Operating and installation
instructions
Freezer
To avoid the risk of accidents or damage to the appliance it is
essential to read these instructions before it is installed and used for
the first time.
en-GB M.-Nr. 12 883 220
Contents
2
Warning and Safety instructions ............................................................................... 5
Sustainability and environmental protection.......................................................... 13
Caring for the environment ...........................................................................................
13
How to save energy.......................................................................................................
14
Familiarisation................................................................................................................ 16
Guide to the appliance ..................................................................................................
16
Display .............................................................................................................................
17
Operating the refrigeration appliance via the display................................................
18
Operation.........................................................................................................................
19
Briefly touching the symbol................................................................................. 19
Touching and holding the symbol for 3seconds.............................................. 19
Touching and holding the symbol for 7seconds .............................................. 19
Main menu................................................................................................................. 19
Sub-menu .................................................................................................................. 19
Display idle mode ..................................................................................................... 19
LED indicators........................................................................................................... 19
Safety ...............................................................................................................................
19
Lock function ............................................................................................................ 19
Temperature alarm.................................................................................................... 20
Door alarm ................................................................................................................. 20
Power failure alarm................................................................................................... 20
Appliance functions .......................................................................................................
21
Miele@home ....................................................................................................... 21
SuperFreeze.......................................................................................................... 22
Sabbath mode........................................................................................................... 23
Factory defaults ........................................................................................................ 23
Demo mode............................................................................................................... 23
Commissioning.............................................................................................................. 24
Before using for the first time.......................................................................................
24
Switching on and off ......................................................................................................
24
To note when switching off for longer periods of time........................................ 24
Switching the refrigeration appliance on............................................................... 24
Switching off the refrigeration appliance .............................................................. 25
Operation........................................................................................................................ 26
Setting the temperature ................................................................................................
26
Switching SuperFreeze on .......................................................................................
26
Switching SuperFreeze off .......................................................................................
26
Contents
3
Freezing and storing food..............................................................................................
27
Freezing fresh food ................................................................................................... 27
Maximum freezing capacity .................................................................................... 27
Storing frozen food ................................................................................................... 27
Home freezing........................................................................................................... 28
Cooling drinks quickly....................................................................................................
29
Making ice cubes............................................................................................................
29
Good to know................................................................................................................. 30
The correct temperature ...............................................................................................
30
Storage time for frozen food .........................................................................................
30
Notes on buying food.....................................................................................................
30
Adjusting settings ......................................................................................................... 31
Switching the lock function on .....................................................................................
31
Switching the lock function off.....................................................................................
31
Switching Sabbath mode on.........................................................................................
31
Switching Sabbath mode off ........................................................................................
31
Resetting the settings to their factory default settings ............................................
31
Activating the WiFi connection ....................................................................................
32
Deactivating the WiFi connection................................................................................
32
Switching on demo mode .............................................................................................
32
Switching off demo mode.............................................................................................
32
Exiting service mode......................................................................................................
33
Cleaning and care ......................................................................................................... 34
Cleaning agents ..............................................................................................................
34
Preparing the refrigeration appliance for cleaning.....................................................
35
Cleaning the interior of the appliance .........................................................................
35
Cleaning accessories by hand or in the dishwasher .................................................
35
Removing and dismantling accessories for cleaning ................................................
35
Cleaning the front of the appliance and the side panels ..........................................
36
Cleaning the door seal...................................................................................................
36
Cleaning the ventilation gaps .......................................................................................
36
Cleaning the compressor and metal grille at the back of the appliance ................
36
After cleaning ..................................................................................................................
36
Defrosting........................................................................................................................
37
Troubleshooting............................................................................................................. 39
Noises ..............................................................................................................................
44
Customer Service Department.................................................................................. 46
Contact in the event of a fault......................................................................................
46
EPREL database .............................................................................................................
46
Warranty ..........................................................................................................................
46
Contents
4
Optional accessories.................................................................................................... 47
Installation...................................................................................................................... 48
Installation site ...............................................................................................................
48
Ventilation requirements...............................................................................................
49
Installing several refrigeration appliances...................................................................
50
Changing the door hinging ............................................................................................
50
Fitting supplied wall spacers ........................................................................................
52
Setting up the refrigeration appliance.........................................................................
52
Aligning the refrigeration appliance........................................................................ 53
Integrating the refrigeration appliance in a run of kitchen units ..............................
53
Appliance dimensions....................................................................................................
55
Installation dimensions/View from above ............................................................ 55
Connections .............................................................................................................. 56
Electrical connection .....................................................................................................
57
EU Conformity declaration.......................................................................................... 58
UK Conformity declaration ......................................................................................... 59
Copyrights and licences .............................................................................................. 60
Warning and Safety instructions
5
This refrigeration appliance complies with current safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Please read the operating and installation instructions carefully
before using the refrigeration appliance for the first time. They
contain important information on safety, installation, use and
maintenance. This is to protect yourself from injury, and from
damaging your refrigeration appliance.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow all information provided
on installing the refrigeration appliance, as well as the safety notes
and warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating and installation instructions in a safe place
and pass them on to any future owner.
Correct application
This refrigeration appliance is intended for use in the home and in
similar environments, for example
– in shops, offices and similar work settings
– by the guests in hotels, motels, bed & breakfasts and other typical
home settings.
This refrigeration appliance is not intended for outdoor use.
It must only be used as a domestic appliance to store deep frozen
food, freeze fresh food and to make ice.
Any other usage is not supported by the manufacturer and could be
dangerous.
Warning and Safety instructions
6
This refrigeration appliance is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or similar
substances or products that are subject to the Medical Device
Directive. Incorrect use of the refrigeration appliance for such
purposes may cause deterioration of the items stored. The
refrigeration appliance is also not suitable for use in areas where
there is a risk of explosion.
Miele cannot be held liable for damage caused by improper or
incorrect use or operation of the appliance.
The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
if they are supervised whilst using it, or have been shown how to use
it in a safe way and recognise and understand the consequences of
incorrect operation.
Safety with children
Children under 8 years of age must be kept away from the
refrigeration appliance unless they are constantly supervised.
Children 8 years and older may only use the appliance
unsupervised if they have been shown how to use it in a safe way and
recognise and understand the consequences of incorrect operation.
Children must not be allowed to clean or maintain the appliance
unsupervised.
Please supervise children in the vicinity of the appliance and do
not let them play with it.
Danger of suffocation! Whilst playing, children could become
entangled in packaging (such as plastic wrapping) or pull it over their
head and suffocate. Keep packaging material away from children.
Technical safety
The coolant circuit has been checked for leaks. The refrigeration
appliance complies with statutory safety requirements and the
appropriate EU directives.
If the cooling circuit is damaged, refrigerant and oil can escape and ignite.
Warning and Safety instructions
7
Warning: fire hazard/flammable materials. This symbol is on the
compressor and indicates flammable materials. Do not remove this
sticker.
The refrigerant inside the appliance (details on the data plate) is
environmentally friendly but flammable.
The use of this refrigerant does, however, sometimes lead to a slight
increase in the noise level of the appliance. In addition to the noise of
the compressor, you might be able to hear the refrigerant flowing
around the cooling circuit. Unfortunately, this cannot be avoided, but
it does not affect the performance of the refrigeration appliance.
When transporting and installing the refrigeration appliance, ensure
that no parts of the cooling circuit are damaged. Splashes of
refrigerant can damage the eyes and leaking refrigerant can ignite.
In the event of damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the refrigeration appliance from the mains electricity
supply.
- Ventilate the room where the refrigeration appliance is located for
several minutes.
- Contact the Miele Customer Service Department.
The more refrigerant there is in a refrigeration appliance, the larger
the room it should be installed in. In the event of a leakage, if the
appliance is in a small room, there is the danger of a combustible
gas/air mixture building up. For every 8g of refrigerant at least 1m
3
of
room space is required. The amount of refrigerant in the refrigeration
appliance is stated on the data plate inside the appliance.
To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data plate
corresponds to the household supply.
Check that this is the case before connecting the appliance. Consult
a qualified electrician if in any doubt.
The electrical safety of this appliance can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested by
a qualified electrician.
Warning and Safety instructions
8
Temporary or permanent operation on an autonomous power
supply system or a power supply system that is not synchronised
with the mains power supply (e.g. island networks, back-up systems)
is possible. A prerequisite for operation is that the power supply
system complies with the specifications of EN50160 or an
equivalent standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronised with the mains power supply, or these measures must
be replaced by equivalent measures in the installation. As described,
for example, in the current version of BS OHSAS 18001–2 ISO
45001.
If the electrical connection cable supplied is damaged, it must only
be replaced by an original spare part to prevent a hazard for the user.
Miele can only guarantee the safety of the appliance when original
Miele spare parts are used. For safety reasons, such replacement
may only be carried out by a qualified specialist or the Miele
Customer Service Department.
Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and do
not guarantee the required safety of the appliance.
If moisture gets into electrical components or into the mains
connection cable, it could cause a short circuit. Therefore, do not
operate this refrigeration appliance in areas which are exposed to
moisture (e.g in a garage or utility room).
