Vax H87-WV-B Clean and Shine Window Vacuum User Manual

vax.co.uk

H87-WV-B

/VRS1WV

Window Vac

Window Cleaner Range

Let’s get started

This Window Vac is intended for household use only

and NOT for commercial or industrial use.

When using the Window Vac basic safety precautions should

always be observed, including the following:

• Keepngers,hairandlooseclothingfrommovingpartsand

openings whilst using the Window Vac.

• Thisappliancecanbeusedbychildrenaged8yearsand

aboveandpersonswithreducedphysical,sensoryormental

capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.

Cleaningandusermaintenanceshallnotbemadeby

children without supervision.

• OnlyVaxrecommendcharger,accessoriesandsolution

should be used with this Window Vac.

Please keep instructions for future reference and use the

Window Vac only as instructed in this guide.

Basic safety precautions

Don’ts

Do’s

This Window Vac is intended for indoor use only

and NOT for outdoor use.

8 Don’tusethisWindowVacifithasbeendropped,damaged,

immersedinwaterorleftoutdoors.

8 Don’t unplug the Window Vac or pull the Window Vac by the

charger cord. Don’t use the charger cord as a handle, pull the

charger cord around corners or sharp edges or close a door

over the charger cord.

8 Don’t charge the Window Vac if the Charger cord or plug is

damaged.PleasecontactourCustomerCareLine.

8 Don’t use the Window Vac charger with incorrect voltage as this

mayresultindamageorinjurytotheuser.Thecorrectvoltageis

listed on the ratings label.

8 Don’t handle the plug or use the Window Vac with wet hands.

8 Don’t use the Window Vac whilst connected to the charger unit.

8 Don’tthrowtheWindowVacintoreorexposetohigh

temperatures,astheWindowVaccontainsarechargeable

batterywhichmaycausedamageorburst.Neverdismantlethe

battery or replace with a dierent type .

8 Don’tattempttoremoveblockageswithsharpobjectsasthis

maycausedamagetoyourWindowVac.

8 Don’tvacuumuphotcoals,cigarettebutts,matchesorsmoking

hotburningitemsoruseinanareawheretheremaybeharmful

uids(chlorine,bleach,andammoniadraincleaner).

Let’s talk safety

3 OnlyusetheWindowVacindoorsonverticalsurfaces.

3 Alwaysmakesurewatercontainerarettedcorrectlybefore

using your Window Vac.

3 TurnoallcontrolsontheWindowVacbeforedisconnectingor

connecting the charger.

3 Always switch o the Window Vac and disconnect the charger

beforecarryingoutanymaintenance.

3 AlwaysreplacethefuseintheplugwithaBritish13ampfuse.

Alwaysprotectthechargercablefromheatedsurfacesornear

openames.

3 UseonlyCEapproved13ampextensioncords,non-approved

extensioncordsmayoverheat.

3 Always charge the Window Vac indoors.

3 Always carry the Window Vac by the handle.

3 StoreyourWindowVacinacool,dryareaawayfromchildren.

3 OnlyuseVaxrecommendedbatteriesandsolution.

Thank you for buying this Window Vac

Taking care of your windows

TheWindowVacWindowCleanerisdesignedtocleanwindowsregularlyaseectivelyand

ecientlyaspossibleandthisuserguidewillhelpyougetthemostoutofyourmachine.

Cleanwindowslookbetterandmakeyourhomebrighter.

Taking care of your Window Vac

Alsoinsidethisguideareinstructionsonmaintainingyournewmachine,sothatit’salways

ready when you are to tackle your windows.

Taking care of you

We’re here if you need us. Insteadoftakingmeback

totheshop,simplyvisit:

vax.co.uk/support or call:

(UK) 0844 412 8455 (ROI)1-800928308

Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm

CallsarechargedattheUKlocalrate.Pleasemakeanoteoftheserialnumberandmodelnumber

of the Window Vac before calling.

Alternatively, you can write to us at:

Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK

Let us know what you think @VaxUK

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

What to do if it goes wrong

Getting in touch

Window Vac

Charger

Included with

your machine

Microbrepad

Scrub pad

Vax window

cleaning solution

Contents Getting to know your machine

PowerOn/Obutton

Powercharger

connector

Cleaning pad holder

Solution spray outlet

Water recovery squeegee

NameWindow Vac

Voltage 3.7V

Weight 0.75kg

Technical Specication

Subject to technical change without notice.

Microbrepads(Type1)*

1-1-133091-00

Scrubpads(Type2)*

1-1-133092-00

Accessories & Consumables

*To purchase consumables and accessories, please visit vax.co.uk

Spray trigger

Water tank

Watertankcap/

watertanklter

(unseen)

WARNING

Getting started Using your machine

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Plugchargerintothe

mainsandinsertthe

charger cable into the back

of the Window Vac.

Removefoamlter.

Topupwithwater(max40°C)tomaxlevel.Replacelter

andpushthewatertankcapbackintothemachine.When

ttingthewatertankcapbackintothemachineensure

the tab is facing downwards to prevent leaking.

