Support and E-Warranty Certificate www.vevor.com/support
JUICER
INSTRUCTION MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: JE2105
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
JUICER
- 2 -
IMPORTANT ASSURANCE
WARNING: Before operating this device, please read this instruction
manual completely and keep it handy for future reference. Always follow
basic safety precautions when using these devices. These include:
This appliance may not be used by children. Store the appliance and its cord out
of the reach of children.
The appliance may be used by persons with limited physical, sensory, or mental
abilities or persons with no experience and knowledge if they remain under
supervision or use the appliance safely per the user manual and understand the
hazards.
Children may not play with the appliance.
Never use the juicer if the filter is damaged.
Clean all parts of the appliance in contact with food in accordance with the
description in section CLEANING AND MAINTENANCE.
Switch off the appliance and unplug it before replacing accessories or coming into
contact with moving parts of the appliance.
The appliance must always be used according to the recommended operating
time. The maximum duration of continuous operation is 1 minute. After this time
the appliance must be switched off for 2 minutes. After 3 cycles, before restarting
it is recommended to stop using the appliance for 15-20 minutes until it cools
down. The method adopted shall prolong the service life.
Do not use other accessories apart from those sold with the appliance.
WARNING: There is a risk of injury if the appliance is used contrary to its
intended use. Care must be taken when handling the filter blades,
emptying the filter and cleaning.
Always unplug the appliance when left unattended before assembly/disassembly
and cleaning.
If the power supply cord is damaged, it must be replaced by the manufacturer, an
authorized service, or qualified persons to avoid any hazard.
This appliance is intended for private indoor use only.
Before using it, always ensure that the supply voltage specified on the appliance
label corresponds to the voltage in the power supply grid.
Do not use the unit if the appliance's power cord, plug, or other parts are
damaged.
- 3 -
Do not immerse the drive base in water or other liquids. Do not wash it under
running water. Clean the motor housing with a damp cloth only.
Observe the basic safety rules to avoid fire or electric shock risks when using
electrical appliances, especially if children are present.
Do not immerse the plug, the power cord or the appliance in water or other liquids
in order to avoid electric shock.
Do not hang the power cord over the edge of table or sink .
Do not use the appliance near flammable fabric (curtains, carpets); do not place it
close to heat sources: gas cookers, electric cookers.
Do not cover the appliance during operation.
Do not put any items (cutlery, tools, etc.) inside the device during its operation.
Do not leave the appliance unattended while connected to the power supply.
Do not use the appliance if it is damaged or works incorrectly.
Do not use the appliance if it falls or has clear damage signs.
Do not attempt to open the body or disassemble any parts of the appliance.
Do not place the drive base on wet surfaces.
Never immerse the drive base in any liquid and prevent the liquid from
penetrating the inside of the drive base housing.
Protect the appliance from moisture. Indoor use only.
If liquid enters the drive base housing, disconnect the appliance from the power
supply and have it repaired by a service center.
Do not hold the appliance, the power cord, or the plug with wet hands.
Do not exceed the maximum appliance operation time.
Do not combine with elements or parts of other manufacturers.
Before inserting the plug into a wall socket, assemble the appliance in
accordance with the manual.
Please cut off the power before dismantling, assembling or tuning any parts of the
product.
If repairs are required during operation, please contact our customer service
department or an authorised service centre. Never try to repair the juicer on your
own.
- 4 -
Before starting the juicer, ensure the accessories, e.g., filter and lid, are correctly
installed.
In operation, putting your hands or sharp objects into the feed port and any
objects instead of the push rod is forbidden. In case of any accidents, please
keep your eyes away from the feed port.
To avoid any personal injury or product damage, keeping your body or other
complex objects away from the filter or motor wheel when starting up the product
is required.
If the appliance stops working when in operation, it may be caused by the
motor overheat protection. In such a case, before starting the appliance again,
it is necessary to unplug it and wait for 20-30 minutes until the appliance cools
down.
To prevent any damage caused by thermal strain, it is forbidden to disinfect the
parts of the product with hot-water and microwave oven more than 80°C. Parts
contacting the food are clean, sanitary and reliable, and have passed the
necessary certificate.
The juicer body shall not be washed in water or other liquid (soft cloth available).
The product shall not be cleaned with the steel wool, abrasive cleaners or
corrosive fluids (e.g. gasoline or acetone) .
Before processing, fruits, and vegetables with kernels, hard seeds, thick skin, or
hard shells shall be removed.