This appliance must not be used in a non-stationary location (e.g.
on a ship).
Do not use a damaged appliance. It could be dangerous. Check the
appliance for visible signs of damage.
This refrigeration appliance is not intended for use as a built-in
appliance.
The appliance must be isolated from the electricity supply during
installation, maintenance and repair work.
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user.
Installation, maintenance and repairs must only be carried out by a
Miele authorised technician.
Warning and Safety instructions
9
While the appliance is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
Faulty components must only be replaced with genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the appliance when Miele replacement parts are used.
This refrigeration appliance is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance and vibration). This lamp must only be
used for the purpose for which it is intended. The lamp is not suitable
for room lighting. Replacement lamps may only be fitted by a Miele
authorised technician or by the Miele Customer Service Department.
This refrigeration appliance contains several light sources with at
least energy efficiency classG.
Proper installation
Always wear protective gloves when transporting and installing the
refrigeration appliance.
Two people are required to install the refrigeration appliance.
Correct use
This refrigeration appliance is designed for use within specific
ambient temperatures (climate range). Do not use in ambient
temperatures for which it is not designed. The climate range is stated
on the data plate in the interior cabinet of the refrigeration appliance.
A lower ambient temperature will cause the compressor to switch off
for longer periods, meaning that the refrigeration appliance is unable
to maintain the required temperature.
Do not cover or block the air vents as this could impair the
efficiency of the appliance, increase the electricity consumption and
could cause damage to the components.
The refrigeration appliance lid has a plastic edge. Make sure that
no oil or grease leaks onto this edge as this could cause stress cracks
in the plastic and cause it to break or split.
If storing food which contains a lot of fat or oil in the appliance or
the door, make sure that it does not come into contact with plastic
components as this could cause stress cracks or break the plastic.
Warning and Safety instructions
10
Risk of fire and explosion. Do not store explosive materials in the
refrigeration appliance or any products containing propellants (e.g.
spray cans). Electrical components can cause flammable mixes of
gases to ignite.
Danger of explosion. Do not operate any electrical equipment (e.g.
an electric ice-cream maker) inside the refrigeration appliance.
Danger of sparking and explosion.
Danger of injury and damage to the appliance. Do not store cans or
bottles containing carbonated drinks or liquids which could freeze in
the freezer zone. Otherwise they could burst.
Danger of injury and damage to the appliance. When cooling drinks
quickly in the freezer zone, make sure bottles are not left in for more
than one hour. Otherwise they could burst.
Danger of injury. Never handle frozen food or the metal parts of the
appliance with wet hands. Your hands may freeze to the frozen food
or to the metal.
Danger of injury. Do not take ice cubes out with your bare hands
and never place ice cubes or ice lollies in your mouth straight from
the freezer zone. The very low temperature of the frozen food can
cause frost burn to the lips and tongue.
Do not refreeze partially or fully defrosted food. Consume
defrosted food as soon as possible, as it will lose its nutritional value
and spoil if left for too long. Defrosted food may only be re-frozen
after it has been cooked.
Observe the manufacturer's “use-by” dates and storage
instructions given on food to avoid the risk of food poisoning. Storage
times will depend on several factors, including the freshness and
quality of the food, as well as the temperature at which it is stored.
Accessories and spare parts
Only use original Miele accessories. If other parts are used,
warranty, performance and product liability claims will be invalidated.
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the discontinuation
of your refrigeration appliance.
Warning and Safety instructions
11
Cleaning and care
Do not use any oils or grease on the door seals, as these will cause
the seals to deteriorate and become porous with time.
Do not use a steam cleaning appliance to clean or defrost this
appliance.
Steam could reach electrical components and cause a short circuit.
WARNING! DANGER of injury and damage! Do not use any
mechanical or other types of aids which are not recommended by the
manufacturer to accelerate the defrosting process.
Sharp edged or pointed objects will damage the evaporator,
causing irreversible damage to the appliance. Do not use sharp edged
or pointed objects to
- remove frost and ice,
- separate frozen food or remove ice trays.
Do not place electric heaters or candles in the appliance to defrost
it. These can damage the plastic parts.
Do not use defrosting sprays or de-icers, as they could contain
substances which could damage the plastic parts or which might
cause the build-up of gases and pose a danger to health.
Transport
Always transport the appliance in an upright position and in its
original transport packaging to avoid damage in transit.
Danger of injury and damage to the appliance. The refrigeration
appliance is very heavy and must be transported by two people.
Disposal of your old appliance
Children playing could become trapped in the appliance and could
suffocate.
- Remove the appliance doors.
- Remove the drawers.
- Leave the adjustable shelves in the refrigeration appliance so
children cannot climb inside.
- If your old refrigeration appliance has a door lock, destroy it. This
will prevent the risk of children playing accidentally locking
themselves in and endangering their lives.
Warning and Safety instructions
12
Risk of electric shock!
- Cut the plug off the mains connection cable.
- Cut the mains connection cable off the old appliance.
Dispose of the plug and mains connection cable separately from the
old appliance.
During and after disposal, make sure that the refrigeration
appliance is not placed near petrol or other flammable gases and
liquids.
Risk of fire due to escaping oil or refrigerant!
The refrigerant and oil inside the appliance are flammable. In high
enough concentrations, escaping refrigerant or oil may ignite if they
come into contact with an external heat source.
During disposal, make sure that the cooling circuit is not damaged in
order to prevent refrigerant and oil escaping in an uncontrolled
manner (see the data plate for details of the refrigerant).
Splashes of coolant can damage the eyes. Be careful not to
damage any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the coolant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.
Symbol on the compressor (depending on model)
This information is only relevant for recycling. There is no risk during normal
operation.
The oil in the compressor can be fatal if swallowed or if it
penetrates the airways.
Sustainability and environmental protection
13
Caring for the environment
Disposing of the packaging material
The packaging material is used for
handling and protects the appliance
from transport damage. The packaging
material used is selected from materials
which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material
reduces the use of raw materials. Use
material-specific collection points for
valuable materials and take advantage
of return options. Your Miele dealer will
take the packaging material away.
Disposing of your old appliance
Electrical and electronic appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for their correct
functioning and safety. These could be
hazardous to human health and to the
environment if disposed of with
household waste or if handled
incorrectly. Please do not, therefore,
dispose of your old appliance with
household waste.
Take care not to damage your
refrigeration appliance before or during
disposal in an authorised,
environmentally friendly manner.
This is to ensure that refrigerant in the
cooling circuit and oil in the compressor
is contained, and will not leak into the
environment.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle
electrical and electronic appliances in
your local community, with your dealer
or with Miele, free of charge. By law, you
are solely responsible for deleting any
personal data from the old appliance
prior to disposal. You are legally obliged
to remove any old batteries which are
not securely enclosed by the appliance
and to remove any lamps without
destroying them, where this is possible.
These must be taken to a suitable
collection point where they can be
handed in free of charge. Please ensure
that your old appliance poses no risk to
children while being stored for disposal.
Sustainability and environmental protection
14
How to save energy...
Installation site The refrigeration appliance has to cool more often at higher
ambient temperatures and consumes more energy in the process.
Therefore:
- Install the refrigeration appliance in a well-ventilated room.
- Do not install the refrigeration appliance near to a heat source
(heater element, cooker).
- Protect the refrigeration appliance from direct sunlight.
- Ensure an ideal ambient temperature of 20°C.
- Clean the ventilation openings on a regular basis to remove any
dust.
- Dust the compressor and the metal grille (heat exchanger) at
the back of the refrigeration appliance at least once a year.
Temperature
setting
The colder the temperature, the higher the energy consumption.
The following settings are recommended:
- -18°C in the freezer section.
Use Energy consumption is increased by heat input and impeded air
circulation. Therefore, you should:
- Only open the appliance door(s) when necessary and for as
short a time as possible. Arrange the food in such a way that
makes it easy to find in the appliance.
- Always close the appliance door(s) properly after opening
them.
- Allow hot food and drinks to cool down before placing them in
the refrigeration appliance.
- Store food well packaged or covered.
- Do not overfill the compartments to allow air to circulate.
- Keep drawers and shelves arranged as they were when the
appliance was delivered.
- When placing food in the appliance, make sure that the
ventilation slots are not blocked.
Sustainability and environmental protection
15
Defrosting A layer of ice hinders the cold from reaching the frozen food.
Therefore, you should:
- Defrost the freezer when a layer of ice 0.5cm (max.) thick has
built up.
Familiarisation
16
Guide to the appliance
a
Display
b
Freezer drawer
Familiarisation
17
Display
a
LED -16°C
(sub-menu: lock function)
b
LED -18°C
(sub-menu: Sabbath mode)
c
LED -20°C
(sub-menu:
back to factory default settings)
d
Control symbol
e
LED -28°C
f
SuperFreeze
g
WiFi LED
The display can be scratched by
pointed or sharp objects, e.g. pens.
Only touch the display with your
fingertips.
It is possible that the display will not
react to finger contact if your fingers
are cold.
Familiarisation
18
Operating the refrigeration appliance via the display
Touch and hold the symbol for 3seconds to switch on the refrigeration
appliance.
