STAINLESS STEEL
ALL-IN-ONE
WINE SET
USER GUIDE
IVAWS30SS
Thank you for purchasing the Ivation® Stainless Steel All-in-
One Wine Set. This User Guide is intended to provide you with
guidelines to ensure that operation of this product is safe and
does not pose risk to the user. Any use that does not conform
to the guidelines described in this User Guide may void the
limited warranty.
Please read all directions before using the product and retain
this guide for reference. This product is intended for household
use only. It is not intended for commercial use.
This product is covered by a limited one-year warranty.
Coverage is subject to limits and exclusions. See warranty
for details.
• The electronic wine opener is only intended to extract the
corks from standard wine bottles.
• Do not operate or attempt to operate the electronic wine
opener if either the AC/DC adapter or charging base stand
have been damaged. This could result in electric shock.
• If the adapter or charging base have been damaged, they will
need to be replaced by the manufacturer or a suitably
qualified person. Do not attempt to modify or repair this
device on your own.
• Do not place or store this appliance near an open flame,
cooking or heating appliances, or any similarly hot surface.
• This appliance is not intended for use in wet or damp
conditions, as this creates the risk of electric shock.
• Always make sure that the power cord is positioned so that it
will not get damaged or create a tripping hazard.
• Use only the AC/DC adapter and the charging base supplied
with your unit, do not attempt to use other parts with
this device.
• Do not immerse this unit in water or any other liquid.
• This product is intended for indoor use only. Do not expose
the wine opener or the charging base to rain or other extreme
outdoor conditions or environments.
• Never force the wine opener and/or preserver onto a bottle,
nor should you attempt to speed up the mechanism. The
cork remover always works best when operated at its
intended speed.
• Do not touch or adjust the electronic wine opener mechanism
or the corkscrew spiral. You should only hold the cork remover
by its plastic housing, or else you could risk electric shock or
other severe injury.
• This appliance contains a rechargeable battery. Do not dispose
of this product on a fire, as this may cause an explosion.
• To avoid electric shock, do not open the casing. There are no
user-serviceable parts inside.
• This appliance should not be used by children or persons with
reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they are closely supervised
at all times, and/or have received extensive instruction and
training on how to use this device by a person responsible for
their safety.
CAUTION: The corkscrew is sharp. Keep fingers and other
body parts, appendages, and/or utensils away from the
operating end of the wine opener.
SAFETY PRECAUTIONS
Before using the wine opener for the first time, we recommend
letting it charge for at least 12 hours.
1. Connect one end of the charging cable into the power socket
at the back of the charging base. Then connect the other end
of the charging cable into an appropriate power socket.
2. Place the electronic wine opener into the charging base,
corkscrew-side down. Ensure the metal pieces on the bottom
of the wine opener match with the ones on the base.
3. When the wine opener is charging, it will glow blue.
4. The wine opener can be used to open up to 30 bottles when
fully charged.
CHARGING THE ELECTRONIC
WINE OPENER
1. Before extracting the cork, be sure
to remove the bottle seal using
the included foil cutter
3. Firmly hold both the wine bottle and the wine opener, then
press and hold the ▼ button. This will cause the corkscrew
to drill into the cork. While the wine opener is operating, it
will glow blue.
4. To remove the cork from the bottle,
press and hold the ▲ button until the
cork has been removed.
2. Place the wine opener on top of
the wine bottle, ensuring that it
remains in an upright position.
Do not hold the wine opener
at an angle, or it will not
remove the cork properly.
USING THE ELECTRONIC
WINE OPENER
1. Place the aerator pourer into
the bottle neck snugly to allow
the wine to pour out smoothly
without splashing into a glass
or other container.
2. The pourer aerates as wine
flows through it, oxygenating
the wine to give it a better,
richer flavor.
USING THE AERATOR POURER
Power Input: 6 V DC 80 mA
Weight: 1.9 lbs. (850 g)
SPECIFICATIONS
1. Place the wine bottle on a flat surface.
2. Insert a wine stopper into the open bottle.
3. While holding the wine stopper onto the
bottle neck, place the vacuum preserver
(on the opposite end of the wine opener)
over the wine stopper. Hold the vacuum
preserver firmly in place, without applying
excessive pressure.
4. Gently press the vacuum preserver down onto the bottle neck.
It will begin to remove the air from the bottle. The unit will run
for 20 seconds. Do not release the power button until it
has stopped.
5. You may need to do this one or two times, depending on how
much wine is left in the bottle.
6. Remove the vacuum preserver and return it to the
charging base.
USING THE VACUUM PRESERVER
AND WINE STOPPERS
1. Use the ▼ symbol on the wine stopper to
indicate the date when the bottle was sealed.
2. Gently swivel the silver ring until the correct
date is in line with the ▼ symbol.
USING THE DATE INDICATOR
ON THE STOPPERS
info@myivation.com
1-866-849-3049
Distributed by C&A Marketing, Inc.
114 Tived Lane East
Edison, NJ 08837 USA
Europe: C&A Europe
167 Hermitage Road
Crusader Industrial Estate
London N4 1LZ
United Kingdom
Made in China
Ivation is a trademark of C&A IP Holdings, LLC in the U.S.
©2019. All rights reserved.
QUESTIONS OR PROBLEMS?
CONTACT US!
PACKAGE CONTENTS
2-in-1 wine
opener &
vacuum
preserver
Wine
stoppers
(2)
Charging
cable
+
Charging
base
(not shown)
Foil
cutter
Aerator
pourer
Note: This electronic wine opener is designed for use with
traditional corks, but is compatible with synthetic ones as
well. Since synthetic corks are smaller than traditional
corks and do not expand, they may occasionally become
stuck to the corkscrew. If this happens, hold the cork firmly
with a small pair of pliers, then press and hold the ▲
button and allow the cork to release slowly.
Note: Since this product uses suction to remove air from
bottles, it may occasionally become stuck. If this happens,
hold the stopper and the bottle neck with one hand, then
carefully tilt the vacuum preserver away from the bottle to
break the suction.
360°
