-V1.0-
Model:LY2206A
6L Mini Fridge
User Manual
Please fully read and understand this manual
before using this product and keep this manual
for future reference.
!
Thank you for purchasing the AstroAI 6L Mini Fridge.
This is a portable fridge that can be used with both a 12V
car and a standard wall outlet. With an included cool and
warm function, you’ll be able to keep everything at the
perfect temperature.
We hope you enjoy your new Mini Refrigerator! Questions
or Concerns? Youarewelcometocontactuswithyour
questionvia[email protected].
SAFETY INFORMATION
● The fridge shall connect to a wall outlet with an AC power cord.
Before using check that the voltage power corresponds to the one
shown on the appliance nameplate (US/Canada: 120V,
Japan: 100-110V, Europe/UK: 220-240V).
● To avoid potential danger, please do not disassemble the fridge.
● To avoid the risk of fire or electric shock, please plug the fridge into
an exclusive grounded outlet.
● Avoid using locations where dust or other airborne contamination
may be drawn into the fan.
● Allow at least 2 inches of distance from the back and sides of the
fridge to allow proper air circulation and heat dispersal.
DO NOT place the fridge in a poorly ventilated area.
● Store the fridge in a dry and well-ventilated place, and avoid direct
sunlight.
● Wash the drip tray regularly for hygiene.
● DO NOT allow children to use the product without the supervision of
an adult.
● Unplug your power cord from the 12V cigarette lighter socket when
the engine is turned off, or the battery power might be running out.
● DO NOT connect the 24V vehicle power supply of heavy-duty vehicles
directly.
● Unplug this fridge during lightning storms or when not in use for long
periods of time to prevent damages.
● To disconnect, turn off the switch on the back of the fridge, then
unplug the plug from the power supply.
● DO NOT bend, stretch or pull the power cable in case of electric
shocks.
● Ensure the power socket is easy to access during the installation.
● Handle with care.
DO NOT squeeze the product.
DO NOT put the product upside down.
● DO NOT place heavy objects on the product.
● When switching the modes, please turn off the fridge and wait for 30
minutes until the fridge reaches room temperature.
● Let the product away from rains or any corrosive gases or liquids.
DIAGRAM
⑥ Anti-slip Silicone Mat
⑦ DC Power Port
⑧ Warm/OFF/Cool Switch
⑨ Cool Indicator
⑩ Warm Indicator
⑪
⑫
⑬
⑬
Removable Basket
⑭ DC Power Cord
⑮ AC Power Cord
⑪ Removable Shelf
⑫ Drip Tray
④ Air Inlet Port
⑤ AC Power Port
③ Door
② Handle
① Air Outlet Port
④
⑤
⑥ ⑦ ⑧
⑨
⑩
③
⑮
⑭
②
①
SIZE DESCRIPTION
INSTRUCTIONS
355ml
355ml
13.4cm/5.28in 14.4cm/5.67in
25cm/9.84in 18.5cm/7.28in
25.6cm/10.08in
31cm/12.20in
I .
CONNECTING THE 12V POWER SUPPLY
●
Turn the switch to the OFF position before
connecting to the power supply, both
indicators will not light up.
●
Insert the DC power cord into the DC power
port on the back of the fridge.
II .
CONNECTING THE HOUSE POWER SUPPLY
●
Turn the switch to the OFF position before
connecting to the power supply, both
indicators will not light up.
●
Insert the AC power cord into the AC power
port at the back of the fridge.
●
Place the fridge on a stable surface, and
insert the DC power cord plug into the
cigarette lighter socket of the vehicle.
●
Switch the Cool Button/OFF Button/Warm Button to the Cool
side, the green indicator light will be turned on; switch to the
Warm side, the red indicator light will be turned on.
●
Switch the Cool Button/OFF Button/Warm Button to the Cool
side, the green indicator light will be turned on; switch to the
Warm side, the red indicator light will be turned on.
●
Place the fridge on a stable
surface, and insert the AC
power cord plug into the wall
outlet. Before using, check
that the local voltage power
corresponds to the one shown on the appliance nameplate.
COOL MODE TIPS
WARM MODE TIPS
TROUBLE-SHOOTING
● To achieve the quickest cooling, fill the fridge with beverages which
have already been refrigerated.
●
The fridge is not only suitable for beverages but also suitable for
cosmetics and fruits.
●
The lowest possible temperature the fridge can achieve depends on
the ambient environment. The lower the ambient temperature, the
better the fridge’s cooling performance.
● The fridge is designed to keep items warm instead of heating up
cold items.
●
The highest temperature of the fridge can achieve
150
°F
(66°C)
.
Never put flammable, explosive articles into the fridge.
● Check the indicator lights (warm/cool indicator
light); if the lights stop working or flash, please
check the power connection.
● Check the rear of the fridge; ensure the switch
is turned on correctly.
● Turn on the car power first (for car use).
● Ensure the working voltage matches the local
voltage (for home use). Only applicable for
12V cigarette lighters (for car use).
Fridge is
not working
● Allow at least 2 inches distance from the wall,
to ensure proper air circulation and heat
dissipation.
● DO NOT use the fridge in a high temperature
environment.
● DO NOT block the heat dissipation part.
Poor heat
dissipation
MAINTENANCE
SPECIFICATIONS
● Make sure the fridge is empty and disconnected before the regular
maintenance.
●
Use a wet cloth and mild cleanser to clean the fridge.
●
If not in use for a long time, please ensure that the interior is
completely dry before storing.
● Ensure the switch is on the ‘Cool’ side.
● Check if the fan works well (contact AstroAI for
help if not).
● The lowest possible temperature depends on
the ambient environment but will not be lower
than 32°F (0°C). The cooler the ambient
temperature it is, the colder the fridge can
become.
The cooler
is not working
● DO NOT open or close the door too frequently
or open for a long time.
● DO NOT cool high temperature objects
directly.
Condensation
water
● Check if there are any foreign objects on the
fan.
● Check the fridge if there are any components
fall off.
Abnormal noise
6L Mini Fridge
Model LY2206A
Capacity 6L
RECYCLING
● You may dispose of the product when its service life has ended,
please recycle the recyclable parts according to local guidelines.
Input voltage
DC12V
cool mode: 40W ; 3.3A
warm mode: 32W ; 2.7A
cool mode: 0.7A
60Hz
warm mode: 0.63A
60Hz
cool mode: 50W
50/60Hz
warm mode: 40W
50/60Hz
cool mode: 50W
50/60Hz
warm mode: 40W
50/60Hz
AC 120V
(USA/CA)
AC100 - 110V
(JP)
AC220 -240V
(DE/UK/FR/ES)
Operating
temperature
32°F-40°F (18-22°C)
below the ambient temperature
Highest Warming Temperature>150°F (66°C)
Certifications ETL / CE / PSE / UKCA
Class II
Construction
1 - Year Warranty Limited Warranty From AstroAI
WARRANTY PERIOD
Each AstroAI 6L Mini Fridge will be free from defects in material and
workmanship. This warranty does not cover damage from neglect,
misuse, contamination, alteration, accident, or abnormal conditions of
operation or handling. This warranty covers the original purchaser only
and is not transferable.
AstroAI always wants to provide our customers with excellent products
as well as Customer Service. To know more about us, please visit