Touch the symbol a few times in succession to activate the LEDs in the main
menu and in the sub-menu.
The LED for the selected temperature or function lights up.
Touch and hold the symbol for 7seconds to switch from the main menu to the
sub-menu.
If 5seconds pass without a function being selected, the display will return to the
main menu.
When a function is selected in the sub-menu, the corresponding LED lights up.
Touch and hold the symbol for 3seconds to exit the sub-menu and return to
the main menu.
Familiarisation
19
Operation
The refrigeration appliance is operated
using the symbol on the display. This
symbol can be used to switch between
the main menu and sub-menu and to
navigate in both menus. Which
functions are selected depends on how
long the symbol is pressed.
Briefly touching the symbol
Briefly touch the symbol to navigate
through the main menu and the sub-
menu until you reach the required
temperature or function.
Touching and holding the symbol for
3seconds
If you touch and hold the symbol for
3seconds, the current status of the
refrigeration appliance does not matter.
A switched-off appliance will be
switched on. The appliance is switched
off in the main menu. An appliance in
the sub-menu switches to the main
menu. An active function is deactivated.
Touching and holding the symbol for
7seconds
If you touch and hold the symbol in
the main menu for 7seconds, the sub-
menu opens. You are in the sub-menu
when all 5 LEDs light up at the same
time. If no function is selected within
5seconds, the display returns to the
main menu.
Main menu
In the main menu, you can choose
between 5 settings; specifically,
temperatures -16°C, -18°C, -20°C and
-28°C, and the SuperFreeze
function.
Sub-menu
In the sub-menu, you can choose from
3 functions; specifically, the lock
function at LED -16°C, Sabbath mode
at LED -18°C and resetting to the
factory default settings at LED -20°C.
Display idle mode
Idle mode switches on when the
symbol in the main menu has not
been touched for 10seconds. This
prevents the temperature from being
changed inadvertently. Idle mode is
ended by briefly touching the symbol.
LED indicators
The LEDs can light up or flash to
indicate the appliance status. If the LED
lights up, the temperature is selected or
the function is active. A flashing LED
indicates a power failure or a
temperature alarm until the set
temperature is reached. If several LEDs
flash at the same time, a fault has
occurred. If the symbol flashes, the
WiFi connection can be established or
the appliance is in the process of
connecting.
Safety
Lock function
When the lock function is switched on,
it protects the refrigeration appliance
from being switched off unintentionally
and being adjusted unintentionally by
unauthorised persons, e.g. children.
The lock function is located in the LED
-16°C sub-menu.
Familiarisation
20
Temperature alarm
The refrigeration appliance has been
fitted with a temperature alarm so that
the temperature in the freezer zone
cannot rise unnoticed.
All 5 LEDs will flash if the temperature
becomes too warm.
An alarm will also sound until the cause
of the alarm is rectified or the alarm is
switched off. The interior lighting will
also pulsate.
The set temperature determines when
the appliance recognises a temperature
as being too warm.
The audible and visual signals may be
activated in the following situations:
- You switch on the refrigeration
appliance and the temperature in
the freezer zone differs greatly from
the set temperature.
- Too much warm ambient air enters
the freezer when you are
rearranging or taking out frozen
food.
- You are freezing large amounts of
food at once.
- You are freezing warm food.
- There was a power cut.
- The refrigeration appliance has a
fault.
Switching the temperature alarm off
early
Before you switch the temperature
alarm off, you must determine the
cause and rectify it.
If you are bothered by the sound of the
alarm, you can switch the alarm off
early.
Tap briefly.
The LED of the previously set
temperature flashes once per second
until the temperature is reached.
Check whether the food in the freezer
has started to thaw or has defrosted.
If it has, it should be used as soon as
possible. Defrosted food may only be
re-frozen after it has been cooked.
Door alarm
The refrigeration appliance is fitted
with a door alarm to avoid increased
energy consumption and food
becoming warm if the door is left
open.
The alarm will sound and the interior
lighting pulses if the door is left open for
a long time.
As soon as the appliance door is closed,
the alarm tone will stop.
Switching the door alarm off early
Tap briefly.
The alarm tone will stop.
If the appliance door is not closed, the
alarm will sound again after a short
time.
Power failure alarm
The refrigeration appliance has been
fitted with a power failure alarm so
that the temperature in the freezer
zone cannot rise unnoticed as a result
of a power failure.
If a power failure has occurred and the
temperature has become too warm as a
result, all 5 LEDs will flash.
An alarm will also sound until the cause
of the alarm is rectified or the alarm is
switched off. The interior lighting will
also pulsate.
Familiarisation
21
The set temperature determines when
the appliance recognises a temperature
as being too warm.
Switching the power failure alarm off
early
If you are bothered by the sound of the
alarm, you can switch the alarm off
early.
Tap briefly.
If the freezer temperature is below -9°C
during the power failure, the LED of the
previously set temperature flashes once
per second until the temperature is
reached.
If the freezer temperature rise above
-9°C during the power failure, the LED
of the previously set temperature
flashes twice per second until the
temperature is reached.
Check whether the food in the freezer
has started to thaw or has defrosted.
If it has, it should be used as soon as
possible. Defrosted food may only be
re-frozen after it has been cooked.
Appliance functions
Miele@home
Your refrigeration appliance is
equipped with an integrated WiFi
module.
Networking is deactivated at the
factory.
Here you can set up the Miele@home
function for the first time, deactivate
and activate the WiFi or reset the
network configuration (see “Adjusting
settings”).
To use this feature, you will need:
- A WiFi network
- The Miele app
- A Miele user account. You can create
a user account via the Miele app
The Miele app will guide you as you
connect your refrigeration appliance to
your home WiFi network.
Once the refrigeration appliance is
connected to your WiFi network, you
can use the app to carry out the
following activities, for example:
- Call up information on the operating
status of your refrigeration appliance
- Change the settings on your
refrigeration appliance
Connecting your refrigeration appliance
to your WiFi network will increase
energy consumption, even when the
appliance is switched off.
Make sure that the signal of your
WiFi network is sufficiently strong in
the place where you want to set up
your refrigeration appliance.
Familiarisation
22
Availability of the WiFi connection
The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This can give rise to sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot be guaranteed.
Miele@home availability
The ability to use the Miele app
depends on the availability of the
Miele@home service in your country.
The Miele@home service is not
available in every country.
For information about availability, please
visit www.miele.com.
Miele App
The Miele App is available to download
free of charge from the Apple App
Store
®
or from the Google Play Store™.
SuperFreeze
When switched on, the SuperFreeze
function can be used to rapidly
reduce the temperature in the
refrigeration appliance to its lowest
setting (depending on the ambient
temperature). The refrigeration
appliance will work at full power and
lower the temperature. Select this
function before freezing fresh food. This
helps food to freeze quickly and retain
its nutrients, vitamins, flavours and
appearance.
The SuperFreeze function should be
switched on around6hours before
placing food in the freezer. If you are
freezing the maximum amount of
food, the SuperFreeze function
should be switched on 24hours
beforehand.
The SuperFreeze function will
switch itself off automatically after a
maximum of 65hours. The quantity of
fresh food placed in the freezer will
determine the duration before it
switches off.
Familiarisation
23
Sabbath mode
The refrigeration appliance offers a
Sabbath mode for the purposes of
religious observance.
When Sabbath mode is switched on,
the following are deactivated:
- Interior lighting when the appliance
door is opened
- All visual and audible signals
- The temperature display
- WiFi connection
- Deactivate all functions in the display
except for the Sabbath mode function
All other functions switched on
previously remain activated.
The Sabbath mode function will switch
off automatically after approx.
80hours.
After a power cut, the appliance
returns to Sabbath mode.
The Sabbath mode function is located in
the LED -18°C sub-menu.
Factory defaults
You can reset the refrigeration
appliance‘s settings to their factory
default settings. The WiFi connection is
also reset.
Tip: We recommend doing this if you
are disposing of or selling your
refrigeration appliance, or if you are
putting a used refrigeration appliance
into operation.
The factory default settings function is
located in the LED -20°C sub-menu.
Demo mode
Demo mode allows the refrigeration
appliance to be presented in the
showroom without the cooling system
being switched on. This setting is not
needed for domestic use.
Commissioning
24
Before using for the first time
Remove all packaging material and
protective film.
Clean the inside of the appliance and
the accessories (see “Cleaning and
care”).
Connecting the refrigeration appliance
Connect the refrigeration appliance to
the electricity supply as described in
“Electrical connection”.
Switching on and off
To note when switching off for longer
periods of time
If, during a long absence, the
refrigeration appliance is switched off
but not cleaned and the door is left
shut, there is a danger of mould
building up inside the appliance.
It is essential to clean the
refrigeration appliance before a long
period of absence.
If the refrigeration appliance is not going
to be used for a longer period of time,
observe the following:
Switch the refrigeration appliance off.
Switch off at the wall and disconnect
the plug from the socket, or
disconnect the fuse.
Defrost the freezer.
Clean the refrigeration appliance and
leave the door ajar to air the appliance
and avoid odours building up inside.
