English
Made in Taiwan
to Matco specifications
DO NOT DISCARD – GIVE TO USER
Page 1
SMCFSM10
10 PIECE 3/8" DRIVE
METRIC CROWFOOT
WRENCH SET
PRODUCT INFORMATION:
• Normal use of this product is likely to expose the user to
dust and/or microscopic particles containing chemicals
known to the State of California to cause cancer, birth
defects or other reproductive harm. Always wear
appropriate safety equipment and clothing when using
this product. Study, understand and follow all instructions
provided with this product. Failure to read and follow all
warnings and operating instructions may result in
damages and serious injury or death.
• Always wear ANSI approved goggles when using this
product. (Users and bystanders).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with
accessories not designed for it could result in serious
injury or death.
• Always select the correct accessories of the correct size
and design for the job that you are attempting to perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
• Do not begin repairs without assurance that vehicle is in
secure position, and will not move during repair.
WARNING
LIFETIME WARRANTY
The manufacturer warrants this product to the original
user against defective material or workmanship with a
lifetime guarantee.
The manufacturer reserves the right to determine
whether the part, or parts failed because of defective
material, workmanship, or other causes. Failures caused
by accident, alteration, or misuse are not covered by this
warranty.
Replacements under warranty also carry a Lifetime
Warranty. The rights under this warranty are limited to
the original user and may not be transferred to
subsequent owners.
The warranty is in lieu of all other warranties, expressed
or implied, including warranties of merchantability and
fitness for a particular purpose.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, so the above
limitations may not apply to you.
WARNING
INTENDED USE OF THE TOOL
1703083-14
Study, understand and follow all instructions provided
with this product. Read these instructions carefully
before installing, operating, servicing or repairing this
tool. Keep these instructions in a safe accessible place.
This crowfoot wrench set is designed for fitting easily
on 3/8" drive extensions and ratchets for use on hex
head fasteners, while the precision machined build
fits fasteners snug, helping end rounded and stripped
heads. Do not use this tool outside of the designed
intent. Never modify the tool for any other purpose
or use.
BEFORE USE
Caution: To help prevent personal injury
Before use, check the parts diagram and part number listing
on page 2 to make sure all parts are included. If any parts
are missing or damaged, please call your distributor.
• Access. Crowfoot design and thin profile is
great for hard to reach areas and on fuel lines,
or hydraulics.
• Coverage. 10mm to 19mm set skips no metric
sizes.
• Design. All sizes use the same 3/8" drive and
feature detents to lock onto ratchets and
extensions.
Spanish
10 PIECE 3/8" DRIVE
METRIC CROWFOOT
WRENCH SET
LIFETIME WARRANTY
The manufacturer warrants this product to the original
user against defective material or workmanship with a
lifetime guarantee.
The manufacturer reserves the right to determine
whether the part, or parts failed because of defective
material, workmanship, or other causes. Failures caused
by accident, alteration, or misuse are not covered by this
warranty.
Replacements under warranty also carry a Lifetime
Warranty. The rights under this warranty are limited to
the original user and may not be transferred to
subsequent owners.
The warranty is in lieu of all other warranties, expressed
or implied, including warranties of merchantability and
fitness for a particular purpose.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, so the above
limitations may not apply to you.
1703083-14
This crowfoot wrench set is designed for fitting easily on
3/8" drive extensions and ratchets for use on hex head
fasteners, while the precision machined build fits fasteners
snug, helping end rounded and stripped heads. Do not use
this tool outside of the designed intent. Never modify the
tool for any other purpose or use.
NO LO DESCARTE O DESECHE, ENTREGESELO AL USUARIO
ADVERTENCIA
APLICACIÓN DE LA HERRAMIENTA
Estudie, entienda y siga todas las instrucciones
que se proveen con este producto. Lea las
instrucciones detenidamente antes de instalar,
operar, dar servicio o reparar esta herramienta.
Guarde estas instrucciones en un lugar seguro
y accesible.
ADVERTENCIA
• El uso normal de esta herramienta puede exponer al usuario
al polvo o a partículas microscópicas que contienen
sustancias químicas que se conocen en el estado de
California por causar cáncer, defectos del nacimiento u otros
daños reproductivos.
Siempre use equipo y ropa de seguridad adecuados para
trabajar con esta herramienta. Lea, comprenda y siga todas
las instrucciones incluidas con esta herramienta. Omitir la
lectura y el no seguir todas las advertencias e instrucciones
de operación puede traer como consecuencia daños y
lesiones graves o hasta la muerte.
• Siempre use guantes del tipo aprobado por la ANSI para
trabajar con esta herramienta. (tanto usuarios como
espectadores).
• Nunca utilice esta herramienta para cualquier otra cosa
que no sean las aplicaciones para lo que fue diseñada.
• Sólo utilice los accesorios diseñados para esta herramienta.
• No modifique o altere esta herramienta de ninguna manera.
