30" PROFESSIONAL OVENS AND COMPANIONS
PLANNING GUIDE
SERIES 9 & 11
SELF-CLEANING OVEN | OB30SPPUX3
SELF-CLEANING STEAM ASSIST OVEN | OB30SPPSUX3
COMBI-STEAM | OS30SPUX3
COMPACT COMBI-STEAM | OS30NPUX3
COMPACT CONVECTION-SPEED | OM30NPUX3
BUILT-IN COFFEE MAKER | EB30PSX1
WARMING DRAWER | WB30SPEX3, WB30SDEI3
VACUUM DRAWER | VB30SPEX3, VB30SDEI3
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 290004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
CONCEPT DESIGN PAGE
DEVELOPED AND DETAILED DESIGN PAGE DEVELOPED AND DETAILED DESIGN PAGE
DESIGN CHoICE
Styles 4
Professional Family 5
Overview 6
Configuration Options 7
Cabinetry Alignment 8
SPECIFICATIoN GUIDE
Self-Cleaning Oven 10
Self-Cleaning Steam Assist Oven 11
Combi-Steam Oven 12
Built-In Coee Maker 13
Compact Combi-Steam Oven 14
Compact Convection-Speed Oven 15
Warming Drawer 16
Integrated Warming Drawer 17
Vacuum Seal Drawer 18
Integrated Vacuum Seal Drawer 19
Dimensions - Ovens 20
Dimensions - Compact Ovens & Built-In Coee Maker 21
Dimensions - Drawers 22
Services 23
SUPPORT
For additional design planning and installation support please
contact the Fisher & Paykel design support team.
designsupport@fisherpaykel.com
CONTENTS | 30" OVENS AND COMPANIONS
INTRODUCTION
This comprehensive planning guide provides you with the
framework and tools to achieve your desired design outcome
with Fisher & Paykel appliances. In this guide, you will find a
range of conceptual, detailed, and dimensional product
information to bring your ideas to life and create spaces that
truly reflect your vision.
NOTES
The models shown in this Planning Guide may not be available
in all markets and are subject to change at any time. Refer to to
our website fisherpaykel.com for the latest document version.
Product specifications may vary from those shown.
This Planning Guide should not be used as installation guidance
for any product. Specific installation guidance will be available
with the product on delivery and on our website.
<< CONTENTS
CONTENTS
PAGE 3© FISHER & PAYKEL APPLIANCES LIMITED 2025PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 202590004607A
DESIGN CHOICE
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 490004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
DESIGN CHOICE | 30" OVENS AND COMPANIONS
MINIMAL STYLE MINIMAL STYLE - HANDLELESS CONTEMPORARY STYLE PROFESSIONAL STYLE
STYLES
Distinctive and bold, Professional style ovens
are the perfect interpretation of the
commercial kitchen for the home chef.
Experience refined performance with
stainless steel construction that is built to
last.
This Planning Guide is for the Professional
Style featuring 30" Ovens and Companions.
For information on other styles, please visit
the Fisher and Paykel website. To see what
models are available, head to the 'Overview'
section in this Planning Guide.
Celebrating a singular aesthetic to blend seamlessly into the kitchen, Minimal style ovens feature subtle
textural and tonal contrasts for a sense of refinement and purity.
Defined by clean lines and timeless design
cues, Contemporary style ovens bring a
sense of balance and refinement. A versatile
aesthetic that complements a range of
kitchen styles.
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 590004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
PROFESSIONAL FAMILYDESIGN CHOICE | 30" OVENS AND COMPANIONS
Stainless Steel
Installation in wall
Installation under-bench
*
FINISH OVENS COMPANIONS INSTALLATION OPTIONS
SELF-
CLEANING
SELF-
CLEANING
STEAM
ASSIST STEAM SPEED
COFFEE
MAKER
WARMING DRAWERS
VACUUM SEAL DRAWERS
*Integrated model, panel ready for a custom front panel.
