MATCO TOOLS
STOW, OH 44224-9978
APPLICATION GUIDE AND PARTS LIST
FOR COOLING SYSTEM ADAPTERS AND COOLING SYSTEM TOOLS
MODEL RPT103
Cooling System Pressure Tester
MODEL MPT100CG
Coolant Guard and Pressure Tester
CHANGE A COMPONENT WITH-
OUT DRAINING THE SYSTEM.
MODEL APC102
SHOP AIR POWERED
COOLING SYSTEM
PRESSURE TESTER
(Pump available
separately,
part number
MPT5001-1)
COOLING SYSTEM REFILLERS:
MODEL MCR103A
For use with positive fit adapters
MODEL MCR103U
No Adapters Necessary!
Better Evacuation!
Faster Fluid Transfer!
PAGE 2
MCR303T
Cooling System Refiller for Large Trucks
• New vacuum generator creates
higher vacuum more quickly
• Enlarged passages & valves help to
move coolant faster.
• Longer hose accommodates
height of trucks
• Larger diameter hose increases
fluid transfer speed
• Faster, more complete fill
MPT8001:
8 Piece Cooling System Adapter Set for Large Truck
This updated set includes the following adapters:
(back row, left to right) MPT10084P, MPT10025P, MPT0010, MPT10027P
(front row, left to right) A4505B, MPT10058P, MPT10054P, TA50.
MPT10084P is used to test 2015 and later
Kenworth trucks, models T270 and T370.
MPT10025P is used on some Volvo trucks
with a 45mm x 3mm threaded filler neck.
MPT0010 is used to test some 2007 and
later Freightliner, Kenworth and Peterbilt
trucks. MPT10027P is used to test Volvo
trucks with a 63mm x 3mm threaded filler
neck. A4505B is used to test trucks with a “B”
size 2 11/16” OD filler neck.
MPT10058P is used to test the Sprinter Van
( M e r c e d e s / F r e i g h t l i n e r / D o d g e ) .
MPT10054P is used to test Freightliners with
a 60mm x 3mm threaded filler neck. TA50 is
used to test Volvo and Mack trucks with a
48mm x 3mm threaded filler neck.
Plastic case available separately #OSMPT8001PB
See page 20
(back cover)
for parts diagram
PAGE 3
MPT17000:
An excellent display case including all
adapters necessary for testing passenger
vehicle cooling systems through 2015.
Designed for the Matco Distributor. Includes
17 adapters in a plastic display
case containing: MPT10128, MPT10138,
MPT0022, MPT0025, MPT0031, MPT0034,
MPT0036, MPT0041, MPT0044, MPT0046,
MPT0048, MPT0052, MPT0056, MPT0245,
MPT0345, MPT0445, A4503B.
Plastic case available separately as part
#0SMPT17000PB
MPT14000P:
Designed as an add-on for the RPT101/RPT102.
Carrying case comes with 14 composite cooling
system adapters. When added to the RPT101/RPT102
with its pump and 3 adapters, the combination will
pressure test the cooling systems of all modern cars
and light trucks through 2015.
Pump and adapters fit into the case as
shown on the right. Includes the
following 14 adapters:
MPT10022P, MPT10025P,
MPT10031P, MPT10034P,
MPT10041P, MPT10044P,
MPT10046P, MPT10048P,
MPT10052P, MPT10056P,
MPT10245P, MPT10345P,
MPT10445P, and A4503B.
MATCO KITS
Matco’s RPT102 shown stored
within the MPT14000P
Note: Plastic case available
separately as Part # 0SMPT17000PB
A
4
5
0
3
B
A
4
5
0
3
B
T
y
p
e
c
a
p
2
3
/
1
6
"
3
/
4
"
W
H
E
R
E
G
A
S
K
E
T
O
F
C
A
P
M
E
E
T
S
R
A
D
I
AT
O
R
N
E
C
K
(A
4
5
0
3
B
)
M
P
T1
0
0
5
6
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
AN
T
B
O
T
T
L
E
N
E
C
K
4
0
2
0
m
m
(
C
a
p
)
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
T
h
r
e
a
d
C
u
t
a
w
a
y
M
P
T1
0
0
4
8
P
M
P
T
1
0
0
2
2
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
G
A
S
K
E
T
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T1
0
2
4
5
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
G
A
S
K
E
T
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
W
H
E
R
E
F
L
A
T
G
AS
K
E
T
O
F
C
A
P
S
E
AL
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T
1
0
0
3
6
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
G
A
S
K
E
T
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T
1
0
0
2
5
P
M
P
T1
0
3
4
5
P
W
H
E
R
E
G
A
S
K
E
T
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
T
h
r
e
a
d
C
u
t
a
w
a
y
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
AL
S
O
N
C
O
O
L
A
NT
B
O
T
T
L
E
N
E
C
K
5
0
M
P
T
1
0
0
5
2
P
M
P
T
1
0
0
3
4
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
G
A
S
K
E
T
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T
1
0
0
3
1
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T
1
0
0
4
6
P
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
AL
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T1
0
1
2
8
3
2
m
m
M
P
T1
0
1
3
8
3
2
m
m
M
P
T1
0
4
4
5
P
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
T
h
r
e
a
d
C
u
t
a
w
a
y
T
h
r
e
a
d
C
u
t
a
w
a
y
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
M
P
T1
0
0
4
1
P
W
H
E
R
E
O
-
R
I
N
G
O
F
C
A
P
S
E
A
L
S
O
N
C
O
O
L
A
N
T
B
O
T
T
L
E
N
E
C
K
T
h
r
e
a
dC
u
t
a
w
a
y
M
P
T
1
0
0
4
4
P
T
h
e
e
a
s
ie
s
t
w
a
y
t
o
s
e
l
e
c
t t
h
e
c
o
r
r
e
c
t
a
d
a
p
t
e
r
is
by
c
o
m
p
a
r
i
ng
i
t
s
sh
a
p
e
t
o
t
he
s
ha
p
e
o
f t
he
c
a
p
r
e
mo
v
e
d
f
r
o
m
t
h
e
c
o
o
l
i
n
g
s
y
s
t
e
m.
I
n
m
o
st
c
a
s
e
s
(
e
x
c
e
p
t
t
h
e
A
4
5
0
3
B
)
t
h
e
y
w
i
l
l
m
atc
h c
l
os
e
l
y
.
I
n th
e
c
as
e
of th
e
M
P
T
1
0
0
2
5
P
,
M
P
T
1
0
0
3
4
P
, M
P
T
1
0
0
3
6
P
an
d
M
P
T
1
0
0
4
1
P
,
th
e
r
e
ar
e m
u
l
ti
pl
e
c
ap
s
h
a
p
e
s s
o
r
e
f
e
r
t
o
t
h
e
p
h
o
t
o
s
o
f
t
h
e
c
a
p
s
o
n
t
h
i
s
d
i
s
p
l
a
y
.
A
d
apt
er
s
l
ook
l
i
ke
c
aps
.
R
o
u
n
d
e
d
A
c
c
e
n
t
s
S
q
u
a
r
e
A
c
c
e
n
t
s
Laminated adapter
application sheet included with both
the MPT17000 and MTP14000P.
