6 DRAWER TOPCHEST & ROLLCAB
COMBINATION WITH BALL-BEARING SLIDES
MODEL NO: AP22 SERIES
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this Topchest
& Rollcab combination.
9 Locate the Topchest & Rollcab combination in a suitable working area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
9 Keep the Topchest & Rollcab combination clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT use the Topchest & Rollcab combination for any purpose other than that for which it is designed.
8 DO NOT move the Topchest & Rollcab combination with drawers open.
8 DO NOT open more than one drawer at the same time.
8 DO NOT step on the drawers.
8 DO NOT use in damp work areas.
WARNING! The warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and situations that
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be applied by the
operator.
2. INTRODUCTION
The economical way to buy American PRO® Ball-Bearing quality tool chests. Supplied packed one inside the other. This mid-size combo has
smooth 25mm ball-bearing slides and all the features of the professional chests, except that the rollcab is not lockable and the castors are
Ø75mm. These boxes are not interchangeable with the rest of the American PRO® Ball-Bearing Range.
3. SPECIFICATION
Model No: .......................................................... AP22 Series
W x D x H:
4 Drawer Topchest:
Overall size: ............................................612 x 260 x 340mm
Small Drawer (x3): ....................................510 x 225 x 35mm
Medium Drawer (x1):.................................510 x 225 x 85mm
2 Drawer Rollcab:
Overall size: ............................................615 x 295 x 705mm
Medium Drawer (x2):.................................515 x 275 x 65mm
Cupboard (x1): ........................................ 610 x 275 x 375mm
4. ASSEMBLY
Refer to
instruction
manual
AP22 Series Issue:1 10/01/22
Original Language Version
© Jack Sealey Limited
fig.
1
fig.
2
4.1. Removethebolts,nutsandwashersfromthebaseoftherollcab(g.1),andthenliftothebodytouncoverthetopchest.
4.2. Removethescrewsfromthebase(g.2),andseparatefromthetopchest,discardthescrews.
Note: Place protective material onto the ground to avoid damaging the back of the topchest.
4.3. Turntherollcabupsidedownandplacethebaseintopositionasshowning.3A.
Note: Place protective material onto the ground to avoid damaging the top of the rollcab.
4.4. Positionthecornerbrackets(g.3B)andsecureusingbolts,washersandnuts.
4.5. Attach the back panel to the base using two bolts, washers and nuts.
4.6. Ensurethebaseissquareintherollcabandtightenallnutsfully(g.3C).
4.7. Placetherollcabuprightandplacethetopchestontopasshowning.4.
5. OPERATION
5.1. To lock the top chest, close all drawers, then insert one lock bar into the back slot inside the top compartment.
Closethelidandlockwiththekey(g.5).
6. MAINTENANCE.
6.1. Periodicallylubricatethedrawerslides(g.4).
6.2. Clean the surfaces with a soft cloth and a mild water/detergent solution.
6.3. Checkallxingsandtightenifrequired.
fig.
3
Original Language Version
© Jack Sealey Limited
AP22 Series Issue:1 10/01/22
fig.
4
fig.
5
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
