MST52
Part No. Maximum load
Jaws Q’ty
Operation range
(diameter)
2 Ton puller 3 Jaws 0.5~3.0"
1.0~5.0"3 Jaws5 Ton puller
MST2T
MST5T
180mm
100mm
#1, #5
#4, #9
#3, #8
#2, #7
#6
Attach or detach
jaws easily.
Pull outwards to rele
ase
90°
Item #
#1
#2
#3
#4
#5
#6
#7
#8
#9
Part Number Description Qty
MST52-1
MST52-2
MST52-3
MST52-4
MST52-5
MST52-6
MST52-7
MST52-8
MST52-9
2 Ton forcing screw
2 Ton legs
2 Ton leg holder
Leg holder spring cap
5 Ton forcing screw
5 Ton forcing screw tip
5 Ton legs
5 Ton leg holder
Leg holder spring cap
1
3
1
1
1
1
3
1
1
PARTS & INSTRUCTIONS
Allows external or
internal pulling.
Three or two jaw
configuration.
1803068-27
Coloque o retire las
patas fácilmente.
Permite sujeción
externa e interna.
Modo de uso de tres
o dos patas.
