Starwatcher Telescope
70060, 525 Power
See reverse side for additional information
For detailed usage see included telescope manual
www.barska.com
Specifications
Description
The 525 power Starwatcher with an aperture of 60mm and a
focal length of 700mm is an ideal entry-level telescope for the
aspiring amateur astronomer. It is easy to set up and comes with
everything necessary to begin the adventure of a lifetime
including telescope, finderscope, diagonal, three eyepieces,
moon filter, Barlow lens, mount and tripod. The beginner's
version of Barska's popular Deepsky Astronomy Software leads
this journey into space. The software is packed with many
features that both experienced and novice users will appreciate
and includes a searchable database of over 10,000+ objects
including, nebulae, star clusters, double stars, and variable
stars. Simply load it into a PC and begin your journey to the
stars and planets.
Telescope Type
Maximum Attainable Power
Focal Length (mm)
Objective Lens Diameter (mm)
Finderscope
Mount
Eyepiece 1
Eyepiece 2
Eyepiece 3
Barlow Lens
Erecting Image Eyepiece
Moon Filter
Accessory Tray
Tripod
Optical Coating
Telescope Weight (kg/lbs)
Refractor
525x
700
60
Red Dot
Altazimuth
SR4
H12
H20
3x
1.5x
Yes
Yes
Aluminimum
Fully Coated
3.2/7
4/16
BC462
© 2016 BARSKA®
Pomona, CA 91767 | (t) 888.666.6769 | (f) 909.445.8169 | www.barska.com
Place the (N) accessory tray on top of (O)
center leg brace. Thread the (N) accessory tray
into the threaded hole in the center of the (O)
leg brace and screw into place.
Line up the (L) main telescope optical tube
with the side mount holes on the (J) yolk
mount and secure in place using the two (D)
optical tube screws.
Insert the (Q) slow motion control rod into
the hole on the (J) yolk mount. Then secure
the (Q) slow motion control rod with the
included (R) control rod screw by tightening
it with the included (G) screwdriver.
Attach (F) tripod leg screw to the extension
base on each of the (S) tripod legs.
Attach each (S) tripod leg to the (J) yolk
mount using the (E) leg to yolk screw sets.
Use the (P) center leg brace screws on the (O)
center leg brace to connect each of the center
leg braces to the three (S) tripod legs.
Remove the (K) knurled nuts and attach the
(I) finderscope to (L) main telescope optical
tube with the battery compartment and lens
facing the front of the telescope. Secure by
tightening the (K) knurled nuts.
Insert the chrome barrel of the (C) diagonal
into the focuser tube on the (I) main
telescope optical tube and tighten the
set screw.
Choose one (B) eyepiece and insert the
chrome barrel of the eyepiece into the (C)
diagonal and tighten the set screw.
See reverse side for additional information.
For detailed usage see included
telescope manual.
S Three Tripod Legs
H Moon Filter
G Screwdriver
D Two Optical
Tube Screws
E Three Leg to
Yolk Screws
F Three Tripod
Leg Screws
J Yolk Mount
M Two Barlow Lenses
K Two Knurled Nuts
I Finderscope
O Center Leg Brace
R Control Rod Screw
Q Slow Motion Control Rod
L Main Telescope Optical Tube
1 2 3
4 5 6
7 8 9
CAUTION: DO NOT LOOK DIRECTLY AT THE SUN.
VIEWING THE SUN OR ANY LIGHT SOURCE WITH THIS
OPTICAL DEVICE CAN CAUSE PERMANENT EYE DAMAGE.
Assembly
Starwatcher Telescope Quick Set Up - 70060, 525 Power
N Accessory Tray
P Three Center Leg
Brace Screws
Parts Included
A Three Eyepiece
Containers
B Three Eyepieces
C Diagonal
