-V1.0-
Mini Fridge
4L Mirror Fridge User Manual
Model:
LY1904
This manual contains important information regarding the safety,
operation, maintenance, and storage of this product. Before
usage, read and understand all warnings, instructions and
product labels. Failure to do so could result in possibly injury or
property damage. Please keep this manual for future reference.
Thank you for purchasing the AstroAI 4LMirror Fridge. This is a
portable fridge that can be used with both a 12-volt car and a
standard wall outlet. With an included cool and warm function,
you’ll be able to keep everything at the perfect temperature.
We hope you enjoy your new Mini Refrigerator! Questions or
Concerns? Youarewelcometocontactuswithyourquestionvia
SAFETY INFORMATION
● The fridge should connect to 110V power supply. (Countries with
different voltages need to select products with corresponding
voltages.)
● When using the 12V vehicle power supply, the fridge should not be
left connected for long periods of time when the engine is not
running.
● Please do not connect the fridge with the 24V cigarette lighter of a
heavy-duty vehicle.
● Unplug this fridge during lightning storms or when not in use for long
periods of time to prevent damages.
● Do not open or remove covers in case of any dangers.
● To avoid the risk of fire or electric shock, please avoid overloading the
socket, extension cord or other devices.
● Use the right power supply according to the instructions in the user
manual or the specifications on the fridge.
● The supply voltage should be the same as that indicated in the
technical specifications and the appliance rating plate.
● In order to disconnect the fridge from power supplies completely,
please unplug the fridge.
● Do not bend, stretch or pull the supply cable in case of electric shocks.
● When installed, the power socket must be within easy reach.
● Avoid using locations where dust or other airborne contamination
may be drawn into the fan.
● Never leave the fridge running in poorly ventilated areas such as a
car’s trunk.
● Handle with ease and do not squeeze. Keep upright.
● Do not sit on the fridge.
● Allow at least 2 inches of distance from the back and sides of the
device to allow proper air circulation and heat dispersal.
● Allow 30 minutes for the fridge to return to room temperature before
attempting to switch from warming to cooling mode, or vice versa.
● Keep the product away from rains or any corrosive gases or liquids.
● Disconnect the power supply when not in use for a long time, the
fridge should be stored in a dry, cool and well-ventilated area away
from direct sunlight.
● For safety, children must operate under the supervision of an adult.
DIAGRAM
OFF
WARM
DC
AC
12V
COOL
Door Handle
DimmableLEDLight
LED light Button
Warm Indicator LightCool Indicator Light
Warm Button / OFF Button / Cool Button
DC Power Port AC Power Port
DC Power Cord
Removable Shelf Door Basket
Carrying Handle
AC Power Cord
SIZE DESCRIPTION
INSTRUCTIONS
355ml
10.43in
9.65in
5.32in
355ml
8.1in
6.89in
5.51in
I .
CONNECTING THE 12V POWER SUPPLY
ADVICE: Please do not remove the protective film as dust may
contaminate the mirrored door, when we use the fridge in the
car frequently.
●
Switch the Warm Button/OFF Button/Cool
Button to OFF position Before connecting the
plug to the socket.The OFF Button is located in
the middle of the Warm button and Cool
Button, when OFF Button is pressed, both of
the indicator lights will not light.
●
Insert the power cord into the DC power port
at the rear of the fridge.
DC 12V
OFF
WARM COOL
II .
CONNECTING THE 110V HOUSEHOLD POWER SUPPLY
●
Switch the Warm Button/OFF Button/Cool
Button to OFF position before connecting the
plug to the socket.The OFF Button is located in
the middle of the Warm Button and Cool
Button, when OFF Button is pressed, both of
the indicator lights will not light up.
●
Insert the power cord into the AC power port
at the rear of the fridge.
AC
●
Place the fridge on a stable surface and plug
the power cord into the 12V socket.
●
Switch the Warm Button/OFF Button/Cool Button to Cool
Button side, the green indicator light will be lit up, switch
Warm Button/OFF Button/Cool Button to Warm side, the red
indicator light will be lit up.
●
Please remove the protective film before use; for clear sight.