**Built-In Coee Maker measurements are dierent to other products. Configurations are possible, but consider installation requirements.
**
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 690004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OVERVIEWDESIGN CHOICE | 30" OVENS AND COMPANIONS
*Integrated models
available.
SIDE
ELEVATION
FRONT
ELEVATION
SELF-CLEANING
OVEN
SELF-CLEANING
STEAM ASSIST
OVEN
COMBI-STEAM
OVEN
BUILT-IN COFFEE
MAKER
COMPACT COMBI-
STEAM OVEN
COMPACT
CONVECTION-
SPEED OVEN
WARMING DRAWER VACUUM SEAL
DRAWER
Series Series 9 Series 11 Series 11 Series 9 Series 9 Series 9 Series 9 Series 9
Models OB30SPPUX3 OB30SPPSUX3 OS30SPUX3 EB30PSX1** OS30NPUX3 OM30NPUX3 WB30SPEX3 VB30SPEX3
Integrated Models - - - - - - WB30SDEI3 VB30SDEI3
Interface 6.8" Touchscreen 6.8" Touchscreen 6.8" Touchscreen 4.3" Touchscreen 6.8" Touchscreen 6.8" Touchscreen - -
Overall Height 28 11/16" (729mm) 28 11/16" (729mm) 23 9/16" (598mm) 18 1/2" (470mm) 18 " (458mm) 18 " (458mm) 10 11/16" (271mm) 10 11/16" (271mm)
Overall Width 29 7/8" (758mm)
Front Panel
Thickness*
15/16" (24mm) 15/16" (24mm) 15/16" (24mm) 1 9/16" (40mm) 15/16" (24mm) 15/16" (24mm) 15/16" (24mm) 15/16" (24mm)
*Flush, Semi-Flush, and Proud alignment is achievable. Head to the 'Cabinetry Alignment' section of this Planning Guide.
**Built-In Coee Maker measurements are dierent to other products. Configurations are possible, but consider installation requirements.
* *
**
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 790004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
CONFIGURATIONS OPTIONSDESIGN CHOICE | 30" OVENS AND COMPANIONS
CONSIDERATIONS
Dierent configurations possible, consider
heights for grid and row installations.
STACK HEIGHT
Stack Height is overall product height with
minimum clearance above appliance front
panel to upper cabinetry front panel or
appliance.
STACKED INSTALLATION GRID INSTALLATION ROW INSTALLATION
Stack Height
28 3/4" (731mm)
Stack Height
46 7/8" (1191mm)
Stack Height
28 3/4" (731mm)
Stack Height
28 3/4" (731mm)
Stack Height
57 9/16" (1462mm)
Stack Height
52 3/8" (1331mm)
BUILT-IN COFFEE MAKER
Built-In Coee Maker measurements are
dierent to other products. Configurations
are possible, but consider installation
options.
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 890004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
CABINETRY ALIGNMENTDESIGN CHOICE | 30" OVENS AND COMPANIONS
PROFESSIONAL STYLE - CABINETRY ALIGNMENT
Professional Ovens and Companions have a control panel thickness of 15/16" (24mm), allowing for Flush, Semi-Flush, and Proud alignment. The drawing below illustrates 3/4" (19mm) cabinetry front panels.
Built-In Coee Maker has a control panel thickness of 1 9/16" (40mm).
PLAN VIEW
PLAN VIEW PLAN VIEW
15/16"
(24mm)
PLAN VIEW
INDICATES CABINETRY DATUM
CoNTRoL PANEL
FLUSH CABINETRY ALIGNMENT SEMI-FLUSH ALIGNMENT
PRoUD ALIGNMENT
R1/16" (R2mm)
<< CONTENTS
PAGE 9© FISHER & PAYKEL APPLIANCES LIMITED 2025PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 202590004607A
SPECIFICATION GUIDE
SERIES 11 & 9
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1090004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB30SPPUX3SPECIFICATION GUIDE | SELF-CLEANING OVEN, 30"
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this oven
matches seamlessly with our Professional style family of
appliances. Pyrolytic self-cleaning simplifies maintenance, while
intuitive temperature and heat type recommendations accessed
via the large touch screen and SmartHQ™ support optimal
cooking results across a wide range of functions and food
types.
