Pre-filter True HEPA Filter Activated Carbon Filter
3 IN 1
CUSTOMER SUPPORT
In the standby state, the panel light is
half bright, touch the power button to
turn on, the button icons lights become
all white, and the airflow defaults to the
first gear operation. In the working state,
press the power button again for 3
seconds and the machine enters the
standby state. All the icon lights are off
and only the power button icon lights
are half on.
Press the Airflow speed button to increase
and decrease the airflow speed from 1,2
and 3.
Your appliance will turn off automatically
after the selected amount of time. To set
the time: Press the button to scroll through
the time options. Once activated press
the Sleep Timer button once to see the
time selected. To cancel the Sleep timer:
Press the Sleep timer button twice.
When the purifier starts to work, the Blue
LED Indicator and the Night Light are ON
at the same time. Please press the Night
light button to turn on/off the light.
CONTROL PANEL
- 05 - - 06 - - 08 -- 07 -
Thirteen Technology Industry Co., Ltd
Room 407, 4/F, Building B, WE Park, South China City,
Longgang District, Shenzhen, Guangdong, 518114, CN
Made in China
Model: PU-P05
尺寸：98*140mm
材质：105g铜版纸
装订方式：风琴折页
印刷颜色：单黑
Product Diagram GENERAL SAFETY
SAFE USE & CARE
MULTI-FUNCTION IN ONE
Package Contents
1*Air Purifier
1*Quick Start Guide
1*AC Power Adapter
1*Filter in Air Purifier
1*User Manual
Specifications
Model
Input Voltage
Output Voltage
Working Current
Power
Working Environment
Dimensions
Net Weight
Power Cord Length
PU-P05
AC 100-240V 50/60Hz
DC 12V
0.5A
6W
13℃-40℃>40% RH
145 x 145 x 251mm /
5.71” x 5.71” x 9.88”
812g /28.64oz
6ft (1.8m)
Thank you for purchasing the FULMINARE Air Purifier.
Please read this manual carefully and keep it for future
reference. If you need any assistance, please contact
our support team with your product model number and
Amazon order number.
- 01 - - 03 - - 04 -- 02 -
Air Purifier
User Manual
1. Power Button
2. Blue LED Indicator
3. Warm Night Light
4. Timer Button
5. Speed Button
6. Night Light Button
7. Air outlet
8. Power Connector
9. Air Inlet
10. Activated Carbon Filter
11. True HEPA Filter
12. Pre-Filter
13. Bottom Cover
14. Power Adapter
1. Efficiently purifier PM 2.5, smog, pollen, and other
particulate pollutants
2. Filter 3 airflow speed
3. Main engine
13
10
9
8
1
4
3
5
6
7
2
11
12
14
Painted Supportive Net
Pre-Filter
True HEPA Filter
Activated Carbon Filter
DO NOT block the air inlet/outlet
DO NOT operate this appliance if it has a damaged power
cord or plug.
DO NOT operate this appliance if it malfunctions or is
damaged in any way. Contact customer service if any part
of this appliance is damaged.
DO NOT immerse any part of the appliance, power cord, or
plug in water or other liquids.
Always unplug from the outlet when not in use, before
putting on or taking off parts, and before cleaning.
Do not use your appliance without the filter in place.
Unplug your appliance from the mains electricity supply
before cleaning or changing filters.
DO NOT use attachments not recommended by FULMIN-
ARE which may cause fire, electric shock, or risk of injuries.
DO NOT use this Air Purifier as a toy. Close supervision is
required when being used near or by children.
DO NOT use it in areas with oil smoke or high humidity in the
bathroom.ti
FULMINARE provides a two-year product warranty from the
date of the purchase for all our products. We will take care
of all quality-related issues with a REPLACEMENT or FULL
REFUNDED including any return shipping costs. If your
product is defective and under warranty, please feel free
to contact us.
Please carefully follow our warranty process to minimize
any delays:
1. Note the product model name. It can be found on a
sticker located underneath or on the back of the product.
2. Provide the order number for a purchase made through
Amazon.
The typical turnaround time to address Warranty claims is
14 business days, depending on your geographical
location and type of damage or Warranty claim.
This warranty does not apply to the following:
Damage due to abuse, accident, alteration, misuse,
tampering, or vandalism.
Improper or inadequate maintenance.
Damage in return transit.
Unsupervised use by children under 18 years of age.
FULMINARE assumes no liability for damage caused by the
use of the product other than for its intended use or as
instructed in the user manual. Some states DO NOT allow
this exclusion or limitation of incidental or consequential
losses so the foregoing disclaimer may not apply to you.
This warranty gives you specific legal rights and you may
also have other rights that may vary from state to state.
Any issues or questions regarding your new product, please
feel free to contact our Customer Support Team.
*Please have your order number ready before contacting
Customer Support.
Please be careful when cleaning the air purifier. Strong
corrosive cleaning agents will damage the surface of the
machine.
Only use the appliance for its intended use as described in
this manual.
DO NOT use the Air Purifier on flames, hot plates, or stoves.
DO NOT expose to heat source.
Remove the filter PE bag
Power
button
Airflow
Sleep
timer
Night Light
button
1.Check whether the plug is inserted
into the socket, and whether turn
on the power button.
2.Reinstall the filter.
Counterclockwise the bottom base
cover to get the charging adapter.
No Power adapter
Fresh air cannot be sent
out smoothly from the
air outlet
1.Please unpack the plastic
packaging first.
2.Clean foreign matter.
Poor odor removal
The machine makes an
unusual sound when it’s
running
1.Change its location and remove
the barrier.
2.Please replace the FULMINARE
filter.
1.Please remove the obstructing
objects(e.g. remove the filter PE
bag).
2.Clean foreign matter.
TROUBLESHOOTING WARRANTY
Problem
NEED HELP? TALK TO US!
Solution
Product not working
