PRODUCT INFORMATION:
Read these instructions carefully before
installing, operating, servicing or repairing this tool.
Keep these instructions in a safe accessible place.
Important
DO NOT DISCARD – GIVE TO USER
WARNING
WARNING
MADE IN CHINA
Study, understand and follow all instructions provided with this
product. Read these instructions carefully before installing,
operating, servicing or repairing this tool. Keep these instructions
in a safe accessible place.
INTENDED USE OF THE TOOL
This tool set is designed to remove and replace ball
joints. Do not use this tool outside of the designed intent.
Never modify the tool for any other purpose or use.
• Normal use of this product is likely to expose the user to
dust and/or microscopic particles containing chemicals
known to the State of California to cause cancer, birth
defects or other reproductive harm. Always wear appropriate
safety equipment and clothing when using this product.
Study, understand and follow all instructions provided with
this product. Failure to read and follow all warnings and
operating instructions may result in damages and serious
injury or death.
• Always wear ANSI approved goggles when using this
product. (Users and Bystanders).
• Never use this tool for any application other than for which
it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with accessories
not designed for it could result in serious injury or death.
• Always select the correct accessories of the correct size
and design for the job that you are attempting to perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
• Do not begin repairs without assurance that vehicle is in
secure position, and will not move during repair.
LIFETIME WARRANTY
The manufacturer warrants this product to the original user against defective material or
workmanship for lifetime from the date of purchase.
The manufacturer reserves the right to determine whether the part or parts failed because of
defective material, workmanship or other causes. Failures caused by accident, alteration,
or misuse are not covered by this warranty.
The manufacturer, at its discretion, will repair or replace products covered under this warranty
free of charge. Repairs or replacements of products covered under this warranty are warranted
for the remainder of the original warranty period.
The manufacturer or its authorized service representatives must perform all warranty repairs.
Any repair to the product by unauthorized service representatives voids this warranty. The
rights under this warranty are limited to the original user and may not be transferred to
subsequent owners.
This warranty is in lieu of all other warranties, expressed or implied, including warranties of
merchantability and fitness for a particular purpose. Some states do not allow the exclusion or
limitations of incidental or consequential damages, so the above limitations may not apply to you.
Unpacking
When unpacking, check the parts diagram and part number
listing on page 6 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.
• Removes and replaces ball joints
• Remove and replace universal joints with
C - Frame press
• Work on press-fit upper and lower ball joints on
most GM, Ford, and Dodge 2 and 4 wheel drive
pickups, vans and sport utility vehicles through
1997 with this set that includes all the receiver
tubes and removing/installing adapters needed
• Live center forcing screw plug also included
• Blow molded case for easy storage and transport
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
Page 1
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
Control
Arm
Ball
Joint
Installing Adaper
Receiving Tube
Removing Adapter
Installing Adapter
Ball Joint
Receiving Tube
Control
Arm
Removing Adapter
OPERATING INSTRUCTIONS
Brake Anchor Pin Removal and Installation
1. Remove all lock ring retainers from the brake anchor pins.
2. Position the C - Frame press over the brake spider as shown in Figure 1.
3. Tighten the forcing screw until the anchor pin is removed.
"U" Joint Assembly and Disassembly
The basic C - Frame press is used to service the "U" joints on most cars and
light trucks. The "U" joints can be serviced either on or off the vehicle.
Disassembly
1. Remove any external and/or internal lock rings.
2. Position the C - Frame press around the drive shaft yoke, and
tighten the forcing screw until the first bearing is removed.
3. Reposition the C - Frame and remove the second bearing.
Assembly
1. Clean all dirt and oil from the yoke area.
2. Align the replacement bearing the C - Frame press as straight
as possible over the yoke. Press the replacement bearing into
the yoke, and reassemble the external/internal lock ring.
3. Reposition the C - Frame press and second replacement bearing
as straight as possible over the yoke, and press the bearing into
the yoke. Reassemble external/internal lock ring.
Ball Joint Removal and Installation
This tool set is designed for use on all cars and light trucks that
have press-fit type ball joints. It will help the user remove and
install ball joints without the need to remove the control arm from
the vehicle.
NOTE: Some cars and light trucks may have the upper ball joint
spot-welded to the control arm. The weld must be cut before
attempting to remove the ball joint.
Removal (Item numbers refer to the parts list on page 6)
1. Assemble the ball joint press over the control arm as shown
in Figure 3. Select the correct size receiving tube, and position
it under the vehicle ball joint as shown.
2. Tighten the forcing screw until the receiving tube contacts the control
arm. Check the alignment of all tooling and components, and continue
tightening the forcing screw until the ball joint is removed.
Installation
1. Clean the control arm and coat the I.D. with a suitable lubricant.
2. Insert the replacement ball joint as straight as possible into the
vehicle control arm.
3. Assemble the ball joint press components as shown in Figure 4.
Position the receiving tube, and tighten the forcing screw. Check
the alignment of all tooling and components, and continue tightening
the forcing screw until the ball joint is firmly seated.
Figure 1
Figure 2
Figure 3
Figure 4
Page 2
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
CONJUNTO MAESTRO DE
ADAPTADORES DE SERVICIO
Page 3
Este conjunto de herramientas está diseñado para extraer y
sustituir junturas o articulaciones de las rotulas. No utilice esta
herramienta para otra cosa que no sea el propósito para lo que
ha sido diseñada. Nunca modifique la herramienta para cualquier
otro propósito o uso.
• Quita y reemplaza las articulaciones de las rótulas
• Retire y vuelva a colocar las junturas o articulaciones
con la prensa en forma de "C"
• Trabaja en encaje de presión superior y rótulas
inferiores en la mayoría de GM, Ford y Dodge de 2 y
4 ruedas motrices en camionetas, y vehículos utilitarios
deportivos hasta 1997 el conjunto incluye todos los
tubos receptores y adaptadores para la extracción o
instalación necesarios
•Tornillo central de fuerza de presión incluido
• Estuche plástico moldeado para facilitar el
almacenamiento y transporte
ADVERTENCIA
Estudie, entienda y siga todas las instrucciones que se proveen
con este producto. Lea las instrucciones detenidamente antes de
instalar, operar, dar servicio o reparar esta herramienta.
Guarde estas instrucciones en un lugar seguro y accesible.
APLICACIÓN DE LA HERRAMIENTA
Precaución: Para ayudar a evitar lesiones a las personas
ADVERTENCIA
• El uso normal de esta herramienta puede exponer al
usuario al polvo o a partículas microscópicas que contienen
sustancias químicas que se conocen en el estado de
California por causar cáncer, defectos del nacimiento u
otros daños reproductivos. Siempre use equipo y ropa de
seguridad adecuados para trabajar con esta herramienta.
Lea, comprenda y siga todas las instrucciones incluidas
con esta herramienta. Omitir la lectura y el no seguir todas
las advertencias e instrucciones de operación puede traer
como consecuencia daños y lesiones graves o
hasta la muerte.
• Siempre use guantes del tipo aprobado por la ANSI para
trabajar con esta herramienta. (tanto usuarios como
espectadores).
• Nunca utilice esta herramienta para cualquier otra cosa
que no sean las aplicaciones para lo que fue diseñada.
• Sólo utilice los accesorios diseñados para esta herramienta.
• No modifique o altere esta herramienta de ninguna manera.
• El funcionamiento y/o mantenimiento inadecuado de la
herramienta, la modificación, o la utilización de la
herramienta con accesorios inadecuados podrían causar
lesiones graves o la muerte.
• Siempre usar los correctos accesorios para el trabajo que
Ud. está realizando.
• Trabaje siempre en un área limpia, segura, bien iluminada,
organizada y equipada adecuadamente.
• NUNCA empiece reparaciones sin estar seguro de que el
vehículo esté en posición segura y que no se mueva
durante la reparación.
El fabricante garantiza que este producto el usuario original contra cualquier defecto de
material o mano de obra de por vida desde la fecha de compra.
El fabricante se reserva el derecho a determinar si una pieza o piezas fallaron debido a
material defectuoso, mano de obra, o por otras causas. Esta garantía no cubre fallas
causadas por accidentes, alteraciones o uso indebido.
El fabricante, a su entera discreción, reparará o reemplazará los productos cubiertos por
esta garantía sin costo alguno. Las reparaciones o reemplazos de productos cubiertos por
esta garantía quedan garantizados durante el resto del periodo original de garantía.
El fabricante o sus representantes autorizados de servicio deben llevar a cabo todas las
reparaciones de garantía. Toda reparación hecha al producto por representantes de
servicio no autorizados invalida la presente garantía. Los derechos que ampara esta
garantía están limitados al usuario original y no se pueden transferir a dueños posteriores.