After long use, please clean the mirrored door gently; for
better use experience. The cleaning method of the mirrored
door is included in the User Manual.
WARNING:
Running the fridge may drain the vehicle’s battery while your
vehicle is off.
OFF
WARM COOL
COOL MODE TIPS
WARM MODE TIPS
MAINTENANCE
● To achieve the quickest cooling, fill the fridge with beverages or
objects which have already been refrigerated.
● The fridge is not only suitable for beverages, but also suitable for
cosmetics and makeup products.
● The lowest possible temperature depends on the ambient
environment. The lowest temperature the fridge can achieve may rise
if the ambient temperature is too high.
● The fridge is designed to keep items warm. It is not designed to heat
up cold items.
●
Hot items will stay warm for several hours after the portable fridge
has been turned off, provided that the door is closed properly.
● Make sure the product is disconnected before regular maintenance.
●
Use wet cloth or mild cleanser to clean the appearance of the fridge.
●
When not in use, please keep the interior of the fridge completely dry
and store it well.
●
Please place the fridge up-straight. Do not squeeze it.
●
Secure the fridge in place and insert the power
cord into the wall outlet.
●
Switch the Warm Button/OFF Button/Cool Button to Cool
Button side, the green indicator light will be lit up, switch
Warm Button/OFF Button/Cool Button to Warm side, the red
indicator light will be lit up.
●
When the mirrored door is in use, you can press the LED light
Button to adjust the light’s intensity.
THE CLEANING METHOD OF THE MIRROR
TROUBLE-SHOOTING
● The sanitizer is a nice option for cleaning the mirror.
●
Use a soft cloth dipped in some wax to clean the mirror.
●
Use a soft cloth dipped in milk to clean the mirror.
●
Apply soap on the mirror first, then use a dry cloth to wipe the
mirror.
●
Skin toner and dishwashing liquid are useful for cleaning the mirror.
● Check the indicator lights (warm/cool indicator
light); if the lights stop working, please check
the power connection.
● Check the plug to ensure it is in a good
contact; clear the dirt on the plug if needed.
● Turn on the car power first (for car use).
● Ensure the working voltage matches the local
voltage (for home use); only for 12V cigarette
lighter (for car use).
Fridge is
not working
● Ensure the switch is on the the ‘ Cool ’ side.
● Check if the fan works well (contact AstroAI for
help if not).
● The lowest possible temperature depends on
the ambient environment but will not be lower
than 32
°F
. The cooler the ambient
temperature it is, the colder the fridge can
become.
The cooler
is not working
● Allow at least 2 inches distance from the wall,
to ensure proper air circulation and heat
dissipation.
● DO NOT use the fridge in a high temperature
environment.
● DO NOT directly cool hot objects.
Poor heat
dissipation
SPECIFICATIONS
● DO NOT open or close the door too frequently
or open for a long time.
● DO NOT directly cool hot objects.
Condensation
Water
Mini Fridge
Model
Input voltage
DC12V
cool mode: 40W
warm mode: 32W
cool mode: 0.7A
50/60Hz
warm mode: 0.63A
50/60Hz
cool mode: 50W
50/60Hz
warm mode: 40W
50/60Hz
cool mode: 50W
50/60Hz
warm mode: 40W
50/60Hz
AC100 - 120V
(USA)
AC100 - 110V
(JP)
AC200 -240V
(DE/UK/FR/ES)
LY1904
● Ensure the power supply is connected well.
● Check if the LED light button is working
properly.
Dimmable LED
light not working
Capacity 4L
1 YEAR LIMITED WARRANTY FROM ASTROAI
Each AstroAI 4L Mirror Fridge will be free from defects in material
and workmanship. This warranty does not cover damage from
neglect, misuse, contamination, alteration, accident, or abnormal
conditions of operation or handling. This warranty covers the
original purchaser only and is not transferable.
AstroAIalwayswantstoprovideourcustomerswithexcellent
productsaswellascustomerservice.Toknowmoreaboutus,
pleasevisitastroai.com.
Operating
temperature
Certifications
Ambient Temp - 32
°F
Chill
140°F (60°C) Heat
ETL / CE / PSE / UKCA / RoHS
Class II
construction
