When calling for parts or
service, please specify the
following number:
Model# 55 - 0012A
SAFETY INSTRUCTIONS
1. The AeroPilates® Pull-Up Bar can be added to the Stamina AeroPilates® reformers that have Pulley Risers.
2. Save these instructions and ensure that other exercisers read this manual prior to using the AeroPilates® Pull-
Up Bar for the rst time.
3. The AeroPilates® Pull-Up Bar should only be used after a thorough review of this instruction sheet and a review
of the safety instructions provided with your AeroPilates® reformer. Make sure that it is properly assembled and
tightened before use.
4. When exercising with this product, do not exercise at an intensity that causes the product itself to move. This
could result in damage to your joints and to the product.
5. Keep children away from the AeroPilates® Pull-Up Bar. Do not allow children to use or play on the AeroPilates®
Pull-Up Bar. Keep children and pets away from the AeroPilates® Pull-Up Bar when it is in use.
6. When using the AeroPilates® Pull-Up Bar, place your AeroPilates® reformer on a solid level surface. Do not
position it on loose rugs or uneven surfaces.
7. Make sure that adequate space is available for access to and around your AeroPilates® reformer when using
the AeroPilates® Pull-Up Bar.
8. Before using, inspect the AeroPilates® Pull-Up Bar for worn or loose components, and tighten or replace any
worn or loose components prior to use.
9. Consult a physician prior to commencing an exercise program and follow his/her recommendations in developing
your tness program. If at any time during exercise you feel faint, dizzy, or experience pain, stop and consult your
physician.
10. Always choose the workout which best ts your physical strength and exibility level. Know your limits and train
within them. Always use common sense when exercising.
11. Do not wear loose or dangling clothing while using your AeroPilates® reformer.
12. Be careful to maintain your balance while using, mounting, dismounting your AeroPilates® reformer, and while
assembling the AeroPilates® Pull-Up Bar. Loss of balance may result in a fall and bodily injury.
13. The AeroPilates® Pull-Up Bar should be used by only one person at a time.
14. The AeroPilates® Pull-Up Bar is for consumer use only. It is not for use in public or semipublic facilities.
Pull-Up Bar Attachment
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springeld, MO 65803
Customer Care
1 (800) 375-7520
customer[email protected]
www.staminaproducts.com
MADE IN CHINA
© 2019 Stamina Products, Inc.
2019, 03
!
WARNING
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
Consult your physician before starting
this or any exercise program. This is
especially important if you are over
the age of 35, have never exercised before, are pregnant, or suffer from any
health problem. This product is for home use only. Do not use in institutional or
commercial applications. Failure to follow all warnings and instructions could
result in serious injury or death.
To reduce the risk of serious injury, read the following Safety Instructions before
using the AeroPilates® Pull-Up Bar.
!
WARNING
!
WARNING
Assembly The AeroPilates® Pull-Up Bar
Part # Part Name Qty
151 Pull-Up Bar 1
152 Post 2
153 Long Foam Grip 1
154 Foam Grip 2
155 Round Plug (25mm) 2
156 Arc Washer (M8) 2
157 Bolt, Button Head (M8x1.25x42mm) 2
Locking Knob
Pulley Riser
Locking Knob
Left Pulley Hook
Pulley Riser
Rear Frame
Right Pulley Hook
Locking Knob
Locking Knob
Left Pulley Hook
Rear Frame
Right
Pulley Hook
STEP 1
To remove the PULLEY RISERS on your AeroPilates®
reformer, unhook the LEFT and RIGHT PULLEY HOOKS
from the PULLEY RISERS on both sides. Unscrew the
LOCKING KNOBS and remove the PULLEY RISERS.
STEP 2
Fully insert the POSTS(152) into the mounting holes in the
REAR FRAME. Align the threaded holes in the POSTS(152)
with the holes in the REAR FRAME and secure with the
LOCKING KNOBS, but don’t tighten the knobs. Attach the
PULL-UP BAR(151) to the POSTS(152) with BUTTON HEAD
BOLTS(M8x1.25x42mm)(157) and ARC WASHERS(M8)
(156). Tighten the LOCKING KNOBS. Hook the LEFT and
RIGHT PULLEY HOOKS onto the POSTS(152) on both
sides.
NOTE: The PULL-UP BAR(151) has two sets of mounting
holes. Select the holes that t your AeroPilates®
reformer. For 3-cord reformers, use the set of holes
closest to the center of the PULL-UP BAR(151).
For 4 and 5-cord reformers, use the holes closest to
ends of the PULL-UP BAR(151).
LIMITED WARRANTY
Products shipped to the manufacturer must be in the original shipping carton with freight prepaid. All expenses for
repairing or replacing the product, including the cost of shipping it back to the original purchaser, will be covered by the
manufacturer. This warranty gives you specic legal rights, and you may have other rights which vary from state to state.
If the product should, for any reason, become defective within 90 days of purchase, the manufacturer will replace the product
once it is returned to the manufacturer. This warranty does not apply to any damage caused by accident, return transit,
improper assembly, alteration, abuse, or misuse. There are no other warranties other than those expressly set forth herein.
This product is warranted to be free from defects in material and workmanship and to be in perfect working order at the
time of purchase. This warranty applies to personal, family or household use. This warranty does not apply to use in
athletic clubs, health clubs, spas, gymnasiums, exercise facilities, and other public or semipublic facilities.