Esta garantía reemplaza a todas las demás garantías expresas o implícitas, incluyendo
garantías de comercialización e idoneidad para un propósito particular. Algunos estados
no permiten la exclusión o limitaciones de daños incidentales o imprevistos, de manera
que las limitaciones mencionadas anteriormente pueden no ser aplicables en su caso.
GARANTÍA DE POR VIDA
INFORMACIÓN DEL PRODUCTO:
Desempacado
Cuando desempaque el producto, revise el diagrama y la lista de
piezas en la página 6 para verificar que se hayan enviado todas
las piezas. En caso de que falten piezas o que estén dañadas,
comuníquese con su distribuidor.
Importante
Lea las instrucciones detenidamente antes de instalar,
operar, dar servicio o reparar esta herramienta.
Guarde estas instrucciones en un lugar seguro y accesible.
NO LO DESCARTE O DESECHE, ENTREGESELO AL USUARIO
HECHO A CHINA
CONJUNTO MAESTRO DE
ADAPTADORES DE SERVICIO
MODELO:
Tipo de producto:
MBP1000
Instalación del
adaptador
Junta esférica
Recepción de tubo
Brazo de
control
Extracción del
adaptador
Brazo de
control
Junta
esférica
Instalación del
adaptador
Recepción de tubo
Extracción del
adaptador
Page 4
MANUAL DE INSTRUCCIONES
Desmontaje e instalación de pasadores de anclaje en el sistema de frenos
1. Retire todos los retenes del anillo de fijación de los pernos de anclaje de freno.
2. Coloque la prensa en forma de "C" sobre la araña de freno como se
muestra en la Figura 1.
3. Apriete el tornillo de fuerza hasta que se retire el perno de anclaje.
Ensamblado y desmontaje de las junturas en "U"
La prensa básica en forma de "C" se utiliza para dar servicio a las junturas
en "U" en la mayoría de los automóviles y camiones ligeros. Las junturas
en "U" pueden ser atendidos ya sea dentro o fuera del vehículo.
Desmontaje
1. Retire los anillos de bloqueo externo y/o interno.
2. Coloque la prensa "C" alrededor del yugo del eje de transmisión y
apriete el tornillo de fuerza hasta que retire el primer cojinete.
3. Reposicione la prensa en C y retire el segundo cojinete.
Ensamblado
1. Limpie toda la suciedad y el aceite de la zona del yugo.
2. Alinee el nuevo cojinete con la prensa "C" tan recto como sea
posible sobre el yugo. Presione el cojinete de repuesto en el
yugo y vuelva a montar el anillo de seguridad externo/interno.
3. Reposicione la prensa "C" y el segundo cojinete de repuesto
repitiendo toda la maniobra como con el primer cojinete.
Instalación y remoción de rotulas
Este conjunto de herramientas está diseñado para uso en automóviles
y camionetas que tienen rótulas tipo ajuste a presión. Esto ayudará al
usuario a desmontar e instalar junturas de rótula sin la necesidad de
retirar el brazo de control del vehículo.
NOTA : Algunos coches y camiones ligeros pueden tener la rótula
superior soldada por puntos al brazo de control. La soldadura se debe
cortar antes de intentar quitar la rótula.
Remoción (Diferentes piezas se describen en la lista de la hoja 6)
1. Montar la prensa "C" en el brazo de control como se muestra en la
Figura 3. Seleccione el tubo receptor del tamaño correcto, y colóquelo
bajo la rótula del vehículo como se muestra.
2. Apriete el tornillo de presión hasta que el tubo receptor haga contacto
con el brazo de control. Compruebe la alineación de todas las
herramientas y componentes y continúe apretando el tornillo de fuerza
hasta que se retire la rótula.
Instalación
1. Limpie el brazo de control y cubra el I.D. con un lubricante adecuado.
2. Inserte la rótula de reemplazo lo más recta posible en el brazo de
control del vehículo.
3. Ensamble todos los componentes de la rotula en la prensa "C", como se
muestra en la Figura 4. Coloque el tubo receptor y apriete el tornillo de fuerza.
Compruebe la alineación de todas las herramientas y componentes y continúe
apretando el tornillo de fuerza hasta que la rótula este firmemente asentada.
Figura 1.
Figura 2
Figura 3
Figura 4
MBP1000
MODEL:
Product Type:
CONJUNTO MAESTRO DE
ADAPTADORES DE SERVICIO
Page 5
WARNING
ADVERTENCIA
Precaución: Para ayudar a evitar lesiones a las personas
Caution: To help prevent personal injury
• Normal use of this product is likely to expose the user to dust and/or microscopic particles containing chemicals
known to the State of California to cause cancer, birth defects or other reproductive harm. Always wear appropriate
safety equipment and clothing when using this product. Study, understand and follow all instructions provided with
this product. Failure to read and follow all warnings and operating instructions may result in damages and serious
injury or death.
• Always wear ANSI approved goggles when using this product. (Users and Bystanders).
• Never use this tool for any application other than for which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool, modification of the tool, or use of the tool with accessories not
designed for it could result in serious injury or death.
• Always select the correct accessories of the correct size and design for the job that you are attempting to perform.
• Always work in a clean, safe, well-lit, organized and adequately equipped area.
• Do not begin repairs without assurance that vehicle is in secure position, and will not move during repair.
• El uso normal de esta herramienta puede exponer al usuario al polvo o a partículas microscópicas que contienen
sustancias químicas que se conocen en el estado de California por causar cáncer, defectos del nacimiento u otros
daños reproductivos. Siempre use equipo y ropa de seguridad adecuados para trabajar con esta herramienta.
Lea, comprenda y siga todas las instrucciones incluidas con esta herramienta. Omitir la lectura y el no seguir todas las
advertencias e instrucciones de operación puede traer como consecuencia daños y lesiones graves o hasta la muerte.
• Siempre use guantes del tipo aprobado por la ANSI para trabajar con esta herramienta. (tanto usuarios como
espectadores).
• Nunca utilice esta herramienta para cualquier otra cosa que no sean las aplicaciones para lo que fue diseñada.
• Sólo utilice los accesorios diseñados para esta herramienta.
• No modifique o altere esta herramienta de ninguna manera.
• El funcionamiento y/o mantenimiento inadecuado de la herramienta, la modificación, o la utilización de la herramienta
con accesorios inadecuados podrían causar lesiones graves o la muerte.
• Siempre usar los correctos accesorios para el trabajo que Ud. está realizando.
• Trabaje siempre en un área limpia, segura, bien iluminada, organizada y equipada adecuadamente.
• NUNCA empiece reparaciones sin estar seguro de que el vehículo esté en posición segura y que no se mueva durante
la reparación.
Mise en garde: Pour aider à prévenir les blessures
AVERTISSEMENT
• L’utilisation normale de ce produit pourrait exposer l’utilisateur à de la poussière et/ou des particules microscopiques
contenant des produits chimiques que l’État de la Californie a reconnu comme étant une cause de cancer, de
déficience congénitale et d’autres effets nocifs sur le système reproductif.
Toujours porter un équipement et des vêtements sécuritaires appropriés en utilisant ce produit. Étudier, comprendre et
suivre toutes les instructions fournies avec ce produit. Echec de lire et suivre des avertissements et le mode d’emploi
devrait causer des endommages et des blessures sévères ou la mort.
• Toujours porter des lunettes à coques approuvées par l’ANSI lorsque vous utilisez ce produit. (Utilisateurs et
Spectateurs).
• Ne jamais utiliser cet outil pour aucune application qui n’est pas conçue.
• Seulement utiliser les accessoires conçus pour cet outil.
• Ne jamais modifier cet outil.
• Le fonctionnement et/ou l’entretien incorrect de cet outil, la modification de cet outil, ou l’utilisation de cet outil avec
les accessoires non conçus pour lui devrait causer des blessures graves ou la mort.
• Toujours utiliser les accessoires adéquats pour le travail que vous effectuez.
• Toujours travailler dans un environnement propre, sécuritaire, bien éclairé, organisé et suffisamment équipé.
• NE JAMAIS commencer les réparations sans d’abord vous être assuré que le véhicule est en position sécurisée et ne
bougera pas lors de la réparation.
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
MBP1000
MODEL:
Product Type:
Page 6
PARTS BREAKDOWN
806
Parts List
MBP1000-01A
MBP1000-02
MBP1000-03
MBP1000-04
MBP1000-05
MBP1000-06
MBP1000-07
MBP1000-08
MBP1000-09
MBP1000-10
MBP1000-11
PART NO. DESCRIPTION QTY.