- FITS RIGHT INSIDE THE CASE -
PAGE 4
A
PPLICATION:
AUDI: models with male threads
on filler neck
P
ORSCHE
:
Boxster: 1997-2006
Cayman: 2006
9
11: 1999-current
SMART CAR
:
All Models: 2008-current
V
OLKSWAGEN
:
models with male
threads on filler neck of radiator or
expansion tank
APPLICATION:
FERRARI/MASERATI:
most models 2000-current
JEEP
: models with male threads
on filler neck (1990-1994)
RENAULT
: (1985-1997)
SAAB 900
: (1978-1993)
-900 Convertible (1994)
-9000 (1986-1998)
STERLING
: (1987-1991)
VOLVO
: most models with threaded
filler neck through 2008 (see page 17)
MPT0022
MPT1C023P
MPT0025
APPLICATION:
VOLKSWAGEN
:
models with female
threads on filler
neck 1990-1998
MPT0031
MPTC030
Thread Cutaway
WHERE O-RING OF CAP SEALS
ON COOLANT BOTTLE NECK
MPT10022P
MPT10025P
MPT10031P
57.7 mm
MPT0010
A
PPLICATION:
S
ome models of Buick, Cadillac,
C
hevrolet, Ford, Freightliner,
GMC, International, Infiniti, Isuzu,
Jaguar, Kenworth, Land Rover,
Lincoln, Mazda, Mercedes,
Mercury, Nissan, Oldsmobile,
P
eterbilt and Pontiac.
MPT1C035P
MPT0034
Thread Cutaway
WHERE GASKET OF CAP SEALS ON
COOLANT BOTTLE NECK
MPT1C047P
APPLICATION:
Some models of Cadillac,
Chevrolet, Daewoo, Ford,
Jaguar, Land Rover, Pontiac,
Saab, Saturn and Suzuki
MPT10034P
MPT1C026P
PAGE 5
APPLICATION:
AUDI
: Most models with
female threads on
filler neck 2000-current
B
ENTLEY
:
2006-current
L
AMBORGHINI
:
2006-current
PORSCHE:
Boxster 2007-2013
Cayenne 2003-2013
Cayman 2007-2011
Macan 2015-current
Panamera 2010-current
VW
: Most Models 1998
& newer
Thread
Cutaway
WHERE O-RING OF CAP SEALS
ON COOLANT BOTTLE NECK
MPT1C040P
MPT0036
MPT0041
MPT1C035P
MPT10036P
APPLICATION:
MERCEDES-BENZ:
with threaded filler
neck on expansion
tank (except M-class,
1998-2005)
(see page 15)
CHRYSLER:
Crossfire 2004-2008
MPT1C045P
MPT0044
WHERE O-RING OF CAP SEALS ON
COOLANT BOTTLE NECK
Thread Cutaway
MPT10044P
MPT0046
WHERE O-RING OF CAP SEALS ON
COOLANT BOTTLE NECK
MPT1C047P
MPT10046P
APPLICATION:
LEXUS
:
LS 2007-current
TOYOTA
:
Celica 2000-2005
Spyder (MR2) 2000-2005
Rav 4 2009-current
Hybrid Synergy Drive
Cooling System:
Prius 2004-current
Camry 2007-current
Highlander 2006-current
SCION:
XB, 2008-2015
MPT0048
MPT10048P
APPLICATION:
Some models of Buick, Cadillac,
Chevrolet, Ford, Freightliner,
GMC, Hummer, International,
I
nfiniti, Isuzu, Jaguar, Land Rover,
L
incoln, Mazda, Mercedes,
M
ercury, Nissan, Pontiac, Saab,
Saturn and Suzuki.
APPLICATION:
Some models of
Aston Martin,
Ford, Jaguar and
Mazda.
MPT1C049P
MPT10041P
PAGE 6
APPLICATION:
PORSCHE:
Boxster: 2006-2012
Caymen: 2006-2012
(Non-pressure relieving cap
located in luggage
compartment of vehicle).
MPT0060
WHERE GASKET OF CAP
MEETS RADIATOR NECK
44 mm
51.0 mm
27.5 mm
MPT0052
APPLICATION:
A
STON MARTIN
6.0 L, V-12 2015-current
F
ORD:
Escape 2013-current
F
-150 2015-current
Fiesta 2011-current
F
ocus 2012-current
Fusion 2013-current
Mustang V-8 2015-current
LAND ROVER
:
LR-2 2008-current
R
ange Rover
Evoque 2012-current
M
AZDA
:
Mazda 3 2004-current
V
OLVO
:
Most Models 2004-current
MPT1C053P
Thread Cutaway
WHERE O-RING OF CAP SEALS ON
COOLANT BOTTLE NECK
50
MPT10052P
MPT10052R
A
PPLICATION:
C
HEVROLET
:
C
obalt SS 2005-2007
(Supercharger
Cooling System)
Volt 2012- (Battery &
Electric Motor)
SATURN
:
Ion Redline 2004-2007
(Supercharger
Cooling System)
CADILLAC
:
STS, CTS, ATS 2006-2010
(Supercharger
Cooling System)
MPT1C057P
MPT0056
MPT10056P
Thread Cutaway
WHERE O-RING OF CAP SEALS ON
COOLANT BOTTLE NECK
MPT1C059P
MPT0058
MPT10058P
APPLICATION:
DODGE
:
Sprinter Van 2007-2010
FREIGHTLINER
Sprinter Van 2008-current
MERCEDES
Sprinter Van 2011-current
APPLICATION:
BMW:
Turbocharger Cooling
Systems (all)
MINI:
Cooper 2002-current
Comment: The MPT0063 and
MPT10063P seal with an o-ring just like
the cap from the system they test. In most
cases the MPT0025 and MPT10025P,
which seal on the top rim will adequately
seal such that pressure testing can be
accomplished.
MPT10063P
Thread Cutaway
WHERE O-RING OF CAP SEALS ON
COOLANT BOTTLE NECK
MPT0063
MPT1C026P
For low
o
ver-head
applications
PAGE 7
MPT10069P
MPT10067
MPT10070P
APRILIA
MOTORCYCLES
THREADED
ADAPTER
KTM
MOTORCYCLES
BAYONET STYLE
ADAPTER
KTM
MOTORCYCLES
THREADED
ADAPTER
WHERE GASKET
OF CAP SEALS ON
RADIATOR NECK
MPT10067R
45 mm
MPT10072P
APPLICATION:
ALFA ROMEO:
Some models with
threaded filler necks
FERRARI:
2015-current
FIAT:
Model 500: Some
versions with
threaded filler necks
DODGE
:
ProMaster
2015-current
MASERATI
:
Ghibli S Q4
2015-current
MPT1C026P
APPLICATION:
BENTLEY
Some Models
VOLKSWAGEN
Sharan (EU)
Phaeton 2004-2006 (US)
MPT10074P
Comment: The MPT10072P seals with an
o-ring just like the cap from the system it tests.
In most cases, the MPT0025 and MPT10025P,
which seal on the top rim will adequately seal
such that pressure testing can be accomplished.
PAGE 8
MPT10078P
APPLICATION:
PORSCHE
Boxster 2015-current
Cayman 2014-current
(
Found in luggage
c
ompartment)
MPT1C087P
MPT10086P
APPLICATION:
HYUNDAI
Tucson 2016-current
KIA
Sportage 2016-current
APPLICATION:
CHEVROLET DURAMAX
Engine 2017-current
MPT1C346P
APPLICATION:
BMW
:
most models 1988-2008
LAND ROVER
:
Some models with male
threads on filler neck
(see page 15)
Discovery 1999-2004
Range Rover 1996-2006
MPT0345
MPT10345P
MPT0245
MPTC246
Thread Cutaway
WHERE GASKET OF CAP SEALS ON
COOLANT BOTTLE NECK
MPT1C047P
MPT10245P
APPLICATION:
BMW
: models with
threaded filler necks
(up to 1987)
325: up to 1991
525: up to 1993
MERKUR SCORPIO
:
(1987-1989)
Comments:
Rubber gasket
seals on "shelf" inside
expansion tank neck
Comments:
Rubber gasket
seals on "shelf" inside
expansion tank neck
MPT0092
MPT10092P
“Image Coming Soon!”
