MOTORCYCLE GROUND ANCHOR WITH TWIN
LAYER PROTECTION
MODEL NO: MCGA01D
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations
that may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator. It is the operator’s responsibility to secure the load.
9 Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Locate the anchor in a suitable area. Keep area clean and tidy and free from unrelated materials and ensure that there is adequate
lighting.
9 Ensurethattheoor/wallislevelandstrongenough(preferablyconcrete)toresistattemptstopulltheanchorfromit’sxings.
9 Keep children and unauthorised persons away from work area.
9 Inspect unit before each use. Check fasteners for tightness, replace any worn or damaged parts.
8 DO NOT attempt to use a unit that is damaged in any way.
8 DO NOT modify the unit in any way.
8 DO NOT use the unit for a purpose it is not designed to perform.
8 DO NOT use the unit if it is damaged.
2. INTRODUCTION
Heavy-dutyhardenedsteelgroundanchor.Thetwinlayerdesigngivesyouextrasecurityandpeaceofmind.Perfecttobeusedwith
heavy-duty chains and locks to provide a secure locking point for items such as motorcycles, bicycles, boats, caravans and trailers.
Boltsdowntoanysolidsurfaceandissuitableforindoorandoutdooruse.Includesanti-tamperbearingsandallxingsneededtoset
this up.
3. SPECIFICATION
Model No.: ............................................................ MCGA01D
Contents:Anchor,SecurityBolts(M10x70mm),BallBearings
Nett Weight: .................................................................. 4.1kg
4. INSTALLATION
4.1. Selectamountingsurfacethatissuitablystrongandatinordertosupporttheanticipatedloads.
4.2. DrillfourholestosuittheM10x70mmrawlbolts(supplied)ona110mmx110mmpitchsquare.
4.3. Oeruptheanchorplatetotheholesandinserttherawlboltswhenaligned.
4.4. Whentherawlboltsandanchorplatearermlyinplace,drivetheballbearing(supplied)intothehexsocketintheheadofthebolt.
WARNING!: Once the ball bearing is driven into the socket, it will not be possible to remove it, hence also the rawl bolt.
5. MAINTENANCE
5.1. Keeptheanchorcleanandwipeoanyoilorgrease.
5.2. Before each use check all parts. If any part of the anchor is damaged or defective, remove it from service and take the
necessary action to remedy the problem.
Refer to
instruction
manual
MCGA01DIssue:129/10/24
Original Language Version
© Jack Sealey Limited
.
MCGA01DIssue:129/10/24
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
