LED HIGH BAY LIGHT 6000K
MODEL NO: LED100HB, LED150HB, LED200HB
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs
and all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with
all electrical products.
Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately
by a qualied electrician.
If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
Ensure that repairs are carried out by a qualied electrician.
9 Suitable for use indoors at -35
o
C to +50
o
C.
9 The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualied person.
9 The external exible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be destroyed.
2. INTRODUCTION
Super bright cool white light with 90° beam angle is capable of lighting a large area. Suitable for warehouses, manufacturing facilities or
any large space. Highly efficient LED lights are brighter and significantly more energy efficient when compared to traditional incandescent,
halogen or fluorescent lights. Robust and rust resistant aluminium body designed to keep the light cool with maximum heat dissipation,
prolonging the life of the light. Supplied with an eyelet which can be used to hang the light from a chain, wire or rod. Mounting bracket also
available Model No. HBB01 - Universal Bracket for High Bay Lights. Built-in DC Driver provides the optimum electrical input for the light
which allows for a 50,000 hour lifespan.
3. SPECIFICATION
MODEL NO: LED100HB LED150HB LED200HB
Beam Angle: 90° 90° 90°
Dimensions: 230 x 230 x 85mm 280 x 280 x 90mm 325 x 325 x 90mm
IP Rating: IP65 IP65 IP65
LED Type: 100W SMD LED 150W SMD LED 200W SMD LED
Lumen Output: 15000lm 22500lm 30000lm
Nett Weight: 1.20kg 1.40kg 1.80kg
Nominal Frequency: 50Hz 50Hz 50Hz
Plug Type: Bare Wire Bare Wire Bare Wire
Power: 100W 150W 200W
4. INSTALLATION
NOTE: the installation base must be able to support 10 times the weight of the product.
High bays must be mounted a minimum of 6m from the ground.
STEP 1
STEP 2 STEP 3
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
LED100HB, LED150HB, LED200HB Issue 2 (3) 30/04/24
Original Language Version© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
LED100HB, LED150HB, LED200HB Issue 2 (3) 30/04/24
Original Language Version© Jack Sealey Limited
STEP 4
STEP 5
STEP 6
STEP 7