C-Frame
1-3/4" x 2" Receiving Tube
1-3/4" x 2-1/2" Receiving Tube
2-1/4" x 3" Receiving Tube
Screw
Center Rod
Sleeve
Removal Adapter
Install Adapter
Install Cup Adapter
Adapter
1
1
1
1
1
1
1
1
1
1
1
MBP1000-12
MBP1000-13
MBP1000-14
MBP1000-15
MBP1000-16
MBP1000-17
MBP1000-18
MBP1000-19
MBP1000-20
MBP1000-21
PART NO. DESCRIPTION QTY.
Adapter
Adapter
Adapter
Adapter
Receiving Cup
Adapter
Adapter
Adapter
Adapter
Install Cup
1
1
1
1
1
1
1
1
1
1
MBP1000-01A
MBP1000-02
MBP1000-03
MBP1000-04
MBP1000-05
MBP1000-08
MBP1000-07
MBP1000-06
MBP1000-10
MBP1000-16 MBP1000-17 MBP1000-18 MBP1000-19 MBP1000-20 MBP1000-21
MBP1000-11 MBP1000-12 MBP1000-13 MBP1000-14 MBP1000-15
MBP1000-09
Page 7
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
MBP1000 does not have all of the recommended adapters, but modification of adapters may or may not work.
This tool not needed. Application requires bolt in ball joint, replacing control arm
(RCA) or replacing steering knuckle (RSK), see Application description.
MBP1000 may not work on your application.
BLANK:
NA:
Not Listed:
BALL JOINT APPLICATION MASTER
AcuraAudi
Make Model Year Application Removal
Installation
CL 2.2L
CL 2.3L
CL 3.0L
CL 3.2L
ILX
Integra
MDX
NSX
RDX
RL 3.5L
SLX
TL 2.5L
TL 3.2L
TL 3.5L
TLX
A3
A4
A4
Quattro
A5
Quattro
A6
A6
Quattro
A8
A8
Quattro
Allroad
Cabriolet
Q7
R8 Quattro
RS4
RS6
S4
1997
(98-99)
(97-99)
(99-03)
2017
(94-01)
(07-13)
(91-05)
(07-12)
(96-12)
(96-99)
(95-99)
(99-03)
(96-08)
(07-08)
2018
(06-08)
(96-04)
(96-08)
(96-05)
(96-04)
(96-08)
2008
(96-04)
(96-08)
(96-04)
(96-05)
(96-08)
(97-99)
(97-02)
(00-08)
(99-05)
2005
(01-04)
(96-98)
(07-08)
(07-15)
(06-08)
(03-04)
(00-02)
(00-08)
Fr. Upper NA (Bolt in)
Fr. Lower applicable in Spindle
Fr. Upper NA (Bolt in)
Fr. Lower applicable in Spindle
Fr. Upper NA (Bolt in)
Fr. Lower applicable in Spindle
Fr. Lower applicable in Spindle
NA application
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RSK
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Upper NA Bolt in
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable in Spindle
Fr. Upper NA Bolt in
NA application
Fr. Upper NA RCA
NA application
Fr. Lower NA (Bolt in)
Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Rear Upper NA RCA
Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Rear Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Rear Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA RCA
Rear Lower NA RCA
Rear Upper NA RCA
Rear Lower NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Rear Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 06
NA
21, 06
NA
21, 06
21, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
AudiBMW
Make Model Year Application Removal
Installation
S4 Avant
S4 Cabriolet
S5
S6
S6 Avant
S8
TT
TT
Quattro
128i
135I
323ci
323i
325ci
325i
325xi
328ci
328i
328xi
330ci
330i
330xi
335i
335xi
525
525i
525xi
528i
528xi
530
530i
530xi
535i
535xi
540i
545
550i
645ci
645i
650i
740i
(04-05)
(04-05)
(07-12)
(99-03)
(06-11)
(99-03)
(01-03)
(07-09)
(00-06)
(06-14)
(98-06)
(06-14)
(08-11)
(07-10)
(98-00)
(98-00)
(01-06)
(01-06)
(01-06)
(98-00)
(07-13)
(98-00)
(07-13)
(07-08)
(01-06)
(01-06)
(01-06)
(07-15)
(07-15)
(04-05)
(06-07)
(06-07)
(97-00)
(08-16)
(08-09)
(04-05)
(01-03)
(06-07)
(06-07)
(08-16)
2008
(96-03)
(04-05)
(06-16)
(04-05)
(04-05)
(06-17)
(95-01)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper & Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Upper & Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Na application (Bolt in)
Fr. Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
Page 8
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
BMWBuickCadillac
Cadillac
740IL
745i
745Li
750i
750iL
750Li
760i
760Li
840Ci
850Ci
Alpina B7
M3
M5
M6
X3
X5
X6
Z3
Z4
Z8
Allure
Centruy
Enclave
LaCrosse
LeSabre
Lucerne
Park Avenue
Rainier
Regal
Rendezvous
Riviera
Roadmaster
Skylark
Terraza
Catera
Concours
CTS
DeVille
(HD Suspension,
Limo Commercial
Chassis)
DeVille
DHS
DTS
Eldorado
(95-01)
(02-05)
(02-05)
(06-17)
(90-01)
(06-15)
(05-08)
(03-08)
(92-99)
(92-99)
(01-08)
(01-06)
(07-13)
(99-03)
(05-10)
(06-10)
(04-10)
(00-06)
(07-13)
(08-14)
(96-02)
(02-16)
(00-03)
(05-09)
(82-05)
(08-17)
(05-09)
(86-05)
(06-11)
(91-05)
(04-07)
(88-04)
(02-07)
(86-99)
(91-96)
(86-98)
(05-07)
(97-01)
(97-99)
(03-13)
(96-99)
(00-05)
2004
(06-11)
(86-02)
Fr. Lower NA RCA
Fr.& Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Rear Lower & Upper NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Upper NA RCA
Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
NA application
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. & Rear Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
04, 03,
08, 09
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
16, 10
12, 18, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
03, 08, 10, 06
03, 09
NA
NA
NA
NA
Make Model Year Application Removal
Installation
Chevrolet
(99-00)
(02-07)
(07-14)
(91-96)
(86-04)
(04-09)
(05-11)
(06-09)
(05-09)
(04-09)
(91-00)
(96-99)
(95-99)
(91-99)
(91-92)
(91-92)
(91-00)
(96-99)
(95-99)
(95-00)
(98-00)
(73-97)
(73-97)
(73-97)
(73-97)
(91-92)
(91-00)
(96-99)
(95-00)
(85-05)
(90-05)
(02-13)
(02-06)
(07-13)
(02-11)
(87-96)
(82-05)
(82-05)
(93-02)
(91-96)
1996
(82-05)
(05-10)
(04-12)
(87-96)
(84-96)
(02-13)
(05-13)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper and Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper NA
Rear Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA
Fr. Upper NA (Bolt in)
Fr. Lower NA
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper NA RSK
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
08, 03, 04, 09, 06
08, 03, 04, 09, 06
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
08, 03, 04, 09, 06
NA
15, 08
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
09, 03, 04, 08
NA
NA
NA
09, 03, 13
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
09, 03,13
NA
NA
NA
09, 03, 13
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
09, 03, 13
NA
13, 03 or 07, 09
NA
NA
NA
10, 13 or 03, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
10 or 09, 07,
13 or 03, 08
Escalade
Fleetwood
Seville
SRX
STS
STS-V (DX)
STS-V8 (DC)
XLR
C/K 1500 2WD
C/K 1500 4WD
C/K 1500 4WD
C/K 2500 2WD
C/K 2500 4WD
30 Comm
30 Motor
Home
30 Step
Van
3500 4WD
3500 4WD
Astro 2WD
Astro 4WD
Avalanche
2WD/ 4WD
Aveo
Beretta
Blazer 2WD
Blazer 4WD
Camaro
Caprice
Cavalier
Cobalt
Corsica
Corvette
C/K 2500 2WD
w/ 7200 lbs GVW
C/K 2500 2WD
