Microwave Oven
INSTRUCTION MANUAL
Model: WEET20
Read these instructions carefully before using your
microwave oven, and keep them safe for future reference.
If you follow the instructions, your new oven will provide you
with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Cello Address: Bishop Auckland, DL14 6XW, England (UK).
Web: www.celloelectronics.com
2
.IMPORTANT SAFEGUARDS… ……………… …… ….
WARNING: If the door or door seals
are damaged, the oven must
not be operated until it has been repaired by a trained expert.
WARNING: It is hazardous for anyone other than a trained expert
to carry out any service or repair operation, which involves the
removal of any cover, which gives protection against exposure to
microwave energy. WARNING: Liquids or other food must not be
heated in sealed containers since they are liable to explode.
1. Only use utensils that are suitable for use in microwave
ovens.
2. Metallic containers for food and beverages are not allowed
during microwave cooking.
3. When heating food in plastic or paper containers, keep an eye
on the oven due to the possibility of ignition.
4. The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of warming
pads, slippers, sponges, damp cloth and similar may lead to
risk of injury, ignition or fire.
5. If smoke is observed, switch off or unplug the appliance and
keep the door closed in order to stifle any flames microwave
heating of beverages can result in delayed eruptive boiling,
therefore care has to be taken when handling the container.
6. The contents of feeding bottles and baby food jars are to be
3
stirred or shaken and the temperature is to be checked before
consumption, in order to avoid burns.
7. Eggs in their shell and whole hard-boiled eggs shall not be
heated in microwave ovens since they may explode, even
after microwave heating has ended.
8. Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life
of the appliance and possibly result in a hazardous situation.
9. The appliance must not be placed in a cabinet.
10. Care should be taken not to displace the turntable when
removing containers from the appliance.
11. The appliance shall not be cleaned with a steam cleaner.
12. The appliance must not be installed equal or higher than 900
mm above the floor. Minimum height of free space necessary
above the top surface of the oven: 100mm.
CAUTION: HOT SURFACE
13. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
4
person in order to avoid a hazard.
14. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
15. Children shall not play with the appliance.
16. Cleaning and user maintenance shall not be made by children
without supervision.
17. Do not put the glass plate into water immediately after
use,please leave it for at least 20 minutes to avoid cracking
theglass.
18. Group 2 Class B appliance
Group 2 ISM equipment: group 2 contains all ISM equipment
in which radio-frequency energy is intentionally generated
and/or used in the form of electromagnetic radiation for the
treatment of material, and EDM and arc welding equipment.
Class B equipment is equipment suitable for use in domestic
establishments and in establishments directly connected to a
low voltage power supply network which supplies buildings
used for domestic purposes.
19. This product internal light source LED light on＜60lm.
20. After plug in or the appliance end the work ,the product
automatically falls into standby mode,and the product
5
indicates the information of time standby power＜0.8W.
.INSTALLATION…………… …… ……………………… …….. ……
1. Remove all the packing. If there is a safe film over the oven,
tear it off before use. Check carefully for damage. If any,
immediately notify dealer or send to the manufacturer’s
service center.
2. Microwave ovens must be placed under dry and
non-corrosiveness environments, kept away from heat and
humidity, such as gas burner or water tank.
3. To ensure sufficient ventilation, the distance between the
back of microwave to the wall should be at least 10 cm, the
side to the wall should be at least 5 cm, the free distance
above the top surface at least 20 cm. The distance from the
microwave to the ground should be at least 85 cm.
4. The position of the oven shall be such that it is far from the TV,
Radio or antenna as picture disturbance, or noise may occur.
The distance should be more than 5m.
5. The appliance must be positioned so that the plug is
accessible, and must ensure a good grounding in case
leakage, ground loop can be formed to avoid electric shock.
6. The microwave oven must be operated with the door closed.
7. The microwave oven must not be placed in a cabinet. The
microwave oven is intended to be used freestanding.