PRODUCTS
oB30SPPUX3
30" Series 9 Professional Self-Cleaning Oven
SERIES & STYLE
Series 9
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space. Matches with Professional style family of
appliances
2 Self-cleaning pyrolytic function breaks down food residue
for an easy clean
3 Premium soft-close door with advanced thermal
performance
4 Generous 4.6 cu ft useable capacity
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Twin vertical fans, perfect for multi-shelf cooking
8 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
9 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Self-cleaning-proof Side Ladders
2 Full Extension Sliding Shelf (x3)
3 Air Fry Tray
4 Multi-functional Deep Roasting Dish
5 Wired Temperature Sensor
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1190004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | SELF-CLEANING STEAM ASSIST OVEN, 30" OB30SPPSUX3
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this oven
matches seamlessly with our Professional style family of
appliances. Steam Assist enhances convection cooking, while
pyrolytic cleaning simplifies maintenance. Intuitive temperature
and heat type recommendations accessed via the large touch
screen and SmartHQ™ support optimal cooking results across a
wide range of functions and food types.
PRODUCTS
oB30SPPSUX3
30" Series 11 Professional Self-Cleaning Steam Assist Oven
SERIES & STYLE
Series 11
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space. Matches with Professional style family of
appliances
2 Steam Assist combines convection heat with steam to
enhance the cooking process
3 Self-cleaning pyrolytic function breaks down food residue
for an easy clean
4 Premium soft-close door with advanced thermal
performance
5 Generous 4.6 cu ft useable capacity
6 Large 6.8" touchscreen is intuitive and easy to use
7 Achieve optimal results with temperature and heat type
recommendations
8 Twin vertical fans, perfect for multi-shelf cooking
9 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
"0
Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Self-cleaning-proof Side Ladders
2 Full Extension Sliding Shelf (x3)
3 Air Fry Tray
4 Multi-functional Deep Roasting Dish
5 Wired Temperature Sensor
6 Descale Solution - 2 sachets (Part 580925)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1290004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMBI-STEAM OVEN, 30" OS30SPUX3
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this Combi-
Steam oven matches seamlessly with our Professional style
family of appliances. Featuring a larger cavity ideal for cooking
larger dishes and multiple trays simultaneously. With versatile
cooking options including steam or convection, plus a Steam
Clean function for easy maintenance. Intuitive temperature and
heat type recommendations can be accessed via the large
touch screen and SmartHQ™, to support optimal cooking results
across a wide range of functions and food types.
PRODUCTS
oS30SPUX3
30" Series 11 Professional Combi-Steam Oven
SERIES & STYLE
Series 11
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space
2 Versatile cooking options with steam or convection heat for
optimal results
3 Premium soft open and close door
4 Generous 2.5 cu ft useable capacity with four shelf positions
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Moisture control and even heat distribution thanks to
ActiveVent™ and AeroTech™ technology
8 Steam Clean function ensures a spotless oven with minimal
effort
9 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
"0
Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Chrome Side Ladders
2 Full Extension Sliding Shelf (x2)
3 Step Down Wire Shelf
4 Roasting Dish
5 Broil Rack
6 Smokeless Broil Tray
ACCESSORIES
7 Large Perforated Steam Dish
8 Small Perforated Steam Dish
9 Large Steam Dish
"0
Wired Temperature Sensor
"1
Descale Solution - 2 sachets (Part 580925)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1390004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OVERVIEW
Designed to complement our Professional style oven and
warming drawer, this built-in coee maker seamlessly integrates
into any kitchen design with a stylish stainless steel finish.
Beautiful to use, it has an intuitive touch display with 13
dierent beverage options to suit individual taste and selection
– from Espresso to Latte. Pair with other companion products
to create a kitchen suite for every need.