w/ 8600 lbs GVW
C/K 2500 2WD
w/ 8600 lbs GVW
C/K 2500 4WD
w/ 7200 lbs GVW
C/K 2500 4WD
w/ 8600 lbs GVW
30 Motor Home
w/ IFS
30 Step Van
w/ IFS
3500 2WD w/ IFS
(5th VIN digit "C")
10 or 09, 07,
13 or 03, 08
Avalanche
1500 2WD/4WD
Avalanche
2500 2WD/4WD
Colorado
2WD/4WD
Page 9
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
Chevrolet
ChevroletChryslerDodge
Daewoo
(05-09)
(03-15)
(96-02)
(03-14)
(96-02)
(96-02)
(03-14)
(96-14)
(71-95)
(73-95)
(73-95)
(06-11)
(00-13)
(94-96)
(90-01)
(90-96)
(97-05)
(06-08)
(04-05 & 08)
(98-01)
(95-07)
(98-02)
(82-05)
(82-05)
(99-06)
2007
2007
(99-06)
2007
(01-07)
1999
(99-00)
(01-07)
(08-11)
2000
(01-11)
(01-11)
(03-06)
1992
(92-99)
(00-06)
(07-14)
(96-99)
(95-99)
1992
2000
(92-99)
(01-13)
(96-99)
2000
(95-99)
(96-97)
(95-99)
2000
2000
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA
Fr. Upper NA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
NA
NA
NA
NA
19
19
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
15, 08
NA
15, 08
NA
NA
15, 08
15, 08
15, 08
15, 08
NA
NA
15, 08
NA
NA
NA
15, 08
15, 08
15, 08
NA
NA
NA
NA
Make Model Year Application Removal
Installation
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13, 03, 08
10, 09 or 07,
13 or 03, 08
NA
NA
NA
NA
10, 03, 08, 13
10, 03, 08, 13
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
10, 13, 03, 08
10, 13, 03, 08
NA
10, 13 or 03, 08
NA
NA
10, 13 or 03, 08
10, 13 or 03, 08
10, 13 or 03, 08
16, 10
12, 18, 06
NA
NA
09, 03, 13
NA
NA
NA
10, 13 or 03, 08
09, 03, 13
10, 13 or 03, 08
NA
NA
NA
NA
08, 03, 04,
09, 06
08, 03, 04,
09, 06
09, 07, 08,
03, 06
Express 2500
w/7300 lbs GVW
Equinox
Express 1500
Express 3500
G10
G20
G30
HHR
Impala
Lumina
Lumina APV
Malibu
Malibu Classic
Metro
Monte Carlo
Prizm
S-10 2WD
S-10 4WD
SSR
Tahoe 2WD
Express 2500 w/7700
& 8600 lbs GVW
Express 2500
w/8500 lbs GVW
Silverado
1500 2WD
Silverado 1500
2WD (Old Style)
Silverado 1500
2WD/4WD
(New Style)
Silverado
1500 4WD
Silverado 1500
4WD (Old Style)
Silverado 1500
HD 2WD / 4WD
Silverado 2500 &
2500 HD 4WD
Silverado
2500 2WD
Silverado 2500
2WD/4WD
Silverado
2500 4WD
Silverado 2500 HD
2WD / 4WD
Silverado 3500
2WD /4WD
Suburban
1500 2WD
Suburban 1500
2WD/4WD
Suburban
1500 4WD
Suburban
2500 2WD
Suburban
2500 2WD
Suburban 2500
2WD/4WD
Suburban
2500 4WD
Suburban 4WD
Tahoe 2WD New
Style (Exc. Limited)
Tahoe 2WD Old
Style Limited
Tahoe
2WD/4WD
Tahoe 4WD
Tracker
Uplander
Venture
300C AWD
300C RWD
300M
Aspen
2WD/4WD
Cirrus
Concorde
Crossfire
Grand Voyager
LHS
New Yorker
Pacifica
Prowler
Sebring Sedan
Town & Country
Voyager
Lanos
Leganza
Nubira
Avenger
Caravan
Challenger
Charger AWD
Charger RWD
Colt
Colt Vista
Dakota 2WD
Tahoe 4WD New
Style (Exc. Z71)
Tahoe 4WD Old
Style Z71
Tracker
2WD/4WD
Trailblazer
EXT 2WD/4WD
Trailblazer
2WD/4WD
Venture
2WD/4WD
(01-06)
(07-14)
(96-00)
(95-00)
2000
2000
(99-04)
1998
(02-09)
(03-07)
(05-08)
(97-05)
(02-05)
(02-05)
(05-10)
(05-10)
(99-04)
(07-09)
(95-00)
(93-04)
(04-08)
2000
(94-01)
(94-96)
2004
(05-08)
(97-02)
(96-06)
(95-00)
(01-06)
(90-00)
(01-16)
(00-03)
(97-02)
(99-02)
(97-02)
(95-00)
(07-12)
(84-00)
(01-06)
(07-17)
(08-10)
(06-10)
(06-10)
(84-94)
1996
(87-96)
(97-99)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper and Lower NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper & Lower NA RCA
Rear Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper & Lower NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Upper NA (Screw in)
Fr. Lower NA (Bolt in)
NA
15, 08
NA
NA
NA
NA
15, 08
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18 or 02, 09
NA
NA
NA
12, 18
NA
NA
NA
NA
NA
NA
12, 18 or 02, 09
12, 18
12, 18 or 02, 09
NA
NA
NA
NA
NA
12, 18
12, 18 or 02, 09
12, 18
NA
NA
NA
12, 18
NA
NA
NA
09, 07, 08, 03, 06
NA
09, 03, 13
NA
NA
NA
NA
12, 18, 06
16, 10
16, 10
12, 18, 06
NA
NA
NA
NA
NA
NA
16, 10
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 08
21, 08
NA
NA
NA
NA
NA
21 , 08
NA
16, 10
NA
16, 10
NA
16
NA
NA
NA
10 or 09, 07,
13 or 03, 08
08, 03 or 13,
07 ,09, 06
Pacifica
FWD/AWD
Sebring
Convertible
Sebring Coupe
Caliber
FWD/AWD
Page 10
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
Dodge
DodgeEagle
Ford
Make Model Year Application Removal
Installation
Dakota 2WD
Dakota
2WD/4WD
Dakota 4WD
Durango 2WD
Durango
2WD/4WD
Durango 4WD
Grand
Caravan
Intrepid
Magnum AWD
Magnum RWD
Nitro
2WD/4WD
Ram 1500
2WD
Ram 1500
2WD HD
Ram 1500
2WD/4WD
Ram 1500
4WD
Ram 2500
2WD
Ram 2500 4WD
Ram 3500
2WD
Ram 3500
2WD w/IFS
Ram 1500 2WD
Light Duty w/IFS
Ram 1500
4WD HD
Ram 1500 4WD
Light Duty w/IFS
Ram 1500 4WD
w/248 FBI Axle
Ram 1500 4WD
w/216 FBI Axle
Ram 2500 4WD
w/ Dana 44 Axle
Ram 2500 4WD
w/ Dana 60
(4500 lb axle)
Ram 3500
2WD w/IFS
Ram 3500 2WD
w/ Solid Fr. Axle
(00-04)
(97-99)
(05-11)
(97-04)
(87-96)
(99-03)
(04-09)
(98-03)
(88-00)
(01-07)
(08-10)
(93-04)
(05-08)
(05-08)
(07-12)
(94-96)
(97-99)
(00-01)
2006
2008
(07-09)
(02-05)
(94-99)
2006
(07-08)
(07-08)
(00-01)
(00-01)
(94-99)
(00-02)
(03-08)
(00-02)
(03-05)
(06-08)
(00-08)
(96-99)
(94-99)
(94-99)
(03-08)
(03-05)
(06-08)
(94-99)
(00-02)
(00-02)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Screw in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA
Fr. Upper NA
Fr. Upper & Lower NA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA
Fr. Lower NA
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper NA
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA
Fr. Upper NA
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
NA
NA
NA
NA
08, 03 or 13
NA
NA
NA
NA
08, 03 or 13
NA
12, 18 or 02, 09
12, 18
NA
NA
NA
NA
NA
NA
04, 08
04, 08
NA
NA
NA
NA
NA
NA
12, 20 or 21
20, 12
NA
NA
20, 12
12, 20 or 21
20, 12
12, 20 or 21
04, 08
NA
19
NA
NA
NA
09, 03
12, 20 or 21
20, 12
03 or 08, 17
08, 17
19
NA
NA
04, 08
09, 03
NA
NA
NA
NA
NA
10, 13
NA
16, 07, 09
NA
NA
NA
NA
16, 07, 09
NA
NA
NA
NA
NA
16, 10
NA
10, 13
NA
09, 07, 16
09, 07, 16
NA
NA
NA
NA
NA
10, 03, 08
NA
18, 11
18, 11
10, 03, 08
NA
NA
18, 11
18, 11
18, 11
18, 11
09, 07, 16
NA
10, 03, 08, 13
NA
NA
NA
NA
18, 11
18, 11
08, 02, 10
16, 10 or 07, 09
10, 03, 08, 13
NA
NA
09, 07, 16
NA
NA
NA
08, 03 or 13,
07, 09, 06
Ram 3500
4WD
Ram SRT-10
Ram Van 1500
Ram Van 2500
Sprinter 2500
Sprinter 3500
Stealth
Stratus
Stratus Sedan
Viper
Summit
Talon
Vision
Aerostar
2WD
Aerostar
4WD
Aspire
Bronco
Contour
Ram 3500 4WD
w/ Solid Fr. Axle
Ram Van 3500
w/3600 lbs Axle
Ram Van 3500
w/4000 lbs Axle
Ram Van B100
(Standard Suspension)
Ram Van B100
(HD Suspension)
Ram Van B150
(Standard
Suspension)
Ram Van B150
(HD Suspension)