Switching the refrigeration appliance
on
Touch the symbol for 3seconds
until a buzzer sounds.
The refrigeration appliance will start to
cool and the interior lighting will come
on when the appliance door is opened.
The refrigeration appliance will adjust to
the preset temperature.
During initial commissioning or if the
appliance was not previously connected
to the WiFi, the connection process
may take several minutes.
If the appliance was already connected
to the WiFi, it will connect
automatically.
Commissioning
25
To enable the temperature to get
sufficiently cold inside the
refrigeration appliance, allow the
appliance to run for a few hours
before placing food in it.
Switching off the refrigeration
appliance
You are in the main menu.
Touch the symbol for 3seconds
until a buzzer sounds.
The LEDs in the display no longer light
up, the interior lighting is switched off
and the appliance is no longer cooling.
Please note: The refrigeration
appliance is not disconnected from
the power supply when it is switched
off.
Operation
26
Setting the temperature
You are in the main menu.
Touch the symbol a few times in
succession until you reach the LED
for the required temperature.
Health risk caused by
decomposing food.
A temperature of -18°C is preset.
Please note that, if the temperature
is any warmer, the food will have a
shorter shelf life.
To freeze fresh food, a temperature of
-18°C is required.
By keeping the freezer zone at a
constant temperature of -18°C and
taking appropriate hygiene measures
you can maximise the storage life of
your food and avoid food waste.
Switching SuperFreeze on
The SuperFreeze function should be
switched on around6hours before
placing food in the freezer. If you are
freezing the maximum amount of
food, the SuperFreeze function
should be switched on 24hours
beforehand.
You do not need to switch on the
SuperFreeze function:
- If you are placing food that is
already frozen in the freezer
- If you only freeze up to 2kg of fresh
food daily
Touch the symbol a few times in
succession until you reach the
LED.
The LED lights up orange.
Switching SuperFreeze off
The SuperFreeze function will
switch itself off automatically after a
maximum of 65hours. The
temperature adjusts to the previously
set value.
To save energy, you can switch the
SuperFreeze function off early once
the food is sufficiently chilled by
setting a temperature.
Touch the symbol a few times in
succession until you reach the
required temperature.
SuperFreeze is deactivated and the
LED no longer lights up orange.
Operation
27
Freezing and storing food
Freezing fresh food
Health risk caused by
decomposing food.
If the temperature in the freezer
remains above -18°C for a long time,
the frozen food can start to defrost.
This will reduce the storage life of the
food.
Check whether the frozen food has
started to defrost. If it has, check that
the food is safe to use and if it is,
then use it as soon as possible or
cook it before freezing it again.
Fresh food should be frozen as quickly
as possible. This way the nutritional
value of the food, its vitamin content,
appearance and taste are not impaired.
If food is frozen quickly, the cells have
less time to lose moisture, so they
shrink significantly less. As there is not
so much moisture loss, it is easier for
the food to reabsorb it during the
defrosting process, and very little water
collects around the defrosted food.
Maximum freezing capacity
To ensure that fresh food placed in the
freezer freezes through to the core as
quickly as possible, the maximum
freezing capacity must not be exceeded.
The maximum freezing capacity for
freezing within a 24-hour period is given
on the data plate: “Freezing
capacity...kg/24hrs”.
Storing frozen food
When buying frozen food to store in
your freezer, check:
- That the packaging is not damaged
- The use-by date
- That the temperature at which the
frozen food is being stored in the shop
is -18°C or colder
Where possible, transport frozen food
in an insulated bag and then store it
quickly in the refrigeration appliance.
Operation
28
Home freezing
Not suitable for freezing
Please note that some food is not
suitable for freezing. This includes, for
example, vegetables that are usually
eaten raw, such as lettuce or radishes.
To note before placing food in the
freezer
When freezing more than 2kg of fresh
food, switch on the SuperFreeze
function for 6hours before placing
the food in the freezer.
When freezing even larger amounts of
food, switch on the SuperFreeze
function for 24hours before
placing the food in the freezer.
This helps the frozen food which is
already stored in the freezer to stay
frozen.
Only freeze fresh food which is in
good condition.
Tip: To retain colour, taste, aroma and
vitamin C, vegetables should be
blanched before they are frozen. To do
so, place vegetables portion by portion
into boiling water for 2–3minutes. Then
remove and plunge the vegetables into
ice-cold water to cool quickly. Leave the
vegetables to drain.
Packaging food for freezing
Freeze food in portions.
Tip: Use suitable packaging to avoid
freezer burn (such as freezer
containers).
Expel as much air as possible from
the packaging and close it tightly.
Make a note of the contents and the
date of freezing on the packaging.
Placing food in the freezer
Risk of damage caused by
loading too much food.
Loading food which is too heavy can
cause damage to the freezer
drawers/glass plates.
Do not exceed the relevant maximum
load size:
Freezer drawer on bottom of
appliance or glass plate = 16kg
Unfrozen food should not touch
frozen food as this will cause the
frozen food to begin to thaw.
To prevent food sticking together
when frozen, make sure that the
packaging and containers are dry.
To ensure that food freezes through to
the core quickly, do not exceed the
following packaging and container
sizes:
- Fruit and vegetables: max. 1kg
- Meat: max. 2.5kg
–Freezing small amounts of food
Place the frozen food flat in the
bottom of the lower freezer drawers
so that it freezes through to the core
as quickly as possible.
Operation
29
–VarioRoom: freezing large amounts
of food
Do not exceed the maximum
permitted amount of food for freezing
(see the specifications on the data
plate).
Remove the lowest freezer drawer.
Place the frozen food in the
refrigeration appliance so that it is in
contact with the bottom of the
appliance or the interior side walls.
Tip: You can expand the space available
in the freezer zone. If you wish to freeze
large items such as a turkey or game,
you can remove the lower freezer
drawers and the glass plates between
the freezer drawers.
After freezing
Switch the SuperFreeze function
off.
Place the frozen food in the freezer
drawers and push them back in.
Cooling drinks quickly
When cooling drinks quickly in the
freezer zone, make sure bottles are
not left in for more than 1hour.
Otherwise they could burst.
Making ice cubes
Fill the ice cube tray 3/4 full with
water and place it on the bottom of
one of the freezer drawers.
Once frozen, use a blunt instrument,
for example a spoon handle, to
remove the ice cube tray from the
freezer if it is stuck.
Tip: Ice cubes can be removed easily
from the tray by twisting the tray gently
or by holding it under cold running water
for a short time.
Good to know
30
The correct temperature
It is very important to set the correct
temperature to ensure the shelf life of
food. Reducing the temperature reduces
the growth rate of microorganisms.
Food does not spoil as quickly.
To freeze fresh food, a temperature of
-18°C is required. This will prolong the
shelf life of your food and retain its
quality.
As soon as the temperature rises above
-10°C, the bacteria become active in
the food again so it cannot be kept as
long. For this reason, partially defrosted
or defrosted food must not be re-frozen.
Food may be re-frozen once it has been
cooked, as the high temperatures
achieved when cooking destroy most
bacteria.
The temperature in the refrigeration
appliance will rise:
- The more often the appliance door is
opened and the longer it is kept open
- The more food is stored in it
- The warmer the food is which is being
put into it
- The higher the ambient temperature
surrounding the refrigeration
appliance This refrigeration appliance
is designed for use within specific
ambient temperatures (climate range).
Do not use in ambient temperatures
for which it is not designed.
Storage time for frozen food
Food group Storage time
(Months)
Ice cream 2to6
Bread, baked goods 2to6
Cheese 2to4
Fish, oily 1to2
Fish, lean 1to5
Sausage, ham 1to3
Game, pork 1to12
Poultry, beef 2to10
Vegetables, fruit 6to18
Herbs 6to10
The storage times given are guidelines only.
For standard freezing results, follow the
advice on packaging.
Notes on buying food
The freshness of the food when it is first
placed in the appliance is the most
important factor for how long it stays
fresh.
Take into account the use-by date and
the correct storage temperature.
Time out of the refrigerator, e.g.
transporting food in a warm car, should
be kept to a minimum.
Adjusting settings
31
Switching the lock function on
The refrigeration appliance must be
switched on.
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Touch the symbol multiple times
briefly until you reach the -16°C LED.
The -16°C LED lights up and the safety
lock has been activated.
Switching the lock function off
Touch the symbol for 3seconds
until a buzzer sounds.
The lock function has been switched off.
You are back in the main menu.
Switching Sabbath mode on
The refrigeration appliance must be
switched on.
When Sabbath mode is switched on,
you cannot make any settings on your
refrigeration appliance.
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Touch the symbol multiple times
briefly until you reach the -18°C LED.
The -18°C LED lights up and Sabbath
mode is switched on.
Ensure that the appliance door is
properly closed, as visual and audible
alarms are switched off.
Health risk caused by
decomposing food.
As power failures are not indicated
while Sabbath mode is active, food
may be exposed to increased
temperatures for a certain period of
time. This will reduce the storage life
of the food.
If there is a power failure during
Sabbath mode, check the quality of
the food.
Switching Sabbath mode off
The Sabbath Mode function will
switch off automatically after approx.
80hours.
