Wireless BT Portable PA Speaker
Portable PA & Karaoke Party Audio Speaker
with Built-in Rechargeable Battery, Wireless microphone,
Speaker stand, Flashing Party Lights, MP3/USB/FM Radio
WARNING
1. DO NOT place objects on top of the device, as objects may
scratch the device.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT insert any foreign objects into the device.
4. DO NOT expose the device to strong magnetic or electrical eld.
5. DO NOT use the device in the rain
6. Please check with your Local Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the device. Only a certied service
technician should perform repair.
8. The device has apertures to disperse heat. DO NOT block the
device ventilation, the device may become hot and malfunction
as a result.
PPHP822NSM CONTROL BOARD FUNCTIONS
1. Power Switch
2. Master volume control
3. DC 5V input jack/Charge LED indicator, red color is on charge mode, light o is
full charge mode
4. Bass volume control knob
5. Treble volume control knob
6. Microphone Echo control knob
7. USB and micro SD memory card input jack
8. 3.5MM AUX input jack
9. 6.5MM microphone input jack
10. LED light switch button
11. Microphone volume control knob
12. Display screen
13. Mode button: Short press to select BT, FM, AUX, USB, SD mode
14. Previous
15. Play/Pause/Press and hold for TWS function
16. Next
17. Short press to start recording, and press again to save and play recording.
Press and hold to play recorded les, press and hold again to quit recording.
18. Microphone priority button: When playing recorded les, press and hold to
delete current recording.
www.PyleUSA.com
2
www.PyleUSA.com
3
7
9
PPHP152NSM CONTROL BOARD FUNCTIONS
1. Power Switch
2. Master volume control
3. DC 15V input jack/Charge LED indicator, red color is on charge mode, light o is
full charge mode
4. Display screen
5. Equalizer control panel
6. Microphone volume control knob
7. USB and Micro SD Memory Card Slot
8. 3.5MM AUX input jack
9. 6.5MM guitar input jack
10. 6.5MM microphone input jack
11. LED light switch
12. Guitar volume control knob
13. Mode button: Short press to choose BT, FM,AUX, USB, SD mode
14. Previous
15. Play/Pause/press and hold for TWS function
16. Next
17. Short press to start recording, and press again to save and play recording.
Press and hold to play recorded les, press and hold again to quit recording.
18. Microphone priority button: When playing recorded les, press and hold to
delete current recording.
19. Microphone Echo, Mic Delay, Mic Bass, Mic Mid-range & Mic Treble control knobs
PPHP1022NSM - PPHP122NSM CONTROL BOARD FUNCTIONS
1. Power Switch
2. Master volume control
3. DC 9V input jack/Charge LED indicator, red color is on charge mode, light o is
full charge mode
4. Bass volume control knob
5. Treble volume control knob
6. Microphone Echo control knob
7. USB and micro SD memory card input jack
8. 3.5MM AUX input jack
9. 6.5MM microphone input jack
10. LED light switch button
11. Microphone volume control knob
12. Display screen
13. Mode button: Short press to select BT, FM, AUX, USB, SD mode; Press & hold to
start power saving mode, press & hold again to quit power saving mode.
14. Previous
15. Play/Pause/Press and hold for TWS function
16. Next
17. Short press to start recording, and press again to save and play recording.
Press and hold to play recorded les, press and hold again to quit recording.
18. Microphone priority button: When playing recorded les, press and hold to
delete current recording.
www.PyleUSA.com
4
www.PyleUSA.com
5
9
7
Micro SD
7
19
9
REMOTE CONTROL FUNCTIONS
TWS FUNCTION
For increase sound eect, our unit provides TWS function as follows:
Step-1: Turn ON BT mode on your device and connect the machine.
Step-2: Press and hold each control board “TWS” button more than 3's, and you will
see "ON" on display, unit will start to connect the other unit automatically,
now you can enjoy stereo sound, and adjusting one unit volume will aect
the other unit.
Remark:
1. After connection, press and hold again one of control board "TWS" button more
than 3's, you will see "OFF" on display, unit's TWS dis-connection.
TROUBLESHOOTING
Wireless BT Connectivity:
• Built-in BT for Wireless Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
• Smartphones, Tablets, Laptops, Computers, etc.