Ram Van B200
(Standard
Suspension)
Ram Van B200
(HD Suspension)
Ram Van B250
(Standard
Suspension)
Ram Van B250
(HD Suspension)
Ram Van B300
(Standard
Suspension)
Ram Van B350
(Standard
Suspension)
Ram Wagon
1500
Ram Wagon
3500
Ram Wagon
2500
2000 GTX
(Canada Only)
(96-99)
(00-08)
(94-99)
(04-06)
(95-03)
(95-03)
(95-03)
(95-03)
(71-80)
(72-80)
(81-94)
(81-94)
(71-80)
(72-80)
(81-94)
(81-94)
(71-80)
(81-94)
(99-03)
(99-03)
(99-03)
(03-10)
(03-10)
1996
(95-00)
(07-08)
(01-06)
(97-17)
1996
(91-93)
(91-96)
(90-94)
(95-98)
(93-97)
(86-97)
(86-97)
(96-97)
(80-96)
(84-90)
1990
(95-00)
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Upper NA
Fr. Upper NA
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Upper NA
Fr. Lower applicable
Fr. Upper NA
Fr. Lower applicable
NA application
NA application
NA application
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower NA (Bolt in)
03 or 08, 17
08, 17
08, 03
03 or 08, 17
08, 17
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
14, 08
14, -08
NA
NA
NA
NA
NA
NA
12, 18
12, 18
12, 18
NA
NA
NA
NA
08, 03 or 13
NA
NA
16
16
08, 03
08, 03
08, 03
08, 03
NA
08, 02, 10
16, 10 or 07, 09
08, 02, 10
16, 10 or 07, 09
10, 03, 08
NA
NA
08, 03, 10
NA
08, 03, 10
NA
08, 03, 10
NA
NA
NA
NA
08, 03, 10
NA
NA
08, 03, 10
NA
NA
08, 03, 10
NA
NA
08, 03, 10
NA
08, 03, 10
NA
NA
NA
10, 03, 08, 13
10, 03, 08, 13
NA
NA
NA
NA
NA
NA
16
16
16
NA
NA
NA
NA
08, 03
10, 08, 02
NA
NA
21, 10
21 or 08, 02, 10
NA
Bronco ll 4WD
w/ Dana 28 Axle
Bronco ll 4WD
w/ Dana 35 Axle
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
Page 11
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Crown
Victoria
E-150
E-250,
E-350,
E-450
E-550
Edge
Escort
Excursion 2WD
Excursion 4WD
EXP
Expedition
2WD/4WD
Explorer
2WD/4WD
Explorer 4WD
w/ Dana 28 Axle
Explorer 4WD
w/ Dana 35 Axle
Explorer Sport
Trac 2WD/4WD
Explorer Sport/
Sport Trac
2WD/4WD
F-150 2WD
F-150
2WD/4WD
F-150 4WD
F-150 Heritage
& Lightning
F250 2WD
F250 2WD HD
w/ Twin I-Beam
Make Model Year Application Removal
Installation
Ford
Ford GeoGMC
Make Model Year Application Removal
Installation
F-150 2WD/
4WD (Base)
F-150 2WD/
4WD (HD)
(03-08)
(95-02)
(92-04)
(03-08)
(96-02)
(03-08)
(96-04)
(05-08)
(96-04)
(05-08)
(02-03)
(07-17)
(84-90)
(91-02)
(00-05)
(00-05)
(82-88)
(97-02)
(03-17)
(97-17)
(96-05)
(02-05)
(06-10)
(95-00)
2006
(91-94)
(91-93)
(93-94)
(91-93)
(93-94)
(02-05)
(04-05)
(07-10)
(04-05)
2001
(02-03)
2001
(02-03)
(87-96)
(87-97)
(97-03)
(97-03)
(04-08)
(97-03)
2008
2008
(80-96)
(97-03)
2004
2004
(87-96)
1997
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable
No Ball Joint applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Rear Lower NA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable
Rear Lower NA
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper applicable in Spindle
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable in Spindle
Fr. Upper applicable in Spindle
Fr. Lower applicable in Spindle
Fr. Upper applicable in Spindle
19
NA
13 or 08, 03
08, 14
08, 17
08, 03 or 13
19
08, 04 or 19
08, 17
08, 03 or 13
NA
NA
NA
NA
16
08, 17
16 or 13
08, 17
NA
19 or 04, 08
7897-19
NA
19 or 04, 08
NA
NA
NA
NA
08, 03
08, 03
08, 03
08, 03
08, 03
08, 03
NA
19 or 04, 08
NA
NA
19 or 04, 08
19 or 04, 08
NA
NA
08, 03
16
NA
19 or 04, 08
19
NA
NA
NA
16
16
NA
19 or 04, 08
NA
08, 03
16
08, 03
16
20, 10, 06
NA
08, 02, 10
08, 02, 10
08, 02, 10
08, 02, 10
16, 10 or 07, 09
16, 10 or 07, 09
08, 02, 10
08, 02, 10
NA
NA
NA
NA
21 or 08, 02, 10
16, 10
21, 10
16, 10
NA
10, 03, 08
10, 03, 08 or 13
NA
10, 03, 08 or 13
NA
NA
NA
NA
NA
10, 03, 08
NA
NA
10, 03, 08
10, 03, 08
NA
NA
08, 02, 10
08, 02, 10
NA
10, 03, 08
10, 03, 08 or 13
NA
NA
NA
21, 10
21 or 08, 02, 10
NA
10, 03, 08 or 13
NA
16, 10 or 07, 09
08, 02, 10
16, 10 or 07, 09
08, 02, 10
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
F-350 2WD
F-350 4WD
(Monobeam Axle)
F53
Five Hundred
Focus
Freestar
Freestyle
Fusion
Mustang
Probe
Ranger 2WD
Taurus
Taurus X
Tempo
Thunderbird
Windstar
ZX2
Metro
Prizm
1500 2WD
1500 4WD
F250 4WD
(Under 8500 lbs.
GVW)
F250 4WD
w/ 3850 lbs. Axle
VF250 4WD
w/ 4600 lbs. Axle
F250 4WD HD
w/ Twin I-Beam
F250 4WD w/
4600 lbs. Axle w/
Twin I-Beam
F-250 Super Duty 2WD
w/ Twin I-Beam Axle
F-250 Super Duty
2W/4WD
(Monobeam Axle)
F-350 SD 2WD
w/ Twin I-Beam Axle
F-350 SD
2WD/4WD
(Monobeam Axle)
F-450 SD
2WD/4WD
F-550 SD
2WD/4WD
(Monobeam Axle)
F-550 SD
2WD/4WD
Ranger 2WD
w/ Coil Spring
Suspension
Ranger 2WD/4WD
w/ Torsion Bar
Suspension
Ranger 4WD
w/ Dana 28 Axle
Ranger 4WD
w/ Dana 35 Axle
Tracker
2WD/4WD
2500 2WD w/
7200 lbs GVW
(97-99)
(80-96)
(80-96)
(80-96)
1997
(99-08)
(99-08)
(87-97)
(92-97)
(99-08)
(99-08)
(05-08)
(96-97)
(99-08)
(05-08)
(05-07)
(98-11)
(04-07)
(05-07)
(06-12)
(94-04)
(05-14)
(89-97)
(89-97)
(98-11)
(98-07)
(08-11)
(98-11)
(83-97)
(90-97)
(86-95)
(08-09)
(08-09)
(84-94)
(02-05)
(89-97)
(94-03)
(97-03)
(89-97)
(93-97)
(89-98)
(91-92)
(91-99)
(96-99)
(95-99)
(91-92)
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable (NA on 4.10 Ratio)
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable in Spindle
Fr. Lower applicable in Spindle
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
NA application
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
NA application
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
19 or 04, 08
NA
16
08, 17 or 13
16
16
08, 17 or 13
16
08, 17
16 or 13
16
08, 03
16 or 13
08, 17
16
16 or 13
08, 17
16 or 13
08, 17
08, 14, 06
NA
16 or 13
08, 17
08, 14, 06
NA
NA
NA
NA
NA
12, 03, 09
08, 03
08, 03
19
NA
NA
19 or 04, 08
NA
08, 03
08, 03
08, 03
08, 03
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
08, 03, 04,
09, 06
08, 03, 04,
09, 06
10, 03, 08 or 13
NA
21, 10
16, 10
21 or 08, 02, 10
21 or 08, 02, 10
16, 10
21 or 08, 02, 10
16, 10
21, 10
08, 02, 10
16, 10 or 07, 09
21, 10
16, 10
21 or 08, 02, 10
21, 10
16, 10
21, 10
16, 10
16, 07, 09, 06
NA
21, 10
16, 10
16, 07, 09, 06
NA
NA
NA
NA
NA
20, 10
16, 10
21, 10
08, 02, 10
10, 03, 08 or 13
NA
NA
10, 03, 08
NA
08, 02, 10
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
09, 03, 13
NA
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
Page 12
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
GMC
GMC
Honda
Hyundai
Infiniti
Hummer
Make Model Year Application Removal
Installation
2500 4WD
3500 4WD
Acadia
Envoy
2WD/4WD
G1500
G2500
G3500
Jimmy 2WD
Jimmy 4WD
Safari 2WD
Safari 4WD
Savana
1500
Savana
3500
Sierra Denali
Suburban
1500 2WD
Suburban
1500 4WD
Suburban