• El funcionamiento y/o mantenimiento inadecuado de la
herramienta, la modificación, o la utilización de la
herramienta con accesorios inadecuados podrían causar
lesiones graves o la muerte.
• Siempre usar los correctos accesorios para el trabajo que
Ud. está realizando.
• Trabaje siempre en un área limpia, segura, bien iluminada,
organizada y equipada adecuadamente.
INFORMACIÓN DEL PRODUCTO:
Página 1
HECHO en Taiwán
Para Matco especificaciones
SMCFSM10
DESEMPACADO
Cuando desempaque el producto, revise el diagrama y la
lista de piezas en la página 2 para verificar que se hayan
enviado todas las piezas. En caso de que falten piezas o
que estén dañadas, comuníquese con su distribuidor.
• Access. Crowfoot design and thin profile is
great for hard to reach areas and on fuel lines,
or hydraulics.
• Coverage. 10mm to 19mm set skips no metric
sizes.
• Design. All sizes use the same 3/8" drive and
feature detents to lock onto ratchets and
extensions.
French
10 PIECE 3/8" DRIVE
METRIC CROWFOOT
WRENCH SET
LIFETIME WARRANTY
The manufacturer warrants this product to the original
user against defective material or workmanship with a
lifetime guarantee.
The manufacturer reserves the right to determine
whether the part, or parts failed because of defective
material, workmanship, or other causes. Failures caused
by accident, alteration, or misuse are not covered by this
warranty.
Replacements under warranty also carry a Lifetime
Warranty. The rights under this warranty are limited to
the original user and may not be transferred to
subsequent owners.
The warranty is in lieu of all other warranties, expressed
or implied, including warranties of merchantability and
fitness for a particular purpose.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, so the above
limitations may not apply to you.
This crowfoot wrench set is designed for fitting easily on
3/8" drive extensions and ratchets for use on hex head
fasteners, while the precision machined build fits fasteners
snug, helping end rounded and stripped heads. Do not use
this tool outside of the designed intent. Never modify the
tool for any other purpose or use.
1703083-14
Etudier, comprendre et suivre toutes les
instructions fournies avec ce produit. Lire ces
instructions attentivement avant d’installer,
d’utiliser, d’entretenir et de réparer cet outil.
Conserver ces instructions dans un endroit
sécuritaire et accessible.
AVERTISSEMENT
Utilisation prévue
Mesure de sécurité
Mise en garde : Pour aider à prévenir
les blessures
• L’utilisation normale de ce produit pourrait exposer
l’utilisateur à de la poussière et/ou des particules
microscopiques contenant des produits chimiques que
l’État de la Californie a reconnu comme étant une cause
de cancer, de déficience congénitale et d’autres effets
nocifs sur le système reproductif. Toujours porter
un équipement et des vêtements sécuritaires appropriés
en utilisant ce produit. Étudier, comprendre et suivre
toutes les instructions fournies avec ce produit.
• Toujours porter des lunettes à coques approuvées par
l’ANSI lorsque vous utilisez ce produit.
• Toujours utiliser les accessoires adéquats pour le travail
que vous effectuez.
• Toujours travailler dans un environnement propre,
sécuritaire, bien éclairé, organisé et suffisamment équipé.
INFORMATIONS PRODUIT:
Page 1
Fabriqué à Taïwan
les spécifications de Matco
SMCFSM10
NE PAS JETER-DONNER À L'UTILISATEUR
DÉBALLAGE
Lors du déballage, vérifier que les pièces contenues dans
le schéma et la liste des numéros de pièces de la page 2
sont toutes incluses.
Si une pièce est manquante ou abîmée, veuillez appeler
immédiatement votre distributeur.
• Access. Crowfoot design and thin profile is
great for hard to reach areas and on fuel lines,
or hydraulics.
• Coverage. 10mm to 19mm set skips no metric
sizes.
• Design. All sizes use the same 3/8" drive and
feature detents to lock onto ratchets and
extensions.
1703083-14
Page 2
PARTS BREAKDOWN
SMCFSM10
Index
No.
Part No. Qty.
Parts List
Description
1
2
3
4
5
6
7
8
9
10
11
MCFS10MA
MCFS11MA
MCFS12MA
MCFS13MA
MCFS14MA
MCFS15MA
MCFS16MA
MCFS17MA
MCFS18MA
MCFS19MA
SMCFSM10R
1
1
1
1
1
1
1
1
1
1
1
10MM Crowfoot Wrench
11MM Crowfoot Wrench
12MM Crowfoot Wrench
13MM Crowfoot Wrench
14MM Crowfoot Wrench
15MM Crowfoot Wrench
16MM Crowfoot Wrench
17MM Crowfoot Wrench
18MM Crowfoot Wrench
19MM Crowfoot Wrench
SMCFSM10 Rail Holder
1
78910
2345
6
11
10 PIECE 3/8" DRIVE
METRIC CROWFOOT
WRENCH SET
