce the life of the appliance.
The oven may produce smoke
if you use oil and cook food at
a hotter setting than what is
recommended.
NEVER spray the heating elements or oven walls with oil.
Not RecommendedRecommended
Cooking Spray
Oil Mister / Spray Bottle
Know Your Air Fryer Oven
For customer service visit www.gourmia.com or call 888.552.00338
Accessories
Air Fry Basket Oven Rack
Baking Pan Crumb Tray
NOTE: Always ensure the crumb tray is in the bottom of the oven during cooking.
Display
Top Rack
Position
Control
Panel
Know Your Air Fryer Oven
Bottom Rack
Position
Center Rack
Position
Know Your Air Fryer Oven
9User Manual | Digital Air Fryer Oven | GTF1130
Display and Control Panel
Temperature /
Time
Air Fry Presets
Presets
Decrease
Temperature /
Time
Increase
Temperature /
Time
To toggle between
displaying
temperature in
Fahrenheit or Celsius,
press and hold TEMP
/ TIME
Stop / Cancel
Power Icon
Start
Using Your Air Fryer Oven
For customer service visit www.gourmia.com or call 888.552.003310
Using Your Air Fryer Oven
1. Tap the desired preset
2. Tap the + and - icons to adjust temperature or shade level.
3. Tap TEMP / TIME then tap the + and - icons to adjust the time.
For the TOAST and BAGEL presets: Time adjustment is not available
NOTE: See the PRESET CHART on pages 11-13 for each presets' settings and
which accessory to use.
For presets without preheat: Place food into the air fryer oven and tap START to
begin cooking.
4. Tap START. The display will show Preheat ( Pre Heat) and the air fryer
oven will begin preheating. Once preheated, the air fryer oven will beep
and the display will show Add Food ( Add Food).
5. Open the door, carefully place food into the air fryer oven, and close the
door. The cook time will begin automatically. When the cook time has
elapsed, the air fryer oven will beep and the display will show End ( End).
Stop / Cancel Cooking
Tap START / CANCEL to pause cooking.
Tap START to resume cooking.
Tap START / CANCEL twice to cancel cooking.
Troubleshooting
Problem Solution
Food is not cooked Use smaller batches for more even cooking
Raise temperature and continue cooking.
Food is not browned evenly Turn over food halfway through cooking process
Cook similar sized foods together
White smoke is coming out
of the air fryer oven
Clean the air fryer oven and accessories after each
use to remove greasy residue
Preset Chart
11User Manual | Digital Air Fryer Oven | GTF1130
Preset Chart
* Note: When cooking greasy or drippy foods, use the baking pan instead of the air fry basket.
PRESET
AIR FRY FRIES WINGS SNACKS
PREHEAT Yes Yes Yes Yes
TIME
RANGE
1 - 60 MIN 1-60 MIN 1-60 MIN 1-60 MIN
TEMP
RANGE
170 °F —
450 °F
170 °F —
450 °F
170 °F —
450 °F
170 °F —
450 °F
ACCESSORY
RACK
POSITION
CENTER CENTER CENTER CENTER
FAN
OR
See Note Below
Preset Chart
For customer service visit www.gourmia.com or call 888.552.003312
Preset Chart
PRESET
TOAST BAKE ROAST BAGEL
PREHEAT No Yes Yes No
TIME
RANGE
N/A 1-99 MIN 1-69 MIN N/A
TEMP
RANGE
1 - 7
SHADES
170 °F —
450 °F
170 °F —
450 °F
1 - 7
SHADES
ACCESSORY
RACK
POSITION
CENTER CENTER CENTER
TOP OR
CENTER
FAN
NO FAN NO FAN NO FAN
Preset Chart
13User Manual | Digital Air Fryer Oven | GTF1130
CONVECTION
BAKE
BROIL DEHYDRATE POPCORN KEEP WARM
Yes Yes No Yes No
1-60 MIN 1-60 MIN
30 MIN —
72 HRS
1 - 15 MIN 1-99 MIN
170 °F —
450 °F
450 °F
90 °F —
170 °F
300 °F —
450 °F
90 °F —
200 °F
CENTER TOP CENTER
Upside Down
Air Fry Basket
Center
Baking Pan
Center
CENTER
NO FAN NO FAN
+
See How to Use
Popcorn Preset
p.14
How to Use Popcorn Preset
For customer service visit www.gourmia.com or call 888.552.003314
How to Use Popcorn Preset
1. Tap the POPCORN preset.
Optional: Adjust the temperature and time.
