Model No.: HD983-R7Q
Item No.: U630181/U630182/U630183
Model No.:
HD984-R7Q
Item No.
: U630192/U630193
Model# HD983-R7Q 120V 60Hz 1200W
Model# HD984-R7Q 120V 60Hz 1200W
IMPORTANT INSTRUCTIONS
When using heater, basic precautions should always be followed to reduce the risk of fire, electric shock,
injury to persons, and hyperthermia, including the following:
1) Read all instructions before using this heater.
2) This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use
handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and keep them away from the sides
and rear.
3) Extreme caution is necessary when any heater is used by or near children or invalids and whenever the
heater is left operating and unattended.
4) Always unplug heater when not in use.
5) Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been
dropped or damaged in any manner. Discard heater, or return to authorized service facility for examination
and/or repair.
6) Do not use outdoors.
7) This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate
heater where it may fall into a bathtub or other water container.
8) Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not
route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped
over.
9) To disconnect heater, turn controls to off, then remove plug from outlet.
10) Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
11) To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft
surfaces, like a bed, where openings may become blocked.
12) A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or
flammable liquids are used or stored.
13) Use this heater only as described in this manual. Any other use not recommended by the manufacturer
may cause fire, electric shock, or injury to persons.
14) Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
15) SAVE THESE INSTRUCTIONS
16) Hyperthermia can result in death. Symptoms of hyperthermia include high body temperature, headache,
nausea, vomiting, tiredness, dizziness, fainting, and rapid pulse. If you begin to experience symptoms
related to hyperthermia, turn off the heater and seek medical attention.
17) To avoid excessive room temperatures which can cause hyperthermia: DO NOT leave product running
unattended in a confined space around infants, or individuals with reduced physical, sensory, or mental
capabilities.
PLEASE READ AND SAVE THESE INSTRUCTIONS
Thank you for choosing our heater please read this instruction carefully before operating and keep
it for future reference.
I. Product characteristics
♦ Our electrothermal warmer operates as follows: tubular element is taken as a heat source,
eicient and permanent heat conduction oil is taken as the medium, heat eliminates via
radiation fin, room temperature is increased via air circulation.
♦ Our electrothermal warmer has the following advantages: convenient, safe, beautiful, tranquil
operation, without electromagnetic disturbance etc. It is suitable for such locations as scientific
research rooms, hospitals, hotels, training practice houses, and bedrooms, etc. The warmer
keeps your room or oice more comfortable in cold seasons!
II. Product structure diagram
I I I I
ntn
I I
-
I
Ill
0
Ill o
- � Co
nol box
I
I
I I I I
I
Ill
�
�-
Ill. Operation instruction
Mounting:
Tce
ke out the heater and all the parts from the packing carton;
1. T
he heater should be unplugged during assembly or disassembly
2. For the convenience of assembly, turn the unit upside down.
3. Place the footplate on the top of both radiation fins; You'd better refer to the product structure diagram,
and check the wheels location between the first and last set of fins;
4. Fix the footplate on the heater with specified U type bolt and wing nut,tighten the screw;
5. Aer assembly is complete, turn the unit wheel side down for operation
Note: Do not operate without wheels attached.
lamp
Ⅰ
Ⅱ
Ⅲ
Level
1 2
automatic
Thermostat
Tip-over Switch
HD983-R7Q
HD984-R7Q
Thank you for purchasing this product! If you have any questions about
the product, such as missing pas, damaged products, product
assembling, and operation, please contact us via Amazon Message or
customer service number: 213-4467172 or 661-4358826.
IMPORTANT
Please call our customer service department r any consulting:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
DED PROOF OF PURCHASE IS REQUIRED FOR WARRANTY
SERVICE.
AVIS
uillez appeler le seice a la clientele pour toutes questions au:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
PREUVE D'ACHAT ORIGINALE REQUISE POUR SERVICE DE
GARANTIE.
IMPORNTE
S61o hay que llamar nuestro departamento de servicio
al cliente en caso de tener preguntas o inquietudes:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
SE REQUIERE PRUEBA DE COMPRA CON FECHA PARA
SERVICIO BAJO GARANT[A.
Address: ROWAN ELECTRIC APPLIANCE LLC
28407 Ascent Way, Santa Clarita, CA 91350
Phone: 213-4467172 or 661-4358826
