INSTRUCTION MANUAL
S3450, Rev A
50W COB Rechargeable Floodlight
with Bluetooth Speaker
Multifunction floodlight with powerful
bluetooth speakers
COB Floodlight
Featuring COB technology the light
delivers a super bright flood output upto
4000 lumens
Light Output
Adjust the light intensity from 400 to
4000 lumens by simply press the button
to change mode
1ST
PRESS
2ND
PRESS
3RD
PRESS
4TH
PRESS
LUMEN 400 1000 2000 4000
RUN TIME 20 hours 10 hours 6 hours 3 hours
Powerful Bluetooth Speaker
Superior sound quality bluetooth speaker
with range upto 10 meter (32') for endless
music at work
For bluetooth connection of worklight
to phone, press and hold the rectangle
orange button for switching on the
Bluetooth of the worklight and connect to
“Audio Floodlight” from your phone.
Durable Construction
a. IP65 Rated
Protected against dust and eects
of low pressure water jets from any
direction
b. Extremely tough & impact proof
composite ABS body makes it suitable
for all rugged applications
c. Steel hook with 360° Rotating action
for convenient placement
of light
Power Source
LITHIUM-ION
RECHARGEABLE
RECHARGEABLE
BATTERY
11.1V, 5200 mAh
Charge Your Mobile Device
5V 1A USB output port for use as
power bank
Charging of Battery
AC CHARGER
(100-240V)
CHARGE TIME
3.5 HOURS
4000
MAX. LUMEN
IP65
WATER & DUST
PROOF RATING
BLUETOOTH
Hanging steel
hook in base
140°
Vertical Rotation
140°
SIZE (L×H ×D)
(INCH) (MM)
8-1/4 × 8-1/4 × 4" 210 × 210 × 100
IK07
RoHs
Bluetooth
Speaker
50W COB
Floodlight
Bluetooth* 4.0
Range: 10 M (32’)
(Compatible with
android and IOS)
2
SAFETY INFORMATION
• Follow workshop health & safety rules,
regulations and conditions when using 50W
COB Rechargeable Floodlight with Bluetooth
Speaker.
• When not in use, COB rechargeable worklight
should be stored in a dry location to inhibit
rust.
• During their period of use, accessories must be
checked for wear, cracks and other damage,
replace any damaged or worn parts.
• Use genuine parts only. Unauthorized parts
may be dangerous and will void the warranty.
• Keep the COB rechargeable worklight clean
and in good working order for best and safest
performance.
• DO NOT use the lamp in the immediate vicinity
of inflammable materials or gases.
• DO NOT point the light directly in your own or
any other person’s or animal’s eyes.
• DO NOT drop, throw or abuse the COB
Rechargeable worklight.
• Eyes protection: Wear a protective mask or
protective eyewear.
• Check that the product has not suered any
damage during transport or storage. Clean and
remove any dust or residual packing material.
• Read the instructions carefully before using
COB Rechargeable worklight and keep them
for further reference.
WARNING!
• DO NOT immerse COB rechargeable worklight
in water.
• DO NOT place COB rechargeable worklight
near a fire or any other source of intense heat.
• DO NOT attempt to open, disassemble, modify
or service the worklight.
• DO NOT expose COB rechargeable worklight
to temperatures above 50°C (122° F).
• DO NOT use COB rechargeable worklight if
you suspect that the batteries or the casing is
damaged
PACKAGING CONTENT
DESCRIPTION QTY.
COB Rechargeable Worklight 1
Power Cable with Adaptor 1
O.I.P.M. 1
OPERATING INSTALLATION
1. 5 LED indicators at the back shows the
percentage charge in the worklight.
2. Fully charge the battery before the first use. To
charge, connect the worklight with the charger
cable provided with it. Connect the adaptor to
the power source.
3. While charging, the 4 LED indicators at the
back will blink continuously.
4. When the battery is fully charged, all the
indicator LEDs will stop blinking. Full charging
takes about 3.5 hours.
5. Press the power button located at the back of
the light
BUTTON PRESS LUMENS
1st Press 400
2nd Press 1000
3rd Press 2000
4th Press 4000
6. For bluetooth connection of worklight to
phone, press and hold the orange button for
switching on the Bluetooth of the worklight
and connect to “Audio Floodlight” from your
phone.
7. The worklight can also be used as power bank
for charging mobile devices.
MAINTENANCE
• Clean any dirt from the housing or the lens
immediately, since it could cause overheating.
• If required, clean with a dry or slightly moist
clean cloth. Do not use cleaners that contain
abrasives or solvents.
• When not in use, COB rechargeable worklight
should be stored in a dry location.
3
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The COB rechargeable worklight has low lumen
output or does not work.
Low battery Recharge the battery
The Bluetooth speaker does not work Bluetooth out of Range Worklight and the phone should be within 10 meter
(33ft) range
If the COB rechargeable worklight still doesn't work Contact nearest authorized service dealer
DISPOSAL
The components or the used products must be given to companies that specialize in the disposal and
recycling of industrial waste.
TROUBLE SHOOTING
4