2500 2WD
Suburban
2500 4WD
Syclone
Typhoon
2500 2WD w/
7200 lbs GVW
2500 2WD w/
8600 lbs GVW
2500 4WD w/
7200 lbs GVW
2500 4WD w/
8600 lbs GVW
3500 2WD w/ IFS
(5th VIN digit "C")
3500 Motor
Home w/IFS
3500 Motor
Home
3500
Step Van
3500 Step
Van w/ IFS
Canyon
2WD/4WD
S-15 Sonoma
2WD
S-15 Sonoma
4WD
Savana 2500
w/7300 lbs. GVW
Savana 2500 w/7700
& 8600 lbs. GVW
Savana 2500 w/8500
& 8600 lbs. GVW
Sierra 1500
2WD
Sierra 1500
4WD
Sierra 2500
4WD
Sierra 1500
HD 2WD/4WD
Sierra 2500
HD 2WD/4WD
Sierra 3500
2WD/4WD
Sierra 2500
2WD/4WD
(91-00)
(91-92)
(91-00)
(96-00)
2000
(95-00)
(95-00)
(91-92)
(91-00)
(96-00)
(95-00)
(73-97)
(73-97)
(73-97)
(73-97)
(07-17)
(04-12)
(98-00)
(02-09)
(71-95)
(73-95)
(73-96)
(82-02)
(82-02)
(82-04)
(82-04)
(85-05)
(90-05)
(96-02)
(03-15)
(03-17)
(96-02)
(96-02)
(03-17)
(03-17)
(96-02)
(99-07)
(99-07)
(00-07)
(01-04)
(99-00)
(01-11)
(01-11)
(02-07)
1992
(92-99)
(96-99)
(95-99)
1992
(92-99)
(96-99)
(95-99)
1991
(91-93)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
NA
NA
15, 08
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
19
19
NA
NA
15, 08
15, 08
15, 08
NA
15, 08
15, 08
NA
15, 08
NA
NA
15, 08
NA
NA
NA
08, 03, 04
09, 06
08, 03, 04
09, 06
08, 03, 04
09, 06
08, 03, 04
09, 06
NA
NA
09, 03, 13
NA
NA
NA
NA
09, 03, 13
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18, 06
16, 10
NA
NA
NA
NA
NA
NA
NA
13, 03 or 07, 09
NA
NA
NA
NA
NA
10, 03, 08 or 13
10, 03, 08 or 13
NA
NA
10, 13 or 03, 08
10, 13 or 03, 08
10, 13 or 03, 08
NA
10, 13 or 03, 08
10, 13 or 03, 08
NA
09, 03, 13
NA
NA
09, 03, 13
NA
NA
NA
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
10 or 09, 07,
13 or 03, 08
Yukon
2WD/4WD
Yukon Denali
& Denali XL
Yukon exc.
5.7L
Yukon XL
2500
(01-07)
(95-99)
(96-99)
2000
2000
(99-00)
(01-05)
2000
(00-07)
(00-08)
(90-93)
(90-97)
(98-02)
(06-11)
(92-00)
(96-00)
(07-11)
(01-08)
(00-06)
(95-98)
(99-06)
(07-10)
(94-02)
(07-08)
(00-01)
(92-96)
(92-99)
1996
(97-01)
(97-01)
(06-14)
(00-09)
(92-06)
(03-09)
(06-10)
(06-11)
(06-11)
(07-10)
(06-10)
2017
(01-06)
(99-10)
(05-10)
(07-12)
2001
(02-05)
(07-12)
(03-12)
(03-08)
(09-13)
(91-96)
(99-02)
Yukon 4WD
w/ 5.7L
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable in Spindle
Rear Upper NA RCA
Fr. Lower applicable in Spindle
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Rear Lower NA RSK
Fr. & Rear Upper NA RCA
NA application
Fr. Lower applicable
NA application
Fr. Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA application
Rear Lower NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. & Rear Upper NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower applicable
Rear Upper NA RCA
NA
15, 08
15, 08
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
12, 18
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18
NA
NA
09, 03, 13
09, 03, 13
NA
10, 13 or 03, 08
NA
21, 06
NA
21, 06
NA
NA
NA
NA
NA
NA
21, 06
NA
NA
NA
NA
NA
21, 06
NA
NA
NA
NA
NA
NA
NA
NA
10, 13 or 03, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
Yukon
Yukon 4WD
Yukon Denali
Accord
Civic
CR-V
Fit
Insight
Odyssey
Pilot
Prelude
Prelude exc. SH
Prelude SH
Ridgeline
S2000
H1
H2
H3
Accent
Azera
Elantra
Entourage
Ioniq
Santa Fe
Sonata
Tucson
Veracruz
XG300
XG350
EX35
FX35
FX45
FX50
G20
Yukon XL
1500
Accord Sedan
& Coupe
Passport
2WD/4WD
Page 13
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
InfinitiIsuzu
Make Model Year Application Removal
Installation
G20t
G35
G37
I30I
I30t
J30
J30t
M35
M37
M45
Q40
Q45
Q45t
QX4
QX56
Amigo
Ascender
2WD / 4WD
Axiom
Hombre 2WD
Hombre 4WD
I-290
I-370
Oasis
Rodeo
Trooper
VehiCROSS
S-Type
Vanden
Plas
XJ
XJ12
XJ6
XJ8
XJR
XJS
XK
XK8
XKR
X-Type
Cherokee
Cherokee
RHD
(99-02)
(03-08)
(08-13)
1997
(97-01)
(93-97)
1997
(06-10)
(11-13)
(03-10)
2015
(96-06)
(97-01)
(97-03)
(07-13)
(04-13)
(98-00)
(03-08)
(02-04)
(96-00)
(96-00)
(06-08)
(06-08)
(96-99)
(88-95)
(91-04)
(96-04)
(95-02)
(92-02)
(99-01)
(00-08)
(94-97)
(98-04)
(03-16)
2003
(04-16)
(94-96)
(92-97)
(98-05)
(95-97)
(98-06)
(92-96)
(03-14)
(98-03)
(05-14)
(97-14)
(00-14)
(01-09)
(90-01)
(96-98)
(06-10)
(07-16)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA
Fr. Lower NA RCA
Rear Lower NA RCA
Rear Upper NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper & Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA in spindle
Fr. & Rear Upper NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA RCA
Fr. Lower NA RSK
Fr. Upper NA
Fr. Upper NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA RCA
Fr. Upper applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
20, 12
12, 20 or 21
20, 12
12, 20 or 21
12, 18
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18, 06
16, 10
NA
NA
NA
NA
NA
NA
21, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
18, 11
18, 11
18, 11
18, 11
10, 13
Pickup
2WD/4WD
JaguarJeep
JeepKiaLand RoverLexus
Commander
2WD/4WD
Compass
2WD/4WD
Grand
Cherokee
Wrangler
Amanti (GH)
Optima (MG)
Optima (MS)
Rio (DC)
Rio (JB)
Rondo (UN)
Sedona
Sephia
Sorento
Spectra (SD)
Sportage
Defender 90
Discovery
Discovery II
Freelander
LR3
Range Rover
ES 300
ES 350
GS 300
GS 350
GS 400
GS 430
GS 450h
GX 470
IS 250
IS 300
IS 350
IS-F
LS 400
LS 430
LS 460
LX 450
LX 470
RX 300
RX 330
RX 350
RX 400h
Grand Cherokee
2WD/4WD
Grand
Wagoneer
Liberty
2WD/4WD
Patriot
2WD/4WD
(96-04)
(93-04)
(05-10)
(93-94)
(08-12)
(02-12)
(07-10)
(87-17)
(07-10)
(04-10)
(06-10)
(01-06)
(01-05)
(06-11)
(07-10)
(02-05)
(06-14)
(94-97)
(98-03)
(02-09)
(00-04)
(95-02)
(05-09)
(94-95)
1997
(94-99)
(00-04)
(02-05)
2005
(95-05)
(92-01)
(02-03)
(04-06)
(07-12)
(93-11)
(05-08)
(98-00)
(01-07)
(07-17)
(03-09)
(06-13)
(01-05)
(06-13)
(08-14)
(96-00)
(01-06)
(04-06)
(07-17)
(96-97)
(98-07)
(99-03)
(04-06)
(07-17)
(06-08)
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
NA application
NA application
NA application
NA application
NA application
NA application
NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
20, 12
12, 20 or 21
12, 20 or 21
NA
NA
20, 12
12, 20 or 21
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
18, 11
18, 11
10, 13
18, 11
10, 13
NA
NA
18, 11
18, 11
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
Page 14
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
LexusLincolnMazda
MazdaMercedes-Benz
Make Model Year Application Removal
Installation
SC 300
SC 400
SC 430
Blackwood
Continental
LS
Mark LT
Mark LT (Base)
Mark LT (HD)
Mark VIII
MKX
MKZ
Navigator
2WD / 4WD
Town Car
Zephyr
626
B-2300 2WD
B-2300 4WD
B-2600 4WD
B-3000 2WD
B-3000 4WD
B-4000 2WD
(96-00)