However, you can switch the Sabbath
mode function off early.
Touch the symbol for 3seconds
until a buzzer sounds.
Sabbath mode is switched off. You are
back in the main menu.
The interior lighting is activated. The
LED for the previously set temperature
lights up. The appliance connects to the
WiFi if it was previously connected to
the WiFi. If the appliance was not
previously connected to the WiFi, the
symbol flashes for several minutes. A
connection can be established during
this time.
Resetting the settings to their
factory default settings
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Adjusting settings
32
Touch the symbol multiple times
briefly until you reach the -20°C LED.
The -20°C LED lights up and all
settings are reset to the factory default
settings. The appliance switches off
after a short time.
Activating the WiFi connection
The WiFi connection is switched off at
the factory. The symbol is dark.
Touch and hold the symbol for
3seconds to switch off the
refrigeration appliance.
Then touch and hold the symbol for
3seconds to switch on the
refrigeration appliance.
The symbol flashes in the display for
several minutes. During this time, you
can connect the appliance to the WiFi.
If the time window for the connection is
not long enough, switch the appliance
off and on again.
As soon as the connection is
established, the symbol lights up.
Deactivating the WiFi
connection
To deactivate the WiFi connection, you
must reset the appliance to the factory
default settings.
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Touch the symbol multiple times
briefly until you reach the -20°C LED.
The -20°C LED lights up and all
settings are reset to the factory default
settings. The appliance switches off
after a short time.
Reset the network configuration if
you are disposing of or selling your
refrigeration appliance, or if you are
putting a used refrigeration appliance
into operation. All personal data is
removed from the refrigeration
appliance. This will also ensure that a
previous owner is no longer able to
access the refrigeration appliance.
Switching on demo mode
Touch and hold the symbol for
3seconds to switch off the appliance.
Touch the symbol for 10seconds
until a buzzer sounds.
Touch the symbol briefly 5 times.
All LEDs light up twice briefly after
2seconds. Demo mode has been
activated.
Switching off demo mode
Touch and hold the symbol for
3seconds to switch off the appliance.
Touch the symbol for 10seconds
until a buzzer sounds.
Touch the symbol briefly 5 times.
All LEDs light up briefly four times after
2seconds. The display goes dark. Demo
mode is switched off.
After demo mode is switched off, the
appliance is reset to the factory default
settings.
Adjusting settings
33
Exiting service mode
If you have accidentally entered service
mode, you can easily exit it again. The
WiFi LED and the LED flash
simultaneously.
Either wait 5minutes or touch the
symbol for 3seconds to exit service
mode.
Cleaning and care
34
The data plate located inside the
interior cabinet of the refrigeration
appliance must not be removed. It
contains information which is required
in the event of a fault.
Do not let water get into the
electronic unit or the lighting.
Risk of damage due to moisture
ingress.
The steam from a steam cleaner can
damage plastic and electrical
components.
Do not use a steam cleaner to clean
the refrigeration appliance.
Cleaning agents
Cleaning and conditioning agents
used in the interior cabinet of the
refrigeration appliance must be food
safe.
To avoid damaging the surfaces of the
appliance, do not use the following:
- Cleaning agents containing soda,
ammonia, acids or chlorides
- Cleaning agents containing descaling
agents
- Abrasive cleaning agents (e.g.
scouring powder, scouring liquid or
pumice stones)
- Cleaning agents containing solvents
- Stainless steel cleaners
- Dishwasher cleaner
- Oven sprays
- Glass cleaning agents
- Hard, abrasive sponges and brushes
(e.g. pot scourers)
- Eraser stain remover blocks
- Sharp metal scrapers
We recommend using a clean sponge
and lukewarm water with a little
washing-up liquid to clean the surfaces
of the appliance.
Cleaning and care
35
Preparing the refrigeration
appliance for cleaning
Switch the refrigeration appliance off.
Take any food out of the refrigeration
appliance and store it in a cool place.
Defrost the freezer section (see
“Defrosting”).
Take out all other removable parts for
cleaning.
Cleaning the interior of the
appliance
Clean the refrigeration appliance
regularly each time it is defrosted
(around twice a year).
If soiling is left on for any length of
time, it may become impossible to
remove under certain circumstances.
Surfaces may suffer discolouration or
damage.
It is therefore best to remove any
soiling immediately.
Clean the interior with a clean sponge
cloth, lukewarm water and a little
washing-up liquid.
After cleaning, wipe with clean water
and dry with a cloth.
Leave the door open to air the
refrigeration appliance sufficiently for
a short while and to prevent odour
build-up.
Cleaning accessories by hand
or in the dishwasher
The following components must be
cleaned by hand only:
- All drawers
The following components are
dishwasher-safe:
Risk of damage due to high
dishwasher temperatures.
Parts of the refrigeration appliance
may become unusable, e.g. deform, if
they are washed in the dishwasher at
more than 55°C.
For dishwasher-safe components,
always select dishwasher
programmes with a maximum
temperature of 55°C.
Contact with natural dyes from
carrots, tomatoes and ketchup, etc.,
may discolour the plastic parts in the
dishwasher. This discolouration does
not affect the stability of the parts.
- The ice cube tray
- The glass shelves
Removing and dismantling
accessories for cleaning
Removing the freezer drawers and
glass plates
Lift the freezer drawers at the front
and pull it up and out at an angle.
Pull out the glass plates between the
freezer drawers.
Cleaning and care
36
Inserting the glass plates and freezer
drawers
Place the glass plates in the freezer
zone.
Insert the freezer drawers back in the
freezer zone at an angle.
Cleaning the front of the
appliance and the side panels
If soiling is left on for any length of
time, it may become impossible to
remove. Surfaces may suffer
discolouration or damage.
Therefore, it is best to remove soiling
from the appliance front and side
panels immediately.
All surfaces are susceptible to
scratching. Contact with unsuitable
cleaning agents can alter or discolour
the surfaces.
See the information on “Cleaning
agents” at the beginning of this
section.
Clean the surfaces with a clean
sponge and a solution of warm water
and washing-up liquid. A clean, damp
microfibre cloth without cleaning
agent can also be used.
After cleaning, wipe with clean water
and dry with a soft cloth.
Cleaning the door seal
Risk of damage as a result of
incorrect cleaning.
If you treat the door seal with oils or
grease, it can become porous.
Do not use any oils or grease on the
door seal.
The door seal should be cleaned
regularly with clean water, and then
wiped dry with a soft cloth.
Cleaning the ventilation gaps
A build-up of dust will increase the
energy consumption of the appliance.
The ventilation gaps should be
cleaned on a regular basis with a
brush or vacuum cleaner (you could
use a Miele vacuum cleaner dusting
brush, for example).
Cleaning the compressor and
metal grille at the back of the
appliance
A build-up of dust will increase the
energy consumption of the appliance.
Risk of damage as a result of
incorrect cleaning.
Cables and other components can
get broken off, bent or damaged.
Carefully clean the compressor and
metal grille.
The compressor and metal grille at the
back of the refrigeration appliance (heat
exchanger) should be dusted at least
once a year.
After cleaning
Close the appliance door.
Switch the refrigeration appliance
back on.
Switch on the SuperFreeze function
so that the refrigeration appliance can
cool down quickly.
Cleaning and care
37
Once the temperature in the
refrigeration appliance is sufficiently
low, place the frozen food back in the
freezer drawers and put them back in
the refrigeration appliance.
Switch the SuperFreeze function off
again.
Defrosting
The freezer zone does not defrost
automatically.
In normal use, ice and frost will form in
the freezer zone, e.g. on the internal
walls. How much ice and frost
accumulates in the appliance will
depend on the following:
- Whether the appliance door has been
opened frequently or left open for a
while
- Whether a large quantity of food has
been placed in the freezer at once
- Whether the humidity in the room has
increased
Too thick a layer of ice will make it hard
to remove freezer drawers In certain
circumstances it can prevent the
appliance door from closing properly.
Too thick a layer of ice also reduces
cooling performance and thus increases
energy consumption.
The freezer zone should be defrosted
from time to time. It must be
defrosted if a layer of ice approx.
0.5cm thick has accumulated.
Tip: It is best to defrost when only very
little or no frozen food at all is left in the
freezer zone or the humidity level and
the ambient temperature in the room
are low.
Risk of damage from an incorrect
defrosting process.
When defrosting the freezer, make
sure that you do not damage the
evaporator as this would cause
irreversible damage to the
refrigeration appliance.
Do not scrape off ice and frost. Do
not use sharp objects.
Do not use any mechanical tools or
other types of aid which are not
recommended by the manufacturer
to accelerate the defrosting process.
Switch on the SuperFreeze
function 1 day before defrosting.
This helps the frozen food to retain
the cold reserve for longer when taken
out of the freezer.
Remove the frozen food and wrap it in
several layers of newspaper or cloths.
Tip: You could also place the frozen food
in a cool box or bag.
Store the frozen food in a cool place
until the freezer zone is ready for use
again.
Remove all freezer drawers and glass
plates from the freezer zone.
The longer the frozen food is left out
at room temperature, the faster it
deteriorates.