2. Tap START
The display will show Preheat ( Pre Heat) and the air fryer oven will begin
preheating.
3. Pour 1/4 a cup of unpopped popcorn kernels into the baking pan.
4. Turn the air fry basket upside down and place it on top of the baking pan.
Once preheated, the oven will beep and the display will show Add Food
( Add Food)
5. Open the door, carefully insert the
baking pan along with the upside
down air fry basket into the center
rack position, and close the door.
The cook time will begin automatically.
When the cook time has elapsed, the
air fryer oven will beep and the display
will show End ( End)
6. Let sit one to two minutes until
popping has stopped before opening the door. Carefully remove the
popcorn and place it on a heat-resistant surface.
• Spread out food in single layer; do not overcrowd.
• When following instructions on item packaging or a standard recipe,
reduce the cooking temperature by 25°F, check food for desired
doneness a few minutes before cook time elapses, and cook a little
longer if necessary.
• Always ensure raw proteins reach food-safe temperature.
Cooking Tips
For an extensive list of foods and their ideal amounts, temperature and time
settings, along with preparation notes, see the Air Fry Cooking Chart and
Dehydrate Chart on pages 48 through 51 of the Gourmia Recipe Book
Cleaning and Maintenance
15User Manual | Digital Air Fryer Oven | GTF1130
Cleaning and Maintenance
Cleaning
• Clean and dry the appliance and accessories after each use.
• Clean the accessories with hot water, mild liquid soap, and a non-abrasive
sponge.
• Wipe the inside and outside of the oven with a damp cloth or non-abrasive
sponge.
• The air fry basket and oven rack are top rack dishwasher safe.
Storage
• Unplug the appliance and let it cool down.
• Make sure all parts are clean and dry.
• Store the appliance in a clean and dry place.
Environment
Do not discard the appliance with normal household waste at the end of its life;
instead, hand it in at an official collection point for recycling. Doing so will help
to preserve the environment.
Guarentee and Service
If you need service or information or if you have a problem, please visit
www.gourmia.com or contact your distributor.
WARNING:
NEVER immerse cord, plug, or oven in water or any
other liquid.
Unplug the appliance and allow it to cool completely
before cleaning.
Do not use metal kitchen utensils or abrasive cleaning
material to clean the unit or the accessories.
For Customer Service, Questions or Comments
Visit gourmia.com
Email [email protected]
Call 888.552.0033
Mon-Thu 9:00 a.m. to 6:00 p.m. Et
Fri 9:00 a.m. to 3:00 p.m. Et
Languages: English, Spanish, French
We’d love to hear from you!
888.552.0033
Warranty and Service
This Limited Warranty is for one full year from the date of purchase and
requires proof of purchase from an authorized seller. It is applicable to the
original purchaser only and is not transferable to a third party user. Repair or
replacement of defective parts is solely at Gourmia’s discretion. In the event
that repair isn’t possible, Gourmia will replace the product/part. If product
repair/replacement won’t suffice, Gourmia has the option of refunding the cash
value of the product or component returned.
Product defects not covered under the Warranty provisions include normal
wear and damage incurred from use or accidental negligence, misuse of
instruction specifications, or repair by unauthorized parties. Gourmia is
not liable for any incidental or consequential damages incurred by such
circumstances.
Only valid within the United States.
Register your product at
www.gourmia.com/warranty