8. As there may be manufacturing residue or oil remaining on the
oven cavity or heat element, you may detect an odour or even
slightly smoke.This is normal, and will dissipate after a few
uses. Keep the door or window open to ensure good
ventilation. It is strongly recommended to place a cup of water
in the cavity, setting at high power and operate several times.
6
.CLEANING …………………… …………
MICROWAVE OVEN CARE
The oven should be cleaned regularly and any food deposits
removed.
a. Remove the power cord from the wall outlet before cleaning.
After cooling products,don't immerse the appliance in water
or other fluids when cleaning.
b. Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life
of the appliance and possibly result in a hazardous situation.
c. Never use hard detergent, gasoline, abrasive powder or
metal brush to clean any part of the appliance.
d. Do not remove the waveguide cover.
e. When the microwave oven has been used for a long time,
tthere may be some strange odors in the oven. The following
methods can get rid of them:
1) Place several lemon slices in a cup, then heat on high
power for 2-3 min.
2) Put some orange peel into oven, and then heat them with
high micro power for 1 minute.
When the product is not used, it should be placed in dry and
ventilated areas as well as possible.
Details how to clean surfaces in contact with food:
7
After use wipe the waveguide cover with a damp cloth, followed
by dry cloth to remove any food splashes and grease. Built-up
grease may overheat and begin to cause smoke or catch fire.
TIPS FOR CLEANING
Details for cleaning door seals, cavity and adjacent parts:
Exterior:
Wipe the enclosure with a dampened soft cloth
Door:
Using a dampened soft cloth, wipe clean the door and window
Wipe the door seals and adjacent parts to remove any spill or
spatter
Wipe the control panel with a slightly dampened soft cloth
Interior walls:
Wipe clean the interior surfaces with a dampened soft cloth
Wipe clean the waveguide cover to remove any food splashes
Turntable / Rotation ring / Rotation axis:
Wash with mild soap water
Rinse with clean water and allow drying thoroughly
8
.PRODUCT INSTRUCTION…… …………… .. .......
⑤
⑥
⑦
① ② ③ ④
1) Door lock
Microwave oven door must be properly closed in order for it to
operate.
2) Viewing window
A
llows user to see the cooking status
3) Rotating ring
The glass turntable sits on its wheels; it supports the turntable and
helps it to balance when rotating
4) Rotating axis
The glass turntable sits on the axis; the motor underneath it drives
the turntable to rotate
5) Turntable
The food sits on the turntable, its rotation during operation helps
to cook food evenly
9
6) Control panel
See below details (the control panel is subject to change
without prior notice)
7) Waveguide cover
It is inside the air fryer oven, next to the wall of control panel.
Never remove the waveguide cover.
Specifications
Model: WEET20
Rated Voltage: 220-240V~ 50Hz
Rated Input Power(Microwave): 1280W
Rated Output Power (Microwave): 800W
Oven Capacity： 20L
Turntable Diameter： 270mm
External Dimensions： 451 x 332 x 258mm
Net Weight： Approx. 10.7kg
- Place the rotating ring first
- Fit the turntable onto the rotating axis and make sure that it is
geared in properly
10
Power
+30Sec.
Defrost
Preset/Clock
Pause/Cancel
Instant/Start
.OPERATION OF CONTROL PANEL…。。。。。。。。
11
1. BE
FORE COOKING
The LED flashes 3 times when plugged in power supply. Then
it flashes “:”, prompting you to input the cooking menu and
time.
2. AUTO COOKING/TIME.WEIGHT DIAL
You can increase or decrease cooking time, weight or select
auto cooking menu during operation by turning the dial.
3. PAUSE/CANCEL
At the initial or input stage: press once to cancel input
programs and resume initial stage.
During cooking: press once to stop oven operation, press twice
to cancel cooking programs.
4. AUTO REMINDER
When your preset cooking procedure have finished, the LED
Display will show End and three beeps sound will be heard to
prompt you to take out food. If you do not press Pause/Cancel
button once or open the door, the beep will be sounded at an
interval of 3 minutes.
5. INSTANT COOKING
On the standby status, press Instant/Start button, the oven will
start cooking with high power; system default cooking time is 1
minute. You can increase or decrease cooking time by turning
the dial.