APPLICATION:
BMW:
(most models, 2007-current)
3-Series 2006-current
5-Series 2005-current
6-Series 2005-current
X3 2009-current
X5 2009-current
X6 2008-current
MPT0445
WHERE GASKET OF CAP SEALS ON
COOLANT BOTTLE NECK
Thread Cutaway
MPT10445P
MPT1C446P
PAGE 9
Comments: The MPTC007/MPT0007/MPT10128 and the
MPTC008/MPT0008/MPT10138
have
applications too numerous to list here. See Application Guide pp 12-17. These adapter sets are
quite similar, but the MPTC007/MPT0007/MPT10128 is a deeper neck than the
MPTC008/MPT0008/MPT10138
. See drawings above, right.
Note: MPT10128 & MPT10138 are shaped to resemble caps from the system to be tested.
MPTC007
MPTC008
32 mm
32 mm
MPT10128
MPT0007R
MPT10138
ROUNDED
EARS
SQUARE
EARS
FORKLIFTS - MOTORCYCLES - TOYOTA SIENNA VAN
Remote adapter allows pressure pump or vacuum refiller
to be installed in various low overhead applications.
Most motorcycles,
including the
Harley Davidson
liquid cooled
models, use this
configuration
1 5/8"
3/4"
WHERE GASKET OF CAP MEETS
RADIATOR NECK
APPLICATION:
Most passenger vehicles through
the mid 1980’s have this radiator
neck and many still do today.
This is the configuration onto
which the pump attaches directly.
For Necks 1” deep use 1/4”
thick MT0006 spacer washer
to compensate.
MT0204
MT0004
PAGE 10
APPLICATION:
MACK TRUCKS:
2008 and later with
48mm x 3mm threads
on filler neck
VOLVO:
Large Trucks with
48mm x 3mm male
thread on filler neck
TA50
WHERE GASKET OF CAP SEALS ON
COOLANT BOTTLE NECK
MPT0027
63
3
APPLICATION:
VOLVO
:
Large Trucks with
63mm x 3mm
thread on filler neck
MPT0054
MPT1C023P
APPLICATION:
FREIGHTLINER
:
Trucks with
60mm x 3mm male
thread on filler neck
MPT10027P
MPT10022P
MPT10054P
LARGE TRUCKS / BUSES / HEAVY EQUIPMENT
PAGE 11
LARGE TRUCKS / BUSES / HEAVY EQUIPMENT / INDUSTRAL
MPT0450
(Two Adapter Set)
2 3/16"
3/4"
WHERE GASKET OF CAP MEETS
RADIATOR NECK (A4503B)
WHERE GASKET OF CAP MEETS
RADIATOR NECK (A4505B)
PART #
A4503B
: GM adapter kit
tests pressure
on "closed cooling systems" on
GM 2.5L "X" body cars and
1.8L "J" body cars
MPT0450
Type cap
A4503B
Type cap
PART #
MPT0450
:
Truck adapter kit for trucks with
"B" size 2 11/16" O.D. filler neck
A4503B
A4504B
(Cap Adapter
Only)
A4505B
(Cooling System
Adapter Only)
MPT10076
APPLICATION:
LIEBHERR CRANE:
Some models
VAN HOOL BUS:
Some models
Note: Cap and
adapter have 3 tabs
MPT10084P
APPLICATION:
KENWORTH
:
2015-current
T270
T370
APPLICATION:
INDUSTRIAL
APPLICATIONS:
With a 84mm neck
MPT0090
Note:
Cap and adapter
have 3 tabs
PAGE 12
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
ACURA
M
odels with 16mm deep MPT0007/MPT10128 MPTC007
filler neck, see page 9
M
odels with 9.5mm deep MPT0008/MPT10138 MPTC008
filler neck, see page 9
ALFA ROMEO
4C
2014-current MPT10072P* MPT1C026P
G
iulia
2
016-current MPT10072P* MPT1C026P
G
iulietta
2014-current MPT10072P* MPT1C026P
Mito
2014-current MPT10072P* MPT1C026P
ASTON MARTIN
6.0 L, V-12
2015-current MPT0052/MPT10052P MPT1C053P
Various Models
2005-current MPT0046/MPT10046P MPT1C047P
Vantage V-8
2013-current MPT0046/MPT10046P MPT1C047P
AUDI
Models with male threads
on filler neck of exp. tank MPT0022/MPT10022P MPTC023/MPT1C023P
Models with female threads
on filler neck of exp. tank MPT0041/MPT10041P MPTC040/MPT1C040P
BLUEBIRD BUS
Late model Thomas
Built buses MPT0036/MPT10036P MPTC037/MPT1C035P
BMW
Most models with threaded
filler neck
Up to 1987 MPT0245/MPT10245P MPTC246/MPT1C047P
1988-2008 MPT0345/MPT10345P MPTC346/MPT1C346P
2009-current MPT0445/MPT10445P MPTC446/MPT1C446P
Model 325
1988-1991 MPT0245/MPT10245P MPTC246/MPT1C047P
Model 535
1989-1993 MPT0245/MPT10245P MPTC246/MPT1C047P
1 Series
2008-current MPT0445/MPT10445P MPTC446/MPT1C446P
3 Series
1990-2006 MPT0345/MPT10345P MPTC346/MPT1C346P
2006-current MPT0445/MPT10445P MPTC446/MPT1C446P
5 Series
1989-2004 MPT0345/MPT10345P MPTC346/MPT1C346P
2005-current MPT0445/MPT10445P MPTC446/MPT1C446P
Turbocharger Cooling Sys (all) MPT0063/MPT10063P
▲
MPT1C026P
6 Series
2004-current MPT0445/MPT10445P MPTC446/MPT1C446P
Turbocharger Cooling Sys (all) MPT0063/MPT10063P
▲
MPT1C026P
7 Series
1994-2008 MPT0345/MPT10345P MPTC346/MPT1C346P
2008-current MPT0445/MPT10445P MPTC446/MPT1C446P
Turbocharger Cooling Sys (all) MPT0063/MPT10063P
▲
MPT1C026P
X1
2009-2011 MPT0345/MPT10345P MPTC346/MPT1C346P
X3
2004 - 7/2009- MPT0345/MPT10345P MPTC346/MPT1C346P
7/2009-current MPT0445/MPT10445P MPTC446/MPT1C446P
Make/Model/Year
Cooling
System
Adapter
Cap
Adapter
Make/Model/Year
Cooling
System
Adapter
Cap
Adapter
▲ MPT0063/MPT10063P seals the same way the radiator cap
seals but the MPT0025/MPT10025P will work in most applications.
**If MPT0036/MPT10036 “Stem” with O-ring does not fit,
MPT0010 may be required.
*MPT0025/MPT10025P may also work.
