COMPACT STEEL CREEPER/SEAT WITH 6
WHEELS
MODEL NO: SCR791
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health & safety, local authority and general workshop practice regulations are strictly adhered to when using this
equipment.
9 Familiarise yourself with product application and limitations, as well as the specic potential hazards peculiar to this product.
9 Maintain creeper in good condition. Use an authorised service agent.
9 Replace or repair damaged parts. Use only genuine parts only. Non authorised parts will invalidate warranty.
WARNING! Use the creeper on level and solid ground, preferably concrete.
8 DO NOT use the creeper for any purpose other than that for which is designed.
8 DO NOT stand on the creeper.
8 DO NOT get the creeper wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT clean the creeper with any solvents which may damage the paint surface or padded areas.
2. INTRODUCTION
Powder coated tubular steel construction with padded vinyl cushions. Super-stable design with six smooth-rolling Ø50mm ball-bearing
swivel castors. Converts to seat mode in seconds. 180kg Capacity in creeper mode and 130kg capacity in seat mode.
SEAT
MODE
HEADREST
CASTORS
CREEPER
MODE
3. SPECIFICATION
Model No: ...........................................................SCR791
Capacity: ...................................... 180kg (creeper mode)
.......................................................... 130kg (seat mode)
Nett Weight: ........................................................... 5.8kg
Wheels: .........................................................6 x Ø50mm
4. ASSEMBLY
Refer to Parts (FIG.1)
4.1. ATTACH ASSEMBLIES 1,2,3.
4.1.1. Using bolts (11) washers (7) and nuts (12) assembly all three
pre-built sections (1, 2, 3).
4.2. ATTACH THE 6 CASTOR WHEELS
4.2.1. Fix the 6 castor wheels (8) to the creeper frame using grub screws
(13) and washers (14) shown g.1.
Refer to
instructions
SCR791 Issue 2 (2) 20/01/25Original Language Version
© Jack Sealey Limited
Wear eye
protection
FIG.1
5. OPERATION
WARNING! If you raise the vehicle to work under it, set the vehicle on jack stands.
8 DO NOT work under a vehicle raised on a jack(s).
5.1. If the vehicle is on the ground, block the tyres, apply the handbrake and put it into gear or Park mode.
5.2. As you slide under the vehicle and prior to sliding out on the creeper, keep your head at on the headrest.
5.3. If storing the creeper vertically, store near a wall and with the cushions facing the wall.
6. MAINTENANCE
6.1. Before each use, inspect the overall condition of the creeper for broken, cracked or bent parts that may effect the proper operation.
6.2. Periodically check tightness of xings.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