Carry out the defrosting procedure as
quickly as possible.
Cleaning and care
38
Risk of damage due to heat and
moisture ingress.
The steam from a steam cleaner as
well as electric heaters and candles
can damage plastic and electrical
components.
Do not use a steam cleaner, electric
heaters or candles to defrost the
refrigeration appliance.
Risk of damage and risk to health
caused by defrosting sprays or de-
icers.
Defrosting sprays or de-icers can
contain substances which could
damage the plastic parts or which
might cause a build-up of explosive
gases and pose a danger to health.
Never use defrosting sprays or de-
icers to defrost the refrigeration
appliance.
Ensure that water does not get into
the surrounding cabinetry.
Switch the refrigeration appliance off.
Switch off at the wall and disconnect
the plug from the socket, or
disconnect the fuse.
Leave the freezer door open.
Tip: To speed up defrosting, place 2
pots of hot water (not boiling), with
plates underneath them, in the freezer
zone. Closing the door in this instance
will help retain the warmth and speed
up the defrosting process.
Remove any loose pieces of ice.
Use a sponge or cleaning cloth to
soak up the defrosted water as often
as necessary.
After defrosting
Clean the freezer zone, then dry it
thoroughly.
Close the appliance door.
Reconnect the refrigeration appliance
to the mains and switch it back on.
Switch on the SuperFreeze
function so that the freezer zone
can cool down quickly.
Place the glass plates and freezer
drawers with the frozen food back in
the freezer zone.
Troubleshooting
39
Many malfunctions and faults that can occur in daily operation can be easily
remedied. You can save time and money in many cases, as you do not need to call
the Miele Customer Service Department.
Information to help you remedy faults yourself can be found at www.miele.com/
service.
The following tables are designed to help you to find the cause of a malfunction or a
fault and to resolve it.
To prevent unnecessary loss of temperature it is advisable not to open the door
while waiting for the appliance to be serviced.
Problem Cause and remedy
The refrigeration appli-
ance is not getting cold
and the interior lighting
does not come on when
the appliance door is
opened.
The refrigeration appliance has not been switched on.
The temperature display on the control panel is not
showing a temperature.
Switch the refrigeration appliance on.
The plug is not inserted into the socket correctly.
Insert the plug into the socket.
The mains fuse has tripped. There could be a fault
with the refrigeration appliance, the household
electrical wiring or another electrical appliance.
Contact a qualified electrician or the Miele
Customer Service Department.
The refrigeration appli-
ance is not getting cold
and the interior lighting
does not come on when
the appliance door is
opened.
Demo mode has been activated. This allows the
refrigeration appliance to be presented in the dealer
showroom without the cooling system being switched
on. This setting is not needed for domestic use.
Switch off demo mode (see “Adjusting settings –
Switching off demo mode”).
The compressor runs
continuously.
This is not a fault. To save energy, the compressor
runs at a lower speed, but for longer, when less
cooling is required.
The compressor is
switching on more fre-
quently and for longer
periods of time. The
temperature in the refri-
geration appliance is too
low.
The ventilation gaps have been covered or become
too dusty.
Do not block the ventilation gaps.
Dust the ventilation gaps regularly.
The appliance door has been opened too frequently, or
a large amount of fresh food has been placed inside or
frozen at the same time.
Only open the appliance door when necessary and
for as short a time as possible.
Troubleshooting
40
Problem Cause and remedy
After a while, the temperature will return to normal by
itself.
The appliance door is not properly closed. A thick layer
of ice may have formed in the freezer zone.
Close the appliance door.
After a while, the temperature will return to normal by
itself.
If a thick layer of ice has already formed, this will
affect cooling and increase energy consumption.
Defrost the refrigeration appliance and clean it.
The ambient temperature is too high. The higher the
ambient temperature, the longer the compressor runs.
See the information in “Installation – Installation
site”.
The temperature setting in the refrigeration appliance
is too low.
Correct the temperature setting.
A large amount of food has been frozen at once.
See the information in “Operation – Freezing and
storing food”.
The SuperFreeze function is still switched on.
Switch off the SuperFreeze function earlier to
save energy.
The compressor comes
on less and less often
and for shorter periods
of time. The temperature
in the refrigeration appli-
ance rises.
This is not a fault. The temperature setting is too high.
Correct the temperature setting.
Check the temperature again after 24hours.
The frozen food begins to defrost.
The ambient temperature is too low for this
refrigeration appliance.
If the ambient temperature is too low, the compressor
will run less frequently. This may cause the freezer
zone to become too warm.
See the information in “Installation – Installation
site”.
Increase the ambient temperature.
Troubleshooting
41
Problem Cause and remedy
Ice or condensation has
built up inside the refri-
geration appliance. The
appliance door may not
close correctly.
The door seal has come out of its groove.
Check that the door seal is correctly positioned in
the groove.
The door seal is damaged.
Check whether the door seal is damaged.
The door seal is dam-
aged or needs to be re-
placed.
No tools are required to change the door seal.
Change the door seal. A replacement is available
from Miele or from specialist retailers.
Other problems
Problem Cause and remedy
The door to the freezer
will not open because it
has been opened and
closed too many times
in succession.
This is not a fault. The suction caused by opening and
closing the door is preventing the door from opening.
Wait approx. 1minute and then try again. It should
now open without force.
Food has frozen to-
gether.
The food packaging was not dry when placed in the
freezer.
Use a blunt instrument, e.g. a spoon handle or
plastic scraper, to prise it apart carefully.
The external walls of the
appliance feel warm.
This is not a fault. The heat created by the evaporator
is used to prevent condensation.
Display warnings
Message Cause and remedy
All 5 LEDs flash on the
display, an alarm sounds
and the interior lighting
pulses.
The temperature has become too warm.
Briefly touch the symbol to switch the alarm off,
and rectify the cause of the alarm (see
“Familiarisation – Temperature alarm”).
All 5 LEDs flash on the
display, an alarm sounds
and the interior lighting
pulses.
The temperature has become too warm because of a
power failure.
Briefly touch the symbol to switch the alarm off,
and rectify the cause of the alarm (see
“Familiarisation – Power failure alarm”).
Troubleshooting
42
Message Cause and remedy
The -18°C, -28°C and
LEDs flash in the display.
This message appears if the appliance cannot be
connected to the WiFi or the connection is
interrupted.
Briefly touch the symbol to switch the alarm off,
and then check the WiFi connection (see
“Familiarisation” and “Adjusting settings –
“Activating the WiFi connection”).
LED and the LED
flash simultaneously in
the display.
This message appears if you have accidentally entered
service mode.
Either wait 5minutes or touch the symbol for
3seconds to exit service mode.
Troubleshooting
43
Interior lighting
Problem Cause and remedy
Risk of electric shock due to exposed, live electrical components.
When removing the lighting cover, there is a risk of coming into contact with
live electrical components.
Do not remove the lighting cover. The LED lighting may only be repaired or
replaced by the Miele Customer Service Department.
Risk of injury from LED lighting.
This lighting corresponds to risk group RG2. If the cover is defective, there is a
risk of eye injury.
If the lighting cover is defective, do not look from a close range directly into the
lighting with optical instruments (e.g. magnifying glass or similar).
Problem Cause and remedy
The interior lighting is
pulsating.
This is not a fault. The door alarm has been activated.
Troubleshooting
44
Noises
The refrigeration appliance is producing various noises during operation.
If the cooling performance is low, the refrigeration appliance will conserve energy
but operate for longer. The volume will be lower.
Food will be chilled faster if the cooling performance is high.
The volume will be higher.
Normal
noises
What is causing them?
Hissing Refrigerant is being injected into the cooling circuit.
Bubbling, gurgling,
splashing
Refrigerant is circulating through the pipes.
Humming The refrigeration appliance is cooling.
Clicking The thermostat is switching the compressor on or off.
Humming, whirring The fan is running.
Automatic door opening is opening or closing the
appliance door.
Cracking Materials are expanding inside the refrigeration
appliance.
Rattling Valves or flaps are active.
Buzzing (refrigeration
appliances with water
container)
Water is being pumped out of the water container.
Slurping (refrigeration
appliances with soft-
close mechanism)
The appliance door with soft-close mechanism is being
opened or closed.
Please bear in mind that a certain amount of noise is unavoidable (from the
compressor and the refrigerant circulating through the cooling circuit).
Troubleshooting
45
Noises Cause and remedy
Vibrating, rattling,
clinking
The refrigeration appliance is uneven. Use a level to
check and adjust the alignment of the refrigeration
appliance by raising or lowering the adjustable feet
underneath the refrigeration appliance.
The refrigeration appliance is touching another appliance
or piece of furniture. Move it away.
Drawers, baskets or shelves are jiggling or are stuck.
Check all removable items and refit them correctly.
Bottles or containers are touching. Separate bottles or
containers slightly.
The transport cable clips (depending on the model) are
hanging loose at the back of the appliance. Remove the
transport cable clips.
Customer Service Department
46
Information to help you rectify faults
yourself and about Miele spare parts
can be found at www.miele.com/
service.
Contact in the event of a fault
In the event of a fault which you cannot
remedy yourself, please contact your
Miele dealer or Miele Customer Service.