PRODUCTS
EB30PSX1
30" Series 9 Professional Built-in Coee Maker
SERIES & STYLE
Series 9
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space. Matches with Professional style family of
appliances
2 Intuitive touch display brews a perfect cup of coffee at the
touch of a button
3 Programmable timer turns on the Coffee Maker at the ideal
time each day
4 Personalised coffee and smart self-learning menu
preferences with 13 functions to suit any taste
5 Allows you to prepare hot milk or creamy froth in seconds
6 Stainless steel conical burr grinder with 13 coarseness
positions
7 15 bar pump pressure
8 Self-cleaning function and easy to empty coffee grounds
container and drip tray
9 81 fl oz (2.4L) water tank capacity
ACCESSORIES
1 Milk Container (Auto-Froth)
2 Steam Wand
3 Coffee Spoon
4 Cleaning Brush
5 Descaler Solution - 1 bottle
6 Water Hardness Indicator Paper
7 Water Filter
SPECIFICATION GUIDE | BUILT-IN COFFEE MAKER, 30" EB30PSX1
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1490004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMPACT COMBI-STEAM OVEN, 30" OS30NPUX3
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this Combi-
Steam oven matches seamlessly with our Professional style
family of appliances. With versatile cooking options including
steam or convection, plus a Steam Clean function for easy
maintenance. Intuitive temperature and heat type
recommendations can be accessed via the large touch screen
and SmartHQ™, to support optimal cooking results across a
wide range of functions and food types.
PRODUCTS
oS30NPUX3
30" Series 9 Professional Compact Combi-Steam Oven
SERIES & STYLE
Series 9
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space
2 Versatile cooking options with steam or convection heat for
optimal results
3 Premium soft open and close door
4 1.6 cu ft useable capacity with four shelf positions
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Moisture control and even heat distribution thanks to
ActiveVent™ and AeroTech™ technology
8 Steam Clean function ensures a spotless oven with minimal
effort
9 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
"0
Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Chrome Side Ladders
2 Full Extension Sliding Shelf
3 Flat Wire Shelf
4 Flat Brushed Baking Tray
5 Roasting Dish
6 Broil Rack
ACCESSORIES
7 Large Perforated Steam Dish
8 Small Perforated Steam Dish
9 Large Steam Dish
"0
Wired Temperature Sensor
"1
Descale Solution - 2 sachets (Part 580925)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1590004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMPACT CONVECTION-SPEED OVEN, 30" OM30NPUX3
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this
Convection-Speed oven matches seamlessly with our
Professional style family of appliances. With versatile cooking
options including microwave or convection for ecient heating
across a variety of dishes. Intuitive temperature and heat type
recommendations can be accessed via the large touch screen
and SmartHQ™, to support optimal cooking results across a
wide range of functions and food types.
PRODUCTS
oM30NPUX3
30" Series 9 Professional Compact Convection-Speed Oven
SERIES & STYLE
Series 9
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space. Matches with Professional style family of
appliances
2 Combines fast microwave cooking with even convection
heat for versatile, efficient heating across a variety of dishes
3 With soft open and close, the CoolTouch door is safe to
touch from the outside - protecting hands and surrounding
cabinetry
4 Generous 1.3 cu ft useable capacity with four shelf positions
5 Large 6.8" touchscreen is intuitive and easy to use
6 Achieve optimal results with temperature and heat type
recommendations
7 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
8 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Chrome Side Ladders
2 Wire Shelf
3 Step Down Wire Shelf
4 Broil Rack
5 Glass Tray
6 Wired Temperature Sensor
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1690004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | WARMING DRAWER, 30" WB30SPEX3
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this Warming
Drawer matches seamlessly with our Professional style family of
appliances. Featuring a soft-close mechanism, intuitive touch
controls, and a smooth glass base for easy cleaning. With six
tailored programmes and space for 16 place settings, it keeps
meals ready to serve.