COOLING SYSTEM ADAPTERS
BMW
X5
2000-2008 MPT0345/MPT10345P MPTC346/MPT1C346P
2
009-current MPT0445/MPT10445P MPTC446/MPT1C446P
Turbocharger Cooling Sys (all) M
PT0063/MPT10063P
▲
M
PT1C026P
X6
2
008-current MPT0445/MPT10445P MPTC446/MPT1C446P
T
urbochargerCooling Sys (all)
MPT0063/MPT10063P
▲
MPT1C026P
Z
3
2002 MPT0345/MPT10345P MPTC346/MPT1C346P
Z4
2
003-2008 MPT0345/MPT10345P MPTC346/MPT1C346P
2009-current MPT0445/MPT10445P MPTC446/MPT1C446P
Z8
2003 MPT0345/MPT10345P MPTC346/MPT1C346P
BUICK
All Models w/male threads on
filler neck except as noted below MPT0036/MPT10036P MPTC037/MPT1C035P
Roadmaster
1994-1996 MPT0036/MPT10036P** MPTC010/MPT1C035P
Skyhawk
1982-1987 1.8L & 2.0L A4503B
Skylark
1982-1988 2.5L A4503B
1992-1998 MPT0036/MPT10036P** MPTC010/MPT1C035P
Somerset
1985-1987 2.5L A4503B
CADILLAC
All Models w/male threads on
filler neck except as noted below MPT0036/MPT10036P MPTC037/MPT1C035P
Catera
1997- 2001 MPT0034/MPT10034P MPTC246/MPT1C047P
Fleetwood
1994-1996 MPT0036/MPT10036P** MPTC010/MPT1C035P
Seville
1998-2004 MPT0036/MPT10036P** MPTC037/MPT1C035P
STS,CTS, ATS
2005-2010
Engine Cooling System MPT0036/MPT10036P MPTC037/MPT1C035P
Supercharger Cooling System MPT0056/MPT10056P MPTC057
CHEVROLET
All Models w/ male threads on
filler neck except as noted below MPT0036/MPT10036P MPTC037/MPT1C035P
Aveo
2004-2011 MPT0034/MPT10034P MPTC246/MPT1C047P
Beretta
1992-1996 MPT0010/MPT10036P** MPTC010/MPT1C035P
Caprice
1994-1996
MPT0010/MPT10036P** MPTC010/MPT1C035P
Cavalier
1995-1998
MPT0010/MPT10036P** MPTC010/MPT1C035P
PAGE 13
COOLING SYSTEM ADAPTERS
CHRYSLER/DODGE/EAGLE/PLYMOUTH
S
printer Van
2007-2010 MPT0058/MPT10058P MPTC059
S
tealth
1991-1996 MPT0007/MPT10128 MPTC007
Stratus (3.0 liter only)
2
001-2006 MPTOO08/MPT10138 MPTC008
Summit
1
989-1992 MPT0007/MPT10128 MPTC007
1992-1996 MPTOO08/MPT10138 MPTC008
T
alon
1990-1998 MPT0007/MPT10128 MPTC007
DAEWOO
All
1999-2002 MPT0034/MPT10034P MPTC246/MPT1C047P
FERRARI
Most Models
2000-current MPT0025/MPT10025P MPTC026/MPT1C026P
FIAT
500
2015-current MPT10072* MPT1C026P
FORD/LINCOLN/MERCURY
All Models w/male threads
on filler neck except as
noted below MPT0036/MPT10036P** MPTC010/MPT1C035P
Aspire
1994-1997 MPT0007/MPT10128 MPTC007
C-Max
2013-current MPT0052/MPT10052P MPTC053/MPT1C053P
Contour/Mystique
1995-1997 MPT0034/MPT10034P MPTC246/MPT1C047P
1998-2000 MPT0046/MPT10046P MPTC047/MPT1C047P
Cougar
1989-1992 MPT0007/MPT10128 MPTC007
1993-1997 V6 MPT0007/MPT10128 MPTC007
1993-1997 V8 MPT0036/MPT10036P** MPTC010/MPT1C035P
Edge
2015-current MPT0052/MPT10052P MPTC053/MPT1C053P
Escape
2001-2012 MPT0046/MPT10046P MPTC047/MPT1C047P
2013-current MPT0052/MPT10052P MPTC053/MPT1C053P
Escort/Tracer
1991-2012 MPT0007/MPT10128 MPTC007
Explorer/Mountaineer/Aviator
1995-2002 MPT0007/MPT10128 MPTC007
2002-current MPT0036/MPT10036P** MPTC010/MPT1C035P
F-150 Pickup
2015-current MPT0052/MPT10052P MPTC053/MPT1C053P
Festiva
1988-1993 MPT0007/MPT10128 MPTC007
Fiesta
2011-current MPT0052/MPT10052P MPTC053/MPT1C053P
Focus
2000-2004 MPT0034/MPT10034P MPTC246/MPT1C047P
2005-2007 MPT0036/MPT10036P** MPTC010/MPT1C035P
2008-2011 MPT0007/MPT10128 MPTC007
2012-current MPT0052/MPT10052P MPTC053/MPT1C053P
Fusion/MKZ
2013-current MPT0052/MPT10052P MPTC053/MPT1C053P
LS
2002-2006 MPT0034/MPT10034P MPTC246/MPT1C047P
MKC
2015-current MPT0052/MPT10052P MPTC053/MPT1C053P
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
CHEVROLET - CONTINUED
Citation
1
982-1985 2.5L A4503B
Cobalt
2
005-2010
Engine Cooling System MPT0036/MPT10036P MPTC037/MPT1C035P
S
upercharger Cooling System MPT0056/MPT10056P MPTC057/MPT1C057P
Corsica
1992-1996 MPT0036/MPT10036P** MPTC010/MPT1C035P
D
uramax (L5P diesel) engine
2017-current MPT0092/MPT10092P
▲
2
017-current MPT0036/MPT10036P
▲▲
M
PT1C035P
Impala
1994-1996 MPT0036/MPT10036P** MPTC010/MPT1C035P
2004-current MPT0036/MPT10036P MPTC037/MPT1C035P
Lumina
1990-1992 A4503B
Malibu
1997-1998 MPT0010/MPT10036P** MPTC010/ MPT1C035P
1999-current MPT0036/MPT10036P MPTC037/MPT1C035P
Metro
1998-2001 MPT0008/MPT10138 MPTC008
Nova
1985-1988 MPT0007/MPT10128 MPTC007
Prizm
1998-2002 MPTOO08/MPT10138 MPTC008
Spectrum
1985-1989 MPT0007/MPT10128 MPTC007
Sprint
1985-1988 MPT0007/MPT10128 MPTC007
Tracker
1998-2004 MPTOO08/MPT10138 MPTC008
Volt
2012-current
Electric Motor MPT0056/MPT10056P MPTC057/MPT1C057P
Battery System MPT0056/MPT10056P MPTC057/MPT1C057P
Gasoline Engine MPT0036/MPT10036P MPTC037/MPT1C035P
CHRYSLER/DODGE/EAGLE/PLYMOUTH
200
2015-current MPT0036/MPT10036P MPTC037/MPT1C035P
2000GTX
1989-90 MPT0007/MPT10128 MPTC007
Avenger
1995-1999 MPT0007/MPT10128 MPTC007
Colt
1984-1993 MPT0007/MPT10128 MPTC007
1992-1994 (some models) MPTOO08/MPT10138 MPTC008
Conquest
1984-1989 MPT0007/MPT10128 MPTC007
Crossfire
2004-2008 MPT0044/MPT10044P MPTC045/MPT1C045P
Dart
2013-2016 MPT0036/MPT10036P MPTC037/MPT1C035P
Laser/Talon
1990-1998 MPT0007/MPT10128 MPTC007
Pacifica
2017-current MPT0036/MPT10036P MPT1C037P
Promaster
2014-current MPT10072P* MPT1C026P
RAM 50 Pickup
1987-1993 MPT0007/MPT10128 MPTC007
Ram Series Pick-up
2013-(6cyl., Diesel) MPT0036/MPT10036P MPTC037/MPT1C035P
Sebring
2003-20056c3.OL & 4c2.4L MPTOO08/MPT10138 MPTC008
2001,2002,2006- none MT0204
*MPT0025/MPT10025P may also work.
▲
Non pressure relieving
▲▲
Pressure relieving
**If MPT0036/MPT10036 “Stem” with O-ring
does not fit, MPT0010 may be required.