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless Range: Up to 32’ ft.
www.PyleUSA.com
6
www.PyleUSA.com
7
1. Power: Used to turn on/o the MP3
player power.
2. MODE: Used to switch the AUX/USB/BT/
Radio
3. Mute button
4. In FM mode, press to search radio station
automatically and save.
5. Next song in USB/In FM mode, short
press to select saved radio station.
6. Previous song in USB//In FM mode, short
press to select last frequency, press and
hold to fast forward frequency.
7. EQ solution
8. Repeat song
9. Increase volume
10. Decrease volume
11. Play/Pause/In FM Mode, press to select
saved radio station.
12. Choose song number directly/In FM
mode, choose FM frequency directl
This product can expose you to a chemical or group of chemicals, which may include
“Lead and lead compounds” which is known in the state of California to cause cancer, birth
defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
1. The audio format in the USB
is incorrect.
2. Improper operation has caused
a process disorder.
3. USB disc is disconnected.
1. Convert audio format into Mp3
format.
2. Reboot the machine.
3. Insert USB disc properly.
MP3
does not
play
Fault
Possible Cause
Solution
No sound
Distortion
of sound
Karaoke
does not
work
1. No input sound source.
2. Volume is too low.
1. Volume too high.
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on.
3. Microphone volume knob is at
the lowest position.
1. Use a better music signal.
2. Adjust volume.
1. Turn down the volume.
2. If speaker is damaged, repair
or replace it.
1. Plug microphone properly into
the socket.
2. Turn on microphone switch.
3. Adjust microphone volume
properly.
Features:
• True Wireless Stereo System
• Portable Speaker System
• High-Powered PA Loudspeaker Style
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
• Built-in Rechargeable Battery
• FM Radio with Digital LED Display
• Connect & Stream Audio from External Devices
• Aux (3.5mm) Input Connector Jack
• USB Flash Memory Reader
• Micro SD Card Reader
• 6.5mm Microphone input
• Battery Level LED Indicator Lights
• Recording function
• Microphone Priority function
• Echo adjust knob
• Bass & Treble adjust knobs
• With wireless microphone
• With speaker stand
• Rugged & Durable Molded Cabinet Design
• Convenient Trolley & Wheels
• For Indoor/Outdoor Use
Technical Specs:
• Material: Polypropylene (PP)
• Max Power Output: 480 Watt Max
• Sound System: 8’’ -inch Subwoofer + 1” Tweeter
• USB Interface Type: 2.0
• Digital Audio File Support: MP3
• Remote Control Battery Operated, Two Pieces AAA Battery (Not Included)
• Battery Life: Up to 3 Hours (Charge Time: Approx. 5Hours)
• Rechargeable Battery: 3.7V, 3600mAh – 13.32Wh
• Power Supply: 120/240V, Switchable (5V/2A Power Adapter)
• Dimensions (L x W x H): 9.3’’ x 7.8’’ x 14.3’’ -inches
Features:
•
True Wireless Stereo System
• Portable Speaker System
• High-Powered PA Loudspeaker Style
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
• Built-in Rechargeable Battery
• FM Radio with Digital LED Display
• Connect & Stream Audio from External Devices
• Aux (3.5mm) Input Connector Jack
• USB Flash Memory Reader
• Micro SD Card Reader
• 6.5mm Microphone input
• Battery Level LED Indicator Lights
• Recording Function
• Microphone Priority Function
• Microphone Echo Adjust Knob
• Bass & Treble Adjust Knobs
• Power saving mode to play music longer time
• With wireless microphone
• With speaker stand
• Rugged & Durable Molded Cabinet Design
• Convenient Trolley & Wheels
• For Indoor / Outdoor Use
Technical Specs:
• Construction Material: Polypropylene (PP)
• Max Power Output: 680 Watt Max
• Sound System: 10’’ -inch Subwoofer + 1” Tweeter