PRODUCTS
WB30SPEX3
30" Series 9 Professional Warming Drawer
SERIES & STYLE
Series 9
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space. Matches with Professional style family of
appliances
2 Soft-close drawer for a smooth closure
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean stainless steel finish for a bold and durable
look
5 Automatic switch-off and delayed start functionality to help
keep dishes warm until it is time to serve
6 Room for 16 standard-sized place settings
7 Six tailored programmes for Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
ACCESSORIES
1 Accessory rack for optimising space
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1790004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Automatic switch-off and delayed start functionality, to help
keep dishes warm until it is time to serve
5 Room for 16 standard-sized place settings
6 Six tailored programmes for Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
7 Six tailored programmes for Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
ACCESSORIES
1 Accessory rack for optimising space
SPECIFICATION GUIDE | INTEGRATED WARMING DRAWER, 30" WB30SDEI3
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Warming Drawer with kitchen cabinetry
for a cohesive kitchen look. Featuring a push-to-open
mechanism, intuitive touch controls, and a smooth glass base
for easy cleaning. With six tailored programmes and space for
16 place settings, it keeps meals ready to serve.
PRODUCTS
WB30SDEI3*
30" Series 9 Integrated Warming Drawer
*Panel ready.
SERIES & STYLE
Series 9
Integrated
Integrated Warming Drawer WB30SDEI3 with Compact
Combi-Steam Oven OS30NPUX3
Integrated Warming Drawer WB30SDEI3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1890004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | VACUUM SEAL DRAWER, 30" VB30SPEX3
OVERVIEW
Designed to make a bold statement in the kitchen space with a
striking handle and brushed stainless steel finish, this Vacuum
Seal Drawer matches seamlessly with our Professional style
family of appliances. A soft-close mechanism and intuitive touch
controls oer eortless use, while three vacuum and heat
sealing levels support sous vide preparation, marinating, and
food storage, using reusable and BPA-free food-grade bags.
PRODUCTS
vB30SPEX3
30" Series 9 Professional Vacuum Seal Drawer
SERIES & STYLE
Series 9
Professional
FEATURES
1 Professional style is designed to make a bold statement in
the kitchen space. Matches with Professional style family of
appliances
2 Soft-close drawer for a smooth closure
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean stainless steel finish for a bold and durable
look
5 Three levels of vacuum and heat sealing - for easy re-
sealing, food portioning, marinating, storage and extending
shelf life
6 Allows effortless preparation for sous vide cooking
7 Our food-grade, BPA-free bags are an excellent storage
option — these can be re-used if sealed and cut
appropriately
ACCESSORIES
1 Large BPA-free Vacuum Bags - 50 bags (Part 793034)
2 Small BPA-free Vacuum Bags - 50 bags (Part 793033)
3 External Vacuuming Accessory Kit
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 1990004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | INTEGRATED VACUUM SEAL DRAWER, 30" VB30SDEI3
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Vacuum Seal Drawer with kitchen
cabinetry for a cohesive kitchen look. A push-to-open
mechanism and intuitive touch controls oer eortless use,
while three vacuum and heat sealing levels support sous vide
preparation, marinating, and food storage, using reusable and
BPA-free food-grade bags.
PRODUCTS
vB30SDEI3*
30" Series 9 Integrated Vacuum Seal Drawer
*Panel ready.
