Installaon Steps and Precauons:
Nominal Impedance
Frequency Response (-3dB)
Power Handling (RMS)*
Power Handling (Peak)*
Recommended Power (RMS)*
Recommended High Pass Filter
Free Air Resonance (Fs)
*With Recommended High Pass FIlter
Specificaons and Recommendaons:
Dimensions:
Fitment Informaon:
Limited Warranty (USA): Audiofrog GS Series products sold in the USA through authorized
Audiofrog dealers are warranted to the original purchaser against defects in materials and
workmanship for one year aer the date of original purchase. They are warranted for an addional
year if they are installed by an authorized Audiofrog dealer. Please save your receipt. A valid receipt
from an authorized Audiofrog dealer is required for warranty service. If you purchased your GB
Series products outside the USA, please consult your local distributor for warranty terms and
condions.
Audiofrog and the Audiofrog logo are trademarks of Audiofrog, Inc, registered in the United States
and/or other countries. Audiofrog et le logo sant des marques est une marque commerciale de
Audiofrog, Inc déposée aux Étas-Unis et/ou dans d’autres pays.
Audiofrog, Inc. 419 S. Mission Dr. San Gabriel, CA 91776 +1 (707) 600-FROG
www.audiofrog.com
GS10OE-0011
4Ω
1.8kHz - 20kHz
70W
200W
15W - 75W
3500Hz, 24dB/Oct
1500Hz
Removal of OE tweeter:
• Using a soldering iron, carefully melt the
three tabs holding the Volkswagen tweeter in
place while pulling the tweeter away from its
frame. Alternately, use a dremel tool or a
knife to shave away the melted plasc to free
the tweeter.
• All of the Volkswagen tweeters in this style
are secured this way regardless of different
models
Installaon of Audiofrog OE tweeter:
• Clip the Audiofrog tweeter into place on the
tabs, and secure with CA (super) glue.
Verified Fit:
• 2007-2021 Volkswagen Golf with tweeters in the sail
panel.
Unverified but May Fit:
• 2007-2021 Volkswagen Tiguan, Passat, and Arteons
aswell as other Volkswagen models with tweeters in
either A pillars, doors, or sail panels.
Please check your car’s tweeter locaon and housing
dimensions to confirm that the GS10OE-0011 will fit.
32.1 mm
40 mm
50 mm
16.6 mm
12.1 mm
