SPECIFICATION SHEET
WESTINGHOUSE LIGHTING
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
^ Based on typical use, excluding lights
* Based on 12 cents per kWh and 6.4 hours use per day
† Values are per lamp
** Based on 3hrs./day
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
Item Number 74004B00
44 in. Black-Bronze Finish
Reversible ABS Blades (Dark Cherry/Mahogany) Frosted Opal Glass
Smart Wi Technology
Specications
Size ............................................................... 44”
Blades .......................................................... Reversible ABS Blades
(Dark Cherry/Mahogany)
Blade Pitch ................................................ 13°
Approved Location ............................... Indoor/Outdoor
Suggested Room Size .......................... Large Room (up to 15x15)
Down Rod .................................................. N/A
Installation ................................................. Hugger
Max. Ceiling Angle ................................. N/A
Lead Wire .................................................. 12”
Light Bulb Usage .................................... Includes (2) Medium (E26) Base,
9 Watt Omni LED Lamps
Remote Control ....................................... Remote Control Included
Motor Finish .............................................. Black-Bronze
Motor Material ......................................... Silicon Steel Motor 153mm
x 17mm
Reverse Airow ....................................... Yes
Capacitor ................................................... Dual
Switch Housing Cap........................... Not Included
Energy Information
Airow (CFM) when operated at high speed..... 4198
Energy Use (Excludes lights)^......................... 35
Airow (CFM)^.................................................... 3072
Airow Eciency (CFM/W)^........................... 87
Estimated Yearly Energy Cost^....................... $10
RPM (High)........................................................... 249
Amp (High).......................................................... 0.42
Watts (High)........................................................ 50
Light Source
Number of Lamps........................... 2
Ene
rgy Use (Watts)†....................... 9
Equiv. Incand. Wattage†................ 60
Light Appearance (Kelvin)........... 3000
Lumens†............................................. 800
CRI...................................................... 80
Average Rated Hours..................... 25000
Life in Years**†................................. 22.80
Estimated Yearly Energy Cost..... $1.08
Halley Ceiling Fan
Smart Wi Technology
Hugger/
Without down rod
Reversible Mahogany
Finish Blades
DIMMABLE
2022
INDOOR
OUTDOOR
DAMP RATED
Compatible with
Amazon Alexa and
Google Assistant
A. Top of Canopy to Bottom of Blades .....................................9.5”
B. Top of Canopy to Bottom of Switch House .........................3”
C. Top of Canopy to Bottom of Canopy ......................................3”
D. Width of Motor Housing .............................................................9.5”
E. Width of Canopy ..............................................................................9.1”
F. Top of Canopy to Bottom of Glass ....................................... 13.8”
Warranty
Ceiling fans backed by our Limited Lifetime Warranty have a lifetime motor warranty and a 2-year warranty on all other parts.
SPECIFICATION SHEET
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
2022
WESTINGHOUSE LIGHTING
Item Number 74004B00
44 in. Black-Bronze Finish
Reversible ABS Blades (Dark Cherry/Mahogany) Frosted Opal Glass
Smart Wi Technology
Halley Ceiling Fan
Smart Wi Technology