6. CLOCK SETTING
Clock button makes it possible for you to input current or preset
12
time when “:” flashes onto LED display after your microwave
is plugged in, or skip it over to continue if unnecessary.
Example: to set 12:30
Steps Display
1 After power-up, the colon flashes
：
2 Press Preset/ Clock button once 00:00
3
Turn Auto Cooking/ Time. Weight dial to
set exact hours.
12:00
4 Press Preset/Clock button once again. 12:00
5
Turn Auto Cooking/ Time. Weight dial to
set exact minutes.
12:30
6
Press Preset/ Clock button once again or
wait for 5 seconds, and the numbers will go
steadily.
7. MICROWAVE COOKING
This function is for cooking and heating food. Press
Power button, LED will cycle to show 100P—80P—60P —
40P— 20P.
High power
100% microwave power. Applicable for quick
and thorough cooking
Medium
High power
80% microwave power. Applicable for medium
express cooking
Medium power
60% microwave power. Applicable for steaming
food
Medium
Low power
40% microwave power. Applicable for defrosting
food
Low power
20% microwave power. Applicable for keeping
warm
13
a. The max time which can be set is 60 minutes
b. Never operate the oven empty.
c. At the maximum microwave power, the oven will
automatically lower the power after a certain time of cooking
to lengthen the service life.
d. If you turn the food during operation, press the Instant/Start
button once and the preset cooking procedure will continue.
e. If you intend to remove the food before the preset time, you
must press Pause/Cancel button once to clear the preset
procedure to avoid unintended operation of next time use.
Exa
mple: To cook at P80 for 10 minutes.
Steps Display
1 After power-up, the colon flashes
：
2
Select the desired microwave power by
pressing Power button consecutively
80P
3
Set cooking time by turning Auto
Cooking/Time. Weight dial
10:00
4
Press Instant/Start button to start and LED will
count down to show running time.
8. +30sec
Press +30sec button LED display will cycle to show 0:30,
1:00, 1:30.
This function will allow you to heat a cup of water or beverage
conveniently, omitting the steps of setting time. Choose the
proper time depending on the beverage capacity.
14
Example: To cook with +30sec for 1 minute
Steps Display
1
After power-up, the colon flashes
：
2
Press +30sec button consecutively to select
desired menu
1:00
3. Start cooking by pressing Instant/Start button
9. DEFROST
This function use for defrost food. Press the Defrost button
and the LED display will cycle to show d.1-d.2-d.3.
d.1 For defrosting meat, the weight range from 0.1 to 2.0 kg.
d.2 For defrosting poultry, the weight range from 0.2 to 3.0kg.
d.3 For defrosting seafood, the weight range from 0.1 to 0.9kg.
a. It is necessary to turn over the food during operation to
obtain uniform effect.
b. Usually defrosting will need longer time than that of
cooking the food.
c. Ensure food is fully defrosted before cooking
d. Microwave penetrates around 4cm into most food
e. Defrosted food should be consumed as soon as possible,
it is not advised to put back to fridge and freeze again.
15
Example: To defrost 0.4kg poultry
Steps Display
1 After power-up, the colon flashes
：
2 Press Defrost button to set the food kind. d.2
3
Turn Auto Cooking/Time. Weight dial to set
the defrost weight
0.4
4 Start cooking by pressing Instant/Start
5
Half way during defrosting 3 beep sound will
be heard two times to prompt you turn over
the food. Open the door and turn over the
food. Then close the door. Press Instant/Start
button again to continue defrosting
10. AUTO COOKING
The oven has default cooking menu for simple operation.
When the LED flashes colon, turn the Auto Cooking dial and
LED
will cycle to show A.1, A.2 …… A.8
Choose the appropriate menu according to the food type and
weight and strictly observe the directions in below table,
otherwise the cooking effect will be largely influenced.