SERIES & STYLE
Series 9
Integrated
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Three levels of vacuum and heat sealing - for easy re-
sealing, food portioning, marinating, storage and extending
shelf life
5 Allows effortless preparation for sous vide cooking
6 Our food-grade, BPA-free bags are an excellent storage
option — these can be re-used if sealed and cut
appropriately
ACCESSORIES
1 Large BPA-free Vacuum Bags - 50 bags (Part 793034)
2 Small BPA-free Vacuum Bags - 50 bags (Part 793033)
3 External Vacuuming Accessory Kit
Integrated Vacuum Seal Drawer VB30SDEI3 with Compact
Combi-Steam Oven OS30NPUX3
Integrated Vacuum Seal Drawer VB30SDEI3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 2090004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB30SPPUX3, OB30SPPSUX3, OS30SPUX3 SPECIFICATION GUIDE | 30" OVENS AND COMPANIONS
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
Ventilation
required
SELF-CLEANING OVEN
OB30SPPUX3
SELF-CLEANING STEAM ASSIST OVEN
OB30SPPSUX3
COMBI-STEAM OVEN
OS30SPUX3
PRODUCT DIMENSIONS inch mm inch mm inch mm
A Overall height 28 11/16 729 28 11/16 729 23 9/16 598
B Overall width 29 7/8 758 29 7/8 758 29 7/8 758
C Chassis height 27 7/8 708 27 7/8 708 22 5/8 575
D Chassis width 28 3/8 720 28 3/8 720 28 3/8 720
E Chassis depth 22 5/8 575 22 5/8 575 22 7/1 6 545
F Control panel thickness 15/16 24 15/16 24 15/16 24
Depth with door fully open* 23 1/4 590 23 1/4 590 18 1/8 460
*Measured from front of control panel.
CAVITY DIMENSIONS inch mm inch mm inch mm
G Minimum inside height of cavity 28 1/32 712 28 1/32 712 22 13/16 580
H Minimum inside width of cavity 28 1/2 724 28 1/2 724 28 1/2 724
I Minimum inside depth of cavity* 23 1/2** 597** 23 1/2** 597** 21 5/8 550
Recommened cabinet height 28 3/4 731 28 3/4 731 23 5/8 600
Recommened cabinet width 30 762 30 762 30 762
*Measured from front of chassis.**Requires ventilation at the rear of the cavity.
Ventilation
required
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 2190004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OS30NPUX3, OM30NPUX3, EB30PSX1SPECIFICATION GUIDE | 30" OVENS AND COMPANIONS
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
Ventilation
required
Ventilation
required
Additional
panel
5/8"
(16mm)
thickness
BUILT-IN COFFEE MAKER
EB30PSX1
COMPACT COMBI-STEAM OVEN
OS30NPUX3
COMPACT CONVECTION-SPEED OVEN
OM30NPUX3
PRODUCT DIMENSIONS inch mm inch mm inch mm
A Overall height 18 1/2* 470* 18 458 18 458
B Overall width 29 13/16* 757* 29 7/8 758 29 7/8 758
C Chassis height 17 7/16 442 17 1/8 435 17 1/8 435
D Chassis width 22 1/16 560 28 3/8 720 28 3/8 720
E Chassis depth 17 6/16 445 21 7/16 545 21 7/ 16 545
F Control panel thickness 1 9/16* 40* 15/16 24 15/16 24
Depth with door fully open** - - 12 5/8 320 12 5/8 320
*Measurements with trim kit. **Measured from front of control panel.
CAVITY DIMENSIONS inch mm inch mm inch mm
G Minimum inside height of cavity 18 3/8**** 466**** 17 5/16 440 17 5/16 440
H Minimum inside width of cavity 22 1/16*** 560*** 28 1/2 724 28 1/2 724
I Minimum inside depth of cavity* 21 1/2** 545** 21 5/8 550 21 5/8** 550**
Recommened cabinet height 18 9/16 472 18 1/8 460 18 1/8 460
Recommened cabinet width 30 1/16 764 30 762 30 762
*Measured from front of chassis. **Requires ventilation at the rear of the cavity. ***Cabinetry requires additional vertical sidewalls to secure the product. ****Includes spacer thickness, Spacer required only for standalone installation.
Note: Built-In Coee Maker measurements are dierent to other products. Configurations are possible, but consider installation requirements.