You can book a Miele Customer
Service call-out online at
www.miele.com/service.
Contact information for Miele
Customer Service can be found at the
end of this document.
Please quote the model identifier and
serial number of your appliance (SN)
when contacting Miele Customer
Service. Both numbers can be found on
the data plate inside the refrigeration
appliance or, depending on the model,
in Settings mode under Information.
EPREL database
Since 1 March 2021, information on
energy labelling and ecodesign
requirements has been available in the
European Product Database (EPREL).
You can find the product database at
the following link https://
eprel.ec.europa.eu/. You will be asked to
enter the model identifier.
The model identifier can be found on the
data plate inside the refrigeration
appliance or, depending on the model,
in Settings mode under Information.
SN-ST
R600a:
XXXXXX
Nr. XX/ XXXXXXXXX.
XXX l
XXg
Warranty
For information on the appliance
warranty specific to your country please
contact Miele. See back cover for
address.
In the UK, your appliance warranty is
valid for 2 years from the date of
purchase. However, you must activate
your cover by calling 0330 160 6640 or
registering online at www.miele.co.uk.
Optional accessories
47
Multi-purpose microfibre cloth
The microfibre cloth is suitable for
removing fingerprints and light soiling
from surfaces such as stainless steel,
glass, plastic and chrome without the
use of chemicals.
MicroCloth Kit
The MicroCloth Kit contains a universal
cloth, a glass cloth and a polishing cloth.
These cloths are extremely resistant to
tearing and very robust. Thanks to very
fine microfibres these cloths achieve an
excellent cleaning performance.
MicroCloth HyClean
The MicroCloth HyClean is a multi-
purpose antibacterial cloth and is
particularly tear resistant and durable. It
can be used wet or dry, with or without
cleaning agent.
Accessories are available to order via
the Miele Webshop, from Miele
directly (see back cover for contact
details) or from your Miele dealer.
Installation
48
Installation site
Risk of damage due to high
humidity.
In environments with high humidity,
condensation can build up on
external refrigeration appliance
panels.
This condensate can cause corrosion
on external appliance panels.
Install the refrigeration appliance in a
dry and/or air-conditioned room with
sufficient ventilation.
After installation please make sure
that the appliance door(s) closes/
close properly and that the specified
ventilation gaps are adhered to.
Fire risk and risk of damage from
appliances which give off heat.
Appliances which give off heat can
catch fire and set fire to the
refrigeration appliance.
Do not place appliances which give
off heat, such as mini-ovens, double
burner hobs or toasters on the
refrigeration appliance.
Fire risk and danger of damage
from open flames.
Open flames can set fire to the
refrigeration appliance.
Keep open flames (e.g. a candle)
away from the refrigeration
appliance.
This appliance should be installed in a
dry, well-ventilated room.
When deciding on the installation site,
please bear in mind that your
refrigeration appliance will use more
energy if installed near to a heater, a
cooker or other appliance that gives off
heat.
Avoid direct sunlight.
The higher the ambient temperature,
the longer the compressor runs and
the higher the energy consumption is.
When installing the refrigeration
appliance, please note the following:
- The socket must be easily accessible
in an emergency, not concealed
behind the appliance.
- The mains plug and mains connection
cable must not touch the rear of the
refrigeration appliance as they could
be damaged by vibrations from the
appliance.
- Do not plug in other appliances into
sockets behind this appliance.
- When installing the refrigeration
appliance, make sure that the mains
connection cable does not get
trapped or damaged.
- Do not position or operate multi-
socket adapters, distributor strips or
other electronic devices (e.g. halogen
transformers) at the rear of the
appliance.
- The floor at the installation site must
be horizontal and level and must be as
high as the surrounding floor.
Installation
49
Climate range
This refrigeration appliance is designed
for use within specific ambient
temperatures (climate range). Do not
use it in ambient temperatures for
which it is not designed.
A lower room temperature leads to the
compressor switching off for longer
periods. This can cause the internal
temperature in the refrigeration
appliance to rise with the risk of food
deteriorating and going off.
The climate range is stated on the data
plate in the interior cabinet of the
refrigeration appliance.
Climate range Ambient
temperature
SN 10to32°C
N 16to32°C
ST 16to38°C
T 16to43°C
SN-ST 10to38°C
SN-T 10to43°C
A freezer from the SN climate range
can operate without any difficulties in
rooms with a cooler ambient
temperature (down to -15°C).
Ventilation requirements
Risk of fire and damage due to
insufficient ventilation.
If the refrigeration appliance is not
ventilated sufficiently, the
compressor will run more frequently
and for longer periods. This will result
in increased energy consumption and
a higher operating temperature for
the compressor. This may, in turn,
cause damage to the compressor.
Please ensure that there is adequate
ventilation around the refrigeration
appliance.
It is essential to observe the required
ventilation gaps.
The ventilation gaps must not be
covered or blocked in any way.
They must also be regularly dusted.
Air at the back of the refrigeration
appliance gets warm. Sufficient space
for proper ventilation must therefore be
ensured (see “Installation dimensions”).
Installation
50
Installing several refrigeration
appliances
Risk of damage due to
condensation on external appliance
panels.
In environments with high humidity,
condensation can build up on
external appliance panels, which can
cause corrosion.
Do not place different refrigeration
appliance models directly next to or
on top of one other.
Your refrigeration appliance must not be
installed next to another refrigeration
appliance (“side-by-side”), or above
another one, because it is not equipped
with built-in heating units in the side
panels.
If you want to place several refrigeration
appliances next to each other, a
distance of 100mm must be
maintained between them.
Changing the door hinging
Danger of injury and damage to
the appliance due to heavy door.
There is an increased risk of injury
and damage if the door hinging is
installed by a single person.
Always change the door hinging with
the help of a second person.
Risk of crushing at the hinge.
Fingers can get trapped in or around
the hinge.
Do not reach into the hinge when
opening and closing the door.
The refrigeration appliance is supplied
with right-hand hinging. If left-hand
hinging is required, the hinges must be
changed.
Place a suitable cover on the floor in
front of the appliance to protect the
appliance door and your floor from
damage while you are changing the
hinging.
Make sure that the appliance is
empty.
Close the appliance door.
Be careful not to damage the door
seal. If the door seal is damaged, the
appliance door may not close
properly and cooling will be
insufficient.
Tip: To change the door hinging, you will
need the following tools:
SW5
TX 15
TX 20
Installation
51
Risk of injury when removing the
appliance door.
The appliance door is not secure
once the screws on the hinge plate
have been removed.
The second person must support the
appliance door.
Unscrew the lower hinge plate and
remove it.
Take the appliance door off
downwards.
Pull the hinge pin out of the hinge
plate, and screw it into the second
hole in the hinge plate. (The hinge pin
can be screwed in and unscrewed
using the open spanner.)
Remove the cover and use it to
cover the empty holes on the
opposite side.
Unscrew the upper hinge pin with
the open spanner and refit it on the
opposite side.
Fit the appliance door from below up
onto the upper hinge pin and then
close the appliance door.
Fit the hinge plate from below into
the lower door bearing and screw it
on tight, first tightening the middle
screw and then the inner screw.
The appliance door can be aligned
using the long slots in the hinge plate.
Ensure that all screws have been
properly tightened.
Installation
52
Fitting supplied wall spacers
The wall spacers supplied must be
used in order to achieve declared
energy consumption values and to
prevent the build-up of condensation
at high ambient temperatures. The
refrigeration appliance depth is
increased by approx.35mm for
appliances with wall spacers fitted.
If the wall spacers are not used, the
functionality of the refrigeration
appliance is not affected. Energy
consumption does, however, increase
slightly with less distance between the
appliance and the wall.
Fit the wall spacers onto the back of
the refrigeration appliance on the
bottom left and right.
Setting up the refrigeration
appliance
Risk of injury and damage due to
the refrigeration appliance tipping
over.
There is an increased risk of injury
and damage if the refrigeration
appliance is installed by a single
person.
Two people are required for installing
the refrigeration appliance.
Risk of damage to the appliance
door caused by impact.
The appliance door could hit the wall
of the room resulting in damage to
the door.
Protect the appliance door by fitting a
felt stopper, for example, to the wall
of the room.
Risk of damaging the floor.
Moving the refrigeration appliance
can cause damage to the floor.
Move the refrigeration appliance
carefully on floors that are sensitive
to scratching.
Tip: The refrigeration appliance must be
empty when it is installed.
Prepare the refrigeration appliance for
installation as close as possible to its
intended installation site.
Connect the refrigeration appliance to
the electricity supply as described in
“Electrical connection”.
Move the refrigeration appliance
carefully to its intended installation
site.
Position the refrigeration appliance
with the wall spacers (if used) or the
back close to the wall.
Installation
53
Aligning the refrigeration appliance
Risk of damage caused by floor
unevenness.
If the adjustable feet are not used to
compensate for any unevenness in
the floor, the body of the appliance
may warp slightly, potentially
preventing the appliance door from
closing properly.
Use the adjustable feet to
compensate for any unevenness in
the floor.
