INSTRUCTION MANUAL
LED CEILING LIGHT
TECHNICAL DATA
INTRODUCTION & WARRANTY
WARNING
LED CEILING LIGHT
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future reference. If you
have any another query, please contact our dealer or local vendor from whom you have purchased the
product. They are trained and ready to serve you at the best. The warranty is valid for 2 years from the date
of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal wear and
tear. The company gives no warranty against damage to any surface due to incorrect removal and installa-
tion of the product. The products are suitable for 12-10 Hours Daily operation. Usage of product for 24
Hours a day would void the warranty. This product is warranted for manufacturing defects only.
1. Please turn o power and read this instruction before starting the installation.
2. Installation should only be done by a certified electrician.
3. The light source of this luminaire is not replaceable; when the light source
reaches its end of life the whole luminaire shall be replaced.
4. Proper grounding should be ensured throughout the installation.
5. For Indoor use only.
MODEL
SKU
POWER
INPUT VOLTAGE
USEFUL LUMEN
BEAM ANGLE
LIFE SPAN
ON/OFF CYCLE
UNIT COLOUR
LED COLOUR
CRI
IP RATING
DIMENSION
VT-7462
213967
45W
AC 220-240V, 50/60Hz
4050 Lm (@SPHERE 360°)
120°
20,000 Hours
>15,000 Times
White
3000K-5000K (Changeable)
>80
IP20
Ø460×100 mm
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
1. Turn o the power before starting the installation.
2. Fix the base with screws by drilling holes in the ceiling
3. Connect the power supply to the AC as per the diagram provided.
4. Fix the lamp to the base.
5. Turn on the power and test the lamp.
1
3
2
REMOTE CONTROL SAFETY INSTRUCTIONS
• Before using this product, make sure that all parts are configured correctly according
to the instructions in the attached instruction.
• The product should not be used by persons under 5 years of age without supervision
by a parent or guardian.
• Ensure that the power batteries are configured correctly and have the appropriate
parameters as specified by the manufacturer.
REMOTE CONTROL INSTRUCTIONS
Turn On
Cold light+
Cycle
Night light
Brightness-
Warm light-
Brightness+
Turn o
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
K+ K-
