Visit our website at: http://www.harborfreight.com
email our technical support at: [email protected]
19571C-B
CORDLESS
LED WORK LIGHT
56925
20v LITHIUM-ION
tM
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 24g
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
©
2024 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 56925
SaFety OperatiOn MaintenanceSetup
table of contents
Safety ......................................................... 2
Specifications ............................................. 4
Setup .......................................................... 5
Operation .................................................... 6
Maintenance ............................................... 7
Warranty ..................................................... 8
tM
WarninG SyMBOLS anD DeFinitiOnS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
iMpOrtant SaFety inStructiOnS
read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Flashlight Safety Warnings
WARNING - When using flashlights or
lanterns, additional precautions should always
be followed, including the following:
1. To reduce the risk of injury, close supervision is
necessary when a product is used near children.
2. Do not use in the rain.
3. To reduce the risk of electrical shock, do
not put Light in water or other liquid. Do
not place or store product where it can
fall or be pulled into a tub or sink.
4. To reduce the risk of injury, do not stare at
operating lamp. Serious eye injury could occur.
5. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
6. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
7. Do not leave the tool unattended when the
Battery Pack is connected. Turn off the tool,
and remove the Battery Pack before leaving.
Page 3For technical questions, please call 1-888-866-5797.Item 56925
SaFetyOperatiOnMaintenance Setup
8. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover
all possible conditions and situations that may
occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
9. Battery tool use and care
a. recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of fire when used with another battery pack.
b. use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c. When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
d. under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e. Do not use a battery pack or power tool that
is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
f. Do not expose a battery pack or power
tool to fire or excessive temperature.
Exposure to fire or temperature above
140°F may cause explosion.
g. Follow all charging instructions and do
not charge the battery pack or power tool
outside of the temperature range specified
in the instructions. Charging improperly or at
temperatures outside of the specified range may
damage the battery and increase the risk of fire.
h. Have servicing performed by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the product is maintained.
i. Do not modify or attempt to repair the power
tool or the battery pack except as indicated
in the instructions for use and care.
j. The battery Charger gets hot during
use. The Charger’s heat can build
up to unsafe levels and create a fire
hazard if it does not receive
adequate ventilation, due to an electrical fault, or
if it is used in a hot environment. Do not place
the Charger on a flammable surface. Do not
obstruct any vents on the Charger.
especially avoid placing the charger on
carpets and rugs; they are not only
flammable, but they also obstruct vents
under the charger. Place the Charger on a
stable, solid, nonflammable surface (such as a
stable metal workbench or concrete floor) at
least 1 foot away from all flammable objects,
such as drapes or walls. Keep a fire
extinguisher and a smoke detector in the area.
Frequently monitor the Charger and
Battery Pack while charging.
Lithium Battery Safety Warnings
LitHiuM BatterieS StOre
a LarGe aMOunt OF enerGy anD
WiLL Vent Fire Or eXpLODe iF MiStreateD:
1. Keep
Battery pack dry.
2. DO nOt DO any OF tHe FOLLOWinG
tO tHe Battery pacK:
a. Open,
b. Drop,
c. Short-circuit,
d. puncture,
e. incinerate, or
f. expose to temperatures greater than 140°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
SaVe tHeSe inStructiOnS.
Page 4 For technical questions, please call 1-888-866-5797. Item 56925
SaFety OperatiOn MaintenanceSetup
Grounding
tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG:
check with a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug provided with the charger. Do not use the
charger if the power cord or plug is damaged. if damaged, have it repaired by a service facility
before use. if the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.
extension cords
note: Extension cords must not be used with this item’s Charger.
Symbology
V
Volts
Direct Current
a
Amperes
n
0
xxxx/min.
No Load Revolutions
per Minute (RPM)
WARNING marking
concerning Risk of Eye Injury.
Wear ANSI-approved safety
goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
Specifications
Battery Bauer 20 V Li-ion
Charger Bauer 20V Li-Ion
Page 5For technical questions, please call 1-888-866-5797.Item 56925
SaFetyOperatiOnMaintenance Setup
Setup - Before use:
read the entire iMpOrtant SaFety inStructiOnS section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
note: For additional information regarding the parts listed in the following pages,
refer to PLEASE READ THE FOLLOWING CAREFULLY on page 6.
Functions
Hook
power
Switch
tM
Page 6 For technical questions, please call 1-888-866-5797. Item 56925
SaFety OperatiOn MaintenanceSetup
Operating instructions
read the entire iMpOrtant SaFety inStructiOnS section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
charging
Charge battery before using this tool. Follow instructions included with battery charger.
Operating instructions
1. Insert fully charged Battery Pack into the Flashlight,
making sure it clicks into place securely.
2. Adjust the Flashlight’s head position by
rotating it up or down to click in place
at any of the locking positions.
3. Press Power Switch once for full light
output. Press again for less light output.
Press a third time to turn light off.
4. Turn off Flashlight and remove Battery
Pack after use. Clean, then store the
tool indoors out of children’s reach.
tM
Page 7For technical questions, please call 1-888-866-5797.Item 56925
SaFetyOperatiOnMaintenance Setup
Maintenance and Servicing
procedures not specifically explained in this manual must
be performed only by a qualified technician.
tO preVent SeriOuS inJury FrOM tOOL FaiLure:
Do not use damaged equipment. if abnormal noise or vibration
occurs, have the problem corrected before further use.
cleaning, Maintenance, and Lubrication
1. BeFOre eacH uSe, inspect the general
condition of the tool. Check for:
• leaking, swollen, or cracked battery pack,
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. aFter uSe, wipe external surfaces
of the tool with clean cloth.
3. Li-Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. Disconnect battery pack and store battery pack,
charger, and tool in dry, indoor area out of
reach of children and away from metal objects
(i.e., paperclips, coins) to prevent shorting.
troubleshooting
problem possible causes Likely Solutions
Flashlight will
not turn on.
1. Battery Pack not properly
connected.
2. Battery Pack not properly
charged.
3. Battery Pack burnt-out.
4. Internal damage or wear.
1. Remove Battery Pack, make sure there
are no obstructions, reinsert the Battery
Pack according to its shape (it should
only fit one way), and press firmly until
the Battery Pack locks in place.
2. Make sure Charger is connected and
operating properly. Give enough time
for Battery Pack to recharge properly.
3. Dispose of old Battery Pack
properly or recycle. Replace Battery Pack.
4. Have technician service tool.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect Battery pack and charger power supply before service.
record product’s Serial number Here:
note: if product has no serial number, record month and year of purchase instead.
note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175558428 when ordering parts.
tM
26677 agoura road • calabasas, ca 91302 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability
standards, and warrants to the original purchaser that this product is free from defects in materials
and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent,
special or consequential damages arising from the use of our product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion
may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
