Please read all instructions carefully before using
Household use only
5010815
Juice Extractor
Model: GS-332E
Manufacturer/Hersteller: Shenzhen Foduosi Trading Co., Ltd.
Address/Adresse: 1403, Block 4, Haixuan Plaza, No.89 Jinlong Road,
Luogang Community, Buji Street, Longgang District, Shenzhen
Facebook Page: http://www.facebook.com/foherehome
Email: [email protected]om
Web: www.fohere.com
MADE IN CHINA
1
1. Pusher
2. Transparent cover
3. Precision filter
4. Juice outlet
5. Safety locking arm
6. Pulp collector
7. Motor base
8. Juice jug
9. Brush
8
9
Know Your Juicer
2
7.In order to prolong service life of this machine, over-
temperature protective device is mounted in the motor. If the
motor runs for a long time or overloaded, when over warning
temperature, power supply will automatically cut off. After the
motor stops, pulling out plug of power supply, waiting for the
motor to cool down(about for 30 min), using again.
8. During operating, please do not leave, never letting children
operate this machine.
9. After operation, do not pour the food out until you are pulling
out the plug of power supply.
11.Cutters are very sharp, in order to avoid danger, when you are
cleaning a cutter, please putting the cutter under water tap for
washing, do not wash it with hand.
12.This machine must not be used for others beyond regulated
purposes.
13.In case of damaged power supply cord, in order to avoid
danger, replacement must be performed by the manufacturer
or its service department or similar professional persons.
1. This machine is unavailable for the weakness, unresponsive or
psychopathic person (including children), unless under the
direction or help from the person who have the responsibility
for security. Children should be overseen, so it can be testified
that they are not playing with it.
2. Before using, putting this machine on a stable and even table
board; operate according to the above methods.
3. Before juicing, first confirm juicing net and rotor clutched in
position, and no hard contact between Precision filter cutter and
transparent cover. Putting the transparent cover on, fasten tight
the locking arm, then turning on the machine.
4. Before being used, the motor is running, there may be slight
peculiar smell and spark, this is normal, after the motor works
for some period, the above phenomenon will disappear.
5. During juicing,making sure there is not over filled and not too
many residue in the middle seat and residue cup,if too
full,please cutting off power supply,cleaning up then using again.
6. During using, do not open the cup cover. In case if power
supply is on, do not put hand or any ware into the mixing cup or
feed port, otherwise, harmful accident may occur or this
machine may be damaged.
Safety Guidelines
3
1. Before using, please confirm the button switch of the main
machine in stop mode, in this way, in case assembly is not
completed, starting the main machine can be avoided, so
unnecessary damage for persons or property avoided.
2. Before juicing, first confirm Precision filter and rotor clutched in
position, and no hard contact between Precision filter cutter and
transparent cover. Putting the transparent cover on, putting the
locking arm into the cover slot, then turning on the machine.
3. Before using, please making sure to put the juice mouth to drip
position, and after turning off the machine, putting the juice
mouth to anti-drip position to avoid juice come out without juice
cup and make the table dirty.
4. For using, assembling according to the map of "name and
position of main components".Turning on power supply,
pressing the switch to let the machine run no-load for 5 sec.
Put prepared vegetable or fruit into feed port of the juicer,
pressing with the pusher, evenly, hard and slowly, juice of
the vegetable or fruit can be found, original, fresh, good for health.
5. Note: when pressing food with the pusher, force shall be
even or indirect, pressing force shall not be more than 1 kg, no
too sudden force, otherwise, juicing effect will be reduced.
Juicing
1.
in for juicing, no cutting apart needed, easy and quick.
2.Design is fine, simple, and beautiful, with combined structure,
easy to operate and clean.
3.High speed electric motor with overheating protection is designed
with, high efficiency, time saving, energy saving, high service
life of the motor.
4.Safety lock unit for switching is especially designed, in order to
make sure safety and reliability in use.
5. Design with anti-drip function juice mouth.
For the juicer with large diameter, entire apple or pear can be put
Performances
Attention before using
.
2. When disassembling or assembling the juicer, pressing the
transparent cover with hand, then forceing the safety locking
arm to slide in or out of the cover slot.
3.When disassembling Precision filter, first removing the cover and
Pulp collector, then turning the middle ring up to 30 degrees by
holding juicing nozzle with your hand, and taking up, the juicing
net will automatically leave the rotor.
4. In order to avoid damage, before using, first checking power
supply for compliance with rated voltage.
5. Cleaning all parts able to disassemble (refer to the section of
"maintenance and cleaning").
6. When assembling, please carefully read the map of " Know
Your Juicer ".
7. Please carefully read the "attentions" before using.
1.This machine is set with safety unit, when the safety locking
arm does not fasten the cover or the cutter seat is not fastened,
the machine will not start, so as to ensure safety for the user.
4
Operating time
5
1.This machine shall be often used, so as to keep the motor dry
and clean.
2.If you are not using for a long time, please storing this machine
at a dry and well-ventilated place so as to prevent the motor
from being damped and going moldy.
3.Don't wash the main machine. When you are cleaning, only
wiping with wet cloth. Other components may be washed
such as pusher, transparent cover, juice outlet, juice jug, pulp
collector.
Maintenance and cleaning
For stopping“O”
“Ⅰ”
“Ⅱ”
A high-speed gear for processing all fruits and vegetables
(see “Juicer Recipe” for the selection of fruits, vegetables
and gears)
A low-speed gear for processing soft fruits and vegetables
such as watermelon, tomato, cucumber and strawberry
Fault Analysis and Elimination
Notes:
The table above introduces the common faults and their cause analysis
and elimination methods. For other faults, contact our customer service
department. Do not dismantle or repair the product by yourself.
Fault Possible cause Elimination
1. Install the middle ring correctly
2. Install the top cover correctly Replace
the top cover.
1. The middle ring is not
correctly installed
2. The top cover is not
correctly installed
3 The top cover contact
has fractured.
After the power supply is
connected and the switch
is made on, the product
does not run.
1. Check whether the voltage is too low
2. Disconnect the power supply and
remove the surplus food materials
3. Gently push the pushing rod
4. Stop the product and start it again 20
to 30 minutes later.
1. The voltage is too low
2. There are many food
materials in the product
3. The pushing rod is
pushed violently
4. The motor is under
temperature protection.
The product stops
automatically in use.
1. Install the juice strainer correctly
2. Place the product steadily or install
the foot pad correctly
3. Check whether the voltage is too high
4. Disconnect the power supply and
remove the surplus food materials
1. The juice strainer is not
correctly installed,
resulting in poor
running balance
2. The product is not
steadily placed or the
foot pad has fallen off
3. The voltage is too high
4. There are many food
materials in the product
The product has
abnormal vibration or big
noise.
1. Clean the middle ring Gently push the
pushing rod.
1. There are too many
residues in the middle
ring
2. The pushing rod is
pushed violently.
There is a little juice.
Disconnect the power supply, take out
the food materials and cut them
into smaller blocks.
The cutter holder is
wound or seized by food
materials.
The cutter holder is
seized.
1. Replace the juice strainer
2. Clean the middle ring.
1. The juice strainer is
damaged
2. There are many
residues in the middle
ring.
There are many residues
in juice.
If the bad smell still exists after the
product has been used for several times,
contact us customer service.
It is normalThere is a bad smell from
the motor in the first few
times of use of the
product.
6
This machine is designed with button switches of “O” for stopping,
“I ” speed gear, “II” speed gear. When the juicer has been operating
for 3 minutes, please stop the machine until the motor cools down.