Display Kind Method
A.1 Popcorn
Suitable for popping a bag of
corn, which is available in the
market, weighted 85g. If the
popping speed has decreased to 1
time per 1-2 seconds you
should press Pause/Cancel
button to stop the popping
process
A.2 Popcorn Same as A.1 except 100g weight
16
A.3 Pizza
Warm a piece of chilled pizza of
0.15kg
A.4 Beverage
Heating a cup of 250 ml liquid. The
liquid temperature is about 5-10℃.
Use a big mouth cup and do not seal
A.5 Beverage
Heating a cup of 500 ml liquid. The
liquid temperature is about 5-10℃.
Use a big mouth cup and do not seal
A.6
Mashed
Potato
Cooking the potato strip
s, cut into
5mm width and height, length. Total
weight is about 0.45kg. Place the
strips on a large dish and cover the
dish with a thin film to prevent water
loss
A.7
Mashed
Potato
Same as A.6 except the weight of
potato strips is about 0.65kg
A.8 Fish
Suitable for steaming a fish of
0.45kg. With the fish washed and
scales removed, make a slits on the
skin of fish .Put the fish on a shallow
dish of 22-27cm diameter,sprinkle
lightly with seasoning ingredient
and cover the dish with a thin
film to prevent water loss. After
cooking, stand for 2 minutes.
a. The temperature of food before cooking would be 20-25℃.
Higher or lower temperature of the food before cooking
would require increase or decrease of cooking time.
b. The temperature, weight and shape of food will largely
influence the cooking result. If any deviation has been found
to the factor noted on above menu, you can adjust the
cooking time for best result.
17
Exam
ple: Steam 0.45kg fish
Steps Display
1 After power-up, the colon flashes
：
2
Turn Auto Cooking/Time. Weight dial to
set the cooking menu
A.8
3
Start cooking by pressing Instant/Start
button, and LED will count down to show
running time.
11. AUTOMATIC STARTING (DELAYED FUNCTION)
If you do not want the menu to start immediately, you can
preset the cooking menu and time and the preset menu will
automatically start at your set time. The setting will consist of 2
steps:
● Setting the current clock;
● Setting the cooking menu and time.
Example: Now it is 12:30 in the afternoon, if you want
the microwave oven to automatically start cooking with 100P
microwave power for 9 minutes and 30 seconds at 14:20
Steps Display
1 After power-up, the colon flashes
：
1.1 Press Preset/Clock button 00:00
1.2
Set hours by turning Auto Cooking/ Time.
Weight dial
12:00
1.3
Press Preset/Clock button again to confirm
hours
12:00
1.4
Set minutes by turning Auto Cooking/ Time.
Weight dial
12:30
18
1.5
Press Preset/Clock button once or waiting
for 5 seconds, and the numbers will go
steady.
12:30
2 Set the cooking menu and time
2.1
Select cooking power by pressing
Power button
100P
2.2
Turn Auto Cooking/Time. Weight dial to
set cooking time
9:30
2.3
Press and hold Preset/Clock
button for 3
seconds to return to current clock.
3
Set the time you expect to start. Repeat the
steps of 1.2, 1.3, 1.4
4
Press Preset/Clock button to confirm the
delayed menu. Now the program has been
activated. And the menu will be started at
14:20.
5
You may check the preset starting time by
pressing Preset/Clock button.
12. MULTI-SEQUENCE COOKING
To obtain the best cooking result, some recipes call for
different cooking modes and time. You may program your
personalized menu as follow:
Example: You want cook food with 100P microwave for 3
minutes then 20P for 9 minutes. This is 2 sequence setting.
Steps Display
1 100P microwave for 3min
1.1
Press Power button to select power level.
100P
1.2
Turn Auto Cooking/Time. Weight dial to
set cooking time.
3:00
19
2 20P for 9min
2.1
Press Power button to select
desired menu
20P
2.2
Turn Auto Cooking/ Time. Weight dial to
set cooking time.
9:00
3 Start cooking by pressing Instant/Start
a. When 100 microwave power cooking is finished, your
microwave oven will begin next operation automatically.
b. Max 4 sequences can be set per time, repeat the steps
13. CHILD LOCK FUNCTION
Use this feature to lock the control panel so that children
can not use the oven unsupervised. All the buttons are
rendered inoperable in this mode.