To align the refrigeration appliance,
adjust the front feet using a spirit level
and the spanner supplied.
Integrating the refrigeration
appliance in a run of kitchen
units
The refrigeration appliance can be
surrounded by kitchen units.
2
607
Top box
Refrigeration appliance
Housing unit
Wall
* The appliance depth is increased by
approx. 35mm for refrigeration
appliances with wall spacers fitted.
Installation
54
Risk of fire and damage due to
insufficient ventilation.
If the refrigeration appliance is not
ventilated sufficiently, the
compressor will run more frequently
and for longer periods. This will result
in increased energy consumption and
a higher operating temperature for
the compressor. This may, in turn,
cause damage to the compressor.
Please ensure that there is adequate
ventilation around the refrigeration
appliance.
It is essential to observe the required
ventilation gaps.
The ventilation gaps must not be
covered or blocked in any way.
They must also be regularly dusted.
The larger the ventilation gap, the
more economically the compressor
will work.
Install the refrigeration appliance next
to the kitchen unit.
- The appliance front must protrude in
front of furniture fronts by at least the
door depth. This enables the
appliance door to be opened and shut
without being obstructed.
- When installed next to a wall, a
distance of 25mm must be
maintained on the hinge side between
the wall and the refrigeration
appliance.
- To match the height of the rest of the
kitchen units, the refrigeration
appliance can be fitted with a suitable
top box.
A ventilation duct of at least 50mm
depth must be provided across the
whole width of the top box.
The ventilation gap under the ceiling
must be at least 300cm
2
to ensure
that warm air can escape without
obstruction.
Installation
*INSTALLATION*
55
Appliance dimensions
Installation dimensions/View from above
All dimensions are given in mm.
The refrigeration appliance will function correctly if the specified ventilation cross-
sections are kept clear.
* Dimensions without wall spacers fitted. Appliance depth is increased by 35mm with the
wall spacers supplied fitted.
Installation
*INSTALLATION*
56
Connections
All dimensions are given in mm.
a
View from the front
b
Mains connection cable, length = 2200mm
A longer mains connection cable is available to order from the Miele Customer
Service Department.
Installation
*INSTALLATION*
57
Electrical connection
The refrigeration appliance must only be
connected to an earthed socket using
the mains connection cable supplied.
The socket must be easily accessible
after the refrigeration appliance has
been installed. If the socket is not easily
accessible, ensure that a suitable
means of disconnection is provided on
the installation side for each pole.
Risk of fire from overheating.
Connecting the refrigeration
appliance to a multi-socket plug
adapter or to an extension lead can
overload the cable.
For safety reasons, do not use an
extension lead or multi-socket
adapter.
The electrical installation must comply
with VDE0100 requirements.
For safety reasons, we recommend
using a type residual current device
(RCD) in the assigned electrical
installation for connecting the
refrigeration appliance.
If the mains connection cable is
damaged, it must only be replaced with
a specific mains connection cable of the
same type (available from the Miele
Customer Service Department). For
safety reasons, such replacement may
only be carried out by a qualified
specialist or the Miele Customer
Service Department.
These operating instructions and the
data plate indicate the nominal power
consumption and the appropriate fuse
rating. Compare this information with
the data of the on-site electrical
connection. If in any doubt, consult a
qualified electrician.
Temporary or permanent operation on
an autonomous power supply system or
a power supply system that is not
synchronised with the mains power
supply (e.g. island networks, back-up
systems) is possible. A prerequisite for
operation is that the power supply
system complies with the specifications
of EN50160 or an equivalent standard.
The function and operation of the
protective measures provided in the
domestic electrical installation and in
this Miele product must also be
maintained in isolated operation or in
operation that is not synchronised with
the mains power supply, or these
measures must be replaced by
equivalent measures in the installation.
As described, for example, in the current
version of VDE-AR-E2510-2.
Connecting the refrigeration appliance
Insert the plug connector into the
socket at the back of the refrigeration
appliance.
Make sure that the plug connector has
clicked into position correctly.
Insert the plug of the refrigeration
appliance into the socket.
The refrigeration appliance is now
connected to the electricity supply.
EU Conformity declaration
58
Miele hereby declares that this freezer
complies with Directive 2014/53/EU.
The complete text of the EU declaration
of conformity is available from one of
the following internet addresses:
- Products, Download from
www.miele.ie
- For service, information, operating
instructions etc: go to https://
miele.co.uk/manuals and enter the
name of the product or the serial
number
Frequency band of
the WiFi module
2.4000GHz –
2.4835GHz
Maximum
transmitting
power of the WiFi
module
<100mW
UK Conformity declaration
59
Miele hereby declares that this freezer complies with UK Radio Equipment
Regulations 2017, as amended.
The complete text of the UK declaration of conformity is available from one of the
following internet addresses:
- Products, Download from www.miele.co.uk
- For service, information, operating instructions etc: go to https://miele.co.uk/
manuals and enter the name of the product or the serial number
Frequency band of the WiFi module 2.4000GHz – 2.4835GHz
Maximum transmitting power of the
WiFi module
<100mW
ThisStatement of Compliance confirms this Miele product fully complies with the
Product Security and Telecommunications Infrastructure (Security Requirements
for Relevant Connectable Products) Regulations 2023.
1) Household Appliance –
2)
Manufactured by: Miele & Cie KG,
Carl Miele Street 29, 33332 Gutersloh Germany
Imported by and contact point: Miele Company Ltd, Fairacres, Marcham Road,
Abingdon, Oxon, OX14 ITW Great Britain
The defined support period at the time of first supply is 10 years
3)
To report vulnerabilities and cybersecurity issues please contact: [email protected]4)
5) Signature
Name: Paul Wright
Company Position: Head of Technical Management
Date of signature: 19th March 2024
Place of signature:
Abingdon, Oxfordshire
Freezer - 120002, 120003, 320001, 320002
Refrigerator - 110001, 110002, 310001, 310002, 310003
Fridge-freezer - 130001, 130002, 130003, 130004,
330001, 330002
Wine unit - 210007, 310004, 330004
Copyrights and licences
60
For the purpose of operating and controlling the communication module, Miele
uses proprietary or third-party software that is not covered by open source
licensing terms. This software/these software components are protected by
copyright. The copyrights held by Miele and third parties must be respected.
Furthermore, the communication module integrated in the appliance contains
software components which are distributed under open source licence conditions.
The open source components contained in the appliance along with the
corresponding copyright notices, copies of the licensing terms valid at the time and
any further information can be accessed locally by IP via a web browser (http[s]://
<IP address>/Licenses). The liability and warranty arrangements for the open
source licences displayed in this location only apply in relation to the respective
rights holders.
United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW
Tel: 0330 160 6600, Internet: www.miele.co.uk, E-mail: [email protected]
Australia
Miele Australia Pty. Ltd.
ACN 005 635 398
ABN 96 005 635 398
Level 4, 141 Camberwell Road
Hawthorn East, VIC 3123
Tel: 1300 464 353
E-mail: [email protected]
Internet: www.miele.com.au
Miele Electrical Appliances Co. Ltd.
No. 82, Shimenyi Road, JingAn District
Shanghai, China, P.R.C
Post Code: 200040
Phone: +86 21 6157 3500
Fax: +86 21 6157 3511
E-mail: info@miele.cn
Internet: www.miele.cn
China Mainland
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road
Kowloon Bay, Hong Kong
Tel: (852) 2610 1025
Fax: (852) 3579 1404
E-mail:
Website: www.miele.hk
Hong Kong, China
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9, Mathura Road,
Jasola, New Delhi - 110025
E-mail: customercare@miele.in
Website: www.miele.in
India
Miele Ireland Ltd.
2024 Bianconi Avenue
Citywest Business Campus
Dublin 24
Tel: (01) 461 07 10
Fax: (01) 461 07 97
E-mail: [email protected]
Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana
Petroleum
Solaris Dutamas No. 1
Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Miele New Zealand Limited
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011
Tel: 0800 464 353
Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd.
29 Media Circle
#11-04 ALICE@Mediapolis
Singapore 138565
Tel: +65 6735 1191
Fax: +65 6735 1161
E-mail: [email protected]
Internet: www.miele.sg
Singapore
Miele (Pty) Ltd.
63 Peter Place, Bryanston 2194
Tel: (011) 875 9000
Fax: (011) 875 9035
E-mail: [email protected]
Internet: www.miele.co.za
South Africa
Miele Appliances Ltd.
Showroom 1, Eiffel 1 Building
P.O. Box 114782 - Dubai
Tel. +971 4 3044 999
Fax. +971 4 3418 852
800-MIELE (64353)
E-mail: [email protected]
Website: www.miele.ae
United Arab Emirates
Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Thailand
Miele Appliances Ltd.
BHIRAJ TOWER at EmQuartier
43rd Floor Unit 4301-4303
689 Sukhumvit Road
North Klongton Sub-District
Vadhana District
Bangkok 10110, Thailand
Sheikh Zayed Road, Umm Al Sheif
E-mail: customercare@miele.co.nz
P.O. Box 69434, Bryanston 2021
M.-Nr. 12 883 220 / 00en-GB
F 4001 ...