(96-00)
(02-10)
(03-05)
2002
(88-94)
(00-06)
(06-07)
2008
2008
(93-98)
(07-15)
(07-12)
(98-02)
(98-06)
(03-14)
(07-14)
(95-02)
(03-11)
2006
(83-97)
(98-02)
(91-93)
(94-97)
(01-04)
2001
(05-09)
(01-04)
(95-97)
(98-01)
(98-01)
(98-01)
(98-01)
(91-93)
(94-96)
(98-04)
(98-01)
(05-09)
(02-04)
(98-04)
(94-96)
(98-01)
(94-97)
(98-04)
(98-01)
Fr. Upper & Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
NA application
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Rear Lower applicable
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Upper & Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper & Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower applicable
NA
NA
NA
NA
19 or 04, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
19 or 04, 08
NA
19
19
NA
19
NA
NA
NA
08, 03
08, 03
19
NA
19 or 04, 08
19
NA
19
NA
08, 03
08, 03
19
NA
19 or 04, 08
NA
19
NA
08, 03
08, 03
19
NA
19 or 04, 08
19
NA
19
NA
08, 03
08, 03
19
08, 03
08, 03
19
NA
19 or 04, 08
NA
NA
NA
NA
10, 03, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
10, 03, 08
NA
10, 03, 08 or 13
10, 03, 08 or 13
20, 10, 06
NA
NA
16, 10
NA
NA
21, 10
08, 02, 10
10, 03, 08 or 13
NA
10, 03, 08
10, 03, 08 or 13
NA
10, 03, 08 or 13
NA
10, 03, 08 or 13
NA
10, 03, 08
NA
10, 03, 08 or 13
NA
21, 10
08, 02, 10
10, 03, 08 or 13
NA
10, 03, 08
10, 03, 08 or 13
NA
10, 03, 08 or 13
NA
10, 03, 08 or 13
21, 10
08, 02, 10
10, 03, 08 or 13
NA
10, 03, 08
Aviator
2WD / 4WD
B series Truck
2WD / 4WD
B-2300 2WD w/
Coil Spring
suspension
B-2500 2WD w/
Coil Spring
suspension
B-2300 2WD w/
Torsion bar suspension
B-2500 2WD w/
Torsion bar suspension
B-2300 2WD/4WD
w/Torsion bar
suspension
B-2300
2WD/4WD
B-2500 2WD/4WD
w/Torsion bar suspension
B-2500 4WD w/
Torsion bar suspension
B-3000 2WD w/
Coil Spring
Suspension
B-3000 2WD w/
Torsion Bar Suspension
B-3000
2WD/4WD
B-3000 2WD/4WD
w/Torsion bar
suspension
B-3000 4WD w/
Torsion bar suspension
B-4000 2WD w/
Coil Spring
Suspension
B-4000 2WD w/
Torsion bar suspension
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
08, 02, 10
or 07, 09
B-4000 4WD
CX-7
CX-9
Mazda3
Mazda5
Mazda6
Miata
MX-5 Miata
Millenia
MPV
MPV 2WD
MPV 4WD
MX-6
Navajo 2WD
Protégé
Protégé5
RX7
RX8
C220
C230
C240
C280
C32 AMG
C320
C350
C36 AMG
C43 AMG
C55 AMG
CL500
CL55 AMG
CL600
CL65 AMG
CLK320
B-4000 2WD/4WD
w/Torsion bar
suspension
B-4000
2WD / 4WD
B-4000 4WD w/
Torsion bar suspension
Mazda Speed 3
Navajo 4WD
w/Dana 35
Axle
(05-09)
(02-04)
(98-04)
(94-97)
(98-01)
(07-12)
(06-15)
(04-09)
(06-15)
(02-09)
(07-13)
(90-05)
(06-15)
(95-02)
(99-06)
(89-98)
(96-98)
(88-97)
(92-94)
(91-93)
(93-94)
(91-94)
(93-98)
(99-03)
(02-03)
(86-95)
(03-12)
(94-97)
(97-00)
(02-07)
(01-05)
(94-00)
(06-07)
(02-04)
(01-05)
(06-15)
(95-97)
(97-00)
(05-06)
(98-99)
(00-06)
(01-06)
(98-99)
(01-06)
(05-14)
(98-03)
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower applicable (Uses Pinch Bolt)
Fr. Lower applicable
Fr. Upper Applicable (uses Pinch Bolt)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
NA application
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
NA application
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
19
19
19
NA
08, 03
08, 03
19
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
08, 03
08, 03
08, 03
08, 03
08, 03
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
10, 03, 08 or 13
10, 03, 08 or 13
10, 03, 08 or 13
NA
10, 03, 08 or 13
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
16, 10
21, 10
08, 02, 10
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
Page 15
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
Mercedes-Benz
Mercedes-Benz
Make Model Year Application Removal
Installation
CLK320
CLK350
CLK430
CLK500
CLK55 AMG
CLK550
CLK63 AMG
CLS550
CLS63 AMG
E300
E320
E350
E420
E430
E500
E55 AMG
E550
E63 AMG
G500
G55 AMG
G55K
GL320
GL450
GLC63 AMG
GT C AMG
ML320
ML350
ML430
ML500
ML55 AMG
ML63 AMG
S320
S350
S420
S430
S500
(03-05)
(06-09)
(99-03)
(03-06)
(01-03)
(03-06)
(07-09)
(06-10)
(06-10)
(06-14)
(95-99)
(96-01)
2002
2003
(03-06)
(06-16)
(94-97)
(98-02)
(03-06)
(99-03)
(03-06)
(07-14)
(07-16)
(02-05)
(03-11)
2005
(07-08)
(07-16)
2018
2018
(97-01)
(05-08)
(03-15)
(99-01)
(02-08)
(00-03)
(07-11)
(94-99)
2006
(94-99)
(00-06)
(94-99)
Fr. & Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
NA application
NA application
NA application
Fr. Lower NA RCA
Fr. Lower NA RCA
NA application
NA application
Fr. Upper & Lower NA RCA
Fr. Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
S500
S550
S55 AMG
S600
S63 AMG
S65 AMG
SL320
SL500
SL55 AMG
SL600
SL65 AMG
SLK230
SLK280
SLK32 AMG
SLK320
SLK350
SLK55 AMG
Cougar
Grand
Marquis
Lynx
Marauder
Montego
Monterey
Mountaineer
Mystique
Sable
Topaz
Tracer
Villager
Clubman
Countryman
Cooper
3000GT
Diamante
Eclipse
(00-06)
(07-14)
(00-06)
(94-99)
(01-06)
(07-13)
(07-10)
(06-14)
(94-97)
(94-02)
(03-06)
(03-08)
(94-02)
(04-09)
(04-12)
(96-04)
(06-08)
(01-04)
(00-04)
(04-11)
(04-11)
(89-97)
(96-97)
(99-02)
(95-02)
(03-11)
(84-87)
(03-04)
(05-07)
(04-07)
(97-05)
(97-01)
(02-05)
(06-10)
(95-00)
(86-95)
(08-09)
(84-94)
(91-99)
(93-02)
(08-14)
(11-18)
(01-13)
(91-99)
(96-04)
(90-94)
(95-01)
(06-12)
(95-99)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
NA application
NA application
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
NA application
Fr. Upper & Lower NA RCA
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Upper & Lower NA RCA
Rear Lower NA RCA
Fr. & Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper NA RCA
Rear Lower NA applicable
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
19
NA
NA
19
NA
NA
NA
19 or 04, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
06, 10, 06
NA
NA
NA
NA
NA
NA
10, 03, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
16
NA
NA
NA
MercuryMiniMitsubishi
Page 16
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
MitsubishiNissanOldsmobilePlymouth
Plymouth
Make Model Year Application Removal
Installation
Eclipse Cross
Endeavor
Galant
Lancer
Mighty Max
Mirage
Montero
Montero Sport
Outlander
Raider
200SX
350Z
370Z
Altima
Armada
Frontier
Maxima
Murano
Pathfinder
Quest
Rogue
Sentra
Versa
Xterra
88
98
Archieva
Alero
Aurora
Bravada
Cutlass
Cutlass Ciera
Cutlass Supreme
Intrigue
LSS
Regency
Silhouette
Silhouette APV
Breeze
Grand Voyager
Laser
Prowler
2018
(04-11)
(85-93)
(94-99)
(94-98)
(02-12)
(83-96)
(96-02)
(12-17)
(92-06)
(97-04)
(03-17)
(06-09)
(95-98)
(03-09)
(09-18)
(93-97)
(98-01)
(02-18)
(04-15)
(91-97)
(91-97)
(98-04)
(03-14)