1) Set lock: Hold Pause/Cancel button about 3 seconds.
2) Cancel lock: Hold Pause/Cancel button about 3 seconds.
.UTENSILS GUIDELINE…。……………………… .
It is strongly recommended to use the containers which are
suitable and safe for microwave cooking. Generally speaking, the
containers which are made of heat-resistant ceramic, glass
or plastic are suitable for microwave cooking. Never use
metal containers for microwave cooking and combination
cooking as spark is likely to occur. You can take the reference of
below table.
20
Material
of container
Microwave Notes
Heat-resistant
ceramic
Yes
Never use the ceramics
which are decorated with
metal rim or glazed
Heat-resistant plastic Yes
Can not be used for long
time microwave cooking
Heat-resistant glass Yes
Grill rack No
Plastic film
Yes
It should not be used when
cooking meat or chops as
over-temperature may do
damage to the film
COOKING TIPS…… …
The following factors may affect the cooking result:
Food arrangement
Place thicker areas towards outside of dish, the thinner part
towards the centre and spread it evenly. Do not overlap if
possible.
Cooking time length
Start cooking with a short time setting, evaluate it after it times out
and extend it according to the actual need. Over cooking may
result in smoke and burns.
Cooking food evenly
Food such as chicken, hamburgers or steak should be turned
once during cooking.
Depending on the type of food, if applicable, stir it from outside to
21
centre of dish once or twice during cooking
Allow standing time
After cooking times out, leave the food in the oven for an
adequate length of time, this allows it to complete its cooking
cycle and cooling it down in a gradual manner
Whether the food is done
Colour and texture of food help to determine if it is done, these
include:
- Steam coming out from all parts of food, not just the edge
- Joints of poultry can be moved easily
- Pork or poultry shows no signs of blood
- Fish is opaque and can be sliced easily with a fork
Browning dish
When using a browning dish or self-heating container, always
place a heat-resistant insulator such as a porcelain plate under it
to prevent damage to the turntable and rotating ring.
Microwave safe plastic wrap
When cooking food with high fat content, do not allow the plastic
wrap come into contact with food as it may melt
Microwave safe plastic cookware
Some microwave safe plastic cookware might not be suitable for
cooking foods with high fat and sugar content. Also, the
preheating time specified in the dish instruction manual must not
be exceeded.
.MAINTENANCE… 。…… ………………… ……
SERVICING
Please check the following before calling for services.
1. Place one cup of water (approx.150ml) in a glass measure
in the oven and close the door securely. Oven lamp shoul
d
go off if the door is closed properly. Let the oven work for 1
min.
2. Does the oven lamp light?
22
3. Does the cooling fan work?
(Put your hand over the rear ventilation openings.)
4. Does the turntable rotate?
(The turntable can rotate clockwise or counter clockwise. This
is quite normal.)
5. Is the water inside the oven hot?
I
f “NO” is the answer to any of the above questions, please
check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly,
CONTACT YOUR NEAREST SERVICE CENTER APPROVED.
SERVICING SAFEGUARDS
Caution: MICROWAVE RADIATION
1. The high voltage capacitor remains charge after
disconnection; short the negative terminal of H. V capacitor
to the oven chassis (use a screwdriver) to discharge before
touching.
2. During servicing below listed parts are liable to be remov
ed
and gi
ve access to potentials above 250V to earth.
●
Magnetr
on
●
High voltage transformer
●
High voltage capacitor
●
High voltage di
ode
●
High voltage fuse
3. The following conditions may cause undue microwave
exposure during servicing.
● Improper fitting of magnetron;
● Improper matching of door interlock, door hinge and door;
● Improper fitting of switch support;
● Door, door seal or enclosure has been damaged.
23
Correct disposal of this product
This marking indicates that this product should not
be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it responsibly
to promote the sustaina
ble reuse of material
resources. To return your used device, please use
the return and collection systems or contact the
retailer where the product was purchased. They
can take this product for environmental safe
recycling.