PAGE 14
COOLING SYSTEM ADAPTERS
FORD/LINCOLN/MERCURY - CONTINUED
Mustang
V8, 1996-current MPT0036/MPT10036P** MPTC010/MPT1C035P
V
6, 1997-2004 MPT0007/MPT10128 MPTC007
V6, 2005-current MPT0036/MPT10036P** MPTC010/MPT1C035P
V8, 2015-current MPT0052/MPT10052P MPTC053/MPT1C053P
P
robe
1989-1997 MPT0007/MPT10128 MPTC007
Ranger Pickup
1995-(non threaded neck) MPT0007/MPT10128 MPTC007
2
002-current MPT0036/MPT10036P** MPTC010/MPT1C035P
Super Duty Pick-up
expansion tank
2012-current MPT0036/MPT10036P** MPTC037/MPT1C035P
Tempo/Topaz
1992-1994 MPT0007/MPT10128 MPTC007
Thunderbird
1989-1993 (All) MPT0007/MPT10128 MPTC007
1994-1997 (V6) MPT0007/MPT10128 MPTC007
1994-1997 (V8) MPT0036/MPT10036P** MPTC010/MPT1C035P
2002-2004 (V8) MPT0036/MPT10036P** MPTC010/MPT1C035P
Transit Connect
2010-2012 MPT0034/MPT10034P MPTC246/MPT1C047P
2013-current MPT0052/MPT10052P MPTC053/MPT1C053P
Villager
1993-2002 MPT0007/MPT10128 MPTC007
Windstar
1995-2000 MPT0007/MPT10128 MPTC007
2000-2003 MPT00036/MPT10036P MPTC010/MPT1C035P
ZX2
2001-2003 MPT0007/MPT10128 MPTC007
FREIGHTLINER
Trucks with:
60mm x 3mm male thread MPT0054/MPT10054P
52mm x 2.5mm male thread
2007-Cascadia MPT0010 MPTC010/MPT1C035P
2002- Century, Columbia MPTOO36/MPT10036P MPTC037/MPT1C035P
GEO
Metro
1989-1994 MPT0007/MPT10128 MPTC007
1995-1998 MPTOO08/MPT10138 MPTC008
Prizm
1989-1992 MPT0007/MPT10128 MPTC007
1993-2002 MPTOO08/MPT10138 MPTC008
Storm
1990-1993 MPT0007/MPT10128 MPTC007
Tracker
1989-1993 MPT0007/MPT10128 MPTC007
1994-2004 MPTOO08/MPT10138 MPTC008
GMC
All Models with male
threads on filler neck MPT0036/MPT10036P MPTC037/MPT1C035P
HONDA
Models with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Models with 9.5mm deep
filler neck, see page 9 MPTOO08/MPT10138 MPTC008
HUMMER
All models with male
t
hreads on filler neck MPT0036/MPT10036P MPTC037/MPT1C035P
HYUNDAI
A
ll models
1987-current MPT0007/MPT10128 MPTC007
Tucson
2
016-current MPT10086P MPT1C087P
INDUSTRIAL
Various industrial applications MPT10090
(see page 11 for specs)
INTERNATIONAL
466 Engine with male
threads on filler neck
1994-1998 MPTOO10 MPTC010/MPT1C035P
INFINITI
All Models with Non-Threaded
Small Cooling System Caps
(see page 9) MPT0007/MPT10128 MPTC007
QX30
2017-current MPT0044/MPT10044P MPT1C045P
QX56
2004-2009 MPT0036/MPT10036P** MPTC010/MPT1C035P
2010-current MPT007/MPT10128 MPTC007
ISUZU
All models except as noted below
1985-2009 MPT0007/MPT10128 MPTC007
Amigo
1999-2000 (L-4 only) MPTOO08/MPT10138 MPTC008
Ascender
2002-2009 MPT0036/MPT10036P MPTC037/MPT1C035P
i280
2006 MPT0036/MPT10036P MPTC037/MPT1C035P
i290
2007-2008 MPT0036/MPT10036P MPTC037/MPT1C035P
i350
2006 MPT0036/MPT10036P MPTC037/MPT1C035P
i370
2007-2008 MPT0036/MPT10036P MPTC037/MPT1C035P
Oasis
1996-1999 MPTOO08/MPT10138 MPTC008
Rodeo
1998-2003 (L-4 only) MPTOO08/MPT10138 MPTC008
JAGUAR
All Models with male
threads on filler neck
1990-1994 MPTOO34/MPT10034P MPTC246/MPT1C047P
F-Type
2013-current MPT0036/MPT10036P** MPTC037/MPT1C035P
XE
2015-current MPT0010 MPT1C035P
XF
2009-current MPT0036/MPT10036P** MPTC037/MPT1C035P
XJ
2009-current MPT0010 MPT1C035P
XJ8
1998-2003 MPTOO46/MPT10046P MPTC047/MPT1C047P
2004-2009 MPT0036/MPT10036P** MPTC037/MPT1C035P
XK8
1997-2004, 2006 MPTOO46/MPT10046P MPTC047/MPT1C047P
S-Type
2002-2008 MPT0036/MPT10036P** MPTC037/MPT1C035P
X-Type
2002-2009 MPTOO34/MPT10034P MPTC246/MPT1C047P
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
**If MPT0036/MPT10036 “Stem” with O-ring does not fit,
MPT0010 may be required.
PAGE 15
COOLING SYSTEM ADAPTERS
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
**If MPT0036/MPT10036 “Stem” with O-ring does not fit,
MPT0010 may be required.