(03-14)
(91-04)
(91-95)
(93-02)
(04-09)
(08-13)
(91-99)
(07-12)
(07-12)
(00-04)
(85-99)
(85-96)
(92-98)
(99-04)
(95-03)
(91-01)
(02-04)
(97-99)
(82-96)
(88-97)
(98-02)
(96-99)
(97-98)
(99-01)
(02-04)
(02-04)
(90-98)
(96-00)
(88-00)
(90-94)
(97-01)
NA application
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
NA application
Fr. Upper & Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RSK
Fr. Upper NA RCA
NA application
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
Rear Upper & Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Upper applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper & Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA RCA
NA
NA
12, 18
NA
NA
12, 18
NA
NA
NA
NA
NA
NA
12, 21
NA
NA
NA
12, 18
12, 18
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 21
NA
12, 18
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18 or 02, 09
12, 18
NA
NA
NA
16
NA
NA
02, 08
NA
NA
NA
NA
NA
NA
10, 13
NA
NA
NA
02, 08
NA
NA
NA
NA
10, 17, 09, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
10, 17, 09, 06
NA
NA
NA
NA
NA
NA
12, 18, 06
16, 10
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21 , 08
16
NA
D21 Pickup
2WD/4WD
D21 Pickup
2WD
Silhouette
2WD/4WD
Bravada
2WD / 4WD
Voyager
Aztek
Bonneville
Bonneville SSEi
Firebird
G3
G5 Soft Ride
G5 Sport Ride
G6
G8
Grand Am
Grand Prix
GTO
Montana
Montana SV6
Pursuit
Solstice
Sunfire
Torrent
Trans Sport
Vibe
911
Boxster
Cayenne
Cayman
Macan
Panamera
900
9000
9--2
9--3
9--5
9-7x
Astra
Aura
Ion
L100
L200
L300
LS
LS1
LS2
LW1
LW2
LW200
LW300
Outlook
Relay
SC1
SC2
SKY
SL
SL1
SL2
(84-00)
(01-03)
(01-05)
(87-05)
2003
(93-02)
(07-09)
(07-09)
(07-09)
(05-10)
(08-09)
(91-05)
(88-08)
(04-06)
(99-06)
(02-06)
2005
(05-06)
(06-10)
(95-05)
(06-09)
(90-98)
(03-08)
(96-17)
(97-17)
(03-17)
(06-17)
(15-17)
(10-16)
(94-98)
(86-98)
(05-06)
(99-12)
(99-11)
(05-08)
(08-09)
(07-10)
(03-07)
(01-02)
(01-03)
(01-05)
2000
2000
2000
2000
2000
(01-03)
(01-03)
(07-10)
(05-07)
(96-02)
(96-02)
(07-10)
(96-02)
(96-02)
(96-02)
Fr. Lower applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA application
NA application
NA application
NA application
NA application
NA application
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Rear Upper & Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
12, 18 or 02, 09
12, 18
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
15, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 18, 06
16, 10
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
PontiacPorscheSaabSaturn
Page 17
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
Make Model Year Application Removal
Installation
SaturnScionSubaru
Make Model Year Application Removal
Installation
SW1
SW2
Vue
FR-S
Im
tC
xA
Xb
xD
B9 Tribeca
Baja
BRZ
Crosstrek
Esteem
Forester
Impreza
Legacy
Outback
SVX
Aerio
Forenza
Grand Vitara
Reno
Sidekick Sport
Swift
SX4
Verona
Vitara
X-90
XL-7
4Runner
Avalon
Camry
Celica
Corolla
Echo
FJ Cruiser
Highlander
Land Cruiser
Mirai
Matrix
MR2 Spyder
Paseo
Previa
Prius
Rav4
Sequoia
Sienna
Solara
Supra
T-100
Tacoma
Tacoma 2WD
(96-01)
(96-01)
(02-10)
(13-16)
2016
(05-10)
(04-06)
(04-15)
(08-14)
(06-14)
(03-06)
(13-17)
(13-15)
(96-02)
(97-08)
(93-11)
(90-09)
(00-09)
(92-97)
(02-07)
(04-08)
(99-13)
(05-08)
(89-98)
(96-98)
(96-01)
(07-14)
(04-06)
(99-06)
(96-98)
(02-08)
(96-02)
(03-09)
(95-10)
(92-11)
(94-05)
(96-08)
(00-05)
(07-14)
(01-08)
(96-08)
(15-17)
(03-08)
(00-05)
(92-97)
(91-97)
(01-09)
(96-09)
(01-08)
(98-10)
(99-08)
(96-98)
(93-98)
(95-04)
(95-04)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
NA application
NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA application
NA application
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper applicable
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Upper & Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper applicable
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Upper NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA (Bolt in)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
12, 21
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 12, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 12, 06
NA
NA
NA
NA
NA
NA
NA
NA
SuzukiToyota
Toyota
Sidekick
2WD/4WD
Tacoma 4WD
Tacoma
Tercel
Tundra
Venza
Yaris
Atlas
Cabrio
CC
EOS
Eurovan
GLI
Golf
Golf (exc. VR6)
Golf GEN IV
Golf GEN V
Golf VR6
GTI
GTI GEN IV
GTI GEN V
Jetta
Jetta (exc. VR6)
Jetta VR6
New Beetle
Passat
Passat VR6
Phaeton
R32
Rabbit
Tiguan
Touareg
Touareg 2
850
960
C30
C70
S40
S60
S70
S80
S90
V40
V50
Tacoma
Prerunner
2WD
(95-04)
(95-04)
(95-04)
(05-15)
(91-98)
(00-06)
(07-13)
(00-13)
(09-15)
(05-13)
2018
(95-02)
(08-17)
(07-15)
(93-03)
(08-11)
(99-05)
(96-98)
2006
2006
(96-98)
(07-08)
(06-07)
2006
(99-11)
(88-98)
1999
(94-98)
1999
(98-11)
(96-05)
(98-05)
(06-15)
(90-97)
(93-97)
(04-06)
2008
(06-09)
(08-18)
(03-07)
(08-10)
(96-97)
(92-98)
(08-13)
(98-13)
(00-12)
(04-12)
(01-09)
(98-00)
(99-16)
1998
(00-04)
(05-12)
Fr. Upper applicable
Fr. Upper applicable
Fr. Lower NA (Bolt in)
Fr. Lower applicable
Fr. Lower NA (Bolt in)
Fr. Upper applicable
Fr. Upper NA RCA
Fr. Lower NA (Bolt in)
NA application
Fr. Lower NA RCA
NA application
Fr. Lower NA (Bolt in)
NA application
Fr. Lower NA (Bolt in)
Fr. Upper NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Rear Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA application
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Upper NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
Fr. Lower NA RCA
Rear Upper NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA RCA
NA
14, 08
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
21, 12, 06
21, 12, 06
NA
10, 03, 08
NA
21, 12, 06
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
VolkswagenVolvo
Jetta (exc. VR6)
Old Style
Jetta VR6
Old Style
Passat (exc. VR6)
Page 18
MBP1000
MODEL:
Product Type:
BALL JOINT SERVICE TOOL AND
MASTER ADAPTER SET
BALL JOINT APPLICATION MASTER
* RCA = Replace Control Arm
* RSK = Replace Steering Knuckle
Make Model Year Application Removal
Installation
Volvo
V50
V60
V70
V90
(05-12)
(15-18)
(98-00)
(01-11)
1998
Rear Upper NA RCA
NA application
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
Fr. Lower NA (Bolt in)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
Make Model Year Application Removal
Installation
Volvo
XC60
XC70
XC90
(10-18)
(03-07)
(08-16)
(03-15)
NA application
Fr. Lower NA (Bolt in)
Fr. Lower NA RCA
Fr. Lower NA (Bolt in)
NA
NA
NA
NA
NA
NA
NA
NA