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 2290004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
WB30SPEX3, WB30SDEI3,
VB30SPEX3, VB30SDEI3SPECIFICATION GUIDE | 30" OVENS AND COMPANIONS
A
B
C
D
E
F
g
h
i
WARMING DRAWER
WB30SPEX3
INTEGRATED WARMING DRAWER
WB30SDEI3
VACUUM SEAL DRAWER
VB30SPEX3
INTEGRATED VACUUM SEAL DRAWER
VB30SDEI3
PRODUCT DIMENSIONS inch mm inch mm inch mm inch mm
A Overall height 10 11/16 271 10 11/16 271 10 11/16 271 10 11/16 271
B Overall width 29 7/8 758 29 7/8 758 29 7/8 758 29 7/8 758
C Chassis height 10 11/16 271 10 11/16 271 10 11/16 271 10 11/16 271
D Chassis width 27 3/4 704 27 3/4 704 28 1/2** 724** 28 1/2** 724**
E Chassis depth* 21 9/16 547 21 9/16 547 21 11/16 551 21 11/16 551
F Front panel thickness 15/16 24 min 5/8*** min 16*** 15/16* 24 min 5/8*** min 16***
Front panel height 10 1/2 267 10 1/2 267 10 1/2 267 10 1/2 267
Front panel width 29 7/8 758 29 7/8 758 29 7/8 758 29 7/8 758
*Including power plug. **Including side brackets. ***A clearance of 1/16" (2mm) between the cabinet and the custom panel is required for the push-to-open mechanism (spacer included). Maximum custom panel weight 11 lb (5kg).
CAVITY DIMENSIONS inch mm inch mm inch mm inch mm
G Minimum inside height of cavity 10 3/4 273 10 3/4 273 10 3/4 273 10 3/4 273
H Minimum inside width of cavity 28 1/2 724 28 1/2 724 28 1/2 724 28 1/2 724
I Minimum inside depth of cavity* 22 13/16 580 22 13/16 580 22 13/16 580 22 13/16 580
Recommened cabinet height 10 3/4 273 10 3/4 273 10 3/4 273 10 3/4 273
Recommened cabinet width 30 762 30 762 30 762 30 762
*Measured from front of chassis.
Note: Drawers can fully support 30inch Fisher & Paykel ovens, without adding shelf in between.
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 2390004607A PLANNING GUIDE 30" ovENS AND CoMPANIoNS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
ALL MODELSSERVICES | 30" OVENS AND COMPANIONS
SELF-CLEANING OVEN
OB30SPPUX3
SELF-CLEANING STEAM
ASSIST OVEN
OB30SPPSUX3
COMBI-STEAM OVEN
OS30SPUX3
BUILT-IN COFFEE
MAKER
EB30PSX1
COMPACT COMBI-STEAM
OVEN
OS30NPUX3
COMPACT CONVECTION-
SPEED OVEN
OM30NPUX3
WARMING DRAWER
WB30SPEX3,
WB30SDEI3
VACUUM SEAL DRAWER
VB30SPEX3,
VB30SDEI3
PRODUCT
REQUIREMENTS
Supply 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 120 V, 60 Hz 208 or 240 V, 60 Hz 208 or 240 V, 60 Hz 120 V, 60 Hz 120 V, 60 Hz
Service 20 A 20 A 20 A 10 A 20 A 20 A 10 A 10 A
Connection
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Plug with flex cord
66 15/16" (1700mm)
Hard wired
78 3/4"(2000mm)
Hard wired
78 3/4"(2000mm)
Plug with flex cord
70 7/8" (1800mm)
Plug with flex cord
70 7/8" (1800mm)
CAPACITY
Total Oven capacity 4.9cu ft (137L) 4.9cu ft (137L) 3cu ft (85L) - 1.9cu ft (55L) 1.7cu ft (49L) - -
Total water tank capacity - 22.65fl oz (0.67L) 47.3fl oz (1.4L) 81 fl oz (2.4L) 47.3fl oz (1.4L) - - -
Note: All Coee Makers and Steam Ovens have internal water tanks which need to be filled manually. No external water supply is required.
ISOMETRIC
VIEW
<< CONTENTS