▲
MPT0063/MPT10063P seals the same way the radiator cap
seals but the MPT0025/MPT10025P will work in most applications
JEEP
Models with male threads
o
n filler neck
1987-1990 MPT0025/MPT10025P MPTC026/MPT1C026P
Cherokee
2
014-current MPT0036/MPT10036P MPTC037/MPT1C035P
Renegade
2015-current MPT0036/MPT10036P MPTC037/MPT1C035P
JOHN DEERE TRACTORS
Most model #’s over 3000
w
ith 48mm O.D. male
threads on filler neck MPT0022/MPT10022P MPTC023/MPT1C023P
Most model #’s over 3000
with 52mm O.D. male
threads on filler neck N/A - consult factory N/A
KENWORTH TRUCKS
Some Models 2007-current MPT0010 MPTC010/MPT1C035P
T270, T370
2015-current MPT10084P
KIA
Models with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Sportage
2016-current MPT10086 MPT1C087P
LAND ROVER
Defender
1993-1995, 1997
Discovery
1998 MPT0034/MPT10034P MPTC246/MPT1C047P
1999-2004 MPT0345/MPT10345P MPTC346/MPT1C346P
Freelander
2002-current MPT0025/MPT10025P MPTC026/MPT1C026P
LR2
2008-current MPT0052/MPT10052P MPTC053/MPT1C053P
LR3
2005-2009 MPT0036/MPT10036P MPTC010/MPT1C035P
LR4
2010-current MPT0036/MPT10036P MPTC010/MPT1C035P
Range Rover
1988-1994 MPT0034/MPT10034P MPTC246/MPT1C047P
1995-2005 MPT0345/MPT10345P MPTC346/MPT1C346P
2006-current MPT0036/MPT10036P MPTC010/MPT1C035P
Range Rover Evoque
2012-current MPT0052/MPT10052P MPTC053/MPT1C053P
LEXUS
Models with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Models with 9.5mm deep
filler neck, see page 9 MPTOO08/MPT10138 MPTC008
GS 460
2008-current MPT0048/MPT10048P MPTC049/MPT1C049P
HS 250h
2010-current MPT0048/MPT10048P MPTC049/MPT1C049P
IS F
2008-current MPT0048/MPT10048P MPTC049/MPT1C049P
LS
2007-current MPT0048/MPT10048P MPTC049/MPT1C049P
NX200T
2015-current MPT0048/MPT10048P MPTC049/MPT1C049P
LIEBHERR CRANE
S
ome Models MPT10076
MACK TRUCK
Late models with male
threads on filler neck TA50/MPT10022P MPT1C023P
MASERATI
Most Models
2000-current MPT0025/MPT10025P MPTC026/MPT1C026P
G
hibli S Q4
2015-current MPT10072P* MPT1C026P
MAZDA
Models with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Models with 9.5mm deep
filler neck, see page 9 MPTOO08/MPT10138 MPTC008
Models with Threaded Caps:
B 2300 Pickup
1994-1997 none MT0204
2001-2009 MPT0036/MPT10036P MPTC037/MPT1C035P
Tribute
2001-2011 MPT0046/MPT10046P MPTC047/MPT1C047P
Mazda 3
2004-current MPT0052/MPT10052P MPTC053/MPT1C053P
Mazda 6
2003-current MPT0036/MPT10036P MPTC037/MPT1C035P
MERCEDES
Models with threaded neck
except as noted MPT0044/MPT10044P MPTC045/MPT1C045P
M-Class with threaded neck
1998-2005 MPT0036/MPT10036P MPTC037/MPT1C035P
M-Class
2006-current MPT0044/MPT10044P MPTC045/MPT1C045P
Sprinter Van
2011-current MPT0058/MPT10058P MPT0059/MPT1C059P
MERKUR
Scorpio
1987-1989 MPT0245/MPT10245P MPTC246/MPT1C047P
MINI
Cooper S Model
2002-current MPT0063/MPT10063P
▲
MPT1C026P
MITSUBISHI
Models with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Models with 9.5mm deep
filler neck, see page 9 MPTOO08/MPT10138 MPTC008
NISSAN
All models with non-threaded
small cooling system caps
1987-current MPT0007/MPT10128 MPTC007
Armada/Titan
2004-2009 MPT0036/MPT10036P MPTC010/MPT1C035P
2010-current MPT0007/MPT10128 MPT1C007
*MPT0025/MPT10025P may also work.
PAGE 16
COOLING SYSTEM ADAPTERS
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
OLDSMOBILE
Achieva
1
992-1998 MPT0036/MPT10036P** MPTC010/MPT1C035P
Alero
1
999-2004 MPT0036/MPT10036P MPTC037/MPT1C035P
Aurora
1
995-1999 MPT0036/MPT10036P** MPTC010/MPT1C035P
Bravada
2002-2004 MPT0036/MPT10036P MPTC037/MPT1C035P
Cutlass
1997-1998 MPT0036/MPT10036P** MPTC010/MPT1C035P
1999 MPT0036/MPT10036P MPTC037/MPT1C035P
Intrigue
1999 MPT0036/MPT10036P** MPTC010/MPT1C035P
2000-2002 MPT0036/MPT10036P MPTC037/MPT1C035P
PETERBILT TRUCKS
Some Models 2007-current MPT0010 MPTC010/MPT1C035P
PONTIAC
Fiero
1984-1988 A4503B
Firebird
1999-2002 MPT0036/MPT10036P MPTC037/MPT1C035P
G3
2009-2010 MPT0034/MPT10034P MPTC246/MPT1C047P
G5
2007-2010 MPT0036/MPT10036P MPTC037/MPT1C035P
G6
2005-2010 MPT0036/MPT10036P MPTC037/MPT1C035P
Grand Am
1985-1988 A4503B
1992-1998 MPT0010/MPT10036P MPTC010/MPT1C035P
1999-2005 MPT0036/MPT10036P MPTC037/MPT1C035P
Grand Prix
2004-2008 MPT0036/MPT10036P MPTC037/MPT1C035P
GTO
2004-2006 MPT0036/MPT10036P MPTC037/MPT1C035P
Le Mans
1988-1993 MPT0034/MPT10034P MPTC246/MPT1C047P
Montana
1999-2006 none MT0204
2007-2009 MPT0036/MPT10036P MPTC037/MPT1C035P
Optima
1988-1991 MPT0036/MPT10036P MPTC010/MPT1C035P
Solstice
2006-2009 MPT0036/MPT10036P MPTC037/MPT1C035P
Sunbird
1982-1992 A4503B
Sunburst
1985-1988 MPT0007/MPT10128 MPTC007
Sunfire
1995-1998 MPT0010/MPT10036P MPTC010/MPT1C035P
1999-2005 MPT0036/MPT10036P MPTC037/MPT1C035P
Vibe
2003-2010 MPTOO08/MPT10138 MPTC008
PORSCHE
9
11
1999-current MPT0022/MPT10022P MPTC023/MPT1C023P
Boxster/Cayman
(
3 prong access cap)
2007-2013 MPT0060
Boxster
1997-2006 MPT0022/MPT10022P MPTC023/MPT1C023P
2
007-2013 MPT0041/MPT10041P MPTC040/MPT1C040P
2015-current MPT10078P
(in luggage compartment)
Cayenne
2003-2013 MPT0041/MPT10041P MPTC040/MPT1C040P
Cayman
2006 MPT0022/MPT10022P MPTC023/MPT1C023P
2007-2011 MPT0041/MPT10041P MPTC040/MPT1C040P
2014-current MPT10078P
(in luggage compartment)
Macan
2015-current MPT0041/MPT10041P MPTC0040/MPT1C040P
Panamera
2010-current MPT0041/MPT10041P MPTC040/MPT10041P
RENAULT
All models
1985-1987 MPT0025/MPT10025P MPTC026/MPT1C026P
SAAB
900
1978-1993 MPT0025/MPT10025P MPTC026/MPT1C026P
1994-1998 MPT0034/MPT10034P MPTC246/MPT1C047P
900 Convertible
1994 MPT0025/MPT10025P MPTC026/MPT1C026P
9000
1986-1998 MPT0025/MPT10025P MPTC026/MPT1C026P
9-3
1999-2003 MPT0034/MPT10034P MPTC246/MPT1C047P
2004-2011 MPT0036/MPT10036P MPTC037/MPT1C035P
9-5
1999-2008 MPT0034/MPT10034P MPTC246/MPT1C047P
9-7 X
2005-2009 MPT0036/MPT10036P MPTC037/MPT1C035P
SATURN
All models except as below
1990-1998 MPT0010/MPT10036P MPTC010/MPT1C035P
1999-2010 MPT0036/MPT10036P MPTC037/MPT1C035P
L - Series
2000-2005 MPT0034/MPT10034P MPTC246/MPT1C047P
Vue
2002 MPT0034/MPT10034P MPTC246/MPT1C047P
2003-2009 MPT0036/MPT10036P MPTC037/MPT1C035P
Ion Redline 2004-2007
Engine Cooling System MPT0036/MPT10036P MPTC037/MPT1C035P
Supercharger
Cooling System MPT0056/MPT10056P MPTC057/MPT1C057P
SCION
All models
2004-current MPTOO08/MPT10138 MPTC008
XB
2008-current MPT0048/MPT10048P MPTC049/MPT1C049P
SMART CAR
All models
2008-current MPT0022/MPT10022P MPTC023/MPT1C023P
**If MPT0036/MPT10036 “Stem” with O-ring
does not fit, MPT0010 may be required.
