LOADING
Frozen Concentrates
NOTE: Loading frozen concentrate in the product cabinet may cause damage to the machine. This damage is not
covered by warranty.
1. Thoroughly mix the thawed concentrate by vigorously shaking the product container.
2. Open the dispenser door.
3. Prior to placing the product container in the dispenser, make sure that the o-ring on the container adapter is
lubricated. This will ease removal of the container when it becomes necessary.
4. Place the product container in the desired position and press it firmly into the bottle adapter opening.
5. Open the vent hole in the product container. (If required)
Note: Concentrate in the container must be completely thawed and be within the temperature range of 35-40 degrees F
(1.6-4.4 degrees C.) Product outside of this temperature range, especially below, may produce an “out of ratio” drink.
Ambient Concentrates (Optional)
1. Install an Ambient Concentrate Conversion Kit (BUNN-O-MATIC part number 33699.0002) per the instructions
provided in the kit.
2. Attach the concentrate product hose to the appropriate concentrate line located at the rear of the dispenser.
3. Attach the other end of the product hose to the product container through an appropriate fitting.
NOTE: Although the dispenser is designed to accept ambient concentrates, the Nitro Coffee cascade performance
may be reduced due to ambient product mixing with the cold nitrogenated water.
PRIMING
1. Open the dispenser door
2. Load concentrate per instructions in section titled Loading.
3. Close the dispenser door.
4. Place a large container under the appropriate dispense nozzle.
Pull and hold the tap handle, until concentrate dispenses from the dispense nozzle.
Note: This may take several seconds, depending on the installation and set pump speed.
55076.0000B 06/22 ©2018 Bunn-O-Matic Corporation
(Continued)
Care & Cleaning Instructions
Recommended Daily Cleaning Instructions
The use of a damp cloth rinsed in any mild, non-abrasive, liquid detergent is recommended for cleaning all surfaces
on Bunn-O-Matic equipment. Do NOT clean this equipment with a water jet device.
DIRTY
CLEAN
REAR OF
DISPENSER
1. Open dispenser door.
Lift up on product con-
tainers to disconnect
them from the machine
inlet.
5. Remove dispenser
nozzles and drip tray.
Wash all parts in warm
soapy water.
6. Use brush to clean
through dispense noz-
zles.
7. Use brush to clean nitro
insert.
8. Use brush to clean noz-
zle connection ports on
machine. BUNN Part
No. 49827.0000.
12. Dispense from each
station until finished
product flows from the
dispense nozzles.
13. Remove Air Filter from
outside rear panel of
dispenser.
14. Wash Filter using warm soapy water,
rinse using water flow from faucet.
Shake out excess water then re-install
on rear panel of dispenser.
9. Apply small amount
of food grade lubri-
cant to o-ring on noz-
zles. BUNN Part No.
M2550.0001.
10. With a warm soapy
cloth, wipe down in-
terior of cabinet and
splash panel area be-
hind dispensing noz-
zles.
11. Replace drip tray and
dispense nozzles. Be
sure to install nitro
nozzle in left dispense
station.
4. Open dispenser door
and reconnect all prod-
uct containers.
2. Close door, place an
empty container under
the dispense nozzles.
3. Dispense from each
station until clear water
flows from the dis-
pense nozzle.
Brush Storage
Lubricant Shelf
Recommended Weekly Cleaning
