Air conditioner
Installation manual
PC4NUFMAN
࡙ Thank you for purchasing this Samsung air conditioner.
࡙ Before operating this unit, please read this manual carefully and retain it for future
reference.
2
English
4 Way Cassette Wind-Free Panel
If the Wind-Free function is not visible on the higher-
level controller after connecting the Wind-Free panel:
࡙ Check if the software of the higher-level controller is
the latest version.
࡙ If the software is not the latest version, update to the
latest version.
࡙ If the software of the higher-level controller is the
latest version but the Wind-Free function is not visible
on it, perform tracking again on the higher-level
controller or reset its power.
࢘²˝˵ʪθࣗʪЭʪʀͱϩθͱʪθࡠUđƊࡡƟͱЇʀ˵Aʪϩθɇіʪʒ
Controller, Wi-Fit kit, or other device
Accessories
Item Bolt (M5xL35 MACHINE) Installation manual
Shape
NOTE
࡙ Ã˙ϩ˵ʪϑЇΧΧʪʒɵͱϩϑͱϑϩࡡцͱЇɇцΧЇθʀ˵ɇϑʪđߦ
machine bolt (with length of the thread more than
ߣߡͱ˝࣎ɇʒɇʀθʀЇɇθиɇϑ˵ʪθ˙θͱɇцθʪϩɇ
hardware store to replace the lost bolt.
࡙ Ɵ˝˵ϩʪ˝ϩͱθαЇʪ˙ͱθϩ˵ʪđߦϑʀθʪиࡠߣࢋߡϩͱߤࢋߡĘ
࣍ߣߡϩͱߤߡ˝˙ʀ࣎
CAUTION
࡙ After installing the product, be sure to explain to the
user how to use the air conditioner.
Installing the panel
CAUTION
࡙ ²ɇʒʪϩ˵ʪΧɇʪʀɇθʪ˙Їцࢋ
࡙ Uͱͱϩʪɇϩ˵ʪΧɇʪɇ˝ɇϑϩɇиɇͱθΧɇʀʪϩͱɇ
protruding object.
Failing to do so may damage the surface of the panel.
࡙ Be careful when installing the air inlet panel by hand.
You may get hurt.
1 Open the electrical component box cover.
࡙ After untightening the screws, slide the electrical
component box cover in the direction of the arrow as
shown in the figure and pull it down.
2 Pull both hooks in the direction of carved arrows and
take the grille to open.
࡙ ²ͱͱϑɇθʪͱʀɇϩʪʒɵʪͱиϩ˵ʪƊɇϑЇ˝ͱ˝ͱͱϩ˵ʪ
grille.
3
English
3 ²ɇ˝ϩ˵ʪΧɇʪͱϩ˵ʪߣ˵ͱͱϑͱϩ˵ʪɵͱϩ˵ϑʒʪϑͱ˙ϩ˵ʪ
indoor unit firmly so that the panel not to fall out.
²ͱͱ
4 Uʪϩɇʀ˵ϩ˵ʪߥʀͱθʪθϑͱ˙ϩ˵ʪΧɇʪЇϑ˝ɵͱϩ˵˵ɇʒϑࢋ
Open both side blade of corner and pull then out using
two grooves under the each corner.
࡙ ²ɇʒʪϩ˵ʪʀͱθʪθиϩ˵ʒ˝ϩɇʒϑΧɇц˝ʪϩцࡡϑʀʪ
there are electrical cables connected to that corner.
࡙ Each corner portion of the panel is easy for you to
adjust the height, but a special tool should be used.
Uͱ࣭ϩЇϑʪʒθʪʀϩц˵ɇʒࢋ
Groove
5 Fix the bolt to the panel.
࡙ уߥɵͱϩϑϩͱϩ˵ʪΧɇʪϩʪΧͱθɇθцࢋ
࡙ Fix them tightly not to make a gap between the panel
and the ceiling.
NOTE
࡙ Adjustment of the indoor unit height from the holes in
the corner of panel is possible.
࡙ Pipe connecting area is not allowed to adjustment of
the indoor unit height.
4
4 Way Cassette Wind-Free Panel
English
6 Aͱʪʀϩߥʀɇɵʪϑɵʪϩиʪʪϩ˵ʪʒͱͱθЇϩɇʒϩ˵ʪ
panel.
࡙ đɇʪϑЇθʪцͱЇʀ˵ʪʀϩ˵ʪЇɵʪθͱ˙Χϑͱϩ˵ʪϩ˵θʪʪ
white terminal before connecting the cables.
Panel
Ǯ˵ϩʪ࣍ߢߡťÃĘ࣎
Blue
Ǯ˵ϩʪ࣍ߥťÃĘ࣎
Ǯ˵ϩʪ࣍ߢߤťÃĘ࣎
7 Close the electrical component box cover and tighten
the screws.
8 Attach and close the front grille.
࡙ đɇʪϑЇθʪϩ˵ʪ˵ͱͱϑͱϩ˵ʪθʪɇθϑʒʪͱ˙˝θʪ˙ϩϑ
properly into the grooves on panel (
1
࣎ɇʒϩ˵ʪΧЇϑ˵
the panel to close (
2
࣎ࢋ
1
2
²ͱͱ
Grille
9 Check out that the panel is fixed to the indoor unit.
࡙ Fix screws tightly between the panel and the surface
of the ceiling. If the panel is installed incorrectly, air
may leak.
࡙ Uͱͱϩɵͱʀɇцʒϑʀ˵ɇθ˝ʪЭʪϩϑϩ˵ʪΧɇʪࢋ
NOTE
࡙ If the angle on the air flow blades has been changed by
user due to opening the front grille for installation or
maintenance, you must turn off the circuit breaker and
turn it on again before using the air conditioner.
Otherwise, angles of the each blade can be different
or some of the blade may not close when the product
is off.
5
English