COOLING SYSTEM ADAPTERS
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
Make/Model/Year
Cooling System
Adapter
Cap
Adapter
VOLKSWAGEN
B
eetle
1
998-current MPT0041/MPT10041P MPTC040/MPT1C040P
C
C
2009-2019 MPT0041/MPT10041P MPTC040/MPT1C040P
C
abrio
1
995-2002 MPT0031/MPT10031P MPTC030
C
orrado
1
990-1994 MPT0031/MPT10031P MPTC030
Eurovan
1993-2003 MPT0031/MPT10031P MPTC030
Golf
1985-1990 MPT0022/MPT10022P MPTC023/MPT1C023P
1991-1999 MPT0031/MPT10031P MPTC030
2000-current MPT0041/MPT10041P MPTC040/MPT1C040P
GTI
1985-1990 MPT0022/MPT10022P MPTC023/MPT1C023P
1991-1999 MPT0031/MPT10031P MPTC030
2000-current MPT0041/MPT10041P MPTC040/MPT1C040P
Jetta
1980-1990 MPT0022/MPT10022P MPTC023/MPT1C023P
1991-1999 MPT0031/MPT10031P MPTC030
1999-current MPT0041/MPT10041P MPTC040/MPT1C040P
Passat
1990-1997 MPT0031/MPT10031P MPTC030
1998-current MPT0041/MPT10041P MPTC040/MPT1C040P
Phaeton
2002-2016 MPT10074P MPT1C023P
Toureg
2004-current MPT0041/MPT10041P MPTC040/MPT1C023P
VOLVO
All with threaded neck except
large trucks and as specified
below MPT0025/MPT10025P MPTC026/MPT1C026P
C30
2008-current MPT0052/MPT10052P MPTC053/MPT1C053P
C70
2008-current MPT0052/MPT10052P MPTC053/MPT1C053P
FH
2012-current MPT0025/MPT10025P MPTC026/MPT1C026P
FM
2010-current MPT0025/MPT10025P MPTC026/MPT1C026P
S40
2004-2011 MPT0052/MPT10052P MPTC053/MPT1C053P
S80
2004-current MPT0052/MPT10052P MPTC053/MPT1C053P
V50
2005-2011 MPT0052/MPT10052P MPTC053/MPT1C053P
V60
2014-current MPT0052/MPT10052P MPTC053/MPT1C053P
V70
2008-2010 MPT0052/MPT10052P MPTC053/MPT1C053P
XC60
2010-current MPT0052/MPT10052P MPTC053/MPT1C053P
XC70
2008-current MPT0052/MPT10052P MPTC053/MPT1C053P
Volvo Large Trucks with:
• 48mm x 3mm thread TA50/MPT10022P MPT1C023P
• 63mm x 3mm thread MPT0027/MPT10027P
STERLING
A
ll models
1
987-1991 MPT0025/MPT10025P MPTC026
SUBARU
M
odels with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Models with 9.5mm deep
f
iller neck, see page 9 MPTOO08/MPT10138 MPTC008
SUZUKI
M
odels with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
M
odels with 9.5mm deep
filler neck, see page 9 MPTOO08/MPT10138 MPTC008
Forenza
2004-2008 MPT0034/MPT10034P MPTC246/MPT1C047P
Reno
2005-2008 MPT0034/MPT10034P MPTC246/MPT1C047P
Verona
2004-2006 MPTOO34/MPT10034P MPTC246/MPT1C047P
XL 7
2007-2009 MPTOO36/MPT10036P MPT1C037/MPT1C035P
TOYOTA
Models with Non-Threaded
Cooling System Caps:
Models with 16mm deep
filler neck, see page 9 MPT0007/MPT10128 MPTC007
Models with 9.5mm deep
filler neck, see page 9 MPTOO08/MPT10138 MPTC008
Models with Threaded
Cooling System Caps:
Avalon
2013-current MPT0048/MPT10048P MPTC049/MPT1C049P
Celica
2000-2005 MPT0048/MPT10048P MPTC049/MPT1C049P
MR2 Spyder
2000-2005 MPT0048/MPT10048P MPTC049/MPT1C049P
RAV 4
1996-2008 MPT0008/MPT10138 MPTC008
2009-current MPT0048/MPT10048P MPTC049/MPT1C049P
Sienna (see page 9)
1998-2006 MPT0007R MPTC007
2007-current MPT0008/MPT10138 MPTC008
Hybrid Synergy Drive
Cooling System:
Camry
2007-current MPT0048/MPT10048P MPTC049/MPT1C049P
Highlander
2006-current MPT0048/MPT10048P MPTC049/MPT1C049P
Prius
2004-current MPT0048/MPT10048P MPTC049/MPT1C049P
TRUCKS/HEAVY DUTY
Vehicles with large fill (“B”)
neck (2 11/16”) see page 11 A450B/MPT0450 (Kit) A450B/MPT0450 (Kit)
or or
A4505B A4504B
(Individual Adapter) (Individual Adapter)
VAN HOOL BUS
Some models MPT10076
VOLKSWAGEN
Models with male threads
on filler neck
1975-1993 MPT0022/MPT10022P MPTC023/MPT1C023P
Models with female threads
on filler neck
2004-current MPT0041/MPT10041P MPTC040/MPT1C040P
PAGE 17
APC102 PARTS LIST
Diagram Stock
Number Part # Description
NOT SHOWN MT0000 Plastic Carrying Case, NOT SHOWN
MPT5001-1 Complete Pump with Gauge and
Hose Assy. (1-4)
1 MT0001 Pressure Gauge Only
2 MPT5001-2 Valve Regulator Assembly
3 MPT5001-4 Tester Head with Hose Assembly
4 MT0005 Tester Seal
5 MT0006 Spacer Washer,
(1/4” Thick Rubber Washer - see page 9)
6 MPT10128 32 mm x 16mm deep
Radiator Adapter with Seal, Silver
7 MPT10138 32 mm x 9.5mm deep
Radiator Adapter with Seal, Gold
8 MT0009 Rubber Seal for 32mm Radiator Adapters
9 MPT10036P Radiator Adapter
10 MPT0025G Rubber Seal for MPT10036P
11 MT0012 Rubber O-Ring for MPT10036P
PAGE 18
MATCO COOLING SYSTEM ADAPTER GASKET APPLICATION GUIDE
(Use gasket part # when ordering replacement gaskets)
ADAPTER GASKET/O-RING SIZE GASKET PART #
MPT0010, MPT10084P 2 1/16" O.D. x 1 1/8" I.D. x 1/8" thick MPT0010G
MPT0034, MPT0036 2 1/16" O.D. x 1 7/16" I.D. x 1/8" thick MT0011
MPT0022, MPT0025, TA50, MPT10034P, MPT10036P 1 7/8" O.D. x 1 3/16" I.D. x 1/8" thick MPT0025G
MPT0245, MPT10245P, MPT0345, MPT10345P 1 7/16" O.D. x 15/16" I.D. x 1/16" thick MPT0345G
M
PT0007, MPT0008, MPT10128, MPT10138 1 1/8" O.D. x 1/2" I.D. x 1/4" thick MT0009
M
PT0031, MPT0041, MPT10031P, MPT10041P, MPT10074P 36mm O.D. x 28mm I.D. x 4mm cross section O-ring MPT0031G
M
PT0036, MPT0046, MPT0052 31mm O.D. x 23mm I.D. x 4mm cross section O-ring MT0012
MPT10046P, MPT10052P, MPT10036P 31mm O.D. x 23mm I.D. x 4mm cross section O-ring MT0012
MPT0044, MPT10044P 42mm O.D. x 34mm I.D. x 4mm cross section O-ring MPT0044G
MPT0048, MPT10048P 13/16" O.D. x 5/8" I.D. x 3/32" cross section O-ring (O-ring # P16) MPT0048G
MPT0027, MPT0054 2 1/2" O.D. x 1 9/16" I.D. x 1/8" thick MPT0027G
MPT0056, MPT10056P 23mm O.D. x 17mm I.D. x 3mm cross section O-ring MPT0056G
MPT0445, MPT10445P 38mm O.D. x 28mm I.D. x 5mm cross section O-ring MPT0445G
A4503B 2 3/4" O.D. x 1 3/4" I.D. x 3/16" thick A4502B
A450B Kit, A4501B Test Plug (Obsolete) 2 1/16 " O.D. x 1/2" I.D. x 1/4" thick (2 required) A4501B1
MPT0450 Molded Gasket MPT0450G
MPT10025P 1 11/16" O.D. x 1 1/16" I.D. x 1/8" thick MPT10025PG
MPT10022P 1 3/4" O.D. x 1" I.D. x 1/8" thick MPT10022PG
MPT10027P 2 3/8" O.D. x 1 5/8" I.D. x 1/8" thick MPT10027PG
MPT10032P 1 7/8" O.D. x 1 1/16" I.D. x 1/8" thick MPT10032PG
MPT10054P 2 1/4" O.D. x 1 1/2" I.D. x 1/8" thick MPT10054PG
MPT0058, MPT10058P 27mm O.D. x 21mm I.D. x 3mm cross section O-ring MPT0058G
MPT0060 Molded Gasket MPT0060G
MPT0063, MPT10063P, MPT10078P 1 7/16” O.D. X 1 3/16” I.D. X 1/8” cross section O-ring MPT0063G
MPT10067, MPT10067R Molded rubber gasket MPT10067G
MPT10069P 1” OD x 5/8” ID x 3/16” thick cross section O-ring MPT10069R
MPT10070P 1” OD x 1/2” ID x 1/16” thick MPT10070G
MPT10072P 19mm OD x 12mm ID x 3.5mm cross section O-ring MPT10072R
MPT10076P Molded rubber gasket (custom) MPT10076G
MPT10086P 14mm OD x 7mm ID x 3.5mm cross section O-ring MPT10086R
MCR103A & MCR103U PARTS LIST
All non-stocking adapters are available through Matco special order. Use "0S" prefix when ordering.
