Quick Start Guide
Bobtot Sound Air2
Portable Wireless Speaker
Bobtot Sound Air2
Portable Wireless Speaker
Packing Content
1x Bobtot Sound Air2
1x USB charging cable(Type-C)
1x 3.5mm AUX cable
1x Quick Start Guide
Specifications
Wireless Version: V5.1
Transmission distance: 10m
Battery: 2500mAh
Input: DC 5V/1A
Charging: USB Type-C
Frequency: 180Hz-18kHz
Connection: BT,USB,AUX,TF supported
Play time: Up to 14hours (varies by volume level and content）
Bobtot Sound Air2
Portable Wireless Speaker
Volume+
Volume-
Light button
Power button
AUX jack
USB port
Charging port
TF card
Device Overview
Indicator
light
Bobtot Sound Air2
Portable Wireless Speaker
Buttons & Controls
Buttons
You want to
How to
Turn on/off
Play/pause
Call back
Accept an incoming call
End an incoming call
Switch light
( 6 modes to light off)
Short press
Double click
Triple press
Long press (in BT mode)
Short press(in calling mode)
Short press (in calling mode)
Double click (in BT mode)
Short press
Long press
Short press
Long press
Switch play
(BT-USB-TF-AUX mode)
Pair two speakers (TWS)
Disconnect the BT
Increase the volume
Next song
Decrease the volume
Previous song
Long press
Short press
Reject an incoming call Press 2s(in BT mode)
Bobtot Sound Air2
Portable Wireless Speaker
The Sound Air2 comes pre-charged, but you may need to charge it
before the first use, in case it is low on battery. it will take 3.5-4
hours to fully charge.
Note:
*We reommend using a USB wall adapter with a DC 5V=1A output.
(USB Type-C)
*The indicator light is red when charging.
*The indicator light turns off once full charged
Charging the speaker
Getting Started
Turn ON the speaker
Long press the power button to turn on the Sound Air 2 speaker.
Pairing your mobile device
1.Enable the BT feature on your smartphone or tablet and search for
"Bobtot Sound Air2", then tap to connect.
2.When hearing the prompt sound "connected" the wireless is pairing
successfully. You can enjoy the music.
Charging port (USB Type-C)
Bobtot Sound Air2
BT device
Bobtot Sound Air2
Portable Wireless Speaker
Connect your device with the speaker via 3.5mm audio cable
*When using the audio input mode, control audio playback via the
connected device.
*When aux cable is plugged, play mode will automatically switch to
AUDIO in mode.
Play music from a micro TF card or a USB flash drive
Support capacity: max file size 64Gb
Support files: mp3,flac,wav,
Play in order: music will play in the download/copy order.
Automatically play: when the TF card/ USB drive is inserted, the
play mode will automatically switch to TF mode/ USB mode.
(Normally the speaker would play the last inserted media.)
TF card
playback
3.5mm Audio Cable
USB Drive
Bobtot Sound Air2
Portable Wireless Speaker
Step1, Long press the power button about 2s speakers
to turn the first speaker on.
Step 2,Turn on the BT searching mode on your device, search
"Bobtot Sound Air 2" and connected.
Step 3, Long press the power button about 2s to turn the
second speaker on.
Step 4, Quickly triple-click the light button of either speaker.
You can hear a indicates sound, which means connect
successfully.
Note:
*While stereo pairing, the speaker will reconnect with the device if
they used to be connected. Triple press button to
disconnect the stereo pairing.
*When you are listening to the music from one speaker and want to
set up the stereo pairing , triple-click the button,
would enter into stereo pairing mode.
How to Set TWS Sync Mode?
Bobtot Sound Air2
Portable Wireless Speaker
Resetting your device
Press and hold the 8s until the power off. Then long press
the to reset.
Troubleshooting:
1. Automatic shut down: when the battery power is low, the
speaker will turn off automatically, please charge it.
2. Unable to play music: Reset the speaker and connect the bt
again. If the music file store in the USB or TF card, check if the
right connect mode, double press the to choose the
right mode.
3. Unable to connect to the computer: Check if the computer has
bt function. If not, please connect the speaker and computer by
the AUX cable and choose the right model by pressing the .
4. The button does not respond or the function is disordered:
try again after reset.
5. Stuck in an abnormal situation: press the power button for 8
seconds to reset.
Bobtot Sound Air2
Portable Wireless Speaker
Warning
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment.
FCC Requirement
(1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection agains tharmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the
instructions, may cause harmful
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
Do NOT drop, hit or shake the device.
Do NOT disassemble, repair or modify the speaker.
Do NOT use cleaning products that contain benzene, solvents or
alcohol.
Do NOT expose the speaker to excessive heat or direct sunlight for
prolonged periods of time.
Do NOT store the device in a place with high humidity or dust.
Do NOT use the speaker near a microwave oven or wireless LAN
products.
Bobtot Sound Air2
Portable Wireless Speaker
Need help?
– Consult the dealer or an experienced radio/TV technician
for help.
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. The device has been
evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Customer Care Guide
At our company, we strive to provide exceptional customer
care to every one of our clients. We believe that building
strong relationships with our customers is essential to the
Bobtot Sound Air2
Portable Wireless Speaker
Feedback
We know that our customers are the heart of our business
so we value your feedback. We encourage you to share
your thoughts and ideas with us.
Solutions
If our customers encounter any issues, we will try our best
to find a quick and efficient solution that meets your needs.
success of our business. To help us achieve this goal,
we have put together the following customer care guide.
Time
We understand that our customers' time is valuable, so we
will respond to any inquiries within 24 hours.
Here at Bobtot, we take customer care very seriously.
Our customers are our first priority, and we are committed
to providing the highest quality service. If you have any
questions or concerns, please don't hesitate to reach out
to us.We will be happy to assist you:
Call or Message: +1 888 572 1718
Email: [email protected]
bobtot.net
2023 BOBTOT//Features and specifications are
subject to change and or improvement without notice.