This appliance is intended for home use only and may not be used for
professional purposes . Any other use is considered to be inappropriate, and
therefore, dangerous .
The manufacturer is not responsible for any damage resulting from improper use
of the appliance.
This juicer is intended for squeezing citrus fruits such as orange, grapefruit,
mandarin, lemon, and lime.
SAVE THESE INSTRUCTIONS
- 5 -
PARTS
Parts list
1.Pusher
2. L id
3. Filter
4.Central ring
5 .
Safety clamp
6 .
Motor wheel
7 . Power Cord
8.Juice jug
9. Body
10 .
Operating knob
11.
Pulp container
Accessories：Filter cleaning brush
SPECIFICATIONS
Model: JE2105
Power Supply Voltage: 120V~ 60Hz
Power: 1000W
Operating time: 1 minute operation/2 minute break
Material: PP, stainless steel
CONTENTS OF PACKAGING
After unpacking, make sure all of the listed items are present in the packaging .
After unpacking the appliance, make sure that it works properly.
- 6 -
Part of the electric citrus juicer:
1 x body
1 x inner body
1 x f ilter
1 x lid
1 x pusher
1 x pulp container
1 x juice jug
1 x cleaning brush
1 x user manual
OPERATION INSTRUCTIONS
NOTE: Before using the appliance for the first time, clean it according to the
instruction specified in Chapter CLEANING AND MAINTENENANCE.
Speed:
Speed “P”: Pulse mode
Speed “0”: shut off and stop
Speed “1”:low speed, applicable to process
soft fruits and vegetables, such as water
melon, tomato, cucumber and strawberry.
Speed “ 2 ”: high speed, applicable to process
all fruits and vegetables .
Using the appliance
This product is equipped with dual security system and it will not start working
before all the parts and component are in correct installation status.
Please install and use the product as follows
- 7 -
1
Put central ring on the body.
2
Put the filter into the central ring and make sure
it is in the right place on the motor wheel.
( Before using, check if the filter is not damaged.
If any damage is detected, stop using the
appliance and immediately contact our customer
service department nearby).
3
Install the lid on the juicer body in the right place
– as shown in the figure.
Snap the safety clamps on the lid and lock them
down. The assembly has been done correctly if
you hear a “click” sound.
4
Put the pulp container under the body, as shown
in the figure.
- 8 -
5
The appliance is ready for use and may be
plugged into an easily accessible socket. Before
plugging the appliance, ensure the operating
knob is set to the “0” position.
6
Wash fruit and vegetables, and slice them into
pieces. If the fruit has hard skin, it must be
peeled. Remove hard pips.
7
Put the juice jug under the juicer spout.
8
Feed fruits and vegetables prepared into the
feed port.
Turn on the appliance by setting the operating
knob to position 1 or 2 or P (pulse mode) and
gently push the fruit with the pusher.
Note! When the juicer is in operation, always
keep your hands and other objects away from
the opening on the lid.
- 9 -
Once you finished using the appliance, dismantle it (reverse as with assembly)
and clean all food contact parts as described in section CLEANING AND
MAINTENANCE
Selection of fruit and vegetables:
1. Select fresh fruits and vegetables: containing much juice; suitable fruits
conclude: pineapple, beetroot, celery stick, apple, cucumber, spinach, melon,
tomato, mandarin orange, grape, etc.
2. Fruit and vegetables with thin skin are not required to peel, but those with thick
ones, such as mandarin orange, pineapple, and raw beetroot, must be peeled.
Citrus fruit seeds must be removed, which may give the juice a bitter taste.
3. In the case of apple juice, its concentration depends on the type of apple
chosen. Clear juice can also be squeezed out from apples with much juice. You
can select the type of apple to be squeezed according to your needs.
4. The freshly-squeezed apple juice may quickly turn brown. A few drops of lemon
juice can be added to slow down the process of discoloring.
5. Leaves and steams (such as lettuce) can be put into food processor for juicing.
6. Fruits containing starch, such as banana, papaya, avocado, figs, and mango,
are not suitable for a food processor to make juice.
7. Nutrition constituent of common fruits and vegetables and the gear selection is
shown as follows:
Fruits/vegetables
Vitamin/mineral
substance
KJ/ calorie
Speed
9
Once you finished extracting the juice and the
juice no longer flows out of the spout, turn off the
appliance by setting the operating knob to the “0”
position. Unplug the appliance. You may remove
the juice jug when the motor and the filter stops.
( Drink the juice when it is fresh, as its taste and
nutritional value may be affected by prolonged
exposure to the air.)