Theindicatorlightwill

show red while the

machineischarging.

Pourin40mlVaxWindow

Cleaner solution.

Theindicatorlightwill

change to green when

fully charged.

Tollthewatertankliftthe

water tank cap.

Always switch o and unplug the

WindowVacfromtheelectrical

socketbeforeassembling,opening

oremptyingthewatertank,or

beforeconnecting/disconnecting

theattachmentsorperformingany

maintenance.

IMPORTANT: This Window Vac is to be used on vertical surfaces only.

NOTE: Fully charge the battery before rst use. Initial charge is 3 hours. Don’t use the Window Vac whilst

connected to the charger unit.

Using your Window Vac

Getting started Using your machine

Pullthetriggertospray

solution onto the surface

to be cleaned.

ToturntheWindowVacon,

press the power button. You

will hear a click sound.

Wipe the surface with the

microbreorscrubpadon

thebackofthemachine.

Vacuumupwaterusing

slow, straight strokes.

Whilst pulling the trigger to spray solution,

youmayneedtopressthetriggerafew

timesrstbeforesolutionisdispensed,

thisclearsairfromtheWindowVac.

Finish with sideways strokes.

MovetheWindowVacinazig-zag

patterntoavoidover-saturatinga

single point.

After use press the power

button to turn o.

Storage

Taking care of your machine

After use, open the water tank,

removethelterandemptywater

into the sink.

TheWindowVacmustbe

stored in a vertical position.

Rinselterunderrunning

warmwater(Max40’C).

Squeeze any excess water

fromlterbeforereplacing

into the Window Vac.

Toremovethecleaningpadgrasponeend

of the cleaning pad and gently pull, this

canbemachinewashed(Max40’C).

Note: The Window Vac must be emptied after each use – DON’T store water/solution in the machine between uses.

Let’s talk technical

Taking care of your machine

Ifthesqueegeebladebecomesdirtyit

canberemovedandwashed.Gripthe

bladeandgentlypullfromthemachine.

Thesqueegeeneedstobepushedrmly

downintothemachinesothereisnogap.

Rinseunderrunningwater(Max40’C).

Toret,pushthesqueegeebladeback

intothemachine.Makingsurethe

suctionholesarefacingthesameside

as the water tank.

Note: Fitting the squeegee incorrectly will result in poor pick up.

Important: Remove the battery from the appliance before recycling. For further information please contact your

local waste management centre.

Let’s talk technical

•Thebatterymaynotbecharged.Connectthecharger,theindicator

lightwillturngreenwhenfullycharged.Theinitialchargeshould

be for 3 hours.

•Theunitmightbepluggedin.TheWindowVacwillnotrunwhen

the charge is plugged in.

•Thesqueegeeblademaybeblocked.Removefromthemachine,

rinseandclearanydirt/debris.Gotothe‘Let’stalktechnical’page.

•Theltermaybecloggedordirty,cleanthelter.Gotothe‘Taking

careofyourmachine’pages.

•TheWindowVacmaybelowoncharge,plugtheWindowVac

in to recharge

•Thewatertankmaybefull,emptythewatertank.Gotothe

‘Takingcareofyourmachine’pages.

•Thesqueegeeblademaybedirty,removeandclean.

•Thecleaningpadsmaybedirty,removeandwash.

•YoumaybeusingtheWindowVaconaat,horizontalsurface,

only use the Window Vac on vertical surfaces

•Thewatertankmaybefull,emptythewatertank.Gotothe‘Taking

careofyourmachine’pages.

•Thechargermaynotbeinsertedcorrectly.

•Checkthemainspowerisswitchedon.

•Theelectricaloutletmaynotbeworking.Checkthefuseinthe

plug,alwaysreplacewithaBritish13ampfuse.

SolutionProblem

What to do if it goes wrong Getting in touch

Why won’t my Window

Vac turn on?

Why won’t the

Window Vac pick up?

Why does my

Window Vac leave

a smear on my

window?

Why does my

Window Vac leak?

Why won’t the

battery recharge?

Warning: Always turn o and unplug the Window Vac before carrying out and maintenance/troubleshooting checks.

Getting in touch

*CallsarechargedattheUKlocalrate.PleasemakeanoteoftheserialnumberandmodelnumberoftheWindowVac

before calling.

Warning: Always turn o and unplug the Window Vac before carrying out and maintenance/troubleshooting checks.

Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK

email: inf[email protected] website: vax.co.uk

Version 1.0

EEC Statement of Compliance: Manufacturer/EECimporter:VaxLimited,herebyonourownresponsibility,

declarethattheH87-WV/VRS1WV seriesismanufacturedincompliancewiththefollowingDirectives:

Safety:2006/95/ECLowVoltageDirective.EMC:2004/108/ECElectromagneticCompatibilityDirective.

Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilitiesexist.

Check with your Local Authority or retailer for recycling advice.