• USB Interface Type: 2.0
• Digital Audio File Support: MP3
• Remote Control Battery Operated, Two Pieces AAA Battery (Not Included)
• Battery Life: Up to 3.5 Hours (Charge Time: Approx. 5 Hours)
• Rechargeable Battery:7.4V, 3600mAh – 26.64 Wh
• Power Supply: 120/240V, Switchable (9V/1.5A Power Adapter)
• Product Dimensions (L x W x H): 11.8’’ x 9.4 ’’ x 19.3 ’’ -inches
www.PyleUSA.com
8
www.PyleUSA.com
9
PPHP822NSM
8’’ Wireless BT Portable PA Speaker
What's in the Box:
• PA Speaker System
• Remote Control
• Power Adapter
• Wireless Microphone
• Speaker Stand
PPHP1022NSM
10’’ Wireless BT Portable PA Speaker
What's in the Box:
• PA Speaker System
• Remote Control
• Power Adapter
• Wireless Microphone
• Speaker Stand
Features:
•
True Wireless Stereo System
• Portable Speaker System
• High-Powered PA Loudspeaker Style
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
• Built-in Rechargeable Battery
• FM Radio with Digital LED Display
• Connect & Stream Audio from External Devices
• Aux (3.5mm) Input Connector Jack
• USB Flash Memory Reader
• Micro SD Card Reader
• 6.5mm Microphone input
• Battery Level LED Indicator Lights
• Recording Function
• Microphone Priority Function
• Microphone Echo Adjust Knob
• Bass & Treble Adjust Knobs
• Power saving mode to play music longer time
• With wireless microphone
• With speaker stand
• Rugged & Durable Molded Cabinet Design
• Convenient Trolley & Wheels
• For Indoor/Outdoor Use
Technical Specs:
• Construction Material: Polypropylene (PP)
• Max Power Output: 880 Watt Max
• Sound System: 12’’ -inch Subwoofer + 1” Tweeter
• USB Interface Type: 2.0
• Digital Audio File Support: MP3
• Remote Control Battery Operated, Two Pieces AAA Battery (Not Included)
• Battery Life: Up to 3 Hours (Charge Time: Approx. 5 Hours)
• Rechargeable Battery:7.4V, 3600mAh – 26.64 Wh
• Power Supply: 120/240V, Switchable (9V/1.5A Power Adapter)
• Product Dimensions (L x W x H): 14 ’’ x 11.4 ’’ x 21.7 ’’ -inches
Features:
•
Equalizer functions that can adjust the sound
frequency according to your preference
• True Wireless Stereo System
• Portable Speaker System
• High-Powered PA Loudspeaker Style
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
• Built-in Rechargeable Battery
• FM Radio with Digital LED Display
• Connect & Stream Audio from External Devices
• Aux (3.5mm) Input Connector Jack
• USB Flash Memory Reader
• Micro SD Card Reader
• 6.5mm Microphone input
• 6.5mm Guitar input
• Battery Level LED Indicator Lights
• Recording Function
• Microphone Priority Function
• Microphone Echo & Delay Adjust Knobs
• Microphone Bass & Mid-range & Treble Adjust Knobs
• Microphone and Guitar volume knobs
• With wireless microphone
• With speaker stand
• Rugged & Durable Molded Cabinet Design
• Convenient Trolley & Wheels
• For Indoor / Outdoor Use
Technical Specs:
• Construction Material: Polypropylene (PP)
• Max Power Output: 1680 Watt Max
• Sound System: 15’’ -inch Subwoofer + 1” Tweeter
• USB Interface Type: 2.0
• Digital Audio File Support: MP3
• Remote Control Battery Operated, Two Pieces AAA Battery (Not Included)
• Battery Life: Up to 3 Hours (Charge Time: Approx. 5 Hours)
• Rechargeable Battery:12.8V, 6000mAh – 76.8 Wh
• Power Supply: 120/240V, Switchable (15V Power Adapter)
• Dimensions (L x W x H): 17.8’’ x13.3’’ x 27.4’’ -inches
www.PyleUSA.com
10
www.PyleUSA.com
11
PPHP122NSM
12’’ Wireless BT Portable PA Speaker
What's in the Box:
• PA Speaker System
• Remote Control
• Power Adapter
• Wireless Microphone
• Speaker Stand
PPHP152NSM
15’’ Wireless BT Portable PA Speaker
What's in the Box:
• PA Speaker System
• Remote Control
• Power Adapter
• Wireless Microphone
• Speaker Stand