- 10 -
Apple
Vitamin C
200 g = 150 kJ (72 calories)
2
Apricot
Rich in DF,
containing
potassium
30 g = 85 kJ (20 calories)
1
Beet
Source of folic
acid, DF, vitamin C
and potassium .
160 g = 190 kJ (45 calories)
2
Blueberry
Vitamin C
125 g = 295 kJ (70 calories)
1
Brussels sprouts
Vitamin C, B, B6, E,
folic acid and DF
100 g = 110 kJ (26 calories)
1
Cabbage
Vitamin C, folic acid,
potassium, B6 and
DF
100 g = 110 kJ (26 calories)
2
Carrot
Vitamin A, C, B6, E and
DF
120 g = 125 kJ (30 calories)
2
Celery
Vitamin C and
potassium
80 g = 55 kJ (7 calories)
2
Cucumber
Vitamin C
280 g = 120 kJ (29 calories)
1
Fennel
Vitamin C and DF
300 g = 145 kJ (35 calories)
1
Grape
Vitamin C, B6, and
DF
125 g = 355 kJ (85 calories)
1
K iwi fruit
Vitamin C and
potassium
100 g = 100 kJ (40 calories)
1
Melon
Vitamin C, folic acid,
DF and vitamin A
200 g = 210 kJ (50 calories)
1
Nectarine
Vitamin C, B3,
potassium and DF
180 g = 355 kJ (85 calories)
2
Peach
Vitamin C, B3,
potassium and DF
150 g = 205 kJ (49 calories)
2
- 11 -
Pear
DF
150 g = 250 kJ (60 calories)
2
Pineapple
Vitamin C
150 g = 245 kJ (59 calories)
2
Raspberry
Vitamin C, iron,
potassium and
magnesium
125 g = 130 kJ (31 calories)
1
Potato
Vitamin C, DF,
vitamin E, folic acid
and vitamin A
100 g = 90 kJ (22 calories)
1
CLEAN AND MAINTENANCE
1
Before cleaning, it is required to shut off and unplug the appliance.
2
Timely cleaning is necessary after using the product.
3
A wet cloth can be used to clean the outside part of the machine body,
which shall not be placed or washed in water or other liquids.
4
The product should be placed in dry place and away from ultraviolet
rays.
5
The product shall be clean and dry before storage.
6
Each dismountable part can be cleaned according to the following steps:
- 12 -
1
Remove the push rod and
Pulp container
2
Open the buckle.
3
Take off the lid, filter, pulp container and
central ring in proper order.
Any disassembled parts in contact with food must be washed under running
water using washing-up liquid.
After cleaning, allow all the parts to dry completely before reassembling the
- 13 -
appliance. The filter may be cleaned with the cleaning brush attached.
TROUBLESHOOTING
If any irregularities are found during operation of the appliance, read the table
below to identify the cause and to ind a solution to the problem .
Problem
Possible cause
Solution
The appliance does
not turn on .
1. Incorrect installation of the
central ring .
2 . Head cover installed in
wrong place.
1. Install the central ring in a
proper place.
2 . Install head cover in place .
3 . Replace the lid .
During the first start
of the appliance,
unpleasant smell
may
be released .
It is normal.
Please send the product to our
company’s maintenance point
nearby if the product still gives
off unpleasant smell after
repeated use.
The product stops
while in operation.
1. Under voltage
2 . Excessive ingredients
3 . Push the rod with
excessive force
4 . Motor thermal control
protection
1. Check if under voltage
2 . Disconnect power, take out
the surplus ingredients .
3 . Push the rod gently.
4 . Restart it after stopping 20-
30 minutes .
The juice contains
a lot of pulp .
1. Juice extraction net
damaged .
2 . Too much pomace in the
central ring .
1. Replace the net .
2 . Clean the central ring .
- 14 -
Abnormal vibration
or
big noise .
1. Improper installation of
juice extraction net and poor
running balance.
2 . Unstable placement of
product or come off of foot
pad .
3 . Over voltage
4 . Excessive ingredients
1. Install juice extraction net in
proper place.
2 . Place product stably or
install the foot pad in proper
place .
3 . Check if any over voltage .
4 . Disconnect power, take out
the surplus ingredients .
Small amount of
juice.
1. Much pomace in the central
ring .
2 . Press the push rod with
excessive force.
1. Clean central ring .
2 . Press the push rod with
proper force.
Filter
Filter is clogged.
Unplug the appliance and
remove any clogging pieces of
food material from
the filter.
