9-Piece
Wine Gift Set
SKU: IVAWGSALL1
User Guide
Thank you for purchasing the Ivation® 9-Piece Wine Gift Set. This User
Guide is intended to provide you with guidelines to ensure that opera-
tion of this product is safe and does not pose risk to the user. Any use
that does not conform to the guidelines described in this User Guide
may void the limited warranty.
Please read all directions before using the product and retain this guide
for reference. This product is intended for household use only. It is not
intended for commercial use.
This product is covered by a limited one-year warranty. Coverage is
subject to limits and exclusions. See warranty for details.
Battery cover
1. INTRODUCTION
⚠WARNING! Please read and understand all safety precautions and
operating instructions before operating this appliance. Failure to properly
follow the guidelines established here could result in severe injury.
• Keep product away from children. Make sure product is out of reach
from children.
• This product is intended to extract corks from standard wine bottles only.
• Do not place product near an open flame, flammable gas, heating
appliance, or a heated surface.
• This appliance is not intended for use in wet or damp conditions, as this
creates the risk of electric shock.
• Do not submerge the appliance in water or any other liquid.
• Do not use this appliance outdoors. This product is intended for indoor
usage only.
• Do not attempt to open, alter, or change mechanisms within the appliance.
• Never force the product onto a wine bottle, nor should you attempt to
speed up the mechanism. Using the product aggressively or recklessly can
damage the appliance.
• Do not turn wine bottle upside down when using this product.
• This appliance should not be used by children or persons with reduced
physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they are closely supervised at all times, and/or have
received extensive instruction and training on how to use this device by a
person responsible for their safety.
CAUTION: The foil cutter, corkscrew, and needle are sharp. Keep body parts
and utensils away from the operating end of the wine openers and blades
of the foil cutter.
2. SAFETY
Installing the Batteries
1. Hold the battery-operated wine opener firmly
and turn the battery cover to open casing.
2. Insert four (4) AA batteries, matching together
the positive and negative terminals with the
positive and negative part of the batteries.
3. Place the battery cover back on the casing and
twist the cover back on to lock it.
BATTERY-OPERATED WINE OPENER
Using the Battery-Operated Wine Opener
1. Hold the base of the wine bottle firmly with one
hand and hold the wine opener over the bottle
with the other hand.
2. Place the bottom of the wine opener on top of
the wine bottle.
NOTE: Ensure the wine opener stays lined up with
the wine bottle. Do not put the opener on the
bottle at an angle.
3. Press and hold the extract button while gently
pressing downward on the wine opener.
Corkscrew will slowly turn in a spiral motion into
the cork. Then, the corkscrew will remove the
cork from the bottle in about eight (8) seconds.
When the cork is removed, the opener will
automatically stop.
4. Release the extract button and remove the
opener from the bottle.
5. Press and hold the release button for about
seven (7) seconds. Release the button once
the cork comes completely out of the opener.
NOTE: Blue LED light will turn on when the
extract or release button is pressed down.
4. INSTRUCTIONS
Battery-operated
wine opener
Air pump
wine opener
Wine
aerator
Wine
stoppers
Champagne
stoppers
Foil
cutter
User guideStand
3. CONTENTS
Win
e
SK
U
U
Release button
Blue LED light
Extract button
USING THE FOIL CUTTER
1. Place the foil cutter onto the bottleneck of the
wine bottle.
2. Hold the foil cutter firmly by its sides.
3. Rotate the bottle to cut o the foil seal on the
wine bottle.
LIMITED WARRANTY ON IVATION® 9-PIECE WINE GIFT SET
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE.
WE WARRANT THAT DURING THE WARRANTY PERIOD, THE PRODUCT WILL BE FREE FROM
DEFECTS IN MATERIALS AND WORKMANSHIP.
LIMITATION OF LIABILITY
TO THE EXTENT NOT PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL
OTHER WARRANTIES, ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED. EXCEPT FOR THE
EXPRESS WARRANTIES CONTAINED IN THIS LIMITED WARRANTY STATEMENT AND TO THE
EXTENT NOT PROHIBITED BY LAW, WE DISCLAIM ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT LIMITATION, THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SOME STATES DO NOT ALLOW
DISCLAIMERS OF IMPLIED WARRANTIES, SO THIS DISCLAIMER MAY NOT APPLY TO YOU. TO THE
EXTENT SUCH WARRANTIES CANNOT BE DISCLAIMED UNDER THE LAWS OF YOUR
JURISDICTION, WE LIMIT THE DURATION AND REMEDIES OF SUCH WARRANTIES TO THE
DURATION OF THIS EXPRESS LIMITED WARRANTY.
OUR RESPONSIBILITY FOR DEFECTIVE GOODS IS LIMITED TO REPAIR, REPLACEMENT OR
REFUND AS DESCRIBED BELOW IN THIS WARRANTY STATEMENT.
WHO MAY USE THIS WARRANTY? C&A Marketing, Inc. located at 114 Tived Lane East, Edison, NJ
(“we”) extend this limited warranty only to the consumer who originally purchased the product
(“you”). It does not extend to any subsequent owner or other transferee of the product.