MT000SET COOLING SYSTEM TESTER PUMP (Diagram #1 through #5)
MT0000 PLASTIC CARRYING CASE (Not Shown)
1 MT0001 PRESSURE GAUGE ONLY
2 MT0002 PUMP ASSEMBLY WITH KNOB (Gauge not included)
3 MT0003 KNOB ONLY
4 MT0004 TESTER HEAD ASSEMBLY WITH HOSE
NOTE: Hose is field repairable with 3/16” fuel line.
5 MT0005 TESTER SEAL
6 MT0006 SPACER WASHER (1/4" thick Rubber Washer)
for 1” deep filler necks see page 9
7 MPT10128 32 mm x 16 mm Radiator Adapter with Seal (Silver)
8 MPT10138 32 mm x 9.5 mm Radiator Adapter with Seal (Gold)
9 MT0009 RUBBER SEAL for 32mm RADIATOR ADAPTER
10 MPT10036P RADIATOR ADAPTER (Seal & O-ring included)
11 MPT0025G RUBBER SEAL for #MPT10036P
12 MT0012 RUBBER O-RING for #MPT10036P and MPT10052P
13 MPT10052P RADIATOR ADAPTER (Seal & O-ring included
Not included in RPT102 but can be ordered
# Stock # Description
MODEL
RPT102/RPT103
PARTS LIST
MCR103A and MCR103U:
Drawing #
Stock # Description
* MCR1020 PLASTIC CARRYING CASE
(NOT SHOWN)
1 MCR1031 LOWER CONNECT VACUUM GAUGE
2 MCR1010 COOLANT REFILL BODY SLEEVE
3 MCR1033 COOLANT REFILL VALVE ASSEMBLY
4 MCR1034 COOLANT REFILL HOSE ASSEMBLY
5 MCR1005 INNER VALVE ASSEMBLY
6 MCR1006 AIR INLET VALVE
7 MCR1007 ASSEMBLY SCREWS, 8-32 X 1 1/4"
(2 REQ’D)
8 MCR1038 VENTURI BODY
9 MCR1009 OVERFLOW HOSE
15 MCR1034S COOLANT REFILL SUCTION
SCREEN ONLY
MCR103A ONLY:
10 MCR1032A COOLANT REFILL BODY ASSEMBLY
11 MT0005 TESTER SEAL
MCR103U ONLY:
12 MCR1032U COOLANT REFILL BODY ASSEMBLY
13 MCR103CS ADAPTER CONE, STEP
(7/16-20 THREAD)
14 MCR103CL ADAPTER CONE, SMOOTH
(7/16-20 THREAD)
MCR103A
MCR103U
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
3
2
1
12
13
10
8
7
6
5
4
9
11
Included in RPT103 only
1
2
3
4
5
6
7
MPT100CG
C
OOLANT
GUARD
PARTS DIAGRAM
&
REPLACEMENT
PART NUMBERS
Number
Part Number
Description
1
2
3
4
5
6
7
Not
Shown
MPT100CG-1
MPT100CG-2
MPT100CG-3
MPT100CG-4
MPT100CG-5
MPT100CG-6
MPT100CG-7
MPT100CG-8
Dual Gauge
Hook Assembly
with Nut
Venturi Body
Air Inlet Valve
Brass GHT cap
Intake Hose with
Cap Assembly
Exhaust Hose
Plastic Box
PAGE 19
The RPT102/RPT103/MCR103A/MCR103U/APC102/MPT100CG/MCR303T is warranted for a period
of twelve months from the end user customer's date of purchase against defects in materials and
workmanship. Matco, or one of its authorized representatives will, at Matco's option, repair or replace the
RPT102/RPT103/MCR103A/MCR103U/APC102/MPT100CG/MCR303T without charge, if the
defective or malfunctioning tool is returned to Matco or one of its authorized representatives, shipping prepaid.
Please be sure to include your name and address with the tool, and describe the nature of the problem.
Matco shall have no obligation pursuant to the Matco Warranty with respect to tools which in Matco's sole judgment
have been altered, damaged, misused, abused or badly worn, lost or improperly maintained. This warranty is
null and void if the customer, or any other person other than the authorized representative Matco, has made any
attempt to service or modify the tool prior to its return to Matco under this Warranty.
For additional warranty information, contact:
Matco Tools, 4403 Allen Road, Stow, Ohio 44224
©2018 Marvac Scientific. All rights reserved.
FN: MATCO-2018A
WARRANTY
MCR303T
Cooling System Refiller for Large Trucks
Parts Diagram and Part Numbers
1
7
2
5
10
3
11
8
6
4
12
9
*
MCR3000 PLASTIC CARRYING CASE (Not Shown)
1 MCR1031 LOWER CONNECT VACUUM GAUGE
2 MCR1010 COOLANT REFILL BODY SLEEVE
3 MCR3031 COOLANT REFILL VALVE ASSY
4 MCR3034 COOLANT REFILL HOSE ASSY
5 MCR1005 INNER VALVE ASSY
6 MCR1006 AIR INLET VALVE
7 MCR1007 ASSEMBLY SCREWS, 8-32 x 1 1/4” (2 REQ’D)
8 MCR3002 VENTURI BODY
9 MCR3033 OVERFLOW HOSE
10 MCR1032A COOLANT REFILL BODY ASSY
11 MT0005 TESTER SEAL
12 MCR3034S COOLANT REFILL SUCTION SCREEN ONLY
Diagram # Part # Description