WHAT DOES THIS WARRANTY COVER? This limited warranty covers defects in materials and
workmanship of the Ivation® 9-Piece Wine Gift Set (the “product”) for the Warranty Period as
defined below.
WHAT DOES THIS WARRANTY NOT COVER? This limited warranty does not cover any damage due
to: (a) transportation; (b) storage; (c) improper use; (d) failure to follow the product instructions or to
perform any preventive maintenance; (e) modifications; (f) unauthorized repair; (g) normal wear and
tear; or (h) external causes such as accidents, abuse, or other actions or events beyond our
reasonable control.
WHAT IS THE PERIOD OF COVERAGE? This limited warranty starts on the date of your purchase and
lasts for one year (the “Warranty Period”). The Warranty Period is not extended if we repair or replace
the product. We may change the availability of this limited warranty at our discretion, but any
changes will not be retroactive.
WHAT ARE YOUR REMEDIES UNDER THIS WARRANTY? With respect to any defective product
during the Warranty Period, we will, at our sole discretion, either: (a) repair or replace such product
(or the defective part) free of charge or (b) refund the purchase price of such product if an exchange
unit cannot be provided.
HOW DO YOU OBTAIN WARRANTY SERVICE? To obtain warranty service, you must contact us at
1-866-849-3049 or by email at info@myivation.com during the Warranty Period to obtain a Defective
Merchandise Authorization (“DMA”) number. No warranty service will be provided without a DMA
number and return shipping costs to our facilities shall be assumed by you, the purchaser. Shipping
costs of the replacement unit to you shall be assumed by us.
info@myivation.com
1-866-849-3049
IVATION is a trademark of C&A IP Holdings, LLC, in the U.S., Canada, and the EU.
All other products, brand names, company names, and logos are trademarks of their respective owners, used
merely to identify their respective products, and are not meant to connote any sponsorship, endorsement,
or approval.
Distributed by C&A Marketing, Inc., 114 Tived Lane East, Edison, NJ 08837. Made in China.
© 2020. C&A IP Holdings, LLC. All Rights Reserved.
Using the Air Pump Wine Opener
NOTE: Air pump wine opener is useful when corks are damaged, fragile, or
just too weak to be removed by an electric wine opener. DO NOT USE AIR
PUMP WINE OPENER TO OPEN BOTTLES WITH PLASTIC CORKS.
NOTE: Before using the air pump wine opener, see the "Using the Foil Cutter"
section to remove the foil seal on the bottle properly.
1. Hold the wine bottle firmly with one
hand and hold the wine opener over
the bottle with the other hand.
2. Lower the wine opener onto the bottle.
The needle should pierce through the
center of the cork. Make sure the needle
comes out the bottom end of the cork.
AIR PUMP WINE OPENER
3. Hold the handle of the wine opener firmly
while still holding the base of the bottle with
the other hand.
4. Push and pull the handle continuously to
pump air into the bottle until the cork is
removed from the bottleneck.
After four to eight pumps (4 -8), the cork
will pop of the bottle.
When pumping slowly:
The cork will gradually rise up as you pump.
Alternate between gently pulling the wine
opener upward and pumping to let the cork
come out with ease.
When pumping quickly:
Be aware that the cork will pop out suddenly.
This may cause liquid to shoot out of
the bottle.
5. Remove the wine opener from the bottle.
6. Place one hand on the sides of the cork
release slider and place the other hand
on the handle of the wine opener.
7. Pull the handle of the wine opener out and
simultaneously, press down on the cork release
slider to let the cork slowly slide o of the needle.
USING THE WINE AERATOR
1. Insert wine aerator firmly into the bottleneck
after opening the bottle with the battery
operated or air pump wine opener.
2. Rotate the gear on the wine aerator to switch
it ON or OFF.
3. Tilt the bottle to pour the wine smoothly
into a wine glass.
USING THE WINE STOPPER
1. Insert the stopper into the bottleneck.
2. Pull the handle up and down a few times to
properly seal the bottle.
3. Store the sealed bottle in a wine cabinet
or refrigerator for better preservation.
USING THE CHAMPAGNE STOPPER
1. Twist the top part of the champagne stopper
to unlock it.
2. Insert the champagne stopper into the bottleneck
and firmly press down on the stopper.
3. Twist the top part of the champagne to lock it.
Then, store the sealed bottle in a wine cabinet
or refrigerator for better preservation.
Air pump wine opener dimensions: 1.9" x 7.62" (48.3 x 193.5 mm)
Battery-operated wine opener dimensions: 1.83" x 8.84" (46.5 x 224.5 mm)
Foil cutter dimensions: 1.97" x 0.47" (50 x 12 mm)
Wine aerator dimensions: 0.83" x 4.25" (21.0 x 108 mm)
Stand dimensions: 6.69" x 5.12" x 1.18" (170 x 130 x 30 mm)
Wine stoppers dimensions: 1.18" x 3.55" (30 x 90.2 mm)
Champagne stoppers dimensions: 1.54" x 1.26" (39.2 x 31.9 mm)
Weight (complete set): 2.64 lbs. (1.20 kg)
5. SPECIFICATIONS
7. GET IN TOUCH!
6. WARRANTY
Handle
Protective cover
Cork release slider
Needle
